Endo ELF-3 User manual

Users Manual
Spring Balancer
ELF-3
ELF-5
ELF-9
For safe and correct operation of the product, please be sure to read this manual and fully
understand its content before use.
After reading keep the manual safe so that you can find and use it readily.
In case of resale or transfer of this product, make sure to transfer the manual to the new owner.
BMU-0011
Issued in December 2022

CONTENTS
Introduction.............................................................................................3
Notation in this manual ................................................................................................
Scope of warranty and liabilities for the equipment .....................................................
Definition of intended users for this manual ................................................................
3
4
4
Emergency contact in case of malfunctions ................................................................ 5
Precautions for handling.......................................................................5
3-1 Packaging arrangement and transportation ...................................................
3-2 Checks after unpacking ..................................................................................
3-3 Disposal of packing materials .........................................................................
5
5
6
Product Description ..............................................................................6
4-1 Components ...................................................................................................
4-2 Operating environment ...................................................................................
4-3 Product specifications .....................................................................................
6
6
6
4-4 Applicable standards ...................................................................................... 7
Installation ..............................................................................................8
5-1 Preparation and checks before installation .....................................................
5-2 Installation procedures ....................................................................................
5-3 Post-installation checks .................................................................................
8
9
10
Usage ....................................................................................................11
6-1 Pre-operation inspections and checks ...........................................................
6-2 Precautions for use.........................................................................................
6-3 Operation method of the drum lock ................................................................
11
12
13
6-4 Replacement of the tools (equipment) ...........................................................13
Troubleshooting ...................................................................................15
7-1 Countermeasures? ......................................................................................
7-2 Releasing the fall-arrest device ..................................................................
15
15
Dimensional Drawing ..........................................................................16
Consumables and Special Accessories ............................................16
Disposal of Product .........................................................................16
2
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Parts list..........................................................................................7-18
11.
Spring Balancer Users Manual
Unpacking and Installation....................................................................5
6-5 Periodical inspections ....................................................................................14



Introduction
1.
Thank you very much for your purchasing of the Spring Balancer. To prevent any trouble and obtain the best
performance, please be sure to read this manual and fully understand its content.
Notation in this manual
Hazard levels
This product is designed with ultimate priority on the safety of operators. However, due to the nature of
the system, there are risks that cannot be removed.
In this manual, the level of significance and risk is defined and indicated in three stages: “WARNING”,
“CAUTION”, and “NOTICE”. Thoroughly read and fully understand the indicated items before operating
the product and performing maintenance procedures. The indications for “WARNING”, “CAUTION”, and
“NOTICE” are in order of risk significance (WARNING > CAUTION > NOTICE). Their details are
described below.
WARNING
CAUTION
A situation that, if mishandled, may cause death or serious disability.
A situation that, if mishandled, may cause minor or moderate injury.
Indicates a situation that, if mishandled, may cause property damage.
The extent of the problem described above (disability, injury, and property damage) is defined as
follows.
Serious disability:
Moderate injury:
REMINDER
Symbols
Indicates a PROHIBITED action that
must not be performed.
Illustrations
3
Spring Balancer Users Manual
Loss of eyesight, wound, burn (high-temperature or low-temperature), electric
shock, bone fracture, poisoning, and other injuries that leave aftereffects and that
require hospitalization or long-term outpatient treatment.
Burn, electric shock, bone fracture, and other injuries that do not require
hospitalization or long-term outpatient treatment.
Scratch, bruise, laceration, and other injuries that have a minor impact on health.
Minor injury:
Property damage: Extended damage to buildings, household articles, and injury to domestic
animals or pets.
Describes important details to be remembered for the operation.
This Users Manual uses the following symbols to simply provide information in addition to the
indications above. Indicates potential property damage
or a danger that may inflict bodily
injury.
Indicates a REQUIRED action that
must be performed.
Indicates that it is necessary to
thoroughly read the manual and the
relevant documents.
This manual covers multiple models of the Spring Balancer. If their functions and details of operations
are identical and can be correctly described in the same way, illustrations are provided taking a specific
model as an example. Therefore, please note that the illustrations may be different from the actual
equipment.

Scope of warranty and liabilities for the equipment
Warranty and liabilities for the equipment
Definition of intended users for this manual
Operator
Spring Balancer Users Manual
1. We will repair or replace the product free of charge if a failure due to manufacturing defects occurs
under proper usage during the warranty period. For details, contact us or your dealer.
2. The warranty will be void in the following cases:
1) Change of ownership.
2) Repair or modification performed by a party other than the manufacturer, agents, or dealers.
3. The warranty period is one (1) year from the date of purchase.
4. Repairs applicable to any of the following shall be charged even during the warranty period:
1) Failure/damage caused by incorrect use.
2) Failure/damage caused by use of non-authorized parts.
3) Failure/damage caused by fire, earthquake, natural disaster, or other unexpected incident.
4) Incident caused by fall, shock, negligence, or by inadequate storage.
5) Failure/damage caused by use of parts or other equipment that are not included in this product.
6) Replacement of consumables.
7) Usage in violation of dangers or cautions stipulated in this manual.
8) Failure/damage caused by any reason that is not attributable to the manufacturer.
5. Warranty exclusions such as opportunity loss.
Either during or after the warranty period, opportunity loss, damage to anything other than our
product(s), or other duties imposed on you/your customer as a result of the failure of our product(s)
are outside the scope of the warranty.
Copyright and liabilities
4
The copyright for this manual is issued to Endo Kogyo Co., Ltd.
The manual is provided for the limited purpose of supporting the safe and proper use of the product. It
cannot be used for other purposes.
The customer may not use or make copies of this manual, in whole or in part, outside of this purpose
without receiving prior consent from Endo Kogyo Co., Ltd.
The customer is also prohibited from translating or modifying the content of the manual, in whole or in
part.
The content described in the manual is subject to change without advance notice. Please note this in
advance.
This manual has been prepared to help all intended users involved with this product. From the stand point of
safety, we have defined intended users according to their ability and experience and provided detailed
descriptions for each group. This manual defines four user levels.
Maintenance
operator
The operator is a user who engages in general operations. Maintenance and other
operations that require special skills are excluded from the general operations. The
operator is therefore not permitted to disassemble the main equipment.
The operator should read the manual thoroughly and carry out their work with
complete understanding of the operating procedures.
In addition to the work of the operator described above, the maintenance operator
is permitted to perform installation, simple troubleshooting, and periodic
inspections. The maintenance operator is required to develop sufficient knowledge
and operating skill for this product. The maintenance operator should read the
manual thoroughly and carry out their work with complete understanding of the
equipment’s characteristics and all work contents.



Precautions for handling
2.
● Do not use in explosive, flammable gas, or dusty atmospheres, any place where
water or oil may splash, and near combustibles. This may cause fire or injury.
● Do not perform any modification of the product.
Unpacking and Installation
3.
3-1 Packaging arrangement and transportation
3-2 Checks after unpacking
● Spring Balancer (main equipment) ---- 1 set
● Support Site guide or Users Manual--- 1 copy
Spring Balancer Users Manual
Emergency contact in case of malfunctions
If any problem with the product arises, contact us or your dealer.
Service engineer
The management supervisor is required to have sufficient knowledge of the product
and advanced operating skill for this product.
The management supervisor should manage not only the product itself but on-site
operations that handle the product, comprehensively.
In The service engineer is a worker with special knowledge and skills for installing the
product, investigating the causes of a failure or damage, and performing repairs
and overhauls. Service engineering (the work by the service engineer) is performed
by our service technicians or authorized service technicians.
Management
supervisor
Incorrect handling of this product may cause damage to the product itself as well as a fire or injury.
Thoroughly read the following precautions and be sure to heed the instructions when handling the
machinery.
The maintenance should be performed by a maintenance operator who has
developed sufficient knowledge and operating skill for the balancer.
● Incorrect usage of the product may cause an injury. Use the product correctly in
accordance with the descriptions in this manual.
● Particularly, “WARNING”, “CAUTION”, and “NOTICE” described in this manual
must be fully understood and always observed.
● Install the product correctly in accordance with the descriptions in this manual.
● Be sure to perform daily and periodic inspections.
● Be sure to use the product within the capacity range that is described in “4-3-1
Specifications”.
The standard set of this product is packaged for delivery in a cardboard box.
The total weight of the package is the sum of the weight described in “4-3-1 Specifications” and the
weight of the packing materials (approximately 0.5 kg).
When transporting the package, do not drop or allow impact to it.
Prepare a box of a similar size for re-packaging.
After opening the package, check that the following products are included.
Please contact us if you find anything missing or damaged.
5
WARNING
CAUTION

3-3 Disposal of packing materials
After opening the package, dispose of any packing and cushioning materials in accordance with the
local regulations of the area where the product is used.

Product Description
4.
4-1 Components
4-1-1 Main equipment（ELF-3,5,9）
Top hook
Cover
Bottom hook
Wire rope
Worm
Drum lock
6
Spring Balancer Users Manual
Casing
Model Factory setting
load (kg) Stroke (m) Wire rope diameter (φ mm) Mass (kg)
4-2Operating environment
4-3Product specifications
ELF-5
ELF-9
ELF-3 4.0
7.0
2.3
3.0〜5.0
5.0〜9.0
1.5〜3.0
2.5
2.5
2.5 3.0
3.0
3.0 Approx. 4.6
4-3-1 Specifications
Installation location: General indoor
Ambient temperature: -10°C to +50°C (no freezing)
Humidity: 85% or less (no condensation)
Atmosphere: Non-explosive, free of flammable or corrosive gas, or dust, water/oil should not
splash directly
Capacity
range (kg)
Approx. 4.8
Approx. 5.4

4-3-2 Fall-arrest device
7
4-3-3 Drum lock device
Spring Balancer Users Manual
If the spring is ruptured, this device prevents the tool (equipment) attached to the bottom hook from
falling across the entire stroke. If the spring is ruptured, the safety pin is activated from the spring casing
and interferes (collides) with the pin installed on the spring casing, stopping the rotation of the drum.
For the method of releasing the activated fall-arrest device, refer to “7-2 Releasing the fall-arrest
device”.
The fall-arrest device is not designed to prevent tools (equipment) from falling. Before
using the balancer, be sure to check that the total mass (weight) of the tool
(equipment) and the accessories is within the capacity range of the balancer.
If the spring tension is set lower than the minimum capacity, the fall-arrest device will
be activated and prevent the vertical movement of the tool (equipment). (See “0
Installation of tools (equipment) and adjustment of the spring tension”.)
You can lock the drum by setting the drum lock device. (See “6-3 Operation method of the drum lock”.)
The drum lock is used to remove the tool (equipment) attached to the bottom hook or to replace the wire
rope or the wire guide. (See “6-4-1 Method of removing the tool (equipment)”.)
4-4 Applicable standards
EN ISO 12100 : Sefety of machinery General principles for design Risk assessment risk reduciion
Machinery Directive 2006/42/EC
■
Note: Only the standard specification of this product complies with the standards. If the product is used
in combination with non-standard parts or modified by the customer, the standards may no longer
be complied with. Please note this in advance.
CAUTION

Installation
5.
5-1 Preparation and checks before installation
5-1-1 Tools and equipment for installation
5-1-2 Check of installation location
1
2
3
4
5
6
8
Spring Balancer Users Manual
● Install the balancer correctly in accordance with the descriptions in this manual.
Incorrect installation may cause an injury, property damage, or damage to the
balancer.
● Be sure to attach an auxiliary wire rope or chain to the balancer to protect workers
in case the top hook or the support member (metal hanger) for the balancer should
be damaged.
The installation should be performed by a maintenance operator who has developed
sufficient knowledge and operating skill for the balancer.
All of the following items must be prepared by the customer.
・Auxiliary wire rope or chain
・Support members (metal hangers)
Before installing the product, check that the installation location does not have any of the following
problems.
Check that the support members have a sufficient strength.
Ensure that sufficient space for performing maintenance, including the adjustment of the spring
tension, is available on a side of the main equipment.
Ensure that adequate work space is available around the main equipment.
Check that the installation location has the installation environment described in “4-2 Operating
environment”.
If a trolley is used, attach a carabiner.
Check that there are no sharp edges in the installation location.
WARNING
CAUTION

5-2 Installation procedures
5-2-1 Installation of the Spring Balancer
1Support members
(metal hangers)
Top hook
2
3
4
5
9
Spring Balancer Users Manual
Do not fix the top hook. Using the product with the top hook fixed may cause
damage or a fall.
●Use a support member (metal hanger) with no opening
as shown in the figure on the right, so that the balancer
does not come off while in motion.
● Attach the support member such that the balancer does
not collide with its surroundings.
● When installing multiple balancers alongside, place
them at different heights so that they do not collide with
each other.
Prepare a support member (metal hanger) with a
sufficient strength.Attach the top hook of the
balancer directly to the support member (metal
hanger).
Note: The support member
(metal hanger) and the tool
(equipment) in the figure
are indicated for reference.
Check that the top hook latch is closed.
Ensure that the balancer moves freely.
Prepare an auxiliary wire rope or chain that has
a strength at least 10 times greater than the
maximum capacity of the balancer.
As shown in the figure on the right, attach an
end of the auxiliary wire rope or chain to a
support member (metal hanger) different from
the support member (metal hanger) to which the
top hook has been attached. Attach the other
end of the auxiliary wire rope or chain to the
main equipment of the balancer.
Support member
for the auxiliary
wire rope
Installation of the
auxiliary wire rope to
the main equipment
Auxiliary wire rope
Note: The auxiliary wire rope
and the support member
in the figure are
indicated for reference.
CAUTION

Slack
Damaged
and falls
Within
100 mm
5-2-2 Installation of tools (equipment) and adjustment of the spring tension
10
Spring Balancer Users Manual
Loosen the auxiliary wire rope or chain to
allow the balancer to move freely.
The slack must be such that the balancer
stops within 100 mm if the top hook or the
support member (metal hanger) for the
balancer are damaged and the balancer
falls.
Do not pull out the wire rope when the balancer is not loaded. If the wire rope is
released by mistake while being pulled out without a load, it may quickly be wound
up, causing an injury.
If the spring tension is set higher than the maximum capacity, not only will the
specified stroke not be obtained, but the life of the spring will also be reduced. Also, if
the spring tension is set lower than the minimum capacity, the fall-arrest device will be
activated and prevent the vertical movement of the tool (equipment).
1
2
3
Check whether the total mass (weight) of the tool (equipment) and the accessories is within the
capacity range of the balancer.
4
“+”
Increase
tension
“-”
Decrease
tension
Worm
If the spring tension is too strong, the main equipment of the balancer or
the wire rope may be damaged.
After attaching the tool (equipment), perform
readjustment and ensure that balance is achieved.
Lift the tool (equipment) and attach it to the bottom
hook of the balancer.Do not pull out the wire rope.
Lift the tool (equipment) and attach it to the bottom
hook of the balancer.Do not pull out the wire rope.
● The tension will increase if you turn the worm inthe “+” direction (clockwise).
● The tension will decrease if you turn the worm inthe “-” direction (counterclockwise).
CAUTION
WARNING

5-3 Post-installation checks
5-3-1 Checking the working range (stroke)
1
2
Stroke
Note: The auxiliary wire rope, the support member, and the
tool (equipment) in the figure are indicated for reference.
Usage
6.
6-1 Pre-operation inspections and checks
11
Spring Balancer Users Manual
Do not extend the wire rope beyond the stroke. Doing
so may damage the balancer.
Ensure that work can be performed within the range of the stroke.
For the stroke of each product, see “4-3-1 Specifications”.
If the range of the stroke is insufficient, lower the
installation height of the balancer or use an appropriate
sling between the bottom hook and the tool (equipment).
If any abnormality is found as a result of inspection, do not use the balancer.
If the range of the stroke is insufficient, lower the
installation height of the balancer or use an appropriate
sling between the bottom hook and the tool (equipment).
Inspect and check the following items before starting the operation:
Check of the surroundings
■
1
2
Ensure that there is no trash or unnecessary equipment around the balancer or in the work
space.
If there is any obstacle and the like that cannot be removed, contact the person in charge of the
work.
Inspection of the support member (metal hanger)
■
1
2Check that the support member (metal hanger) is not worn.
If any wear is found, immediately stop the operation.
Note:Thesupportmember
(metalhanger)inthe
figureisindicatedfor
reference.
Wear
WARNING

Note: The support member (metal hanger)
and the auxiliary wire rope in the figure
are indicated for reference.
6-2 Precautions for use
12
Spring Balancer Users Manual
Check of the main equipment of the balancer
■
For the main equipment of the balancer, perform the following
inspections and checks.
Check that the top and bottom hooks are not worn
and can rotate smoothly.
1
2
3
4
6
7
5
Check that the latches of the top and bottom hooks
are not deformed and do not come off the hooks.
Check that the wire rope is not worn (Note:
particular attention should be paid to wire breakage
and the base of terminal locks).
Check that the buffer is not worn or cracked.
Check that the case is not worn, the mounting bolts
are not loose, and air is not leaking.
Check that the auxiliary wire rope (or chain) is not
worn and the mounting bolts are not loose.
8Check the E-type retaining ring is not removed.
Check that the screws and the bolts in various parts
are not loose.
● Do not move directly under the tool (equipment) suspended from the balancer.
● Do not perform any modification of the balancer.
● Do not remove tools (equipment) with the wire rope pulled out. The wire rope may
be quickly wound up, causing an injury.
CAUTION
Be sure to use the product within the capacity range. (Refer to the capacity range in
“4-3-1 Specifications”)
● Do not extend the wire rope further than its stroke.
● Do not extend the wire rope in an oblique direction.
Adjust the spring tension before the operation.
Remove the tool (equipment) while lifting it and with the wire rope completely wound inside the drum.
WARNING
CAUTION
1
2
7
35
4
6
8
1
2

6-3 Operation method of the drum lock
Spring pin
Lock position
(deeper slot)
Release position
(shallower slot)
6-3-1 Activation of the drum lock
1
2
6-4 Replacement of the tools (equipment)
6-4-1 Method of removing the tool (equipment)
2
3
13
Spring Balancer Users Manual
Operate the drum lock according to the figure below.
● Do not remove the tool (equipment) attached to the bottom hook until it is
confirmed that the drum is securely locked.
If the drum is locked inadequately, the drum lock may be released during the work.
Then, the wire rope may be quickly wound up, causing an injury.
Remove the spring pin from the release position and move it to the lock position.
Move the tool (equipment) up and down to check that the drum is securely locked.
● Do not move directly under the tool (equipment) suspended from the balancer.
● Do not remove tools (equipment) with the wire rope pulled out. The wire rope may
be quickly wound up, causing an injury.
Confirm that the tool (equipment) can be moved up and down.
Lift the tool and wind the wire rope completely inside the drum.
Remove the tool (equipment).
6-3-1 Activation of the drum lock
1
2
● Do not release the drum lock when the balancer is not loaded or after the tool
(equipment) is replaced with one with a different mass (weight). If the drum lock is
released in such situations, the wire rope may be quickly wound up as soon as the
lock is released, the tool may fall, or an injury may be caused. Attach the tool and
adjust the spring tension before releasing the drum lock.
If the tool has been removed, be sure to attach the removed tool.
Remove the spring pin from the lock position and move it to the release position.
WARNING
WARNING
WARNING

1
2
6-4-3 Replacement of the tool (equipment) using the drum lock
1
2
3
6-5 Periodical inspections
http://www.endo-kogyo.co.jp
14
Spring Balancer Users Manual
6-4-2 Method of attaching the tool (equipment)
● Do not move directly under the tool (equipment) suspended from the balancer.
Be sure to use the product within the capacity range. (Refer to the capacity range in
“4-3-1 Specifications”)
Adjust the spring tension before the operation.
Check whether the total mass (weight) of the tool (equipment) and the accessories is within the
capacity range of the balancer.
Install the tool (equipment) and adjust the spring tension in accordance with “0 Installation of tools
(equipment) and adjustment of the spring tension”.
CAUTION
● Do not move directly under the tool (equipment) suspended from the balancer.
● Do not replace the tool with one with a different mass.
● Do not remove the tool before checking that the drum is securely locked by
moving the tool (equipment) up and down. If the drum is locked inadequately, the
drum lock may be released during the work. Then, the wire rope may be quickly
wound up, causing an injury.
Be sure to use the product within the capacity range. (Refer to the capacity range in
“4-3-1 Specifications”)
Adjust the spring tension before the operation.
Confirm that the tool (equipment) can be moved up and down.
Lock the drum within the range of the stroke according to “6-3 Operation method of the drum lock”,
and then remove the tool.
Confirm that the mass of the tools is identical, and attach the tool (equipment) according to “0
Installation of tools (equipment) and adjustment of the spring tension”.
Perform an inspection at least once per month.
For the method of the periodical inspections, download “Repair Manual” from our website and refer to
“2-2 Periodical inspections” in “Repair Manual”.
If the product is used in an unfavorable environment or used frequently, reduce the interval between the
inspections.
WARNING
CAUTION
CAUTION
WARNING

7.
7-2 Releasing the fall-arrest device
1
2
3
4
15
Spring Balancer Users Manual
Troubleshooting
7-1 Countermeasures?
● Do not remove the tool (equipment) attached to the wire rope end until the cause of
the failure is identified. If the tool (equipment) is removed, the wire rope may be
quickly wound up, causing an injury.
● If you notice anything unusual, stop the operation immediately. After checking the
items listed in the table below, appropriate measures should be taken by a
maintenance operator who has developed sufficient knowledge and operating skill
for the balancer.
● If the situation does not relate to any of the listed items in the table below, contact
us or your dealer.
Failure Reason Measure
・The wire rope cannot
be pulled out or
wound.
・ The drum lock is activated. ・ Release the drum lock.
See “6-3 Operation method of the drum
lock”.
・ The spring tension is
increased too much and the
spring has been tightly
wound.
・ Decrease the spring tension.
See “0 Installation of tools (equipment)
and adjustment of the spring tension”.
・ The spring tension is
decreased too much and the
fall-arrest device has been
activated.
・ Release the fall-arrest device.
See “7-2 Releasing the fall-arrest
device”.
・ The wire rope came off the
groove on the drum and is
caught between the casing
and the drum.
・ Return the wire rope to the groove on the
drum.
・ The spring has been
ruptured. ・ Replace the spring.
See “2-4 Replacement of the spring” in
“Repair Manual”.
If the fall-arrest device is activated, for example, when the spring tension is reduced too much, release
the fall-arrest device with the following procedure.
Confirm that the tool can be moved up and down, and that the fall-arrest device is released.
If the tool descends after being lifted up by hand and then released, turn the worm in the “+”
direction (clockwise) until the tool starts ascending. At this time, never remove the tool.
If the fall-arrest device cannot be released with the procedure above, the spring is ruptured.
Replace the spring according to “2-4 Replacement of the spring” in “Repair Manual”.
Move the tool (equipment) up and down manually.
The tool can be moved up and down within approximately 70 mm to 160 mm.
WARNING
CAUTION


8.


Outline drawing (Table of external dimensions)
Model Dimension (mm) AB C D E
MIN. MAX.
ELF-3
ELF-5
ELF-9
374
374
374
2874
2874
2874
130
130
130
221 14
14
14
15
15
15
Φ
221
Φ
221
Φ
9.
10.
16
Spring Balancer Users Manual
Dimensional Drawing
Consumables and Special Accessories
Disposal of Product
The consumables include the following parts. If any of these parts are broken or any wear or damage is
found, replace them.
● Spring
● Wire rope
● Wire guide
● Drum
Note: For the replacement of the consumables and other parts, download “Repair Manual” from our
website or contact us or your dealer.
For special accessories of the Spring Balancer, check in the catalog linked on our website.
Our website: http://www.endo-kogyo.co.jp/
When disposing of the product, follow the local regulations of the area where the product to be disposed,
and dispose it as industrial waste.

11.
17
Spring Balancer Users Manual
Parts list
Ref.No. Part No. Description Quantity
-
1
-
2
-
3
4
5
6
P2B100109
Casing assembly
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
LBP000749
LBP000241
-
LBP000240
-
-
-
-
ーCasing
ーHook complete
ーーHook
ーーLatch set
ーーーLatch
ーーーSpring
ーーーRivet
ーーShaft
EWS-3 EWS-5 EWS-7
1 1 1
1 1 1
1 1 1
How to find the parts from the list
Please refer the reference number on the exploded view and choose the parts from the list
according to its reference number
The mark indicates the range of the set or the complete unit.
● How to order the parts
Please inform us or our distributors of the parts information which include the model, part
description, parts number and quantity.
Example
model：ELF-3 parts name：drum parts number：P2B100140 quantity：1

18
Spring Balancer Users Manual
-
1
-
2
-
3
4
5
6
7
8
9
10
12
P2B100141 1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
LBP001317
LBP000262
-
LBP000263
LBP001318
-
-
-
-
-
ELF-3
ELF-5 ELF-9
1 1 1
1 1 1
1 1 1
14
15
16
17
18
19
20
21
22
23
P2B400041
1
1
1
1
1
1
1
P2B400348
P2B300957
P2B100140
1
1
24
25
27
28
29
30
31
32
33
34
35
36
P2B401579 1
1
1
1
1
1
1
1
1
1
-
1
1
1
37
38
P2B400146
P2B400149
P2B401575
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
13
-
26
P2B401573
-
-
-
-
LBP001505
LBP001524
1 1 1
-
11
18
18
-
-
-
-
-
-
-
KA60104010
P2B300951
P2B300950
P2B300952
LBP001299
P2B401587
-
-
KA10120512
KA31120500
LBP001300
-
-
-
-
-
-
2 2 2
1
1
1
1
1
1
1 1 1
- -
-- --
3 3 3
3 3 3
1 1 1
1 1 1
1 1 1
Ref.No. Part No. Description Quantity
Casing assembly
−Casing
−Hook complete
−Hook −
−Latch set −
−Latch −−
−Spring −−
−Rivet −−
−Shaft −
−Rivet −
Drum lock assembly
−Pin
−Spring
−Collar
−Spring pin
Cap
Set screw
Spindle
O-ring
Drum
Ball bearing
Spring
Spring
Spring
Bushing
Disc assembly
Cover
Rivet
Spring
Stopper
−
−
−
−
Rivet
−
Bushing
Screw
Spring washer
Wire rope assmbly
Wire rope
Thimble
−
−
Hook complete
−
−Hook −
−Latch set −
−Latch −−
−Spring −−
− −−
−Lock tube −
−Lock tube −
Rivet
Collar
Buffer
−
−
Bushing

18
NOTE）When placing an order, clearly specify the product model, part number and description.
Parts without a part number cannot be supplied individually.
Please purchase a set or complete unit.
Spring Balancer Users Manual
40
44
45
46
47
P2B200190 1
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
2
1
P2B401619
P2B400860
KA40310050
P2B300956
P2B300955
KA50200140
P2B300954
-
-
P2B401213
ELF-3
ELF-5 ELF-9
1 1 1
3 3 3
1 1 1
39
42
41
43
-
47
47
48
LBP300446
LBP001021
111
- -
-- --
Ref.No. Part No. Description Quantity
Screw
Cover
Screw
Worm
Retaining ring
Wire guide set
Wire guide
Wire guide
Hex.socket button bolt
−
−
−
Name plate
Name plate
Name plate
O-ring



●
●
●
●
〒959-1261新潟県燕市秋葉町3丁目14番7号
http://www.endo-kogyo.co.jp
本社営業部
エ コ ファクトリ ー
東京営業部
名古屋営業所
大阪営業部
九州営業所
サービス営業グループ
〒959-1261新潟県燕市秋葉町3丁目14番7号
TEL：0256-62-5133 FAX：0256-62-5772
〒959-1276新潟県燕市小池5181番地1
TEL：0256-63-9306 FAX：0256-63-4393
〒101-0042東京都千代田区神田東松下町12番2号JBSL神田ビル2F
TEL：0256-63-9306 FAX：0256-63-4393
〒460-0011愛知県名古屋市中区大須1丁目7番14号パークIMビル3F
TEL：052-253-6231 FAX：052-253-6240
〒556-0021大阪府大阪市浪速区幸町2丁目3番14号ダイトービル3F
TEL：052-253-6231 FAX：052-253-6240
〒812-0013福岡県福岡市博多区博多駅東3丁目11番15号文喜ビル3F
TEL：052-253-6231 FAX：052-253-6240
〒959-1261新潟県燕市秋葉町3丁目14番7号
TEL：0256-64-4786 FAX：0256-62-5772
E-mail：[email protected]
3-14-7,Akiba cho, Tsubame, Niigata 959-1261, Japan
http://www.endo-kogyo.co.jp TEL : [phone]
本書ならびに本製品の仕様は改善のために予告なしに変更することがあります。
本書の内容の無断転載を禁止します。
improvement without advance notice.
This manual and the specifications of this product are subject to change for
It is strictly prohibited to reprint or copy any information contained in this manual.
遠藤工業株式会社
