Brief Operating Instructions
Liquistation CSF39
Automatic sampler for liquid media
These Instructions are Brief Operating Instructions; they are not
a substitute for the Operating Instructions pertaining to the
device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation via:
• www.endress.com/device-viewer
• Smart phone/tablet: Endress+Hauser Operations App

Liquistation CSF39
Endress+Hauser 2
TAG No.: XXX000
Ser. No.: X000X000000
Order code 00X00-XXXX0XX0XXX
www.endress.com/deviceviewer Endress+Hauser Operations App
Serial number

Table of contents Liquistation CSF39
3Endress+Hauser
Table of contents
1 Document information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.1 Requirements for personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Occupational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Incoming acceptance and product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Incoming acceptance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4 Certificates and approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.1 Installation conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.3 Post-installation check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
5.1 Connection conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.2 Connecting the sampler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.3 Connection compartment in the controller housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.4 Terminal assignment for input/output signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.5 Connecting sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.6 Connecting additional inputs, outputs or relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.7 Guaranteeing the degree of protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.8 Post-connection check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6 Operation options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
6.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.2 Access to the operating menu via the local display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.3 Configuration options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
7.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.2 Switching on the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.3 Basic setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
7.4 Sampling program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Liquistation CSF39 Document information
Endress+Hauser 4
1 Document information
1.1 Warnings
The structure, signal words and safety colors of the signs comply with the specifications of ANSI
Z535.6 ("Product safety information in product manuals, instructions and other collateral
materials").
1.2 Symbols used
Safety message structure Meaning
DANGER
!
Cause (/consequences)
Consequences if safety
message is not heeded
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the situation will result in a fatal or serious
injury.
WARNING
!
Cause (/consequences)
Consequences if safety
message is not heeded
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid the situation can result in a fatal or serious
injury.
CAUTION
!
Cause (/consequences)
Consequences if safety
message is not heeded
‣Corrective action
This symbol alerts you to a dangerous situation.
Failure to avoid this situation can result in minor or medium
injury.
NOTICE
Cause/situation
Consequences if safety
message is not heeded
‣Action/note
This symbol alerts you to situations that can result in damage
to property and equipment.
Additional information, tips
Permitted or recommended
Forbidden or not recommended

Document information Liquistation CSF39
5Endress+Hauser
1.3 Documentation
The following manuals which are available on the product pages complement these Operating
Instructions:
• Brief Operating Instructions Liquistation CSF39
• Operating Instructions Memosens, BA01245C
– Software description for Memosens inputs
– Calibration of Memosens sensors
– Sensor-specific diagnostics and troubleshooting
• Operating Instructions for HART communication, BA00486C
– Onsite settings and installation instructions for HART
– Description of HART drivers
• Guidelines for communication via fieldbus and web server
– HART, SD01187C
– Web server (optional), SD01190C

Liquistation CSF39 Basic safety instructions
Endress+Hauser 6
2 Basic safety instructions
2.1 Requirements for personnel
‣Installation, commissioning, operation and maintenance of the measuring system must only
be carried out by specially trained technical personnel.
‣The technical personnel must be authorized by the system operator to perform the specified
tasks.
‣The electrical connection may be performed only by an electrical technician.
‣The technical personnel must have read and understood these Operating Instructions and
must comply with them.
‣Faults at the measuring point may only be rectified by authorized and specially trained
personnel.
Repairs not described in the enclosed Operating Instructions may only be carried out
directly at the manufacturer’s or by the service organization.
2.2 Designated use
Liquistation CSF39 is a stationary sampler for liquid media. The samples are taken
discontinuously using a vacuum pump or peristaltic pump and are then distributed into sample
containers and optionally refrigerated.
The sampler is designed for use in the following applications:
• Municipal and industrial wastewater treatment plants
• Laboratories and Water Conservancy Boards
• Monitoring of liquid media in industrial processes
Any other use than the one described here compromises the safety of persons and of the entire
measuring system and is therefore not permitted.
The manufacturer is not liable for damage caused by improper or non-designated use.
2.3 Occupational safety
As the user, you are responsible for observing the following safety regulations:
• Installation guidelines
• Local standards and regulations
Electromagnetic compatibility
The product has been tested for electromagnetic compatibility in accordance with the applicable
European standards for industrial applications.
The electromagnetic compatibility indicated applies only to a product that has been connected
in accordance with the instructions in these Operating Instructions.

Basic safety instructions Liquistation CSF39
7Endress+Hauser
2.4 Operational safety
‣Before commissioning the entire measuring point, ensure that all the connections are correct.
Ensure that electric cables and hose connections are not damaged.
‣Do not operate damaged products and secure them against unintentional commissioning.
Mark the damaged product as defective.
‣If faults cannot be rectified, the products must be taken out of service and secured against
unintentional commissioning.
CAUTION
!
The cleaning system is not switched off during calibration or maintenance activities
Risk of injury due to medium or cleaning agent
‣If a cleaning system is connected, switch it off before removing a sensor from the medium.
‣If you are not switching off the cleaning system because you wish to test the cleaning
function, wear protective clothing, goggles and gloves or take other appropriate measures.
2.5 Product safety
2.5.1 State of the art
The product is designed to meet state-of-the-art safety requirements, has been tested and left
the factory in a condition in which it is safe to operate.
Relevant regulations and European standards have been observed.
Equipment connected to the sampler shall be in compliance with the relevant safety standards.
2.5.2 IT security
We only provide a warranty if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any
inadvertent changes to the device settings.
IT security measures in line with operators' security standards and designed to provide
additional protection for the device and device data transfer must be implemented by the
operators themselves.
Support in the performance of this task can be requested from Endress+Hauser.

Liquistation CSF39 Incoming acceptance and product identification
Endress+Hauser 8
3 Incoming acceptance and product identification
3.1 Incoming acceptance
1. Make sure the packaging is undamaged.
Inform your supplier of any damage to the packaging.
Keep the damaged packaging until any issues have been resolved.
2. Make sure the contents are undamaged.
Inform your supplier of any damage to the contents.
Please keep the damaged goods until any issues have been resolved.
3. Check that the delivery is complete and nothing is missing.
Compare the scope of delivery against the delivery papers and your order.
4. Pack the product in such a way as to protect it reliably against impact and moisture for
storage and transportation.
The original packaging offers the best protection.
Keep to the approved ambient conditions (see "Technical data").
If you have any questions, contact your supplier or your local sales center.
NOTICE
The top of the sampler may be damaged or torn by incorrect transportation
‣Always use a lifting truck or a fork-lift to transport the sampler. Never lift the sampler by
the top. Lift it in the middle between the upper and lower sections.

Incoming acceptance and product identification Liquistation CSF39
9Endress+Hauser
3.2 Product identification
3.2.1 Nameplate
Nameplates can be found:
• on the inside of the top door
• On the packaging (adhesive label, portrait format)
The nameplate provides you with the following information on your device:
• Manufacturer ID
•Ordercode
• Extended order code
• Serial number
•Firmwareversion
• Input and output values
• Environment
• Activation codes
• Safety notices and warnings
Compare the data on the nameplate with your order.
3.2.2 Identifying the product
The order code and serial number of your device can be found in the following locations:
• On the nameplate
• In the delivery papers
To find out the version of your device, enterthe order code indicated on the nameplate into
the search screen at the following address:
www.endress.com/order-ident
3.3 Scope of delivery
The scope of delivery comprises:
• 1 Liquistation CSF39 with:
– The ordered bottle configuration
– Optional hardware
• Accessories kit
For peristaltic or vacuum pump:
– Connection fitting for suction line with various angles (straight, 90˚), Allen key (for version
with vacuum pump only)
• 1 Brief Operating Instructions KA01165C
(In the preferred language if the "Default operating language" order option is selected.
Otherwise, the Brief Operating Instructions are supplied in English.)
• Optional accessories
If you have any questions, contact your supplier or your local sales center.

Liquistation CSF39 Incoming acceptance and product identification
Endress+Hauser 10
3.4 Certificates and approvals
Declaration of Conformity
The product meets the requirements of the harmonized European standards.
As such, it complies with the legal specifications of the EC directives.
The manufacturer confirms successful testing of the product by affixing to it the 4mark.

Installation Liquistation CSF39
11 Endress+Hauser
4 Installation
4.1 Installation conditions
4.1.1 Dimensions
a0013080
Fig. 1: Dimensions of plastic version of Liquistation CSF39 without/with stand. Engineering unit mm (in).
A Suction line connection

Liquistation CSF39 Installation
Endress+Hauser 12
a0013082
Fig. 2: Dimensions of stainless steel version of Liquistation CSF39 without/with stand. Engineering unit mm (in).
A Suction line connection

Installation Liquistation CSF39
13 Endress+Hauser
4.1.2 Mounting location
For version with pump
1. Correct
The suction line must be routed with a downward slope to the sampling point.
2. Incorrect
The sampler should never be mounted in a place where it is exposed to aggressive gases,
e.g. hydrogen sulfide (H2S).
3. Incorrect
Avoid siphoning effects in the suction line
4. Incorrect
The suction line should never be routed with an upward slope to the sampling point.
Note the following when mounting the device:
1. The mounting location must be well-ventilated with fresh air.
2. Place the device on a level surface.
3. Protect the device from additional heating (e.g. from heaters).
4. Protect the device from mechanical vibrations.
5. Protect the device from strong magnetic fields.
6. Make sure air can circulate freely through the side panels of the housing. Do not mount the
device directly against a wall. Allow at least 150 mm (5.9") between the wall and the device
on the left and right-hand sides.
a0011693
Fig. 3: Mounting conditions for Liquistation CSF39 for open channels

Liquistation CSF39 Installation
Endress+Hauser 14
7. Do not mount the device directly over the inlet channel of a municipal wastewater treatment
plant.
Note the following when mounting the sampler:
1. Place the device on a level surface.
2. Protect the device from additional heating (e.g. from heaters).
3. Protect the device from mechanical vibrations.
4. Protect the device from strong magnetic fields.
5. Make sure air can circulate freely through the side panels of the housing. Do not mount the
device directly against a wall. Allow at least 150 mm (5.9") between the wall and the device
on the left and right-hand sides.
6. Do not mount the device directly over the inlet channel of a municipal wastewater treatment
plant.

Installation Liquistation CSF39
15 Endress+Hauser
4.1.3 Mechanical connection
Foundation plan
a0012761
Fig. 4: Foundation plan. Engineering unit mm (in).
AFasteners(4xM10)
B Cable inlet
C Outlet for condensate and overflow > DN 50
D Sample supply from below > DN 80
- - - Dimensions of Liquistation
302 (11.9)
195.4 (7.69)
C
C
D
B
AA
AA
137.4 (5.41) 355 (14.0) 61 (2.4)
605 (23.8)
730 (28.7)
786 (30.9)
214 (8.43)
255 (10.0)
311 (12.2) 305 (12.0)
33.6 (1.32)

Liquistation CSF39 Installation
Endress+Hauser 16
4.1.4 Connection for sampling
• Maximum suction height:
Vacuum pump: Standard 6 m (20 ft), 8 m (26 ft) optional
Peristaltic pump: standard 8 m (26 ft)
• Maximum hose length: 30 m (98 ft)
• Hose connection diameter:
Vacuum pump: 10 mm (3/8"), 13 mm (1/2"), 16 mm (5/8") or 19 mm (3/4") internal diameter
Peristaltic pump: internal diameter of 10 mm (3/8")
• Intake speed:
> 0.5 m/s (> 1.6 ft/s) for ≤13 mm (1/2") ID, in accordance with EN 25667, ISO 5667
> 0.6 m/s (> 1.9 ft/s) for 10 mm (3/8") ID, in accordance with Ö 5893, US EPA
Note the following when mounting the device:
• Always route the suction line with an upward slope from the sampling point to the sampler
• The sampler should always be located above the sampling point
• Avoid siphoning effects in the suction line
The following conditions must be met at the sampling point:
• Do not connect the suction line to pressurized systems.
• Use a suction strainer to catch bigger, abrasive solids that could clog the system
• Immerse the intake hose in the direction of flow
• Take the sample at a representative point (turbulent flow, not directly at the base of the
channel).
Useful sampling accessories
• Suction strainer:
Catches bigger, abrasive solids that could clog the system.
• Immersion assembly:
The adjustable immersion assembly fixes the suction line to the sampling point.
4.2 Mounting the device
4.2.1 Connecting the suction line from the side
1. Observe the installation conditions when installing the device.
2. Route the suction line from the sampling point to the device.
3. Screw the suction line onto the suction line connection of the device.
4.2.2 Connecting the suction line from below
If the suction line is connected from below, the suction line is routed upwards behind the rear
panel of the sample compartment. First remove the rear panel of the dosing chamber and
sample compartment as described in the "Wiring" section.
1. Remove the drain plug from the hose gland located at the back of the device base.
2. As illustrated, guide the suction line upwards and through the opening towards the front.

Installation Liquistation CSF39
17 Endress+Hauser
Connecting the suction line in the version with the vacuum pump
1. Unscrew the thread adapter nut (item 3).
2. Unscrew the hose gland (item 4) from the side panel.
3. Fit the hose gland in the fixing clamp (item 2) as illustrated.
4. Screw the hose tight from above.
5. Attach the hose adapter supplied to the suction line and screw it onto the hose gland from
below.
6. Insert the dummy plugs supplied.
a0013704
Fig. 5: Sample supply from below
1
2
Gland for the suction line
Suction line
1
2

Liquistation CSF39 Installation
Endress+Hauser 18
Connecting the suction line in the version with the peristaltic pump
1. Unscrew the thread adapter nut (item 3) and the hose gland (item 4) from the side panel.
2. Unscrew the small thread adapter nut (item 1) and remove the hose.
3. Connect the suction line from below as illustrated.
4. Insert the dummy plugs supplied.
a0013707
Fig. 6: Connecting the suction line from the side (as-delivered
state)
1Hose
2 Fixing clip for hose gland
3 Thread adapter nut
4Hosegland
a0013708
Fig. 7: Suction line connected from below
a0013705
Fig. 8: Connecting the suction line from the side
(as-delivered state)
1 Small thread adapter nut
2Hose
3 Thread adapter nut
4Hosegland
a0013706
Fig. 9: Suction line connected from below
1 Suction line
1
2
3
4

Installation Liquistation CSF39
19 Endress+Hauser
4.3 Post-installation check
• Make sure the suction line is securely fitted to the device.
• Perform a visual inspection to ensure the suction line is routed correctly from the sampling
point to the device.
• Ensure that the distribution arm is correctly engaged.
• Allow the sampler to rest for a minimum of 12 hours following installation and before
switching on. Otherwise the cooling module may be damaged.

Liquistation CSF39 Electrical connection
Endress+Hauser 20
5 Electrical connection
WARNING
!
Device is energized
Incorrect wiring can result in injury or fatality
‣The electrical connection must only be carried out by a certified electrician.
‣Technical personnel must have read and understood the instructions in this manual and
must adhere to them.
‣Prior to beginning any wiring work, make sure voltage is not applied to any of the cables.
5.1 Connection conditions
5.1.1 Remote operation via HART (e.g. via HART modem and FieldCare)
a0015608
Fig. 10: HART via modem
1 Device module Base-E: current output 1 with HART
2 HART modem for connecting to PC, e.g. FXA195fo1)
3 HART handheld terminal
1) Switch set to "on" (substitutes the resistor)
