Endress+Hauser Liquisys M COM 223 User manual

BA 199C/07/en/07.02
No.51500272
Software version 2.40 or higher Liquisys M
COM 223 / 253
Transmitter for
Dissolved Oxygen
Operating Instructions
Endress Hauser
The Power of Know How
Quality made by
Endress+Hauser
ISO 9001
ENDRESS+HAUSER
LIQUISYS M
ENDRESS+HAUSER
LIQUISYS M

You want to find out about the device.
Just look here:
Safety
General information
You wish to install the device.
The required steps are described in this chapter:
Installation
You wish to operate or reconfigure the device.
The operating concept is explained in these chapters:
Operation
Setting the device configuration
Interfaces
If faults occur or a warning is required, look here
for help:
Maintenance and troubleshooting
Diagnostics and corrective maintenance
Accessories
Appendix
Technical data
Index
%Ω°C

OM253D00.CHP
Inhaltsverzeichnis
1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Symbols used ............................................................. 2
1.2 Storage and transport ....................................................... 2
1.3 Unpacking ................................................................ 2
1.4 Dismantling, packaging, disposal .............................................. 2
1.5 Product overview ........................................................... 3
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Intended application ........................................................ 4
2.2 General safety instructions ................................................... 4
2.3 Installation, start-up, operation ................................................ 4
2.4 Monitoring and safety features ................................................ 5
2.5 Immunity to interference ..................................................... 5
2.6 Declaration of conformity ..................................................... 5
3 Installation........................................................... 6
3.1 Measuring system .......................................................... 6
3.2 Dimensions ............................................................... 7
3.3 Mounting ................................................................. 8
3.4 Electrical connection ....................................................... 12
3.5 Sensor installation and measuring cable connection .............................. 16
4 Operation........................................................... 17
4.1 Operator interface ......................................................... 17
4.2 Display .................................................................. 17
4.3 Key functions ............................................................. 18
4.4 Auto / manual mode of operation.............................................. 19
4.5 Operating concept......................................................... 20
5 Instrument configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.1 Start-up ................................................................. 25
5.2 System configuration ....................................................... 25
5.3 Current input ............................................................. 27
5.4 Current outputs ........................................................... 30
5.5 Monitoring functions........................................................ 34
5.6 Relay contact configuration .................................................. 39
5.7 Service .................................................................. 50
5.8 E+H Service .............................................................. 52
5.9 Interfaces ................................................................ 53
5.10 Calibration ............................................................... 54
6 Interfaces........................................................... 57
7 Maintenance and troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.1 Troubleshooting instructions ................................................. 58
7.2 Troubleshooting using the error messages ...................................... 62
8 Diagnostics and corrective maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8.1 Diagnosis ................................................................ 65
8.2 Corrective maintenance of Liquisys M COM 223 ................................. 68
8.3 Corrective maintenance of Liquisys M COM 223 ................................. 71
8.4 Spare parts orders ......................................................... 74
8.5 Service equipment »Optoscope« with »Scopeware« .............................. 74
8.6 Corrective maintenance on the complete measuring point
COM 2x3-DX/-DS.......................................................... 75
8.7 Corrective maintenance on the complete measuring point
COM 2x3-WX/WS.......................................................... 76
9 Accessories ......................................................... 78
10 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11 Appendix........................................................... 82
12 Index............................................................... 94
Liquisys M COM 223 / 253
Endress+Hauser

1 General information
1.1 Symbols used
Warning:
This symbol alerts to hazards which
could cause serious injuries as well
as damage to the equipment if
ignored.
Caution:
This symbol alerts to possible faults
which could arise from improper
operation. They could cause
damage to the equipment if ignored.
Note:
This symbol indicates important
items of information.
Double insulation
Equipment protected by double
insulation.
Alarm relay
Input
Output
1.2 Storage and transport
The packaging material used to store or
transport the transmitter must provide shock
protection. Optimal protection is provided by
the original packaging materials.
Conformance with permissible ambient
conditions (see Technical data) must be
assured.
1.3 Unpacking
Make sure that the packaging and the
contents are undamaged! Inform the post
office or freight carrier of any damage.
Damaged merchandise must be retained until
the matter has been settled.
Check that the delivery is complete and
agrees with the shipping documents and your
order (refer to nameplate for type and version).
Keep the original packaging materials for
future storage or shipping of the instrument.
If you have any questions, please contact
your supplier of the Endress+Hauser Sales
Office responsible for your area (see reverse
side of these Operating Instructions).
The delivery includes:
•Transmitter COM 223 or COM 253
•Operating Instructions BA 199C/07/en
•Panel-mounted instrument:
–1 set of plug-in screw terminals
–2 clamping screws (see p. 11)
•Field instrument:
–1 plug-in screw terminal
–1×cable gland Pg 7
–1×cable gland Pg 16, reduced
–2×cable glands Pg 13.5
–1 x NPT adapter set
(optional for CSA versions)
1.4 Dismantling, packaging, disposal
For reuse at a later time, the measuring
transmitter must be carefully packed.
Optimum packaging is provided by the
original packaging. When disposing of the
equipment, observe local regulations.
General information Liquisys M COM 223 / 253
2Endress+Hauser

1.5 Product overview
You can recognise the device version from the order code or the nameplate. Sub “codes”are
the release codes for Software upgrade shown for ChemoClean (left of diagonal line) or Plus
packet (right of diagonal line).
Additional version of Plus Package (version DS or WS):
•Current output table, fields O23x
•Monitoring for sensor and process,
function group P
•Automatic start of cleaning function, field F8
131085-4D
ENDRESS+HAUSER
LIQUISYS M
order code
serial no. /
codes
diss. oxygen
COM 223-WS0116
276945
0…20 mg/l 0 …200% SAT
-10 …60°C
0/4 …20 mA
230 VAC 50/60 Hz 7.5 VA
-10 …+55°CIP 54 / IP 30
0/4 …20 mA
-8732
prot. class ambient temp.
output 1 output 2
mains
meas. range
temperature
Made in Germany
D-70839 Gerlingen
3472
TYPO2223.CDR
Fig. 1.1 Nameplate COM 223
(left)
131085-4D
ENDRESS+HAUSER
LIQUISYS M
order code
serial no. /
codes
diss. oxygen
COM 253-WS0116
276944
0…20 mg/l 0 …200% SAT
-10 …60°C
0/4 …20 mA
230 VAC 50/60 Hz 7.5 VA
-10 …+55°CIP 65
0/4 …20 mA
-8732
prot. class ambient temp.
output 1 output 2
mains
meas. range
temperature
Made in Germany
D-70839 Gerlingen
3472
TYPO2253.CDR
Fig. 1.2 Nameplate COM 253
(right)
Liquisys M COM 223 / 253
Version
DX Basic functions, Sensor COS 41 / 4 / 4HD
DS With Plus package, Sensor COS 41 / 4 / 4HD
WX Basic function, Sensor COS 31 / 71 / 3 / 3HD
WS With Plus package, Sensor COS 31 / 71 / 3 / 3HD
Power supply
0 Power supply: 230 V AC
1 Power supply: 115 V AC
2 Power supply: 230 V AC, CSA Gen. Purp.
3 Power supply: 115 V AC, CSA Gen. Purp.
5 Power supply: 100 V AC
7 Power supply: 24 V AC, CSA Gen. Purp.
8 Power supply: 24 V AC / DC
Measurement output
0 1 output signal: Dissolved oxygen
1 2 output signals: Dissolved oxygen and temperature / set value
3 1 output signal: PROFIBUS-PA
4 1 output signal: PROFIBUS-DP
5 1 output signal: Dissolved oxygen with HART
6 2 output signals: Dissolved oxygen with HART, temp. / set value
Contacts
05 No additional contacts
10 2 contacts (limits / PID / timer)
15 4 contacts (limits / PID / timer / ChemoClean)
16 4 contacts (limits / PID / timer)
20 2 contacts with current input (limits / PID / timer)
25 4 contacts with cleaning, current input
(limit / PID / ChemoClean)
26 4 contacts with timer, current input
(limits / PID / timer)
COM253- complete order code
COM223-
OM253D01.CHP
Liquisys M COM 223 / 253 General information
Endress+Hauser 3

2 Safety instructions
2.1 Intended application
The COM 223/253 transmitter is a field-tested
and reliable measuring transmitter used to
determine the oxygen concentration of liquid
media.
The transmitter COM 223/253 is particularly
suitable for use in the following areas:
•Sewage treatment plants
•Sewage treatment
•Drinking water
•Water conditioning and monitoring
•Surface water (rivers, lakes, oceans)
•Fish farming
2.2 General safety instructions
This device has been manufactured for safe
operation according to the state of the art in
engineering and conforms to the applicable
regulations and European standards (see
Technical data). It has been designed
according to EN 61010-1 and has left the
manufacturer’s works in perfect condition.
However, if used improperly or for purposes
other than the intended purpose, it may be
dangerous, e.g. due to incorrect connection.
Warning:
•Operating this instrument in any
way other than as described in
these instructions may compro-
mise the safety and function of the
measuring system and is therefore
impermissible.
•The notes and warnings in these
installation and operating instruc-
tions must be strictly adhered to!
2.3 Installation, start-up, operation
Warning:
•This device may only be installed,
connected electrically, commis-
sioned, operated and serviced by
properly trained personnel autho-
rised by the system operator.
•The personnel must be familiar
with these operating instructions
and must adhere to the
instructions described therein.
•Make sure that the power supply
ratings match the data specified
on the nameplate before you
connect the instrument to a power
source.
•A clearly identified mains
disconnecting device must be
installed close to the instrument.
•Live components can be touched
through the vent slots in the
housing and the openings on the
rear of the housing. Do not insert
any tools, wires or similar objects
into these slits (only COM 223).
•Check that all connections have
been properly made before
powering up the system!
•Damaged equipment that may be
dangerous must not be operated
and should be clearly identified as
being defective.
•Any troubleshooting of the measur-
ing system is to be performed
exclusively by authorised, trained
personnel.
•If faults cannot be remedied, the
instrument must be removed from
service and secured to prevent
accidental start-up.
•Repairs not described in these
operating instructions may only be
performed at the manufacturer’s
works or by the Endress+Hauser
Service Organisation.
Safety instructions Liquisys M COM 223 / 253
4Endress+Hauser

2.4 Monitoring and safety features
Safety features
The transmitter is protected against external
influences and damage by the following
design measures:
•Rugged housing
•Degree of protection provided by enclosu-
re: IP 65 (COM 253)
•UV resistance
Monitoring features
In the event of a system error or power failure,
an alarm condition is signalled via a fault-
signalling contact.
2.5 Immunity to interference
This instrument has been tested according to
the applicable European standards for
industrial applications with regard to
electromagnetic compatibility. The transmitter
is protected against external influences and
damage by the following design measures:
•Cable screening
•Fault protection filters
•Fault protection condensers
Warning:
The specified immunity to inter-
ference only applies for devices
connected as outlined in these
operating instructions.
2.6 Declaration of conformity
The transmitter COM 223/253 complies with
the legal demands of the harmonized
European standards.
E+H certfies the compliance with the
standards by using the 4sign.
OM253D02.CHP
Liquisys M COM 223 / 253 Safety instructions
Endress+Hauser 5

3 Installation
For a complete installation of the measuring point, proceed as follows:
•Installation or attachment of measuring transmitter (see Chap. 3.3)
•Selection and connection of cables and measuring cell (see Chap. 3.4, 3.5 and 9)
•Installation is followed by start-up (see Chap. 5).
3.1 Measuring system
The complete measuring system comprises:
Variant 1
•The transmitter Liquisys M COM 223 or
COM 253 in DX or DS version
•An oxygen sensor COS 4, COS 4HD or
COS 41
•An immersion, flow or retractable
assembly
Options:
•Extension cable OMK
•Junction box VBM
Variant 2
•The transmitter Liquisys M COM 223 or
COM 253 in WX or WS version
•An oxygen sensor COS 3, COS 3S,
COS 3HD, COS 31 or COS 71
•An immersion, flow or retractable
assembly
Options:
•Extension cable OMK
•Junction box VS
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL1
REL1
ALARM
REL2
REL2
E
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL1
REL1
ALARM
REL2
REL2
E
OM2X3SYS.CDR
Immersion
assembly
CYA 611
Universal hanging
assembly holder
CYH 101 Liquisys M COM 253
Oxygen sensor
Weather protection cover
CYY 101
Retractable
assembly
COA 461
Liquisys M COM 223
Fig. 3.1
Complete measuring
system Liquisys M COM
223 / 253 with measuring
cable, assembly and
oxygen sensor
Installation Liquisys M COM 223 / 253
6Endress+Hauser

3.2 Dimensions
Note:
There is a hole in the punching for
Pg 16 cable entry. It serves as a
pressure balance during air freight
dispatching. Make sure that there is
no moisture penetrating into the hou-
sing before cable installation. After
cable installation, the housing is
completely tight.
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL1
REL1
ALARM
REL2
REL2
E
FELD1.CDR
11
170
247
115
∅6
157
154
70
70
SXB only -WX/-WS
Fig. 3.3
Dimensions of Liquisys M
COM 253
FELD2.CDR
1
2
3
5
4
Fig. 3.2
Inner view
Liquisys M COM 253
1 Removable
electronics box
2 Partition plate
3 Terminal blocks
4 Fuse
5 Sensor plug-in
(only for version WX/WS)
GEHAEUS1.CDR
OM253D03.CHP
Liquisys M COM 223 / 253 Installation
Endress+Hauser 7

3.3 Mounting
3.3.1 Field instrument
Several mounting options are available for the
Liquisys in the field instrument version:
•Post mounting on cylindrical pipes
•Post mounting on a square post
•Wall mounting with fastening screws
Weather protection cover CYY 101 can be
used for outdoor installation in conjunction
with all mounting variants. With direct weather-
ing, use the weather protection cover.
Weather protection cover CYY 101
Weather protection cover for operation in the
open, for installation on the field instrument;
Material: Stainless steel 1.4301 (AISI 304);
Order No.: CYY101-A
EINBAU2.CDR
96
6
139
90
Fig. 3.4
Liquisys M COM 223,
mounting version
DACH.CDR
300
270
320
Fig. 3.5
Weather protection cover
CYY 101 for field
instruments
EINBAU1.CDR
Installation Liquisys M COM 223 / 253
8Endress+Hauser

Post mounting kit
Installation kit for installing the field housing
on horizontal and vertical posts
(max. dia. 60 mm);
Material: Stainless steel 1.4301 (AISI 304);
Order No. 50086842
Universal mounting post CYY 102
Square pipe for installation of transmitters;
Material: Stainless steel 1.4301 (AISI 304);
Order No. CYY102-A
MONT5.CDR
60
90
70
∅6
70
∅8
70
90
M6
∅8
30
90
60 x 60
1495
150
120
Fig. 3.6
Left:
Mounting kit
for post mounting on
cylindrical pipes
Right:
Four edged mounting
post CYY 102
OM253D03.CHP
Liquisys M COM 223 / 253 Installation
Endress+Hauser 9

3.3.2 Mounting examples
MONT10.CDR
Fig. 3.7
Liquisys, field instrument:
Pipe mounting
MONT2.CDR
Fig. 3.8
Liquisys, field instrument:
Left:
Wall mounting
Right:
Mounting with universal
post and weather
protection cover
Installation Liquisys M COM 223 / 253
10 Endress+Hauser

3.3.3 Panel-mounted instrument
The instrument is attached using the supplied tensioning screws (see Fig. 3.9).
The required overall installation depth is approx. 165 mm.
MONT9.CDR
92+0,5
92+0,5
90
57
33
ca. 25 max. 45
96
92
1
2
3
139 6
3
3
Fig. 3.9
Fixing the installation
instrument
1 Front of the
control cabinet
2 Seal
3 Clamping screws
OM253D03.CHP
Liquisys M COM 223 / 253 Installation
Endress+Hauser 11

3.4 Electrical connection
Connection diagram COM 223 / 253 in DX or DS version
The connection diagram depicted in Fig. 3.10 shows the connections when using an oxygen
sensor of type COS 4, COS 4HD or COS 41.
Note:
•The instrument has protection
class II and is generally operated
without protective earth connecti-
on.
•Mains supply voltage fluctuations
should not exceed ten percent of
the nominal supply voltage.
•24V AC/DC models must be supp-
lied from an energy limiting SELV
source in accordance with dir. IEC
1010.1 Annex H.
47
48
49
57
58
59
41
42
43
15 V
85
86
10-50 V
81
93
82
94
10-50 V
mA
31
32
mA
33
34
51
52
53
54
55
56
90
12
11
91
S
O2
O2
K
A
A
K
NTC
GN
RD
BN
23 +
24 -
mA
L+
L–N
L1
∼=
ANO201.CDR
Auxiliary voltage
output
Digital
Input 2
(Chemoclean)
Digital
Input 1
(Hold)
Signal output 2:
temperature
Signal output 1
oxygen
Sensor
COS 4 /
COS 4 HD /
COS 41
Alarm
(contact
position
current-free)
Relay 1
(contact
position
current-free)
Relay 2
(contact
position
current-free)
Relay 3
(contact
position
current-free)
Relay 4
(contact
position
current-free)
Mains
Current input
4 ... 20 mA
Fig. 3.10
Electrical connection of
Liquisys M COM 223 / 253
in DX or DS version with
full wiring
** Auxiliary voltage supply
terminal 85/86 usable
Installation Liquisys M COM 223 / 253
12 Endress+Hauser

Connection diagram COM 223 / 253 in WX or WS version
The connection diagram in Fig. 3.11 shows the connections when using an oxygen sensor of
type COS 3, COS 3 S, COS 3HD, COS 31 or COS 71.
47
48
49
57
58
59
41
42
43
15 V
85
86
10-50 V
81
93
82
94
10-50 V
mA
31
32
mA
33
34
51
52
53
54
55
56
18
96
97
19
S
O
2
O
2
GN
PK
BU
8,5 V DC
88
0
87 +
0
-8,5 V DC
WH
BR
GY
YE
1
2
5
4
3
7
6
GN
PK
BU
WH
BR
GY
YE
ϑRS 485
analog *** digital ***
23 +
24 -
mA
L+
L–N
L1
∼=
Oxygen sensor
Alarm
(contact
position
current-free)
Relay 1
(contact
position
current-free)
Relay 2
(contact
position
current-free)
Relay 3
(contact
position
current-free)
Relay 4
(contact
position
current-free)
Mains
ANO201-2.CDR
Auxiliary voltage
output
Digital
Input 2
(Chemoclean)
Digital
Input 1
(Hold)
Signal output 2
temperature
Signal output 1
oxygen
Current input
4 ... 20 mA
Fig. 3.11
Electrical connection of
Liquisys M COM 223 /
253 in WX or WS
version with full wiring
** Auxiliary voltage supply
terminal 85/86 usable *** analogue: with COS 3, 3-S, 3HD digital: with COS 31, 71
Box VS with extension with COM 253-WX/-WS plug connection f. O2 Sensor
for COM 223-WX/-WS the sensor cable plug must
be removed or box VS used
OM253D03.CHP
Liquisys M COM 223 / 253 Installation
Endress+Hauser 13

Instrument connections for field instrument COM 253 in DX or DS version
For connection, the measuring cables are introduced through the cable glands on the field
instrument and connected according to the diagrams in Figs. 3.10, and 3.12.
Note:
NC: Do not connect!
Instrument connections for installed instrument COM 223 in DX or DS version
42
++ ++++-
-
----
434154 55 56
NC
NC
NC NC
31
K11
12
32
A
3433
S
NC 938685 94 81 82 23 24 NC
51 52 53 57 58 59 47 48 49
O2
Temp.
(opt.)
+15V
10mA
RDGN
BN
REL 4SENSOR REL 3 REL 2 REL 1
131093-4F
COM 253
Digital 2 Digital 1
4..20mA
11
12
NC
Mains
Hilfsenergie
L1
+N -(AC)
(DC)
Contacts:
max. 2A
AC: 250V/500VA
DC: 30V/60W
131093_F.CDR
Fig. 3.12
Connection box sticker
for field instruments
COM 253 in DX or DS
versions
31 +
32 -
33 +
12
34 -
85 +
NC
NC
NC
NC
NC
Sensor
NC
86 -
93 + S
94 - 42
81 + 43
82 - 41
O2
Temp.
(opt.)
+15V
10mA
Digital 2
Digital 1
11
91
90 K
A
RD
BN
GN
131080-4C
Mains Contacts: max. 2A, AC:250V/500VA, DC:30V/60W
L1 +
AC DC
N-
REL1
REL2
REL3
REL4
4..20mA 24
23
49
COM
COM
COM
COM
-
+
59
54
55
56
52
51
53
58
57
48
47
131084-4C
131080_C.CDR
Fig. 3.13
Connection box sticker for
installation instruments
COM 223 in DX or DS
versions
Installation Liquisys M COM 223 / 253
14 Endress+Hauser

Instrument connections for field instrument COM 253 in WX or WS version
For connection, the measuring cables are introduced through the cable glands on the field
instrument and connected according to the diagrams in Figs. 3.11, and 3.14. The sensor is
plugged in from the outside (7-pin socket SXB).
Note:
Please label the sensor terminal
block with the enclosed sticker.
Instrument connections for installed instrument COM 223 in WX or WS version
For connection to the COM 223-WX/WS, the sensor plug must be removed and directly
attached to the litz wires. If the connection plug is to stay as an isolatable connection, a junction
box VS can be inserted between the sensor and the instrument.
42
+++++-----
434154 55 56
NC 31 32 3433 NC 938685 94 81 82 NC
51 52 53 57 58 59 47 48 49
O2
Temp.
(opt.)
+15V
10mA
REL 4 REL 3 REL 2 REL 1
133226-4C
Digital 2 Digital 1
19
18 87
87, 88
96 88
97 0
S
GRBU
B
A
YE
WH
BNGN
analog:
PK
SENSOR
96
97
NC
Mains
Hilfsenergie
L1
+N -(AC)
(DC)
Contacts:
max. 2A
AC: 250V/500VA
DC: 30V/60W
+-
23 24
4..20mA
133226_B.CDR Fig. 3.14
Connection box sticker for
field instruments COM
253 in WX/WS versions
31 +
32 -
33 +
34 -
85 +
NC
19
18
NC
87
Sensor
NC
86 -
93 + S
94 - 42
81 + 43
82 - 41
O2
Temp.
(opt.)
+15V
10mA
Digital 2
Digital 1
88
0
97
96
GR
YE
BN
BU
A
B
-
+
PK
GN
WH
133228-4B
Mains Contacts: max. 2A, AC:250V/500VA, DC:30V/60W
L1 +
AC DC
N-
REL1
REL2
REL3
REL4
4..20mA 24
23
49
COM
COM
COM
COM
-
+
59
54
55
56
52
51
53
58
57
48
47
131084-4C
133228_B.CDR Fig. 3.15
Connection box sticker for
installation instruments
COM 223 in WX/WS
versions
OM253D03.CHP
Liquisys M COM 223 / 253 Installation
Endress+Hauser 15

3.5 Sensor installation and measuring cable connection
Measuring cable connection
The terminal block is located in a separate
connection compartment which is accessible
by opening the plastic cover. Remove the pre-
pressed knock-outs for cable entry.
The oxygen sensor is connected via a special
screened, multi-core cable. To extend the
measuring cable, use junction box and
extension cable.
Note:
•Protect connectors, cable ends
and terminals against moisture to
prevent inaccurate measurement!
•For further information on cables
and junction boxes refer to chap.
9 Accessories.
Structure and preparation of the sensor cable (COS 4 / 4HD / 41)
Preparation of the sensor connector (COS 3 / 3S / 3HD / 31 / 71) with OMK cable
Sensor type Sensor cable Extension
COS 4 / 4HD / 41 CMK/CYK 71 prepared VBM junction box + CYK 71 cable
COS 3 / 3S / 3HD OMK with SXP plug VS junction box + OMK cable
COS 31 / 71 OMK with SXP plug VS junction box + OMK cable
COS 31 / 71 with TOP 68 connection CYK 71 with SXP plug VS junction box + OMK cable
Maximum cable length
COS 4 / 4HD / 41 max. 50 m with CMK cable
COS 3 / 3S / 3HD / 31 / 71 100 m with OMK cable
K
A
green
brown
Assignment
Outer screen
Active inner screen
NTC temperature sensor
Cathode
Anode
NTC temperature sensor
red
COS4KABL.CDR
Fig. 3.16
Structure of the special
measuring cable CMK /
CYK 71
Pin assignment
1 yellow +UB
2 grey OV
3 pink NTC temperature sensor
4 blue NTC temperautre sensor
5 brown -UB
6 green Alarm
7 white Sensor signal
OMK.CDR
Fig. 3.17
Production of a
sensor plug with
special measuring
cable OMK
Installation Liquisys M COM 223 / 253
16 Endress+Hauser

4 Operation
4.1 Operator interface
4.2 Display
LED indicators
Liquid crystal display
185 mg/l
R232
Setpoint
DISPLAY1.CDR
LCD to display
measured values
and configurations
data
4 main operating keys
for calibration and
instrument configuration Shift key for
Automatic / Manual
operation
Display LEDs for
limit contactor
relay
(switching state)
Display LED for
alarm function
Display of active
contact and key for
relay switchover
in manual mode
Field for inscription by
user
Fig. 4.1
Operating elements
Liquisys M
Display of current operating mode »Auto«(green LED) or »Manual«(yellow LED)
Display of controlled relay in »Manual«mode (red LED)
Display of working state of relays 1 and 2
LED green: Measured value within allowed limits, relay inactive
LED red: Measured value outside allowed limits, relay active
Alarm display e.g. when limit values constantly exceeded,
Temperature sensor failure or system error
185 mg/l
R232
Setpoint
DISPLAY3.CDR
Display for
measuring mode
(normal operation)
Display for
calibration mode Display for
setup mode
(configuration)
Error
indicator In measuring mode:
Secondary measured value.
In setup / calibr. mode
e.g. setting value
In measuring mode:
Main measured value.
In setup / calibr. mode
e.g. parameter
Function coding display
Display of working
state Rel 3/4:
inactive active
Hold mode display
(current outputs reflect
last state)
For instruments with
communication:
Display to receive
messages.
Constantly visible in
Burst mode (with HART)
Sensor symbol
Temperature
offset
Manual
temperature
compensation Fig. 4.2 Liquid crystal display
OM253FE4.CHP
Liquisys M COM 223 / 253 Operation
Endress+Hauser 17

4.3 Key functions
CAL key
When the CAL key is pressed, the instrument prompts for the calibration
access code:
Code 22 for calibration
Code 0 or any code for calibration data checking.
Press the CAL key to acknowledge the calibration data or to proceed
within the calibration menu.
ENTER key
The ENTER key has the following functions:
Opens the Setup menu in Measurement mode
Saves (confirms) entered data in Setup mode.
Moving on within the function groups.
PLUS key and MINUS key
The PLUS and MINUS keys have the following functions:
Selection of function groups
Setting parameters and numeric values
Relay operation in manual mode (see Chap. 4.4).
Pressing the PLUS key allows you to switch between the current
output in % and mA.
Repeatedly pressing the PLUS key displays the following settings in
sequence as secondary measured values:
1. Temperature display in °F
2. Hides the temperature display
3. - 5. Measured value display in mg/l, % SAT, hPa
6. Sensor current in nA/mV
7. Current input signal in %
8. Current input signal in mA
9. Return to basic setting
Repeatedly pressing the MINUS key shows errors:
1. The current errors are displayed one after the other (max. 10)
2. After all the errors are displayed, the standard display is unhidden.
In function group F, you can define an alarm for each error code
separately.
REL key
The REL key toggles between the relay and manual cleaning start in
manual mode. In automatic mode you can output the corresponding
switch-on points (limit contactor) ot set points (PID controller) when
pressing the REL key. Pressing the PLUS key allows you to display the
settings of the following relay. Press the REL key to return to measuring
mode (automatic return after 30s).
AUTO key
Pressing the AUTO key switches between the automatic and manual
modes.
Escape function
Pressing the PLUS and MINUS keys simultaneously returns the display
to the main menu. Press the PLUS and MINUS keys again to return to
measuring mode.
Locking the keypad
Pressing the PLUS and ENTER keys simultaneously for minimum 3s
locks the keypad against unintentional entries. However, all settings can
still be read. The code prompt displays the code 9999.
Unlocking the keypad
Pressing the CAL and MINUS keys simultaneously for minimum 3s
unlocks the keypad. The code prompt displays the code 0:
Operation Liquisys M COM 223 / 253
18 Endress+Hauser
