Endress+Hauser Mycom S CPM 153 User manual

BA233C/07/en/12.02
51513612
Software version 1.20 or later
Mycom S
CPM 153
pH and Redox Transmitter
Operating Instructions
MYCOM S CPM 153
ENDRESS+HAUSER
MEAS CAL
DIAG PARAM
?
7.54
pH
Select
Measure

First Start-up page 25 Mycom S CPM 153
2Endress+Hauser
First Start-up ................................................ page 25
Using the menu "Quick Setup" in the chapter "First Start-up" you can configure the
transmitter with the most important parameters quickly and easily. Important basic
functions like language, measuring parameter, temperature compensation and current
outputs are configured with the help of the on-site display.
You carry out further configuration in the corresponding menus as required.
Brief operating instructions
"PARAM": Parameter entry menu
"PARAM" allows you to return to the previous "return field" from any point in the menu.
"DIAG": brings you to the instrument diagnosis menu.
Help page: Press "DIAG" and "PARAM" together
"MEAS": Operation
Press "MEAS" to exit any of the menus ("PARAM", "DIAG", "CAL") without having com-
plete the settings / calibration.
"CAL": Calibration
"E": (Enter): Continue in menu / confirm your selection
LED: "green" = everything OK. "red" = error.
Arrow keys:
• Scroll through menu options and highlight a selection or
• increment/decrement numbers by one step with "+" / "-".
Next digit: using the "right arrow" (editor type 1) or
• "Activate" with the "right arrow" and scroll through the selection with "+" / "-"
(editor type 2).

Mycom S CPM 153
Endress+Hauser 3
Contents
1 Safety instructions . . . . . . . . . . . . . . . . . 4
1.1 Safety symbols . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Installation, commissioning and operation . . . 5
1.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . 6
1.5 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Identification . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Instrument designation . . . . . . . . . . . . . . . . . . 7
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Certificates and approvals . . . . . . . . . . . . . . . 8
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Incoming acceptance, transport, storage . . . 9
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . 9
3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Checking the installation . . . . . . . . . . . . . . . . 11
4 Electrical connection . . . . . . . . . . . . . 12
4.1 Quick wiring guide . . . . . . . . . . . . . . . . . . . . . 12
4.2 Sensor connection and measuring cable . . . 15
4.3 Post connection check . . . . . . . . . . . . . . . . . 19
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.1 Display and operating elements . . . . . . . . . . 20
5.2 Replaceable memory . . . . . . . . . . . . . . . . . . 24
6 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1 Installation and function inspection . . . . . . . 25
6.2 Switching on the measuring device . . . . . . . 25
6.3 Special features for measurement
with glass-free IsFET sensor . . . . . . . . . . . . . 25
6.4 Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.5 Description of functions . . . . . . . . . . . . . . . . . 31
7 Maintenance . . . . . . . . . . . . . . . . . . . . . . 89
7.1 Maintaining the measuring system . . . . . . . . . 89
8 Troubleshooting . . . . . . . . . . . . . . . . . 92
8.1 Troubleshooting instructions . . . . . . . . . . . . . 92
8.2 Response of outputs to errors . . . . . . . . . . . 102
8.3 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . 103
8.4 Installation and removal of parts . . . . . . . . . . 105
8.5 Replacing the device fuses . . . . . . . . . . . . . 106
8.6 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
9 Accessories . . . . . . . . . . . . . . . . . . . . . . 107
10 Technical data . . . . . . . . . . . . . . . . . . . 110
10.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
10.2 Output parameters . . . . . . . . . . . . . . . . . . . . 111
10.3 Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
10.4 Ambient conditions . . . . . . . . . . . . . . . . . . . 113
10.5 Mechanical data . . . . . . . . . . . . . . . . . . . . . 113
11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . 115
11.1 Operating matrix . . . . . . . . . . . . . . . . . . . . . 115
11.2 Wiring examples . . . . . . . . . . . . . . . . . . . . . 128
11.3 Buffer tables . . . . . . . . . . . . . . . . . . . . . . . . . 131

1 Safety instructions Mycom S CPM 153
4Endress+Hauser
1 Safety instructions
1.1 Safety symbols
To avoid damage to persons and property, always pay attention to the safety instruc-
tions in these Operating Instructions. The following symbols are used to provide you
with important information:
General
safety instructions
Electrical symbols
Symbol Meaning
#
Warning!
This symbol alerts you to hazards which could cause serious injuries as well as
damage to the instrument if ignored.
"
Caution!
This symbol alerts you to possible faults which could arise from incorrect ope-
ration. They could cause damage to the instrument if ignored.
!
Note!
This symbol indicates important items of information.
Symbol Meaning
%
DC voltage
A terminal at which DC voltage is applied or through which DC flows.
&
AC voltage
A terminal at which (sine-form) AC voltage is applied or through which AC
flows.
)
Ground connection
A grounded terminal, which, from the user’s point of view, is already grounded
using a ground system.
*
Protective earth terminal
A terminal which must be grounded before other connections may be set up.
+
Equipotential connection
A connection which must be connected to the grounding system of the equip-
ment. This can be, for example, a potential matching line of a star-shaped
grounding system, depending on national or company practice.
/
Double insulation
The equipment is protected with double insulation.
b
Alarm relay
Input
Output

Mycom S CPM 153 1 Safety instructions
Endress+Hauser 5
1.2 Designated use
The transmitter Mycom S CPM 153 is a measuring instrument for measurement pH
value or redox potential. The transmitter is designed for measuring or control tasks in
applications in the following industries:
•Chemical process systems
•Pharmaceuticals
•Foodstuffs
•Water conditioning and monitoring
•Wastewater treatment
•Sewage treatment plants
•Drinking water
The Ex version of the Mycom S CPM 153 allows operation even in hazardous areas
(refer to "Approvals" in the product structure on page 7).
The manufacturer is not liable for damage caused by improper use or use other than
that for which it is intended.
1.3 Installation, commissioning and operation
Note the following points:
•If the transmitter is used improperly or other than for its designated use, it may pose
a hazard, e.g. due to improper connection.
•Installation, electrical connection, start-up, operation and maintenance of
the measuring system must therefore be carried out exclusively by trained specialists
authorised by the system operator.
•Technical personnel must have read and understood these operating instructions and
must adhere to them.
•Always follow the regulations in your country pertaining to the opening
and repairing of electrical instruments.

1 Safety instructions Mycom S CPM 153
6Endress+Hauser
1.4 Operational safety
#
Warning!
If the device is used for any application other than those described in these Operating
Instructions, it may lead to unsafe and improper functioning of the measuring system
and is therefore not permitted.
The instrument has been designed and tested according to the state of the art and left
the factory in perfect functioning order. The instrument meets all the prevailing
regulations and EC directives - see "Technical data".
However, always pay attention to the following points:
•Measuring systems used in Ex areas have a separate document (XA 236C/07/en)
which forms a component part of these Operating Instructions. Always follow the
installation regulations and the - partly deviating - connection data of the Ex documen-
tation as well. You can find the following symbols on the front page of the additional
Ex documentation (according to approval and test centre
(
0 Europe, 2 USA, 1 Canada).
•The measuring device complies with the general safety requirements in accordance
with EN 61010, the EMC requirements of EN 61326, and NAMUR Recommendation
NE 21, 1998.
•The manufacturer reserves the right to change the technical data in line with technical
progress at any time. You can obtain information on the current version of these
Operating Instructions and possible additions from your E+H sales centre.
1.4.1 Fail-safety
This instrument has been checked for protection against electromagnetic interference
in industrial use according to applicable European standards. It is protected against
electromagnetic interference by the following design measures:
•cable screening
•interference suppression filter
•interference suppression capacitors
#
Warning!
Protection against interference as specified above is valid only for an instrument
connected according to the instructions in these Operating Instructions.
1.5 Return
If the transmitter has to be repaired, please return it cleaned to the E+H sales centre
responsible. You can find the address on the last page of these instructions. For returns
please use the original packaging.
With the instrument, please enclose a completed copy of the "Declaration of
Contamination" form. You can find this at the end of these Operating Instructions.

Mycom S CPM 153 2 Identification
Endress+Hauser 7
2 Identification
2.1 Instrument designation
2.1.1 Product structure
pH/redox transmitter in aluminium housing for wall mounting with one alarm and two
output contacts for NAMUR, ChemoClean, and controller functions as well as three
binary inputs, logbooks, data logger. Plain text operation. 247x167x111 mm (HxWxD).
Degree of protection IP 65.
Approvals
A Basic equipment: non-Ex
G With Atex 100a approval, Atex II (1) 2G EEx em ib[ia] IIC T4
O With FM approval; NI Cl. I, Div. 2
P With FM approval; NI Cl. I, Div. 2, Sensor IS Cl. I, Div. 1
S With CSA approval; NI Cl. I, Div. 2, Sensor IS Cl. I, Div. 1
T With TIIS approval
Sensor input
1 1 measuring circuit for glass electrodes, pH/redox and temperature
2 1 measuring circuit for glass electrodes/IsFET pH sensors, pH/redox and temperature
3 2 measuring circuits for glass electrodes, pH/redox and temperature
4 2 measuring circuits for glass electrodes/IsFET pH sensors, pH/redox and temperature
Measurement output
A 2 current outputs 0/4 ... 20 mA, passive (Ex and non-Ex)
B 2 current outputs 0/4 ... 20 mA, active (non-Ex)
C HART with 2 current outputs 0/4 ... 20 mA, passive (Ex and non-Ex)
D HART with 2 current outputs 0/4 ... 20 mA, active (Ex and non-Ex)
E PROFIBUS-PA, without current outputs
Contacts, current input
0 Without additional contacts
1 Three additional contacts
2 2 additional contacts, 1 passive current input (Ex and non-Ex)
3 2 additional contacts, 1 resistance input (non-Ex)
4 1 additional contact1, 2 passive current inputs (Ex and non-Ex)
5 1 extra contact, 1 passive current input, 1 active resistance input (only non-Ex)
Power supply
0 100 ... 230 V AC
8 24 V AC / DC
Language versions
A E / D
B E / F
C E / I
D E / ES
E E / NL
F E / J
Cable connection
0 Cable glands M 20 x 1.5
1Adapter for cable gland NPT ½"
3 Cable glands M 20 x 1,5, PROFIBUS-PA M12 plug
4 Cable glands NPT 1/2", PROFIBUS-PA M12 plug
Additional equipment
0Without additional equipment
1Additional equipment: DAT module
Configuration
0 Factory settings
CPM 153- Complete order code

2 Identification Mycom S CPM 153
8Endress+Hauser
2.1.2 Nameplate
2.2 Scope of delivery
Check the scope of delivery using your order and the delivery documents for:
•Completeness
•Instrument type and version acc. to the nameplate (see Chap. 2.1.2)
•Accessories (see Chap. 9)
•Operating Instructions BA 233C/07/en (for Ex-system also the XA 233C/07/a3)
•Instrument identification card
2.3 Certificates and approvals
Declaration of Conformity
The transmitter complies with the legal demands of the harmonized European stan-
dards. Endress+Hauser certifies the compliance with the standards by using the
4
sign.
Fig. 1: Example for a nameplate of the transmitter Mycom S CPM 153.

Mycom S CPM 153 3 Installation
Endress+Hauser 9
3Installation
3.1 Incoming acceptance, transport, storage
•Make sure the contents are undamaged! If any damage is found, inform your postal
service, freight handler or forwarding agent. Keep any damaged goods until matters
have been clarified.
Check that the scope of delivery is complete.
•For storage and transport purposes, pack the instrument so that it is protected against
impacts and humidity. The original packaging offers the best protection. Also, keep to
the approved ambient conditions (see "Technical data").
•If you have any questions, please contact your supplier or your nearest
Endress+Hauser sales centre (see the back page of these Operating Instructions).
3.2 Installation conditions
3.2.1 Installation dimensions
You can find the dimensions and length of the transmitter in the
"Technical data" on page 110 ff.
3.3 Installation
3.3.1 Installation instructions
•The standard installation method for the CPM 153 transmitter is as a field instrument.
•The CPM 153 transmitter can be fixed to vertical or horizontal posts using the round
post fixture available from Endress+Hauser (see "Accessories"). When installing the
instrument outdoors, you also require the weather protection cover CYY 101. This
cover is compatible with all field instrument installations options.
•Always mount the transmitter horizontally so that the cable entries point downwards.
•The transmitter can be installed as a panel-mounted unit as well.
3.3.2 Wall mounting
"
Caution!
•Check that the temperature does not exceed the maximum permitted operating
temperature range (–20°... +60°C). Install the instrument in a shady location. Avoid
direct sunlight.
•Mount the wall mounting housing so that the cable entries always point downwards.

3 Installation Mycom S CPM 153
10 Endress+Hauser
Fig. 2: Dimensions for wall mounting: Fixing screw: ø 6 mm
Wall plug: ø 8 mm
1: Fixing drill holes
2: Plastic cover cap
For the wall mounting of the transmitter proceed as follows:
1. Prepare drill holes acc. to Fig. 2.
2. Push both fixing screws through the appropriate fixing drill holes ➀.
–Fixing screws (M6): max. Ø6.5 mm
–Screw head: max. Ø10.5 mm
3. Mount the transmitter housing on the wall as shown.
4. Cover the drill holes with the plastic cover caps ➁.
3.3.3 Post mounting and panel mounting
Mount the parts of the mounting kit (see
accompanying figure) at the back of the
housing as depicted in Fig. 4.
Required mounting cutout:
161 x 241 mm
Installation depth: 134 mm
Pipe diameter: max. 70 mm
Fig. 3: Mounting kit Mycom S CPM 153
154
100
247
142
167
∅8
2
C07-CPM153xx-11-00-08-xx-001.EPS
1

Mycom S CPM 153 3 Installation
Endress+Hauser 11
Fig. 4: Panel mounting ➀and post mounting for CPM 153, horizontal ➁and vertikal ➂
"
Caution!
Danger of instrument damage.
For outdoor use, the CYY 101 weather protection cover is required (see Fig. 5 and
"Accessories").
Fig. 5: Post mounting of the transmitter CPM 153 with weather protection cover CYY 101.
3.4 Checking the installation
After installing the transmitter, carry out the following checks:
➀➁➂
C07-CPM153xx-11-00-08-xx-003.EPS
80
80
ø 70
Instrument status and specifications Remarks
Is the transmitter damaged? Visual inspection
Installation Remarks
Are the measuring point number and the labelling correct? Visual inspection
Process environment/conditions Remarks
Is the transmitter protected against rainfall and direct
sunlight?
For outdoor installation, the weather
protection cover CYY 101 is required
(see "Accessories").
C07-CPM153xx-11-00-01-xx-001.EPS

4 Electrical connection Mycom S CPM 153
12 Endress+Hauser
4 Electrical connection
4.1 Quick wiring guide
4.1.1 Wiring diagram
Fig. 6: Electrical connection for CPM 153
mA
mA
15 V
E1
ext. Hold
E2
ChemoClean
"Clean"
E3
ChemoClean
"User" 



S
S
S
S
11
11
11
11
12
12
13
13
13
13
n.c.
n.c.
pH
pH
Ref.
Ref.
Ref.
Ref.
n.c.
n.c.
SRC
SRC
DRN
DRN
PA/
PM
PA/
PM
PA/
PM
PA/
PM
Temp. 1
Temp. 2
Temp. 1
Temp. 2




S
A
B
bn
wt
gn
ye
Alarm relay
Relay 1
Relay 2
Relay 3
Relay 4
Relay 5
Relay 3
Relay 4
Relay 3
Current input 1
or
resistance
input2, 3
Current input 24Power supply
RS 485
12V DC
Current output 2
Current output 1
+
–
C07-CPM153xx-04-06-00-en-001.EPS
89
85
41
51
51
51
47
54
54
21
57
44
21
23
93
81
90
86
42
52
52
52
48
55
55
22
58
45
22
24
94
82
N/L–
PE
L/L+
+
+
+
Power supply
output
Current input
or
resistance
input2, 3
31
32
33
34
+
-
-
+
-
+
+
-
+
-
For order variant 11
For order variant 2, 3
1
For order variant 4, 5
1
)
1
2
3
4
: Current input 1 / resistance input for position feedback.
: Current input 2 for look-ahead measurement / feed forward control.
:
:
You can find variants 1 to 5 under "Contacts, current input" in the Product structure.
Resistance input only with non-Ex and without galvanic isolation.
TopCal S /
TopClean S
pH electrode 1 or
pH electrode 2 or
IsFET pH sensor 1
IsFET pH sensor 2 (optional)

Mycom S CPM 153 4 Electrical connection
Endress+Hauser 13
#
Warning!
A mains disconnecting device must be installed near the instrument and must be
identified as the mains disconnection device for the Mycom S CPM 153
(see EN 61010-1).
!
Note!
Connect unused signal wires from input and output lines to the internal PE rail of the
CPM 153.
4.1.2 Connection sticker
Connections in the connection compartment
Fig. 7: Connection compartment sticker (you will find it in the connection compartment of the transmitter)
DRN = Drain
SCR = Source
REF = Reference
CPM153
Stromausgang / current out / Hart
zusammengehörige
Klemmen /
combined clamps
non EXEX
135042-0001-4B
E1: ext.Hold
15V 9mA
E2: CC "Clean"
E3: CC "User"
F
L
N F
Relay contact 2
Relay contact 1
Alarm contact
I1: 0-20mA / Hart
I2: 0-20mA
CPC RS485
CPC Supply
Glaselektrode / glass electrode IsFET Kontakte, contacts, order code.Best.-Variante /
-..1.. -..2.. -..3.. -..4.. -..5..
51 23 21
2252 24
+
-
+
-
Relay contact 3
4-20mA
0 - 1 /10kkΩΩ
51 23 21
2252 24
+
-
+
-
Relay contact 3
4-20mA
4-20mA
51 54 21
2252 55
+
-
Relay contact 3
Relay contact 4
4-20mA
51 54 21
2252 55
+
-
Relay contact 3
Relay contact 4
0 - 1 /10kkΩΩ
51 54 44
4552 55
Relay contact 3
Relay contact 4
Relay contact 5
Kanal / channel 1 Kanal / channel 1Kanal / channel 2 Kanal / channel 2
PH REF PA 12 13 11 S PH REF PA 12 13 11 S DRN SRC REF PA 12 13 11 S REF PA 12 13 11 S DRN SRC
Pt100 / Pt1000
weiß / white
gelb / yellow
grün/green
braun / brown
PA
11
12
13
Koax / coax
REF
pH/mV
()gelb / yellow
grün/green
braun / brown
PA
11
12
13
Pt1000
rot/red
DRN
Koax / coax
REF
SRC
weiß / white

4 Electrical connection Mycom S CPM 153
14 Endress+Hauser
Connections in the front cover
Fig. 8: Terminal assignment in the housing cover of the transmitter
Connections in the back cover
Fig. 9: Terminal assignment in the lower housing section of the transmitter
4.1.3 Contact assignment
In the basic version, the Mycom S CPM 153 possesses 1 alarm and 2 additional
contacts. The instrument can be upgraded with the following additional equipment:
•3 contacts
•2 contacts and 1 current or resistance input (only for non-Ex)
•1 contact, 1 current input and 1 current or resistance input (only for non-Ex)
The available contacts can be assigned via the software (see the "PARAM" menu ➞ "Set
up 1" ➞ "Contacts" from page 36)
!
Note!
•If you use NAMUR contacts (acc. to recommendations of process control engineering
of the chemical and pharmaceutical industry), the contacts are set to the relays as
follows:
–Failure to "ALARM"
–Maintenance required to "RELAY 1" and
–Function check to "RELAY 2".
•You can assign up to three relays to the controller.
pH
DRN DRNSRC SRC
pH RefRef
Ref Ref
1212
12 12
1313
13 1311
11
11
11
S
S
S
S
PAPA
PA PA
C H A N N E L 1 C H A N N E L 2
C07-CPM153xx-04-06-00-en-007
For
pH glass electrode:
For
IsFET pH sensor:
31 85 41
L
32 86 42
A93 57
n.c.
B94 58
33 81 47
N
34 82 48
L+ 89
L– 90
C07-CPM153xx-04-06-00-xx-006
Selection by software NAMUR on NAMUR off
ALARM Failure Alarm
RELAY 1 Warning when
maintenance
required
freely selectable
RELAY 2 Function check freely selectable

Mycom S CPM 153 4 Electrical connection
Endress+Hauser 15
4.2 Sensor connection and measuring cable
4.2.1 Cable types
You require a screened special cable to connect pH and redox electrodes. You can use
the following multicore and preterminated cable types:
•CPK 1 for electrodes without Pt 100
•CPK 6 for:
–Sensopac with double reference electrode
–1 pH individual electrode, 1 reference electrode, 1 Pt 100
–2 pH combination electrodes with 1 Pt 100 or
2 pH combination electrodes with 1 shared reference electrode
•CPK 9 for electrodes with TOP 68 plug-in heads (ESA / ESS) and Pt 100
•CPK 12 for IsFET pH sensors and pH/redox glass electrodes with TOP 68 plug-in
heads (ESB) and Pt 100 / Pt 1000
Fig. 10: Preterminated special measuring cables to connect pH and redox electrodes.
Pt 100
Pt
1000
d.n.c.
CPK 1
Outer screen PA
Ref.
pH / Redox
bn
Coax bk
PA
pH / Redox
Temp. (pin 13)
bn
Temp. (pin 11)
Temp. (pin 12)
PAbk
pH for circuit 2
pH for circuit 1
wt
Coax rd
Ref. 2
Ref. 1
wt
Coax wt
gn
wt
PA bk
PC ye/gn
Outer screen
pH
Ref.
Pt 100
CPK 6-S
Application:
Sensopac
CPA 320 with
double reference
electrode
Temp. (- - -) 13 - - -
bn
Temp. (Ref.) 11 (Ref.) - - - (Ref.)
Temp. (- - -) 12 - - -
PA PA - - -
Signal Slot 1
FCP1 (1)
Slot 2
FCP1 (2)
Remove from PA, attach end sleeve
pH 1 pH/mV - - -
remove
Ref. 1 Ref. - - -
Ref. 2 Ref. - - -
pH 2 - - - pH/mV
bk
rd
gn
wt
Coax wt
Coax wt
Coax rd
Coax wt
PA bk
rd
wt
gn
wt
PE ye/gn
Outer screen: ground via metal cable union
or connect to PE
Ye/gn is connected
to outer screen
Unter sleeve, wt
connected to bn
(alternative: reference electrode)
Application:
2 pH combination
electrodes
and 1 Pt 100 or
2 pH combination
electrodes
and 1 common
reference electrode
pH 1
pH 2
Pt 100
CPK 6-A
1
2
3
Tem p .
bn
Tem p .
Tem p .
PA
pH
remove
Screen to 0 V (PA)
Ref.
bk
gn
wt
wt
Coax wt
Coax rd
wt
PA bk
rd
wt
gn
wt
PC ye/gn Outer screen: ground via metal cable union
or connect to PE
Ye/gn is connected
to outer screen
Under sleeve,
wt connected to bn
Application:
1 pH single
electrode,
1 reference
electrode and
1 Pt 100
pH
Ref.
Pt 100
CPK 6-D
1
2
3
CPK 9
for pH/redox elec-
trodes with and without
integrated temperature
sensor (for TOP 68
plug-in heads ESA/ESS)
CPK 12
for IsFET pH sensors
and pH/redox glass
electrodes with
and without integrated
temperature sensor
(for TOP 68 plug-in heads
ESA/ESS)
PA
PA
pH/
Redox
+Pt 100
pH/
Redox
+Pt 100/
Pt 1000
PA
Ref.
pH
bn
bn
ye
ye
gn
gn
rd
Coax bk
Coax bk
wt
wt
Pt 100
C07-CPM153xx-00-06-08-en-001.EPS
source pH
IsFET Glass el.
reference reference
drain
PA PA

4 Electrical connection Mycom S CPM 153
16 Endress+Hauser
4.2.2 Changing the pH input from glass electrode to IsFET
sensor
With this device you can run the electrode types glass electrode / redox electrode or
IsFET sensors.
For adapt the electrical connection from glass electrodes to IsFET sensor CPS 401,
please proceed as follows:
1. Open housing cover of the CPM 153.
2. Pull off both ends of the red line to the pH input (s. Fig. 29, p. 105; line to
position 130).
3. Pin up the jumper on the back sides of the included terminals "DRN" and "SRC".
4. Remove the "pH" terminal out of the transmitter and replace it by the terminals
"DRN" and "SRC".
5. Change the setting "electrode type" in the Quick Setup menu (p. 27) to "IsFET".
!
Note!
Please switch from IsFET sensor to glass electrode correspondingly.
4.2.3 Outer screen connection
"
Caution!
Danger of inaccuracy.
Always protect plugs and terminals against humidity.
Fig. 13: Outer screen connection for CPK 1 to CPK 12 with metal cable gland. The
screen contact is within the cable gland.
ƒig. 11: Cable (red) for connection of
pH / Redox glass electrodes.
ƒig. 12: Jumper for connection of IsFET sensor
TopHit H CPS 401

Mycom S CPM 153 4 Electrical connection
Endress+Hauser 17
4.2.4 Cable extension
If a cable extension is necessary, use
•junction box VBM
and the following types of non-terminated measuring cables:
•for CPK 1, CPK 9: Cable CYK 71
•for CPK 6: Cable DMK
•for CPK 12: Cable CYK 12
4.2.5 Symmetrical or unsymmetrical electrode connection
!
Note!
The instrument is preset for symmetrical measurement (= with PML, potential matching
line). For unsymmetrical measurement, the setting must be changed accordingly (s.
page 32, Field A6, "Select connection type")..
Fig. 14: Left: symmetrical electrode connection
Right: unsymmetrical electrode connection
! Note!
With all cable types, the inner coaxial
cable has a black, plastic, semi-
conductor layer (arrow), which you
must remove.
C07-CPC300xx-04-12-00-xx-007.EPS
ϑϑ
PA
PA PA
pH /
mV
pH /
mV
pH /
mV
IsFET IsFET
11
11 11
1213 13
13 pH Ref.
Ref. Ref.
PA
pH /
mV
11 12 13 pH Ref.
) ) ) )
A AAA
B BBB
))) )
SRC SRCDRN DRN
IsFET CPS 401 IsFET CPS 401
ϑ ϑ
Glass electrodes Glass electrodes
C07-CPM153xx-00-06-08-en-003.EPS
symmetrical unsymmetrical
gn
wt
bn
gn
wt
ye
bn
rd
gn
wt
bn
rd
gn
wt
ye
bn

4 Electrical connection Mycom S CPM 153
18 Endress+Hauser
Symmetrical (with PML) Unsymmetrical (without PML)
" Caution!
With a symmetrical connection, the line
to the potential matching pin (PML) must
be connected to the potential matching
terminal of the instrument. The PML must
always be in contact with the medium,
i.e. immersed in the buffer solution
during calibration.
If the instrument input is unsymmetrical,
pH measuring chains connected to
assemblies can be connected without
an additional potential matching pin.
If necessary, connect the available
potential matching pin to terminal PE.
Benefit of symmetrical connection
Measurement is easier under difficult
ambient conditions (e.g. strongly flowing
or high-impedance media or partially
soiled diaphragm).
Disadvantage of unsymmetrical
connection
The measuring chain reference system
has a heavier load, meaning that measu-
ring errors in limiting operating conditi-
ons are possible (see symmetrically
high-resistance instrument input).
Monitoring of the reference electrode by
the SC system (s. page 52) is not pos-
sible with unsymmetrical measurement.
" Note!
Do not connect the PML, otherwise there
can be shunt excitations.

Mycom S CPM 153 4 Electrical connection
Endress+Hauser 19
4.3 Post connection check
After wiring up the electrical connection of the measuring instrument, carry out the
following checks:
Instrument status and specifications Note
Is the measuring instrument or the cable damaged externally? Visual inspection
Electrical connection Notes
Does the supply voltage match the specifications on the
nameplate?
100 V ... 230 V AC long-range
24 V AC / DC
Do the cables used fulfil the required specifications? Use an original E+H cable for
electrode and sensor connec-
tion, see "Accessories".
Are the installed cables strain-relieved?
Is the cable type route completely isolated? Along the whole cable length,
run the power supply and signal
line cables separately to avoid
any mutual influence. Cable
channels are best.
No loops and cross-overs in the cable run?
Are the power supply and signal cable correctly connected
according to the wiring diagram?
Are all the screw terminals tightened?
For connection with potential matching (PML):
Is the PML connected to the measuring medium?
! Note!
During calibration, insert the
PML into the buffer solution.
Are all the cable entries installed, tightened and sealed?
Cable run with "water sag"?
"Water sag": cable circuit han-
ging down so that water can drip
off.
Are all the housing covers installed and tightened? Check seals for damage.

5 Operation Mycom S CPM 153
20 Endress+Hauser
5 Operation
5.1 Display and operating elements
5.1.1 Display reading/symbols
Mycom S CPM 153 user interface
1: Current menu
2: Current parameter
3: Navigation bar: Arrow keys for scrolling, "E" for browsing, note for Cancel
4: "MEAS" (Operation) key
5: "CAL" (Calibration) key
6: "DIAG" (Diagnosis menu) key
7: "PARAM" (Parameter entry menu) key
? = Press DIAG and PARAM simultaneously to open the help pages
8: HOLD display, if HOLD active
9: Current main measured value
10: "Failure" display, "Warning", if the NAMUR contacts respond
11: Labelling strip
12: Arrow keys for scrolling and editing
13: ENTER key
5.1.2 Key assignment
"PARAM" brings you to the Configuration menu of the Mycom S CPM 153.
! Note!
"PARAM" allows you to return to the previous "return field" from any point in the menu.
These are marked in bold in the menu overview (see Chap. 11.1).
LED: This is the send LED for the service adapter "Optoscope" (see "Accessories").
"DIAG" brings you to the instrument diagnosis menu.
LED: This is the receive LED for the service adapter "Optoscope" (see "Accessories").
Help:
Press the "DIAG" and "PARAM" keys simultaneously to open the help page.
MYCOM S CPM 153
ENDRESS+HAUSER
MEAS CAL
DIAG PARAM
1
2
3
9
10
4
5
12
13
6
11
7
8
?
7.54
pH
HOLD
Measure
Off
Select
Temperature25.0°C
C07-CPM153xx-19-06-00-en-002.EPS
