Brief Operating Instructions
iTEMP TMT86
Dual-input temperature transmitter
PROFINET® protocol
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
For detailed information, refer to the Operating Instructions
and other documentation.
Available for all device versions via:
• Internet: www.endress.com/deviceviewer
• Smart phone/Tablet: Endress+Hauser Operations App
KA01529T/09/EN/01.21-00
71562442
2021-11-30

iTEMP TMT86
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

iTEMP TMT86 Table of contents
Endress+Hauser 3
Table of contents
1 About this document .............................................................. 3
1.1 Symbols used ......................................................................... 3
1.2 Tool symbols ..........................................................................4
1.3 Registered trademarks .................................................................. 4
2 Safety instructions ................................................................ 4
2.1 Requirements for personnel .............................................................. 4
2.2 Intended use .......................................................................... 5
2.3 Workplace safety ...................................................................... 5
2.4 Operational safety ......................................................................5
2.5 Product safety ......................................................................... 5
2.6 IT security ............................................................................ 5
3 Incoming acceptance and product identification ................................... 6
3.1 Incoming acceptance .................................................................... 6
3.2 Product identification ................................................................... 6
3.3 Certificates and approvals ................................................................ 7
3.4 Storage and transport ................................................................... 7
4 Installation ....................................................................... 7
4.1 Mounting requirements ................................................................. 7
4.2 Mounting the measuring device ............................................................8
4.3 Post-mounting check ................................................................... 9
5 Electrical connection .............................................................. 9
5.1 Connection requirements ................................................................ 9
5.2 Connecting the measuring device ......................................................... 10
5.3 Connecting the sensor cables ............................................................. 12
5.4 Ensuring the degree of protection ......................................................... 14
5.5 Post-connection check ..................................................................15
6 Operation options ............................................................... 16
6.1 Overview of operation options ............................................................ 16
6.2 Access to operating menu via web browser .................................................. 18
6.3 Access to the operating menu via operating tools .............................................. 18
7 Commissioning .................................................................. 18
7.1 Post-installation check ................................................................. 18
7.2 Switching on the device ................................................................. 18
7.3 Configuring the device ................................................................. 18
8 Maintenance .................................................................... 19
1 About this document
1.1 Symbols used
1.1.1 Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.

Safety instructions iTEMP TMT86
4 Endress+Hauser
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2 Tool symbols
Symbol Meaning
A0011219
Phillips head screwdriver
1.3 Registered trademarks
PROFINET®
Registered trademark of the PROFIBUS User Organization, Karlsruhe, Germany
2 Safety instructions
2.1 Requirements for personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Personnel must be authorized by the plant owner/operator.
‣Be familiar with federal/national regulations.
‣Before starting work: personnel must read and understand the instructions in the manual
and supplementary documentation as well as the certificates (depending on the
application).
‣Personnel must follow instructions and comply with general policies.
The operating personnel must fulfill the following requirements:
‣Personnel are instructed and authorized according to the requirements of the task by the
facility's owner-operator.
‣Personnel follow the instructions in this manual.

iTEMP TMT86 Safety instructions
Endress+Hauser 5
2.2 Intended use
The device is a universal and user-configurable temperature transmitter with either one or
two sensor inputs for a resistance thermometer (RTD), thermocouples (TC), resistance and
voltage transmitters. The head transmitter version of the device is intended for mounting in a
terminal head (flat face) as per DIN EN 50446. The device is also optionally available in a
version that is integrated into a field housing. It is also possible to mount the device on a DIN
rail using the optional DIN rail clip.
If the device is used in a manner not specified by the manufacturer, the protection provided by
the device may be impaired.
The manufacturer is not liable for damage caused by using the device incorrectly or for
purposes for which it was not intended.
2.3 Workplace safety
When working on and with the device:
‣Wear the required personal protective equipment as per national regulations.
2.4 Operational safety
‣Operate the device only if it is in proper technical condition, free from errors and faults.
‣The operator is responsible for ensuring trouble-free operation of the device.
Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the hazardous
area (e.g. explosion protection or safety equipment):
‣Based on the technical data on the nameplate, check whether the ordered device is
permitted for the intended use in the hazardous area. The nameplate can be found on the
side of the transmitter housing.
‣Observe the specifications in the separate supplementary documentation that is an integral
part of these instructions.
Electromagnetic compatibility
The measuring system complies with the general safety requirements and EMC requirements
of the IEC/EN 61326 series and the APL EMC Test Specification.
2.5 Product safety
This product is designed in accordance with good engineering practice to meet state-of-the-
art safety requirements and has been tested and left the factory in a condition in which it is
safe to operate.
2.6 IT security
Our warranty is valid only if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any
inadvertent changes to the settings.

Incoming acceptance and product identification iTEMP TMT86
6 Endress+Hauser
IT security measures, which provide additional protection for the device and associated data
transfer, must be implemented by the operators themselves in line with their security
standards.
3 Incoming acceptance and product identification
3.1 Incoming acceptance
1. Unpack the temperature transmitter carefully. Are the contents or packaging
undamaged?
 Do not install damaged components, as otherwise the manufacturer cannot
guarantee the material resistance or ensure compliance with the original safety
requirements, and therefore cannot be held responsible for any resulting damage.
2. Is the delivery complete or is anything missing? Check the scope of delivery against your
order.
3. Does the nameplate match the order information on the delivery note?
4. Are the technical documentation and all other necessary documents provided? If
applicable: are the Safety Instructions (e.g. XA) for hazardous areas provided?
If one of these conditions is not met, please contact the manufacturer's sales office.
3.2 Product identification
The following options are available for identification of the device:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
• Enter the serial number from the nameplate in the W@M Device Viewer
(www.endress.com/deviceviewer): all data relating to the device and an overview of the
Technical Documentation supplied with the device are displayed.
• Enter the serial number on the nameplate into the Endress+Hauser Operations App or scan
the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations App:
all the information about the device and the technical documentation pertaining to the
device is displayed.
Approval in hazardous areas: Ensure that the information on the nameplate matches the
enclosed Ex documentation (XA...).
3.2.1 Name and address of manufacturer
Name of manufacturer: Endress+Hauser Wetzer GmbH + Co. KG
Model/type reference: TMT86
Address of manufacturer: Obere Wank 1, D-87484 Nesselwang or www.endress.com

iTEMP TMT86 Installation
Endress+Hauser 7
3.3 Certificates and approvals
For certificates and approvals valid for the device: see the data on the nameplate
Approval-related data and documents: www.endress.com/deviceviewer → (enter the
serial number)
3.4 Storage and transport
Storage temperature: –52 to +100 °C (–61.6 to +212 °F)
Humidity
• Condensation permitted with head transmitter
• Max. rel. humidity: 95 % as per IEC 60068-2-30
Pack the device for storage and transportation in such a way that it is reliably protected
against impact and external influences. The original packaging provides optimum
protection.
Avoid the following environmental influences during storage and transport:
• Direct sunlight
• Vibration
• Aggressive media
4 Installation
4.1 Mounting requirements
4.1.1 Mounting location
Head transmitter:
• in the terminal head, flat face, as per DIN EN 50446, direct mounting on insert with cable
entry (middle hole 7 mm)
• in the field housing, separated from the process
• with DIN rail clip on DIN rail as per IEC 60715, TH35
For use in hazardous areas, the limit values specified on the certificates and approvals must be
observed (see Ex Safety Instructions).
4.1.2 Important ambient conditions
• Operating height: up to 4000 m (4374.5 yards) above mean sea level
• Overvoltage category: overvoltage category II
• Pollution degree: 2
• Insulation class: class III
• Ambient temperature: –40 to +85 °C (–40 to 185 °F);
Optional –50 to +85 °C (–58 to 185 °F), –52 to +85 °C (–61.6 to 185 °F)
• Head transmitter climate class: C1 (–5 to +45 °C (23 to 113 °F), 5 to 95 % r.h.) as per IEC
60654-1

Installation iTEMP TMT86
8 Endress+Hauser
• Condensation permitted with head transmitter
• Max. rel. humidity: 95 % as per IEC 60068-2-30
• Degree of protection:
• Head transmitter with screw terminals: IP00, with push-in terminals: IP30. When
installed, the degree of protection depends on the terminal head or field housing used.
• When installing in field housing TA30x: IP IP66/68 (NEMA Type 4x encl.)
4.2 Mounting the measuring device
A Phillips head screwdriver is required to mount the device:
• Maximum torque for securing screws = 1 Nm (¾ foot-pound), screwdriver: Pozidriv Z2
• Maximum torque for screw terminals = 0.35 Nm (¼ foot-pound), screwdriver: Pozidriv Z1
4.2.1 Head transmitter mounting
1
2
3
4
5
6
7
9
8
1 2 3 4 5 1234
120 mm
(4.72 in)
120 mm
(4.72 in)
Item A Item B
Item C
A0048481
 1 Head transmitter mounting (three versions)

iTEMP TMT86 Electrical connection
Endress+Hauser 9
Mounting typical of North America
12 3 456
A0008520
 2 Head transmitter mounting
NOTICE
The terminal head cover must be secured properly to meet the requirements for
explosion protection.
‣After wiring, securely screw the terminal head cover back on.
4.3 Post-mounting check
After installing the device, run the following final checks:
Device health and specifications Notes
Is the device undamaged (visual inspection)? -
Do the ambient conditions match the device specification (e.g. ambient temperature,
measuring range, etc.)?
→  7
5 Electrical connection
5.1 Connection requirements
A Phillips head screwdriver is required to wire the head transmitter with screw terminals. No
tools are required for the version with push-in terminals.

Electrical connection iTEMP TMT86
10 Endress+Hauser
LCAUTION
‣Switch off the power supply before installing or connecting the device. Non-compliance
may result in the destruction of parts of the electronics.
‣When connecting Ex-certified devices, please take special note of the instructions and
connection schematics in the Ex-specific supplement to these Operating Instructions.
‣Do not occupy the display connection. An incorrect connection can destroy the electronics.
‣Before connecting the power supply, connect the potential equalization line to the external
ground terminal.
‣The device may only be powered by a power unit with an energy-limited circuit in
accordance with UL/EN/IEC 61010-1, Section 9.4 and the requirements of Table 18.
5.2 Connecting the measuring device
Head transmitter:
A
C
RD
WH
B
1+
2-
7
6
5
4
3
RD (BK)
WH (YE)
D
E
F
1
2
A0046019
 3 Assignment of terminal connections for head transmitter
A Sensor input 1, RTD and Ω, 4-, 3- and 2-wire
B Sensor input 1, TC and mV
C Sensor input 2, RTD and Ω, 3- and 2-wire
D Sensor input 2, TC and mV
E Display connection, service interface
F Bus terminator and power supply
NOTICE
‣ ESD - Electrostatic discharge. Protect the terminals from electrostatic discharge. Non-
compliance may result in the destruction or malfunction of parts of the electronics.
5.2.1 Fieldbus connection
Devices can be connected to the fieldbus in two ways:

iTEMP TMT86 Electrical connection
Endress+Hauser 11
• via conventional cable gland →  11
• via fieldbus device connector (optional, available as an accessory)
Risk of damage
• Switch off the power supply before installing or connecting the head transmitter. Non-
compliance may result in the destruction of parts of the electronics.
• Grounding via one of the grounding screws (terminal head, field housing) is
recommended.
• If the shielding of the fieldbus cable is grounded at more than one point in systems
without additional potential equalization, mains-frequency equalizing currents may
occur and cause damage to the cable or shielding. In such cases, the shielding of the
fieldbus cable should be grounded on one side only, i.e. it must not be connected to the
ground terminal of the housing (terminal head, field housing). The shield that is not
connected should be insulated!
• We recommend that the fieldbus not be looped using conventional cable glands. If you
replace even just one measuring device at a later date, the bus communication will
have to be interrupted.
Cable glands or entries
Please also follow the general procedure on →  10.
2
1
3
4
5
6
A0041953
 4 Connecting the signal cables and power supply
1 Head transmitter installed in field housing
2 Head transmitter installed in terminal head
3 Terminals for fieldbus communication and power supply
4 Internal ground connection
5 External ground connection
6 Shielded fieldbus cable

Electrical connection iTEMP TMT86
12 Endress+Hauser
Terminals
Choice of screw or push-in terminals for sensor cables and supply cables. The terminals for
connecting the fieldbus (1+ and 2-) are protected against reverse polarity. A shielded cable
must be used for the connection.
Terminal design Cable design Cable cross-section
Screw terminals
(with tabs on the fieldbus terminals
for easy connection of a handheld
terminal, e.g. Field Xpert)
Rigid or flexible ≤ 2.5 mm² (14 AWG)
Push-in terminals
(cable design, stripping length = min.
10 mm (0.39 in))
Rigid or flexible 1) 0.2 to 1.5 mm² (24 to 16 AWG)
Flexible with wire end ferrules with/
without plastic ferrule
0.25 to 1.5 mm² (24 to 16 AWG)
1) In the case of push-in terminals and flexible cables with a cross-section ≤ 0.3 mm² (22 AWG), wire end ferrules
must be used.
5.2.2 Supply voltage
Connecting to an APL field switch
The device must be used in accordance with the APL port classification:
Hazardous areas: SLAA or SLAC (details in Ex safety instructions)
Non-hazardous areas: SLAX connection to an APL field switch with maximum voltage of 15
VDC and minimal output power of 0.54 W. This corresponds to an APL field switch with APL
port classification SPCC or SPAA, for example.
Connecting to an SPE switch
In non-hazardous areas, the device can be used in accordance with PoDL power class 10: The
device can be connected to an SPE switch with a maximum voltage of 30 VDC and a minimum
output power of 1.85 W. This corresponds to an SPE switch that supports PoDL power classes
10, 11 or 12, for example.
Ethernet-APL power class A (9.6 to 15 VDC, 540 mW)
Maximum power consumption: 0.7 W
The field switch must be tested to ensure that it meets safety requirements (e.g. PELV,
SELV, Class 2).
5.3 Connecting the sensor cables
Terminal assignment of sensor connections

iTEMP TMT86 Electrical connection
Endress+Hauser 13
NOTICE
When connecting 2 sensors ensure that there is no galvanic connection between the
sensors (e.g. caused by sensor elements that are not isolated from the thermowell). The
resulting equalizing currents distort the measurements considerably.
‣The sensors must remain galvanically isolated from one another by connecting each sensor
separately to a transmitter. The transmitter provides sufficient galvanic isolation (> 2 kV
AC) between the input and output.
The following connection combinations are possible when both sensor inputs are assigned:
Sensor input 1
Sensor input
2
RTD or
resistance
transmitter,
2-wire
RTD or
resistance
transmitter,
3-wire
RTD or
resistance
transmitter,
4-wire
TC, voltage
transmitter,
internal CJ
TC, voltage
transmitter,
external CJ
RTD or resistance
transmitter, 2-wire   -  -
RTD or resistance
transmitter, 3-wire   -  -
RTD or resistance
transmitter, 4-wire - - - - -
TC, voltage
transmitter,
internal CJ
    -
TC, voltage
transmitter,
external CJ
  - - 

Electrical connection iTEMP TMT86
14 Endress+Hauser
5.3.1 Connecting to push-in terminals
2.
3.
4.
5.
1.
2.
3.
AB
C
A0039468
 5 Connecting to push-in terminals
5.4 Ensuring the degree of protection
Compliance with the following points is mandatory following installation in the field or
servicing in order to ensure that IP67 protection is maintained:
• The transmitter must be mounted in a terminal head with the appropriate degree of
protection.
• The housing seals must be clean and undamaged when inserted into their grooves. The
seals must be dried, cleaned or replaced if necessary.
• The connecting cables used must have the specified external diameter (e.g. M20x1.5, cable
diameter 8 to 12 mm).
• Firmly tighten the cable gland. →  6,  15
• The cables must loop down before they enter the cable glands ("water trap"). This means
that any moisture that may form cannot enter the gland. Install the device in such a way
that the cable glands are not facing upwards. →  6,  15
• Replace unused cable glands with dummy plugs.
• Do not remove the grommet from the cable gland.

iTEMP TMT86 Electrical connection
Endress+Hauser 15
A0024523
 6 Connection tips to retain IP67 protection
5.5 Post-connection check
Device health and specifications Notes
Are the device and cables undamaged (visual check)? --
Electrical connection Notes
Does the port classification match the information on the
nameplate?
Compare the port classification with the information on
the nameplate
Do the cables used meet the required specifications? Fieldbus cable,
Sensor cable, →  12
Do the mounted cables have adequate strain relief? --
Are the power supply and signal cables correctly
connected?
→  10
Are all the screw terminals firmly tightened and have the
push-in terminal connections been checked?
→  14
Are all cable entries mounted, firmly tightened and
secure?
Cable run with "water trap"?
--
Are all housing covers installed and firmly tightened? --
Electrical connection of the fieldbus system Notes
Are all connecting components (switch, device connector,
etc.) correctly connected to each other?
--
Does the max. length of the fieldbus cable comply with the
fieldbus specifications?
For more information, see www.ethernet-apl.org
"Ethernet-APL Engineering Guideline"
Does the max. length of the APL spurs match the fieldbus
specifications?
Is the fieldbus cable fully shielded and correctly grounded?

Operation options iTEMP TMT86
16 Endress+Hauser
6 Operation options
6.1 Overview of operation options
1
5
2 43
A0048408
1 Local operation via DIP switch on display module
2 Computer with web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, SIMATIC
PDM)
3 Field Xpert SMT70
4 Control system (e.g. PLC)
5 Temperature transmitter
6.1.1 Measured value display and operating elements
For the head transmitter, display and operating elements are available locally only if the
head transmitter was ordered with a display unit!

iTEMP TMT86 Operation options
Endress+Hauser 17
Option: Display TID10 for head transmitter
The display can also be ordered later, see
the "Accessories" section in the Operating
Instructions for the device.
1. 2.
3.
A0010227
 7 Attach the display to the transmitter
Local operation
NOTICE
‣ ESD - Electrostatic discharge. Protect the terminals from electrostatic discharge. Non-
compliance may result in the destruction or malfunction of parts of the electronics.
ON
OFF
1
2
4
8
16
32
64
HW
SW
ADDR ACTIVE
SIM
WRITE LOCK
DISPL. 180°
1
2
3
A0014562
 8 Hardware settings via DIP switches
1: Connection to head transmitter
2: DIP switch
3: DIP switch functions:
ADDR ACTIVE: service IP address 192.168.1.212
SIM = simulation mode (no function);
WRITE LOCK = write protection;
DISPL. 180° = rotate the display monitor 180°
Switching write protection on/off
Write protection is switched on and off via a DIP switch on the rear of the optional attachable
display.
When write protection is active, parameters cannot be modified. A lock symbol on the
display indicates that write protection is on. Write protection remains active even when
the display is removed. To disable write protection, the display must be attached to the
transmitter with the DIP switch deactivated (WRITE LOCK = OFF). The transmitter
adopts the setting during operation and does not need to be restarted.
Turning the display
The display can be rotated 180° via a DIP switch.

Commissioning iTEMP TMT86
18 Endress+Hauser
Setting the service IP address
The service IP address can be set via a DIP switch.
6.2 Access to operating menu via web browser
The device can be operated and configured via a Web browser with the integrated Web server.
A web server is enabled when the device is delivered, but can be disabled via an appropriate
parameter. For device versions with Industrial Ethernet communication types, the connection
can be established at the signal transmission port via the network.
6.3 Access to the operating menu via operating tools
Operating tools
DeviceCare (Endress+Hauser)
FieldCare (Endress+Hauser)
Field Xpert SMT70 (Endress+Hauser)
SIMATIC PDM (Siemens)
Field Device Manager FDM (Honeywell)
Fieldbus Information Manager FIM (ABB)
7 Commissioning
7.1 Post-installation check
Before commissioning the measuring point make sure that all final checks have been carried
out:
• "Post-installation check" checklist
• "Post-connection check" checklist
7.2 Switching on the device
Switch on the supply voltage after completing the final checks. The transmitter performs a
number of internal test functions after power-up. As this procedure progresses, a sequence of
device information appears on the display.
Normal measuring mode commences as soon as the switch-on procedure is completed.
Measured values and status values appear on the display.
7.3 Configuring the device
The transmitter is configured and measured values obtained via the Ethernet or CDI (=
Common Data Interface) interface.
For detailed information on configuring specific parameters, see the associated
Operating Instructions (BA) and Description of Device Parameters (GP)

iTEMP TMT86 Maintenance
Endress+Hauser 19
8 Maintenance
No special maintenance work is required for the device.
Cleaning
A clean, dry cloth can be used to clean the device.

www.addresses.endress.com
*71562442*
71562442
