Enelion Wallbox User manual

Wallbox
Duo Power
Assembly manual
Enelion Sp. z o.o.
inf[email protected]

Copyright, Enelion Sp. z o. o.
The manual may change as the product develops. The information provided may not be correct. All rights
reserved.
Revision: V 3.2
Number of pages: 22
Released: March 2, 2021
1

Wallbox Duo Power - Assembly manual 3 - 2021
Contents
1 Important information 4
1.1 General Provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 General information 5
2.1 Opening and closing Enelion Wallbox Duo Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Design indications of the installation 8
3.1 Recommended power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Recommended communication network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Location selection criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Assembly 10
4.1 Preparing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.2 Selection of bolts and anchors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Cableroutes............................................... 11
4.4 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Connection 13
5.1 Power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.1.1 Standard power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1.2 Power connection in version with MID meter . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2 Connection of communication wires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.3 EnelionChain .............................................. 16
5.4 Internet connections via Ethernet interface in LAN network . . . . . . . . . . . . . . . . . . . . . . 17
6 Maintenance 18
6.1 Cleaning................................................. 18
7 Technical data 19
7.1 Enelion Wallbox Duo Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2 Contents

Wallbox Duo Power - Assembly manual 3 - 2021
Before the installation, make sure that the module packages contain all the elements. Current version of the
operation manual can be accessed at http://enelion.com/en/help/.
See the contents of the manual before initiating any activities related to the installation or the activation of the
charger.
3 Contents

Wallbox Duo Power - Assembly manual 3 - 2021
1. Important information
1.1. General Provisions
Installation and servicing of the device must be per-
formed by qualified and authorized persons, and re-
pairs may only be carried out by the manufacturer or
entities authorized by the manufacturer.
Tampering with the mechanical, electrical and elec-
tronic components and the device software is forbid-
den and shall result in the nullification of the warranty.
The exceptions include operations described herein
and those agreed in writing with the manufacturer.
The manufacturer is not responsible for damage to
property resulting from the forbidden interference in the
product.
The electrical installation to be used by the device dur-
ing its operation must meet the conditions described
in the installation manual. The manufacturer is not re-
sponsible for incorrect assembly and/or protection of
the electrical installation to which the device is con-
nected.
The manufacturer is not responsible for the malfunction
of the electrical installation to which the device is con-
nected.
The electrical installation to be used by the device dur-
ing its operation must comply with the legal standards
in force in the place of assembly and the operation of
the device. The manufacturer is not liable for any dam-
age caused by an electrical installation that does not
meet legal standards.
The device does not have a built-in switch. The de-
vice activates when the supply voltage is applied. The
power supply cut off function must be provided by the
appropriate electrical installation devices described in
the assembly manual. Except in emergencies, the de-
vice must not be turned off during the charging process.
It is forbidden to supply the power to the device when
the device casing remains open.
The use of a mechanically damaged charger or a
charger that indicates a critical error is forbidden.
It is forbidden to place in the charger socket any objects
not intended for this purpose. A working power cable
with a cross-section appropriate for the power supplied
to the device and appropriate for the type of electric
vehicle, terminated with a functional plug type 2 in ac-
cordance with EC 62196-2 is the only object that may
be plugged in the charger socket.
It is forbidden to use any extensions of the charging ca-
ble.
The manufacturer is not responsible for loss of health
or life by any persons resulting from failure to comply
with the above-mentioned recommendations.
The data plate on the device is an integral part of the
device and its removal or damage shall result in the nul-
lification of the warranty.
1.2. Safety instructions
Outdoor installation should not be carried out during
precipitation or strong wind, if there is a risk that wa-
ter or dirt may get into the device.
All operations described in this manual should be per-
formed only having made sure that there is no voltage
in the power cable.
4 Important information

Wallbox Duo Power - Assembly manual 3 - 2021
2. General information
Wallbox Duo Power is a charging station intended for
electric road and passenger vehicles. It is made of
an aluminum casing, closed at its sides with reinforced
polymer material. It includes a charging process control
module, a front panel with an RFID reader, an OLED
screen and LED signaling.
It is distinguished by two available TYPE 2 charging
sockets operating in a 3-phase mode.
Additional accessories can be installed. The range of
functions of the device can be extended by adding such
accessories as Enelion Bridge, Enelion MID or Enelion
RCM B protection. Some parameters and functions can
be changed by reprogramming the device with the use
of the attached RFID card. Enelion Wallbox Duo Power
is available in two colors: black and silver.
Fig. 1: Enelion Wallbox Duo Power in black.
All Enelion charging stations are compatible with the
original Enelion Chain communication protocol, which
enables operation in the local network of chargers. This
enables the Enelion DLB function to be activated for dy-
namic load balancing, thus reducing the number of de-
vices that require an Internet connection and optimizing
the use of power in charging vehicles.
All Enelion devices can be fitted with Enelion Bridge
(an add-on to be purchased separately). It provides the
devices with Smart functions and facilitates their con-
nection to a remote management system (OCPP 1.6
compliant) via the Internet.
INFO
For more information, see the “User Guide”. It
contains detailed information about the func-
tionality and use of the device.
2.1. Opening and closing Enelion Wallbox
Duo Power
INFO
The 3 mm Allen key – included with the charger
– is needed to open (or close) the Enelion Wall-
box Duo Power. No other tool is necessary for
this operation.
INFO
Closing of the device is performed by repeating
the steps in the reverse order.
INFO
The operations described below are identical for
the device already mounted on the wall. Please
note that the device must be opened at least
once before the installation to allow access to
the mounting holes on its back and to connect
the power cable.
1. Remove the rubber plugs from the top left and
right hole of the device.
Fig. 2: Removal of rubber plugs.
5 General information

Wallbox Duo Power - Assembly manual 3 - 2021
2. Insert the supplied Allen key into the exposed
hole. The key should be inserted until resistance
is felt, i.e. until it cannot be pushed deeper.
Fig. 3: Inserting an Allen key.
3. Turn the key counterclockwise until the locking
pin is aligned with the side of the charger. Re-
move the Allen key from the hole. Repeat action
number 2 for the second locking pin.
Fig. 4: Unscrewing the locking pin.
4. Slide the front panel upwards of the device by
holding the socket housing – use a suction cup
as an option – until the lower edge of the front
panel is exposed.
Fig. 5: Front panel moved upwards.
5. Holding the socket housing, pull the bottom edge
of the panel until it is released from the housing
and tilted slightly.
Fig. 6: Front panel slightly tilted.
6. Holding the front panel in the same plane, slide it
downwards from the top frame of the device.
Fig. 7: Removing the front panel from the device
housing.
7. Slowly continue to pull out the front panel, watch-
ful of the socket lock not hooking onto the hous-
ing.
Fig. 8: Pulling out the front panel.
8. The front panel may freely rest next to the hous-
ing, hanging within the reach of the socket con-
nection wires.
6 General information

Wallbox Duo Power - Assembly manual 3 - 2021
Fig. 9: The device open with the access to its in-
terior.
INFO
The panel is fitted into place by following the
above operations in the reverse order.
oWARNING
Be careful not to crimple the signal tape while
fitting the front panel.
7 General information

Wallbox Duo Power - Assembly manual 3 - 2021
3. Design indications of the installation
3.1. Recommended power connection
Enelion charging stations are adapted to five-wire
power supply from TN-S type and TT type grid. It is
possible to apply three-wire power supply from TN-S
type grid.
oWARNING
Connection possibilities have been described in
“User manual”, in the Device configuration sec-
tion.
Enelion charging terminal must be powered from the
electrical switchboard. The board must have the re-
quired protections in the form of an overcurrent circuit
breaker with B or C characteristics and rated current
of 32 A or lower, appropriate to the device version. To
be compliant with the PN-EN IEC 61851-1: 2019-10
standard, each charging point must also be protected
against type A or B residual current. This requirement
must be met by one of the below:
1. installation of a type B residual current device
(RCD B 30 mA/40 A) or RCD EV (30 mA/40 A) in
the switchboard,
2. installation of a type A residual current device
(RCD A 30 mA/40 A) in the switchboard with the
application of Enelion RCM B – type B Residual
Current Monitor, attached to the charging termi-
nal.
The final selection of the safety devices belongs to an
authorized designer or a qualified electrician.
HINT
The above requirements result in the neces-
sity to use independent cables for multi-socket
devices: Wallbox Duo Power and Wallbox
Adspace.
INFO
Wallbox Duo multi-socket device allows one to
power the charging sockets only in 1-phase
mode. Therefore, it should be powered with one
four-wire cable.
The cross-section of the power supply cables must be
selected by an authorized electrician, depending on the
distance from the switchboard and other conditions per-
tinent to the location. To obtain the maximum charging
power in wall-mounted devices, the use of cables with a
conductor cross-section not greater than 6 mm2is rec-
ommended. The maximum cross-section of the power
supply cable to be assembled in connection terminals
is 16 mm2. The diameter of the power supply ca-
ble with insulation must not exceed 16 mm2.´ Srednica
przewodu zasilaj ˛acego z izolacj ˛a nie mo˙ ze przekracza´ c
16 mm.
Cables running underground must be installed in accor-
dance with the binding building regulations. For conve-
nient installation, flexible power cables, stranded type,
terminated with clamping sleeves are recommended
oWARNING
To supply the voltage to the installed and con-
nected charging station, first switch on the RCD
protection, and next the overcurrent switch.
For installation, about 50 cm of power cable re-
serve from the expected installation position is recom-
mended.
HINT
For Wallbox Adspace devices, a reserve of
about 110 cm of the cable supplying power to
the left socket is recommended.
3.2. Recommended communication net-
work
Enelion devices support the Enelion Chain communica-
tion interface. For its implementation, a wired connec-
tion between the devices is required using an Ethernet
CAT 5 or CAT 6 cable.
For installation, leave about 50 cm of communication
cables from the expected installation position.
The network works in a serial topology where:
• the number of Enelion charging points does not
exceed 100 devices,
• the total length of the communication cable con-
necting the devices does not exceed 500 m.
8 Design indications of the installation

Wallbox Duo Power - Assembly manual 3 - 2021
Fig. 10: Enelion Chain network topology.
Enelion devices equipped with the Enelion Bridge mod-
ule can use the Internet connection via the Ethernet in-
terface in the LAN network. In order to utilize this func-
tion, run the Ethernet CAT 6 cable to the device in which
the use of this option is expected.
INFO
Devices equipped with Enelion Bridge can also
use WiFi and GSM interfaces to ensure the In-
ternet connection, but they do not have require-
ments related to cable installation.
3.3. Location selection criteria
Wall-mounted Enelion devices may be installed both in-
ternally or externally.
The device has been designed to be installed near
parking spaces for electric vehicles. When used in the
vehicle collision hazard zone, the structure should be
secured with appropriate fenders painted in yellow and
black stripes (warning about the gauge).
Bear in mind that the national regulations may define
the space for the installation. The device should not be
located in a place of high exposure to sunlight, which
could cause overheating. Do not install the device near
heat sources or in small, closed spaces (e.g. in a box).
It is forbidden to install a power cord that does not com-
ply with the guidelines in section 3.1 Recommended
power connection. It is forbidden to install the device
in potentially explosive environment.
Local regulations for electrical installations, fire preven-
tion measures and accident prevention must be taken
into account, and escape routes at the installation site
must be provided.
It is forbidden to install the device in a location where
falling objects may damage the charger.
Before installation, make sure that the mounting space
for the device is sufficient.
Wallbox family devices should have at least:
1. 10 cm clearance on each side of the unit.
Stilo family devices should have at least:
1. 10 cm clearance on the right side of the unit.
2. 50 cm clearance above the top edge of the de-
vice.
3. 100 cm clearance below the bottom edge of the
device.
oWARNING
The manufacturer accepts no responsibility for
any damage resulting from failure to comply
with the above-mentioned recommendations.
9 Design indications of the installation

Wallbox Duo Power - Assembly manual 3 - 2021
4. Assembly
oWARNING
Before commencing the installation, switch off
the power supplied to the cables.
4.1. Preparing the installation
1. Place the packaged Enelion Wallbox Duo Power
horizontally, in accordance with the markings on
the packaging. Cut the package open along
the indicated line. Take the device out of the
cardboard box, remove the polystyrene protective
casing and put the device in the safe position.
2. The polystyrene protection contains useful ac-
cessories necessary for the mounting of the de-
vice. Before recycling the packaging, collect
those accessories that include:
• 3 mm Allen key,
• cable gland plug,
• RFID configuration card and RFID pendant.
3. Open Enelion Wallbox Duo Power in accordance
with the instruction included in section 2.1 Open-
ing and closing Enelion Wallbox Duo Power.
4.2. Selection of bolts and anchors
Enelion Wallbox Duo Power is mounted on vertical sur-
face using bolts. The device has four mounting open-
ings. Additionally, the device is equipped with holds fa-
cilitating the assembly.
Fig. 11: Mounting holes of Enellion Wallbox Duo Power
as seen from the back of the device.
Fig. 12: Assembly of the holds at the back of the device.
Fig. 13: Hanging Enelion Wallbox Duo Power on the
holds.
10 Assembly

Wallbox Duo Power - Assembly manual 3 - 2021
Fig. 14: Attaching the device to the holds with screws.
Follow the information listed below to choose the appro-
priate method of assembly, depending on the mounting
surface:
1. four mounting holes are positioned on the plan of
a rectangle with dimensions of 490 mm x 96 mm
(width x height),
2. mounting holes have a diameter of 5,5 mm,
3. the device weighs 6,2 kg,
4. mounting must provide stability for the device to
withstand significant forces affecting it when plug-
ging and unplugging the charging cable in the
socket.
oWARNING
Use all mounting holes in the process of instal-
lation. Failure to do so will result in the loss
of water and dust resistance of the device, as
a default classified as IP 54. This can lead to
damage or failure of the charger, and conse-
quently to loss of life or health. The manufac-
turer is not responsible for damage and injuries
arising from failure to observe the above recom-
mendations.
4.3. Cable routes
The default power cable entry (“A” entry) is at the top
part of the device.
It is possible to insert the power cables from the bottom
of the device by moving the glands by oneself. To do
this, remove the plugs at the bottom of the device.
The insertion of communication cables (“B” entry) is
possible from the bottom of the device. This requires
the removal of the plug and the installation of a gland
suitable for the type and number of communication ca-
bles to be routed. The opening diameter for the com-
munication cable gland is 19 mm.
Fig. 15: Locations of cable entry points in Enelion Wall-
box Duo Power.
The removal of plugs for the assembly of cable glands
should be performed according to the following guide-
lines:
1. place the device on a stable surface,
2. use a hammer and a flat-bladed screwdriver to
knock out the gland hole plug carefully.
The cable gland in the upper part of the device should
be put into the hole in the lower part of the device and
screwed to ensure tightness. The gland nut requires a
32 mmspanner and the gland requires a 30 mm span-
ner. After repositioning the gland, the opening in the
upper part of the device should be closed with the plug
provided with the product.
The cable gland for communication cables should be
installed in accordance with the manufacturer’s instruc-
tions.
11 Assembly

Wallbox Duo Power - Assembly manual 3 - 2021
oWARNING
If the gland is moved by the user, the manufac-
turer’s warranty for the tightness of the device in
accordance with the IP54 class becomes void.
Correct performance of the operation ensures
adequate tightness; however, the manufacturer
reserves the right to refuse to repair, under war-
ranty, the damage resulting from the relocation
of the cable gland from the top to the bottom of
the device.
4.4. Mounting the device
INFO
The device has been equipped with a template
facilitating the installation.
1. Determine the final location of the device using
the attached template and the level, and mark the
mounting holes. The template marks the mount-
ing holes, the outline of the rear wall of the de-
vice, the axis of the glands (both in the version
with a gland in the upper and the lower part of
the device) and the optimal cable lengths. Mount-
ing holes should be at least 5 cm from the edge of
the wall (in case of a recess, minimum 20 cm — to
leave enough space for the use of Allen key). The
axis of the power cable must coincide with the
axis of the glands marked on the template. Make
sure that the power cord is at least 350 mm long,
measured from the edge of the device marked on
the template.
2. Make assembly holes and install expansion bolts.
Mounting holes should be made in accordance
with the specification of expansion bolts, which
should be placed in the cleaned holes.
3. Make sure that there is no voltage in the power
cords.
4. Open the device as described in section 2.1
Opening and closing Enelion Wallbox Duo Power.
5. Put the device in the target position by threading
the power cable through the glands.
6. Fasten the device with screws using a screw-
driver with a shaft length of at least 150 mm.
7. Screw on the power cable gland ensuring tight-
ness.
8. (Optional) Insert at least 350 mm of the commu-
nication cables into the device.
The device mounted in this way can be connected.
12 Assembly

Wallbox Duo Power - Assembly manual 3 - 2021
5. Connection
5.1. Power connection
Enelion Wallbox Duo Power devices come in various
types. Depending on which type is being installed, the
power supply cables may be connected directly to the
terminals or to the approved integrated MID meter.
Fig. 16: Diagrams of connection types 1/2.
13 Connection

Wallbox Duo Power - Assembly manual 3 - 2021
Fig. 17: Diagrams of connection types 2/2.
5.1.1. Standard power connection
INFO
For both sockets to operate, the voltage in Ene-
lion Wallbox Duo Power must be supplied to
the connection clamps of both charging con-
trollers. Operations described below should be
performed for the terminals of both charging
sockets.
1. Prepare the power supply cable.
Remove 200 mm of the main insulation off the
power supply cable. Terminate the individual
wires of the cable with fork (M4 or M5 size) or
sleeve terminals.
2. Insert the power supply cables into the terminals.
Fig. 18: Connection using fork terminals
14 Connection

Wallbox Duo Power - Assembly manual 3 - 2021
Fig. 19: Connection with solid conductors – wire
3. Use a PZ2 end screwdriver to tighten the termi-
nals with 1,5 N m torque.
Fig. 20: Electrical connection executed correctly.
HINT
The colors of the phase wires in Enelion Wall-
box Duo Power may not match the colors of the
power cables, maintaining, however, the guide-
lines on Enelion Wallbox Duo Power label. This
is a correct and expected situation when using
the phase sequence function.
5.1.2. Power connection in version with MID meter
INFO
For both sockets to operate, the voltage in Ene-
lion Wallbox Duo Power must be supplied to
the connection clamps of both charging con-
trollers. Operations described below should be
performed for the terminals of both charging
sockets.
1. Prepare the power cord.
Remove 200 mm of the main insulation off the
power supply cable. Terminate the individual
wires of the cable with sleeve terminals.
2. Insert the power cables into the terminals of the
MID meter and tighten them.
Unless otherwise marked on the label of the de-
vice, make a standard connection in accordance
with the markings on the meter. The PE protec-
tive conductor should be connected to the pre-
pared coupling.
Fig. 21: Electrical connection with MID meters
executed correctly.
Fig. 22: Recommended connection when apply-
ing a MID meter.
HINT
The colors of the phase wires in Enelion Wall-
box Duo Power may not match the colors of the
power cables, maintaining, however, the guide-
lines on Enelion Wallbox Duo Power label. This
is a correct and expected situation when using
the phase sequence function.
15 Connection

Wallbox Duo Power - Assembly manual 3 - 2021
5.2. Connection of communication wires
HINT
As a default, both integrated charging con-
trollers in Enelion Wallbox Duo Power are con-
nected with the communication cable. When
setting up Enelion Chain network, this section
should be considered as a section between de-
vices, applying all the recommendations de-
scribed below.
5.3. Enelion Chain
If the communication between the devices is expected
to be via Enelion Chain network, the cables should
be connected to the charge controller. Two cores of
the communication cable and the screen grounding are
used for communication. To connect correctly:
1. Prepare communication cables
2. (a) for devices at the beginning of the network,
select a pair of communication wires,
(b) for devices in a section of the network, pre-
pare the communication cables inserted into
the device by connecting together the cores
of the incoming and outgoing wires (in vari-
ant A) or move to the next step (in variant B,
check figures below).
Fig. 23: Incoming and outgoing communi-
cation cable connection (variant A)
Fig. 24: Incoming and outgoing communi-
cation cables (variant B)
3. Release the connector terminal by pressing the
button using a flathead screwdriver and insert the
wires into the respective locations. There will be
single wires for devices at the start and end of the
network.
Fig. 25: Diagram of Enelion Chain communica-
tion cables connection (variant A)
Fig. 26: Diagram of Enelion Chain communica-
tion cables connection (variant B)
16 Connection

Wallbox Duo Power - Assembly manual 3 - 2021
4. Use termination for devices at the beginning and
end of the network. Termination is done by
placing a jumper on two pins inside the charger
marked as TERM.
Fig. 27: A sample jumper.
Fig. 28: The place of applying the terminating
jumper (variant A)
Fig. 29: The place of applying the terminating
jumper (variant B)
5.4. Internet connections via Ethernet in-
terface in LAN network
To provide the Internet connection to a charger
equipped with Enelion Bridge module via Ethernet in-
terface:
1. Insert the Ethernet cable into the device through
the gland for communication cables.
2. Terminate the cable with the RJ45 connector ac-
cording to TIA-568A/B to 100BaseT.
Fig. 30: Termination of the Ethernet cable accord-
ing to TIA-568A/B to 100BaseT.
3. Connect the Ethernet cable to the
WAN/INTERNET socket of Enelion Bridge mod-
ule marked with number 2.
Fig. 31: Enelion Bridge module diagram.
17 Connection

Wallbox Duo Power - Assembly manual 3 - 2021
6. Maintenance
The device is designed to operate in temperatures from
−25 °C to 55 °C. The manufacturer does not guarantee
the proper functioning of the charging station in temper-
atures outside the specified range. Chargers that are
damaged because of exposure to temperatures below
−25 °C or above 55 °C are not covered under the war-
ranty. In case it is necessary to open the device, make
sure that it is disconnected from the power source. With
the device installed outdoors, make sure that there is no
precipitation or strong wind.
oWARNING
The device may only be opened by a qualified
and authorized person.
6.1. Cleaning
The correct way to clean the charger is to wipe the
housing with a microfiber cloth using a cleaning agent
dedicated to anodized aluminum. Plexiglas elements
(front panel) and plastic elements (socket) should be
cleaned with a microfiber cloth using a cleaning agent
dedicated to cleaning windowpanes. Other cleaning
methods (e.g. wire brush) may lead to the damage of
the device housing. Damage resulting from improper
cleaning of the device does not constitute grounds for
warranty claims.
oWARNING
The device meets the IP 54 standard. There-
fore, it is forbidden to wash the charger with
pressure washers, garden hoses, shower or any
other water stream sources.
18 Maintenance

Wallbox Duo Power - Assembly manual 3 - 2021
7. Technical data
7.1. Enelion Wallbox Duo Power
Electrical data
Routing of the power cord Surface mounted
Power cord cross-section
Recommended minimum cross-section
• 2 cables 5 x 6,0 mm2(32 A nominal current)
Supply voltage (Europe) 3 x230 V/400 VAC
Voltage frequency 50 Hz/60 Hz
Network type TN, TT
(IT per special request)
Overvoltage category III according to EN 60664–1
Rated short-circuit current Effective value < 6 kA according to EN 61439–1
Overcurrent protection Not included. Protection to be made in accordance with
the locally valid regulations and according to the type of
the device.
Protection Class Class I
Socket type 2 x Type 2, standard socket 32 A/400 VAC in accordance
with EN 62196–1
Mechanical data
Dimensions (width x height x depth) 530 mm x 249 mm x 156 mm
Weight 2,75 kg ±5%
IP Class IP54
Mechanical strength class IK10
Interfejsy
Charging network development Enelion Chain
Add-ons
• Enelion MID
• Enelion Bridge
• Enelion RCM B
RFID MIFARE cards compliant with ISO 14443
19 Technical data
