Enelion Vertica User manual

Vertica
Manual for Vertica Modules,
Vertica Pole and accessories.
Enelion sp. z o.o.
[email protected]

Copyright, Enelion sp. z o.o.
The manual may change as the product develops.
The information provided may not be correct.
All rights reserved.
Revision: V 3.9
Number of pages: 40
Released: 05.06.2023

5 - 2023
1
Vertica - assembly manual
Contents
1. Important information 3
1.1. General Provisions 3
1.2. Safety instructions 3
2. General information 4
2.1. Additional functions 4
2.2. Vertica Pole 4
2.2.1. Opening and closing of the device 4
2.3. Vertica Module 6
2.3.1. Vertica Module with a socket 6
2.3.2. Vertica module with a cable 6
2.3.3. Assembly and disassembly of Vertica Modules 7
3. Design indications of the installation 8
3.1. Recommended electrical connection 8
3.2. Supplied accessories and electrical connection 8
3.3. Location selection criteria 8
3.3.1. Connection type diagrams 10
3.3.2. Pictorial diagrams of Vertica Modules 12
4. Foundation 14
4.1. Enelion prefabricated foundation 14
4.1.1. Construction of the foundation applying the Enelion prefabricated element 14
4.2. Appropriate existing foundation 15
4.2.1. Preparation of the existing foundation 15
4.3. Enelion foundation set 16
4.3.1. Construction of the foundation using the Enelion foundation set 16
5. Installation of Vertica Pole 19
5.1. Preparation for installation 19
5.1.1. Standard connection 21
5.1.2. Enelion MID Add-on 21
5.1.3. Enelion Chain Add-on 24
5.2. Internet connection via Ethernet interface in the LAN 25
5.2.1. Vertica Splitter Add-on with an additional meter and residual current protection 26
5.3. Installation of Vertica bottom maskingpanels 27

5 - 2023
2
Vertica - assembly manual
6. Installation of the Vertica Module 28
6.1. Preparation for installation of the Vertica Module with socket 28
6.2. Preparation for installation of the Vertica Module with a cable 28
6.3. Installation of accessories 29
6.3.1. Enelion Bridge 29
6.3.2. Enelion RCMB 30
6.3.3.EnelionModułLTE 31
6.4. Activation and use 33
7. Maintenance 34
7.1. Cleaning 34
8. Technical data 35
8.1. Vertica Pole 35
8.2. Vertica Module with a socket 36
8.3. Vertica Module with a cable 37
9. Technical description 38
9.1. Formwithboxestollin 38
Congratulations on the purchase of the Enelion charger and thank you for your trust.
Before the installation, make sure that the module packages contain all the elements. Current version of the
operation manual can be accessed at: https://enelion.com/en/support/
See the contents of the manual before initiating any activities related to the installation or the activation of the
charger.
Thank you for your purchase

5 - 2023
Vertica - assembly manual
3
1.Important information
1.1. General Provisions
Installation and servicing of the device must be per-
formedbyqualiedandauthorizedpersons,and
repairs may only be carried out by the manufacturer
orentitiesauthorizedbythemanufacturer.
Tamperingwiththemechanical,electricalandelectro-
nic components and the device software is forbidden
andshallresultinthenullicationofthewarranty.
Theexceptionsincludeoperationsdescribedherein
and those agreed in writing with the manufacturer.
Themanufacturerisnotresponsiblefordamageto
property resulting from the forbidden interference
in the product.
Theelectricalinstallationtobeusedbythedevice
during its operation must meet the conditions descri-
bedintheinstallationmanual.Themanufacturer
is not responsible for incorrect assembly and/or
protection of the electrical installation to which the
device is connected.
Themanufacturerisnotresponsibleforthemalfunc-
tion of the electrical installation to which the device
is connected.
Theelectricalinstallationtobeusedbythedevice
during its operation must comply with the legal
standards in force in the place of assembly and the
operationofthedevice.Themanufacturerisnotliable
for any damage caused by an electrical installation
that does not meet legal standards.
Thedevicedoesnothaveabuilt-inswitch.Thedevice
activateswhenthesupplyvoltageisapplied.The
powersupplycutofunctionmustbeprovidedbythe
appropriate electrical installation devices described
in the assembly manual. Except in emergencies, the
devicemustnotbeturnedoduringthecharging
process.
It is forbidden to supply the power to the device when
the device casing remains open.
Theuseofamechanicallydamagedchargerora
charger that indicates a critical error is forbidden. It
is forbidden to place in the charger socket any objects
not intended for this purpose. A working power cable
with a cross-section appropriate for the power supplied
to the device and appropriate for the type of electric
vehicle, terminated with a functional plug type 2 in
accordance with EC 62196-2, is the only object that
Important information
may be plugged in the charger socket.
It is forbidden to use any extensions of the charging
cable.
Themanufacturerisnotresponsibleforlossofhealth
or life by any persons resulting from failure to comply
with the above-mentioned recommendations.
Thedataplateonthedeviceisanintegralpartofthe
device and its removal or damage shall result in the
nullicationofthewarranty.
Fig. 1: Example of info plate
1.2. Safety instructions
Outdoor installation should not be carried out during
precipitation or strong wind, as there is a risk that
water or dirt may get into the device.
All operations described in this manual should be
performed only after making sure that there is no
voltage in the power cable.
i INFO
ThesetofVerticachargerincludesthree
self-adhesive plates with information about the
value of supply current. Select the appropriate
oneaccordingtothespecicationandxitnext
to the data plate.

5 - 2023
Vertica - assembly manual
4
2. General information
Vertica is a modular charging station for electric cars,
which consists of Vertica Pole as a casing, Vertica
Modules involved in the charging process and optional
addons and accessories.
Themodulardesignfacilitatesaneasymodication
of the functions of the device by replacing or adding
charging modules and accessories to best suit custo-
mers’ needs. Preparation for use depends on the
selected machine functions of the device.
2.2. Vertica Pole
Vertica Pole is a necessary part of the device. Vertica
Modules are installed in it, which are the executive
part of the charging process. It is available in 2 colors:
silver and black.
General information
i INFO
For more information, please refer to the User
Manual. It contains detailed information about
the functionality and use of the device.
2.1. Additional functions
All Enelion charging stations are compatible with the
original Enelion Chain communication protocol, which
enablesoperationinthelocalnetworkofchargers.This
enablestheEnelionDLBfunctiontobeactivatedfor
dynamic load balancing, reducing the number of devi-
cesthatrequireanInternetconnectionandoptimizing
the use of power in charging vehicles.
AllEneliondevicescanalsobettedwiththeEnelion
Bridge (an add-on sold separately), which equips the
devices with smart functions and facilitates their
connection to a remote management system (OCPP
1.6 compliant) via the Internet.
Fig. 2: Enelion Vertica charging station.
2.2.1. Opening and closing of the device
Vertica Pole structure secures the access to the inte-
rior of the device. Before performing any operations
on the device, open the Vertica Pole according to the
instructions.
Fig. 3: Vertica Pole without the charging modules
installed.

5 - 2023
Vertica - assembly manual
5
1. UsingtheTorxSecurityT25bitprovided,unscrew
thedevicecoverbolts.Theyarelocatedonboth
sides of the device. Put the cover in a safe pla-
ce where it will not be exposed to damage.
Fig. 4: Removing the cover of the Vertica Pole.
Fig. 5: Unlocking the lock plate.
Fig. 6: Removing the lock plate.
i INFO
In order to close the Vertica Pillar, perform all
steps in reverse order.
i INFO
Closing and opening of the Vertica Pole does not
change depending on the presence of Vertica
Modules in the device.
2. Unlock the lock plate with the key (if there is a Yale
lock). Next, using the 5 mm Allen key, unscrew
the M6 bolts and remove the lock plate.
3. Dismantle the lock plate by lifting it upwards.
General information

5 - 2023
Vertica - assembly manual
6
Fig. 8: Enelion Vertica Module with a cable.
2.3. Vertica Module
2.3.1. Vertica Module with a socket
TheVerticamodulewithasocketisafunctionalpart
of the charging station.
ThismoduleprovidesaType2socketforcharging
vehicles with up to 32A three phase and can be moun-
ted on either side of the Vertica Pole. It is equip-
pedwithanOLEDscreendisplayinginstructions
and information about the charging in progress.
Fig. 7: Enelion Vertica Module with a socket.
2.3.2.Vertica module with a cable
TheVerticamodulewithacableisafunctionalpart
of the charging station.
TheVer ticamodulewithacableisafunctionalpartof
thechargingstation.Thismoduleprovidesacharging
cable for charging vehicles with up to 32A three phase
and can be mounted on either side of the Vertica Pole.
ItisequippedwithanOLEDscreendisplayinginstruc-
tions and information about the charging in progress.
General information

5 - 2023
Vertica - assembly manual
7
Fig. 9: Assembly of Vertica Modules
General information
2.3.3. Assembly and disassembly of Verti-
ca Modules
i INFO
Toshutdownthedevice,performallstepsin
reverse order.
1. Open the Vertica Pole according to the instruc-
tions in section 2.2.1 Opening and closing of the
device.
2. Lift the moduleabove the VerticaPole and pla-
ce the bottom edge in the guide slot. Carefully
insert the Vertica Module into the power socket
untilitstopedgeisushwiththeedgeoftheVer-
tica Pole.
3. Close the Vertica Pole in accordance with the in-
struction 2.2.1 Opening and closing of the device.

5 - 2023
Vertica - assembly manual
8
terminated with clamping sleeves are recommended
for the installation.
Thecableshouldprotrudeapproximately80cmabove
the foundation level.
3.Design indications of the installation
3.1. Recommended electrical connection
Vertica System charging stations are adapted to a
vewirepowersupplyinaTN-Stypenetwork.Inthe
standard type of installation, each Vertica Module
should be powered by a separate cable from the
switchgear.Theswitchgearshouldhavetherequired
protection in the form of an overcurrent circuit bre-
aker with B or C characteristics and rated current of
32Aorless,dependingonthecongurationofthe
device.In compliance with the PN-EN IEC 61851-1:
2019-10 standard, each charging point must also be
individually protected against residual current type A
andB.Thisrequirementcanbemetbytheadministra-
tor/owner when installing a type B residual current
device (RCD B 30 mA/40 A) or RCD EV (30 mA/40A) in
the switchboard.
Thenalselectionofthesafetydevicesbelongstoan
authorizeddesigneroraqualiedelectrician.
Another recommended and simultaneously more
economical solution is the installation of an RCD B
purchased from Enelion together with the device.It
is also possible to use the Enelion RCMB– Residual
Current Monitor type B accessory – see section 6.3.2
Enelion RCM B.Enelion RCM B additionally protects
the station and, together with the RCD A used in the
switchgear, meets all safety requirements.If it is neces-
sary to supply the power to the pole with two charging
modules from one cable, Vertica Splitter, described
in chapter 5 Installation of Vertica Pole, should be
used – the accessory allows for safe branching of the
power supply to two charging panels inside Vertica
Pole.Ene-lion Spliter includes a junction block, two B32
over current protections, a wiring set and mounting
hardware.Thewholedeviceismountedontheattached
TS35railsatthebottomofVerticaPole.Rememberto
protect each Vertica Module with a residual current
devicewiththecharacteristicsdescribedabove.The
cross-section of the power cables must be selected
byanauthorizedelectricianbasedonthedistance
from the switchgear and other location conditions.
Cables in the ground must be installed in accordance
with the binding building regulations.As a matter of
convenience,exiblepowercables,strandedtype,
3.2. Supplied accessories and electrical
connection
Due to the modular structure of the Vertica System
charging stations, the method of electrical connection
depends on the applied add-ons.Moreover, in order for
certain functions to be performed, it is necessary to
connect the device according to the determined sequ-
ence of phases.Electrical connection of the Vertica Pole
is typically made with two separate 5 x 6 mm2 Due to
the modular structure of the Vertica System charging
stations, the method of electrical connection depends
on the applied add-ons.Moreover, in order for certain
functions to be performed, it is necessary to connect
the device according to the determined sequence of
phases.Electrical connection of the Vertica Pole is
typically made with two separate (6 mm2 insulated
ring terminal, M5 mount).A dedicated crimping tool
for insulated connectors is required.Stranded cables
must be terminated with an insulated crimp ferrule
oftheappropriatesize.
Design indications of the installation
i INFO
In case of Enelion Splitter, the standard cross-
section of the Cu power cables is 16 mm2.
At the customer’s request, the maximum cross-
section of Cu/Al power cables is 50 mm2
3.3. Location selection criteria
Enelion Vertica may be installed both inside or outside.
Thedeviceisdesignedforinstallationnearparking
spaces dedicated to electric vehicles.When used in
thevehiclecollisionhazardzone,thestructureshould
be secured with appropriate fenders painted in yellow
and black stripes (warning about the gauge).
i INFO
Vertica Pole assembly system enables the pole
to rotate by multiple 90-degree angle turns.
Please bear in mind that the national regulations may
denethespacefortheinstallation.Thedeviceshould
not be located in a place of high exposure to sunlight,
which could cause its overheating.Do not install the
device near heat sources or in small, closed cubicles
(e.g.in a box).
It is forbidden to install a power cord that does not
comply with the guidelines in section 3.1 Recommen-
ded electrical connection.It is forbidden to install the
device in potentially explosive environment.
Localregulationsforelectricalinstallations,repre-

5 - 2023
Vertica - assembly manual
9
Design indications of the installation
vention measures and accident prevention must be
taken into account, and escape routes at the installation
site must be provided.
It is forbidden to install the device in a location where
falling objects may damage the charger.
Before installation, make sure that there is free space
above the charger at least one meter from its outline.
Alsoafterinstallation,makesurethatnoxedobjects
(e.g.advertising boards, road signs, etc.) appear in
thespaceabovetheoutlineofthedevice.Thisspace
is required for servicing the charging station.
!WARNINIG
Themanufactureracceptsnoresponsibilityfor
any damage resulting from failure to comply
with the above-mentioned recommendations.

5 - 2023
10
Vertica - assembly manual
Design indications of the installation
3.3.1. Connection type diagrams
Fig. 10: Connection types part 1/2

5 - 2023
11
Vertica - assembly manual
Design indications of the installation
Fig. 11: Connection types part 2/2.

5 - 2023
12
Vertica - assembly manual
Design indications of the installation
Fig. 12: Pictorial diagrams of Vertica Modules part 1/2.
3.3.2.Pictorial diagrams of Vertica Modules

5 - 2023
13
Vertica - assembly manual
Design indications of the installation
Fig. 13: Pictorial diagrams of Vertica Modules part 2/2.

5 - 2023
Vertica - assembly manual
14
4. Foundation
Vertica Pole can be installed in three ways:
• ona customizedEnelion prefabricatedfoun-
dation,
• on an appropriate existing foundation with
the use of additional mounting bolts,
• using the Enelion foundation set.
4.1. Enelion prefabricated foundation
ThecustomizedEnelionprefabricatedfoundation
enables shortening the assembly period by eliminating
the need to wait for the concrete to cure.
Fig. 15: Diagram of the foundation excavation.
Fig. 16: Placing the prefabricated element in the
excavation.
The foundation set consists of:
• 1 x prefabricated foundation,
• 8 x washers,
• 8 x M12 nuts.
4.1.1. Construction of the foundation ap-
plying the Enelion prefabricated
element
Fig. 14: Enelion prefabricate foundation.
2. An excavation of over 400 mm x 600 mm (dia-
meter x depth) or 400 mm x 400 mm x 600 mm
(width x length x depth) should be made. Com-
pact the soil directly under the foundation to the
compaction index of at least 0.97.
3. Threadalltherequiredcablesthroughthecable
ducts of the prefabricated foundation. Place the
prefabricated element and plumb it in the trench
at a depth of 0,55 m below the ground level.
1. Remove the M12 nuts and washers from the pre-
fabricated foundation and secure them until Ver-
tica Pole has been installed.
Foundation

5 - 2023
Vertica - assembly manual
15
Fig. 17: Properly constructed foundation using the
prefabricated element.
Fig. 19: Properly constructed foundation with the
use of anchors.
Thefoundationpreparedinthiswayenablesthe
installation of Vertica Pole.
After preparing the anchors according to the instruc-
tions, the installation of Vertica Pole may proceed.
4.2. Appropriate existing foundation
In case there is an existing foundation suitable for
the purpose, equipped with an electrical connection,
meeting the legal and construction requirements, it
is possible to install Vertica Pole after ensuring that
Vertica Pole is properly attached to the foundation.
It is recommended to apply M12 threaded rods.
1. Drill holes for chemical anchor bolting in the fo-
undation in accordance with the instructions of
the manufacturer of the applied bolting. Install
theanchorsinasquareof120mmx120mm.The
cablesmusttintothecablegrommetsofVerti-
ca Pole.
4.2.1. Preparation of the existing foundation
Fig. 18: Drilled holes for chemical anchor bolting.
2. Install chemical anchor bolting in accordance
with the instructions of the manufacturer. The
minimumanchoragedepthis110mm.Theinstal-
lation should result in the ends of the threaded
rods protruding 40 mm to 60 mm above the fo-
undation surface.
4. Fixtheprefabricatedelementbyllingtherema-
ining space in the excavation with soil and com-
pact it to the compaction index of at least 0.97.
Foundation

5 - 2023
Vertica - assembly manual
16
Thefoundationpreparationsetconsistsof:
• 4 x threaded rods,
• 2 x base plates,
• 8 x washers,
• 20 x M12 nuts.
Fig. 20: Enelion foundation set.
Fig. 21: Guidelines for the installation of the Enelion
foundation set.
4.3.1. Construction of the foundation using
the Enelion foundation set
1. Make a trench in the substrate with dimensions
of250 mm x 600 mm (diameter x depth) or 250
mmx 250 mm x 600 mm (width x length x depth).
Compact the soil directly under the foundation
tothe compaction index of at least 0. 97.
2. Assemble the Enelion foundation set as shown.
Theupperbaseplateshouldbe40mmto60mm-
from the end of the threaded stud.
3. Place the assembled Enelion foundation set inthe
trench. Run the power cables above the surface
to a height of about 800 mm. Fix the foundation
set vertically so that the ends of the threaded
rods protrude 45 mm to 65 mm above the inten-
ded foundation surface. The upper base plate
should be above the intended foundation surfa-
ce and be level so that it can be removed once the
concrete has cured.
4.3. Enelion foundation set
TheEnelionfoundationsetenablestheconstruction
of a foundation suitable for the installation of the
VerticaPole.Toconstructthefoundationcorrectly,
the Enelion foundation set needs to be set in concrete
in the excavation.
Foundation

5 - 2023
Vertica - assembly manual
17
Fig. 22: Diagram of placing the foundation set in
the excavation
4. Put concrete B25 (C20/25) in the foundation.
5. Once the concrete has cured, unscrew the M12
nuts, remove the washers and the upper base
plate.Thewashersandnutswillbeneededlater
toaxVerticaPole.
Fig. 23: Details of placing the upper base plate in
the excavation
Fig. 24: Foundation set correctly placed in the
excavation
Fig. 25: Cross-section of the foundation set cast in
the concrete
Foundation

5 - 2023
Vertica - assembly manual
18 Foundation
Fig. 26: Correctly cast foundation set.
Fig. 27: Removing of the upper base plate from the
foundation set.
Fig. 28: Screwing nuts and spacer washers onto
protruding rods.
6. Secure the bolts partly protruding from the con-
crete with bituminous mass (do not cover the
thread).
Thefoundationpreparedinaccordancewiththeabove
instructions is ready for Vetrtica Pole to be mounted.
