Energenics UV-MAX RAD User manual

UV-max RAD
AIR Disinfection Unit
USER GUIDE
Models:
UV-MAX RAD
ENERGENICS.COM
CORPORATION
®

The technical data and images which appear in this manual are for informational purposes only. NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE CREATED BY THE DESCRIPTIONS AND DEPICTIONS OF THE PRODUCTS SHOWN IN THIS MANUAL.
Energenics makes no warranty (and assumes no liability) as to function of equipment or operation of systems built according to customer design or of the ability of any of its
products to interface, operate or function with any portions of customer systems not provided by Energenics.
Seller agrees to repair or exchange the goods sold hereunder necessitated by reason of defective workmanship and material discovered and reported to Seller within one
year after shipment of such goods to Buyer.
Except where the nature of the defect is such that it is appropriate, in Seller’s judgment, to effect repairs on site, Seller’s obligation hereunder to remedy defects shall be
limited to repairing or replacing (at Seller’s option) FOB point of original shipment by Seller, any part returned to Seller at the risk and cost of Buyer. Defective parts replaced
by Seller shall become the property of Seller.
Seller shall only be obligated to make such repair or replacement if the goods have been used by Buyer only in service recommended by Seller and altered only as
authorized by Seller. Seller is not responsible for defects which arise from improper installation, neglect, or improper use or from normal wear and tear.
Additionally, Seller’s obligation shall be limited by the manufacturer’s warranty (and is not further warranted by Seller) for all parts procured from others according to
published data, specifications or performance information not designed by or for Seller.
Seller further agrees to replace or at Seller’s option to provide a refund of the sales price of any goods that do not conform to applicable specifications or which differ from
that agreed to be supplied which non-conformity is discovered and forthwith reported to Seller within thirty (30) days after shipment to the Buyer. Seller’s obligation to
replace or refund the purchase price for non-conforming goods shall arise once Buyer returns such goods FOB point of original shipment by Seller at the risk and cost of
Buyer. Goods replaced by Seller shall become the property of Seller.
There is no guarantee or warranty as to anything made or sold by Seller, or any services performed, except as to title and freedom from encumbrances and, except as herein
expressly stated and particularly, and without limiting the foregoing, there is no guarantee or warranty, express or implied, of merchantability or of fitness for any particular
purpose or against claim of infringement or the like.
Seller makes no warranty (and assumes no liability) as to function of equipment or operation of systems built to Buyer’s design or of the ability of any goods to interface,
operate or function with any portions of Buyer’s system not provided by Seller.
Seller’s liability on any claim, whether in contract, tort (including negligence), or otherwise, for any loss or damage arising out of, connected with, or resulting from the
manufacture, sale, delivery, resale, repair,replacement or use of any products or services shall in no case exceed the price paid for the product or services or any part
thereof which give rise to the claim. In no event shall Seller be liable for consequential, special, incidental or other damages, nor shall Seller be liable in respect of personal
injury or damage to property not the subject matter hereof unless attributable to gross misconduct of Seller, which shall mean an act or omission by Seller demonstrating
reckless disregard of the foreseeable consequences thereof.
Seller is not responsible for incorrect choice of models or where products are used in excess of their rated and recommended capacities and design functions or under
abnormal conditions. Seller assumes no liability for loss of time, damage or injuries to property or persons resulting from the use of Seller’s products. Buyer shall hold Seller
harmless from all liability, claims, suits and expenses in connection with loss or damage resulting from operation of products or utilization of services, respectively, of Seller
and shall defend any suit or action which might arise there from in Buyer’s name - provided that Seller shall have the right to elect to defend any such suit or action for the
account of Buyer. The foregoing shall be the exclusive remedies of the Buyer and all persons and entitles claiming through the Buyer.
ENERGENICS, CORP.

Advisories (Purpose/Contents) Page 4
Safe Operation Procedure Page 5
Safety Instructions Page 6
System Delivery Page 7
System Description & Installation Page 8
Operation Settings (Default) Page 9
Filter Replacement & Alarm Page 11
Cycle Stop Status Screens Page 10
System Care Page 12
FAQ Pages 13
Appendix A - Dosage Guidelines Page 14
INDEX

ADVISORIES
Safety Observation:
It is required for the person(s) responsible for the installation of this equipment, operators of this equipment, and operation
personnel managers to review and understand this manual.
USE OF LISTED SYSTEM / EQUIPMENT MUST COMPLY WITH INSTRUCTIONS AND SAFETY REQUIREMENTS.
This manual will serve as your general
reference guide for installation, operation, and
service of your UV-MAX device. Reference to all
parts, warranty, and support are included. This
manual covers the following product:
Purpose
Energenics Room Air Disinfector (RAD) is designed to
protect room occupants including personnel, students,
clients and patients from infection due to airborne
microbes, particularly in crowded or poorly ventilated
areas where the risk of cross infection is highest.
Energenics Room Air Disinfector is an enclosed
germicidal ultraviolet fixture that efficiently and
effectively destroys airborne bacteria, mold, viruses in
enclosed, occupied spaces and is safe for use in most
applications.
Contents
•Room Air Disinfector
Questions that are not specifically answered
by these instructions should be directed to
the manufacturer.
4

SAFE OPERATION
Safety
1. You should never look directly at a UV lamp in operation without wearing
approved safety glasses. Safety glasses should be made of any material
other than Quartz or Teflon.
Disposal of Mercury Added Lamps
Germicidal ultraviolet lamps, like standard fluorescent lamps
contain small amounts of mercury. Mercury added lamps
should not be placed in the trash. Dispose of properly. For
further information regarding the disposal and recycling
of lamps containing mercury, along with Federal and State
requirements visit LampRecycle.org.
Safety Guidelines
Exposure to UV-C light is dangerous. The adverse health
effects that may occur are erythema (sunburn) and
photokeratitis (a feeling of sand in the eyes). These effects
are considered transient. UV-C may also be carcinogenic but
since it has very limited penetrating ability, it is unlikely to
cause damage to anything beyond the outer layer of skin or
other exposed surfaces. Unfortunately, there are no
immediate warning symptoms to indicate overexposure to
UV radiation and adverse effects typically appear hours after
exposure has occurred.
The RAD is designed for zero user exposure to UV-C;
however, we will review safety factors regarding UV-C for
better knowledge and understanding.
Protective Clothing and Eyewear
It is not recommended that any personnel be subject to
direct UV-C exposure. Personnel that may be exposed to
harmful amounts and wavelengths of UV must take adequate
steps to shield themselves and in some cases limit the
duration of exposure.
If there is any potential for the eyes and face to be exposed
to UV radiation, a polycarbonate face shield stamped with
the ANSI Z87.1-1989 UV certification must be worn to protect
the eyes and face. Ordinary prescription eyeglasses may not
block UV radiation. UV certified goggles and safety glasses
will protect the eyes, but workers may suffer facial burns in
the areas not covered by the goggles or glasses.
OSHA Guidelines for Ultraviolet Exposure
There is no Occupational Safety and Health Administration
(OSHA) standard regarding exposure to ultraviolet light, but
the OSHA general duty clause states the employer must
provide a workplace free of recognized hazards that may
cause death or serious physical harm.
5

SAFETY INSTRUCTIONS
WARNING: To guard against injury, basic safety precautions should be observed,
including the following:
1. Read and follow ALL safety instructions.
2. Avoid exposure to direct or highly reflected germicidal ultraviolet rays.
(Ultraviolet rays are harmful to eyes and skin)
3. This device is intended for indoor use only.
4. Do not alter the device in any way.
5. Do not override safety interlocks.
6. Do not remove or alter safety labels or devices.
7. Do not operate damaged equipment. Replace damaged power cords immediately.
8. Do not operate equipment that is not properly grounded.
9. Keep blower inlets and outlet free of debris and blockage.
10. Do not operate without louvered panels and air filters in place.
11. Stay clear of moving parts that may cause injury.
12. Use only appropriate power sources as specified on device labeling.
13. Disconnect power source prior to performing any maintenance to avoid electrical hazard.
14. Read and follow safety notices and warnings in the disinfector labels and user touchscreen.
15. Retain this safety manual for future reference.
6

SYSTEM DELIVERY / OPERATION OVERVIEW
Time Settings Can Be Customized on Units Prior to Shipment. Consult factory for custom settings prior to unit shipped.
When you receive your Energenics Room Air Disinfector you will need to
unpack and inspect the system. Please perform the following procedure:
1. Unpack your new system and stand device upright
2. Inspect fully for damage
(If damage present, contact manufacturer prior to use at 1.239.643.2778)
3. Verify secure lamp installation within upper chamber
4. Plug in system power cord to ensure power to device
5. Do not activate unit without reading and adhering to instruction below
The Energenics Room Air Disinfector is designed to operate in the following
manner:
Start Sequence
1. Position unit in treatment space, centralized
for optimum performance operation
2. Lock wheels to secure in position
3. Plug system into appropriate power supply
4. Press on-screen "Start Cycle" to initiate
5. System is operating with blower fan and UV-C
lamps on
Audio and Visual Indicators
Audio
1. When in operation, blower fan is
audible with variation between
Low and High settings
System Display
1. Operating Status
2. Control Functions
3. Indication of System Functions
7

SYSTEM DESCRIPTION & INSTALLATION
•User safety protection
•Ease of use controls
•Industrial strength frame and structure
•Corrosion proof construction
•12,000 Hour high-output shatterproof UV-C lamps (8)
•Antimicrobial powder coating
•6" Rubber wheels with locks
Description
The Energenics Room Air Disinfector is a recirculation unit, continuously recirculating the ambient room
air through a multi-stage filtration and UV-C disinfection system and removing airborne contaminants every
time the air passes through the unit. The device is designed for maximum disinfection. Disinfection times
vary based on size of treatment space. The system design provides:
•Individual lamp and ballast monitoring
•Hospital grade filtration
•Pressure sensing filter monitoring
•Reflective stainless core
•UL controls
•6" Touchscreen control
•Proven ultraviolet treatment application
Application
Safe for use in a clean, dry environments, the Energenics Room Air Disinfector effectively destroys airborne
microbes including; bacteria, mold and viruses in enclosed spaces. In operation, air is drawn into louvered filter
panels located around the base of the fixture. The air passes into the exposure chamber where it is irradiated by 8
germicidal ultraviolet lamps. The air then pases out of the fixture through the exhaust panel located at the top of the
fixture.
Installation
Remove the Energenics Room Air Disinfector from its shipping container. Inspect the unit for damage. If noticeable
damage to the device is present, call manufacturer. Do not operate a damaged unit.
Location
The Energenics Room Air Disinfector is recommended for use in large spaces where occupants remain for
extended periods of time. This may include cafeterias, conference halls, auditoriums and the like.
WARNING: Take caution to avoid room occupant direct line-of-sight from above of device exhaust vent (top). This
may occur in auditorium or stadium type settings potentially exposing occupants to the UV-C lamps within the unit.
System
The Energenics Room Air Disinfector is completely portable. The device requires no professional installation. The
unit is equipped with locking swivel castors and can be moved to any location. Once in place, simply lock wheels,
plug into appropriate power source. The device is now ready for use.
8

OPERATION SETTINGS
High / Low Fan Selection
1. From the Home screen, select User Settings
2. Choose preferred fan speed option on System Status screen
3. Press Home to return to main screen
*Fan speed selection can be made prior to starting treatment
cycle or while the device is in operation.
Normal operation for factory default settings are covered on this page.
Safety
Read and follow safety notices and warnings on device labels and
user touchscreen. For detailed safety information, see Page 9 of this
Installation & Operation Manual.
Device Operation
1. Review system for condition
a. There should be no physical damage to the device
b. Display of the system should be clean
c. Upper and lower doors should be latched securely
2. Plug in power cord
3. Observe power to display screen
a. Advisory screen will illuminate briefly followed by Home screen
4. Start System
a. Press Start Cycle on Home screen to initiate treatment
b. Observe "UV Lamps & Blower Fan On" status screen
5. Ending Cycle
a. Select Turn Off from "UV Lamps & Blower Fan On" status screen
9

CYCLE STOP NOTIFICATIONS
1. Observe the fault on the display screen
2. Ensure all system faults have been properly addressed
3. Select Alarm Log then Home to return to main screen
4. Press Start Cycle to resume normal operation
System Faults
Should cycle deactivation occur by means of a system fault,
the following may be required to reset the system:
Fan Overload Indication
Should the blower fan overload resulting in system shut-down,
the following should occur to resume normal operation:
1. Recognize fault notification(s) on display screen
2. Disconnect power supply to device as UV lamps will remain on
3. Ensure filters are clean and there is no intake blockage
4. With power disconnected, open lower compartment and locate
black fan reset button on back of control panel
5. Close lower compartment door and secure shut
6. Plug in power cord and observe fault notification has cleared
7. No red text should be present on Alarm Log for normal device
operation to occur
8. On Home screen, press Start Cycle to resume treatment
Cycle stop displays for normal system operation are covered on this page.
10

FILTER REPLACEMENT & ALARM
The Energenics Room Air Disinfector is designed to monitor
internal pressure changes signaling increased amperage draw
of the device. Generally, increased draw is a result of:
1. Need for filter replacement / dirty filter(s)
2. Blockage to intake airflow
Alarm notification will be present on display screen should the
amperage cross the factory preset threshold. After a 10 second
sustained draw above the preset amperage threshold, the
device will shut off. To resume normal operation of the device:
1. Check to ensure there is no air intake blockage
2. Replace outdated / dirty filter(s)
3. Press Reset Filter Alarm on System Status screen
4. Press Home and Start Cycle to resume normal operation
Replacing Filter(s)
Filters should be replaced 90 days from date of installation
or when they are visibly soiled. Do not operate device with
damaged or missing filters.
To replace filters with Filter Alarm present:
1. Turn off unit at display and disconnect power supply
2. Replace filters and secure louvered vent hatches
3. Reconnect power supply
4. Select User Settings on display screen, then Reset Filter
Alarm
5. Press Home and Start Cycle to resume operation
6. Alarm notifications should be cleared from display(s)
11

SYSTEM CARE
WARNING: To guard against injury, basic safety precautions should be observed,
including the following:
1. Read and follow ALL instructions.
2. Avoid exposure to direct or strongly reflected germicidal ultraviolet rays.
3. Disconnect power source prior to performing any maintenance to avoid electrical hazard.
4. Do not alter the device in any way.
5. Do not operate damaged equipment.
6. Stay clear of moving parts that may cause injury.
System Care
The Energenics Room Air Disinfector is designed for repeat performance with consistent
results. Based on system designs, minimal maintenance is required. Adherence to the
following regular service of your system should provide years of disinfection.
Each Duty Cycle
1. Inspect the system for damage
2. Clean exterior of device as needed
Monthly
1. Inspect system interior for loose debris
2. Remove debris if present avoiding contact with lamps
90 Days
1. Replace filters and clean intake grills
2. Gently wipe down UV lamps with soft cloth to remove dust build-up
Service Maintenance
Should a service issue arise that is unable to be remedied by the methods on the previous
pages of this manual, it is recommended that the machine be placed "Out-of-Order" with
power source disconnected.
For issues concerning lamps or ballasts, please contact the manufacturer:
•[phone]
•[e-mail]
12

Q: What should I do if the unit will not turn on?
A: Verify there is power to the system by observing that all time sequence buttons are illuminated.
A: Verify the Emergency Stop is not engaged
Q: My system will turn on, but the lamps will not come on.
A: Verify the start cycle button is pressed
A: Inspect the lamp for age or physical failure
A: Contact Energenics Support for further information
Q: What should I do if the unit will not come on?
A: Verify there is power to the system
A: Verify the display reads correctly
A: Verify the doors are properly latched and the interlock safety interrupter has not been tripped
Q: What should I do if the lamps turn on but the fan doesn't?
A: Check the Overload Reset
A: Contact Energenics for further information 1.239.643.1711
Q: My system will turn on, but the lamps will not come on.
A: Verify the Start Cycle button was pressed
A: Inspect the lamps for physical failure (breakage)
A: Contact Energenics for further information if needed
Q: How do I clear the Replace Filter notification?
A: Ensure the vent intakes are not blocked
A: Replace damaged or dirty filters
A: Press the Rest Filter Alarm button on the User Settings screen
Q: What should I do if I have a ballast or lamp alarm notification?
A: Contact Energenics for further information 1.239.643.1711
FAQ'S & TROUBLESHOOTING
13

Energenics Corp.
1470 Don Street
Naples, FL 34104
energenics.com
1.239.643.1711
APPENDIX A: DOSE GUIDELINES
CORPORATION
®
Room
Dimensions
(feet)
Room Square
Footage
Room
Cubic
Feet
Low
Fan
ACH
High
Fan
ACH
Room
Cubic
Feet
Low
Fan
ACH
High
Fan
ACH
Room
Cubic
Feet
Low
Fan
ACH
High
Fan
ACH
10 x 10 100 800 67.5 82.5 1,000 54.0 66.0 1,200 45.0 55.0
15 x 15 300 1,800 30.0 36.6 2,250 24.0 29.3 2,700 20.0 24.4
20 x 20 400 3,200 16.9 20.6 4,000 13.5 16.5 4,800 11.3 13.8
25 x 25 625 5,000 10.8 13.2 6,250 8.6 10.6 7,500 7.2 8.8
30 x 30 900 7,200 7.5 9.2 9,000 6.0 7.3 10,800 5.0 36.7
35 x 35 1,225 9,800 5.5 6.7 12,250 4.4 5.4 14,700 3.7 4.5
40 x 40 1,600 12,800 4.2 5.2 16,000 3.4 4.1 19,200 2.8 3.4
45 x 45 2,025 16,200 3.3 4.1 20,250 2.7 3.3 24,300 2.2 2.7
50 x 50 2,500 20,000 2.7 3.3 25,000 2.2 2.6 30,000 1.8 2.2
Area Measurements
*ACH calculated using 900 CFM (low fan speed) and 1,100 CFM (high fan speed) inputs with MERV 14 filtration.
ENERGENICS ROOM AIR DISINFECTOR
AIR CHANGES PERHOUR (ACH) CHART
8' Ceiling 10' Ceiling 12' Ceiling
