ENFORCER E-9622-4B25 User manual

SECO-LARM®U.S.A., INC.
INSTALLATION MANUAL
ENFORCER®
Page 8
Curtain/Barrier Sensors Installation Manual
®PICTN1
Curtain/Barrier Sensors
(E-9622-4B25 shown)
E-9622-4B25 -- 4-Beams
E-9644-6B25 -- 6-Beams
E-9660-8B25 -- 8-Beams
E-9680-10B25 -- 10-Beams
Range: 50 ft. indoor, 25 ft. outdoor
Dimensions:
Side View
1
5
/
16
”(33.5mm)
1
7
/
32
” (30.6mm)
7
/
8
”(22.3mm)
3
/
4
” (19.6mm)
22.5” (57cm) -- E-9622-4B25
44.5” (113cm) -- E-9644-6B25
60.1” (153cm) -- E-9660-8B25
79” (201cm) -- E-9680-10B25
Typical
Door/Window Frame
Windows
Garages / Gates / Walls
Fence Tops
(Indoor) Skylights
E-9622-4B25 E-9644-6B25 E-9660-8B25 E-9680-10B25
89mA 94mA 102mA 110mA
73mA 79mA 92mA 100mA
221/2” x 15/16” x 7/8”44
1/2” x 15/16” x 7/8”60 1/8” x 15/16” x 7/8” 79” x 15/16” x 7/8”
0.5~32.5mS 0.5~48.5mS 0.5~60mS 0.5~70mS
Indoor: 50’ (16m), outdoor: 25’ (8m)
Simultaneous break of 2 adjacent beams or any single beam (programmable)
NO./NC. relay output, 1A @ 12 ~ 24VDC
-49°~131° F (-45°~55° C)
(On): powered, aligned properly*
(Flashing): beam is broken or unaligned*
(Off): no power*
*Depending upon how programmed
IP65 / A1 alloy
Included
Specifications:
Standby -- 12~24VDC
Active -- 12~24VDC
Dimensions
Response time
Maximum Range
Detection method
Output
Operating temperature
Attenuation LED
Enclosure / Case
Mounting bracket
CurtainSensor1206.pmd
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in
normal service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM’s obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair,
or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such
equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser’s exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM’s option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal
or property damages of any kind to the purchaser or anyone else.
NOTICE
The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM policy is one
of continual development and improvement. For this reason, SECO-LARM reserves the right to change specifications without notice.
SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2007 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part,
without the written permission of SECO-LARM.
SECO-LARMSECO-LARM
SECO-LARMSECO-LARM
SECO-LARM®U.S.A., Inc.U.S.A., Inc.
U.S.A., Inc.U.S.A., Inc.
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: [phone] Fax: [phone]
Website: www.seco-larm.com
E-mail: sales
@ seco-larm.com

Curtain/Barrier Sensors Installation ManualCurtain/Barrier Sensors Installation Manual
SECO-LARM U.S.A., Inc.
Page 2 Page 7
Fig. 1: Typical Installations
Typical
Door/Window
Frame
Windows
Indoor Fence Tops
Skylights
Garages / Gates / Walls
Mounting
Hardware
Manual
L-Bracket x 4
Transmitter
Receiver
What’s Included:
Possible cause
!Power not connected, or power wires cut
!Transmitter jumper “JMP1” is programmed
in the open position
Power not connected, or power wires cut
Receiver jumper “JMP1” is programmed in the open
position
Transmitter and receiver are out of alignment
Mounted too close to a shiny surface which causes
the beam to reflect in multiple angles
!Transmitter and receiver are out of alignment
!The cover on the end cap of the receiver with the
tamper button is not snapped in place, or the
tamper button is not in the right position
!Interference from other sensors
!Wind blowing leaves into beam
!Rain water running into the beam
!Other interference outdoors
Possible solution
!Test the power and ground wire with a
voltage meter to ensure power is
connected and is of the correct voltage.
!Change the programming, or if no LED
is desired, leave the jumper in the open
position.
Test the power and ground wire with a voltage
meter to ensure power is connected and is of
the correct voltage.
Change the programming, unless having the
LED not remain turned ON is better for that
installation.
Re-align the transmitter and receiver.
Remount the curtain sensor, or repaint the
surface to cut down on the reflection.
!Re-align the transmitter and receiver.
!Check that the tamper button and the cover
for the tamper button are mounted correctly.
!Re-install so that one sensor does not
interfere with another sensor.
!Cut back leafy vegetation, and/or
!Program for two-beam use (see table 2).
!Do not mount under the edge of the roof.
!Mount under a roof or shelter.
Problem
Transmitter LED never
turns ON
Receiver LED never turns
ON
Receiver LED does not
turn ON unless the sensor
is triggered
Receiver LED flashes all
the time
Does not trigger when
beam is broken
Receiver continuously
triggers the alarm
False alarm
Table 3: Troubleshooting
Table of Contents:
What’s Included ------------------------------------------- 2
Typical Installations - Fig. 1-------------------------- 2
Features ------------------------------------------------------ 3
Choosing a Location ------------------------------------- 3
Beware Natural Interference - Fig. 2 ------------- 3
Orientation to Sun - Fig. 3 ---------------------------- 3
Orientation - Fig. 4 --------------------------------------- 3
Forming Barriers - Fig. 5 ------------------------------- 4
Mounting the Curtain Sensor ------------------------ 4
Running the Wires ----------------------------------------4
Connecting the Wires -----------------------------------4
Maximum Wire Length - Table 1 --------------------- 4
Maximum Distance - Fig. 6 ---------------------------- 4
Wiring the Receiver - Fig. 7 -------------------------- 4
Wiring the Transmitter - Fig. 8----------------------- 5
Removing the Lens Caps ------------------------------- 5
Removing the Lens Caps - Fig. 9 -------------------- 5
Programming - Table 2 ---------------------------------- 5
Connecting One or More Sensors - Fig. 10 -----6
Connecting Multiple Curtain Sensors------------- 7
Mount Transmitter & Receiver, & Test Sensor -7
Tamper Protection ----------------------------------------7
Troubleshooting - Table 3 ------------------------------ 7
Dimensions -------------------------------------------------- 8
Specifications ----------------------------------------------8
Warranty ------------------------------------------------------8
Connecting Multiple Curtain Sensors
Several units can be connected together in parallel to
the same power supply output and alarm input of an
alarm control panel, as shown in fig. 10.
Mount the Transmitter and Receiver, and Test
the Sensor
1. Temporarily mount the transmitter and receiver to
where they are expected to be mounted, so the
mounting position can be changed if necessary.
2. Connect the transmitter and the receiver.
3. Once it is powered up, test the curtain sensor by
breaking two adjacent beams or any single beam
(depending on how programmed).
4. The curtain sensor also has red LEDs which can be
used for testing purposes (see Table 2).
5. After the curtain sensor is tested and aligned,
permanently mount it.
6. After it is mounted, test the curtain sensor again.
Tamper Protection
The receiver and the transmitter both have a tamper
switch on one end to protect against someone
attempting to open the unit. However, there is no
separate tamper output to the alarm control panel.
Instead, the alarm output is triggered if the cover of
the end cap with the tamper button is removed, if the
transmitter or receiver is moved out of alignment, or if
power is disconnected.

Curtain/Barrier Sensors Installation ManualCurtain/Barrier Sensors Installation Manual
SECO-LARM U.S.A., Inc. Page 3
Fig. 3: Orientation to Sun
Page 6
Fig. 4: Orientation
Fig. 2: Beware Natural Interference
NO!
Terminal
Block
OK
Terminal
Blocks Terminal
Block
Rain running directly
off roof thru beams
Tree or shrub leaves
passing thru beams
* Note: Only if unavoidable,
mount so transmitter, not
receiver, faces the sun
Note: If the wires will be
running out the end,
place sensors so wires
are at the bottom. If
sensors must be placed
so wires are at top, seal
the opening with
silicone to prevent
water from leaking in.
{
Fig. 10: Connecting One or More Sensors
Please reference fig. 7 & 8 for terminal blocks.
Control panel
(12VDC)
}Power
}Alarm signal
Transmitter Receiver
Control panel
(12VDC)
}Power
}Alarm signal
Transmitter Receiver
Example connection 3 - In-line, Single Alarm Channel
Transmitter Receiver
Control panel
(12VDC)
}Power
}Alarm (ch. 1)
Transmitter Receiver
Example connection 2 - Dual Sensors, Separate Alarm Channels
Transmitter
}Alarm (ch. 2)
Example connection 1 - Standard
Receiver
*See “Choose a Location” below for details on mounting the sensor outdoors.
OK*
NO!
Tx Rx
Rx Tx
Features:
!Install on windows, doorways, skylights, fence tops,
and any place where space is limited.
!
Perfect for indoor and outdoor* perimeter security.
!Slim-line design (7/8” x 15/16”).
!4, 6, 8, or 10 separate photoelectric beam sensors.
Programmable trigger upon simultaneous
breaking of any single or 2 adjacent beams.
!Rugged aluminum construction.
!Anti-tamper circuit for use when power is cut or
end cap is removed.
!No synchronizing wires required.
!N.O./N.C. relay output.
!LED alignment indicator.
!L-brackets and mounting hardware included.
Important
Do not connect to power until the sensor is
completely installed and the installation has been
double-checked.
If it becomes necessary to replace a sensor for
maintenance purposes, always replace both the
transmitter and receiver at the same time.
Choose a Location
When used outdoors, place the curtain sensor
under a roof or shelter. This will reduce the
chance of false alarms caused by rain or snow.
To prevent erratic operation and/or false alarms:
!Wind will not directly cause false alarms, but
could cause leaves or similar objects to fly or
wave into the beams. Do not mount near trees,
bushes, or other leafy vegetation (see fig. 2).
!
Do not mount where water which runs off the roof
might break the beam (see fig. 2). In such a case,
the sensor must be sheltered.
!Do not mount near reflective surfaces, as this
could prevent the sensor from working properly.
!Do not mount where the transmitter or receiver
could be splashed by water or mud.
!Do not mount where the unit could be suddenly exposed
to a bright light, such as a floodlight or a passing
automobile’s headlight.
!Do not let sunlight or any direct beam of light shine
directly on curtain beam sensor. If unavoidable, mount
so the transmitter, not the receiver, faces the sun (see
fig. 3).
!Do not mount where animals or other objects could
accidently break the beams.

Curtain/Barrier Sensors Installation ManualCurtain/Barrier Sensors Installation Manual
SECO-LARM U.S.A., Inc.
Fig. 6: Maximum
Distance Between the
Transmitter and Receiver
Page 4 Page 5
Fig. 5: Forming Barriers
Outdoors: 25’ (8m)
Indoors: 50’ (16m)
Max. Distance
OK
NO!
TT
R R
T R
RT
OKNO!
T
T
R
R
T
R
R
T
Parallel barriers Consecutive barriers
Fig. 7: Wiring
the Receiver
Fig. 8: Wiring
the Transmitter
Fig. 9: Removing the Lens Caps
+
To Alarm Control Panel
N.C.
-
COM + N.O. or
COM + N.C.
}
COM
N.O.
To Alarm
Control Panel
12 ~ 24VDC
Mounting the Curtain Sensor
1.Find a suitable location (see fig. 1):
a.The transmitter and receiver can be mounted at any
angle as long as they are parallel to each other and
directly facing each other, and as long as the wires
come out of the same ends of both units (see fig. 4).
b.
If multiple curtain sensors are set up to form longer or
deeper barriers, mount so that one transmitter is not
facing multiple receivers (see fig. 5).
c. The transmitter and receiver must not be separated by
more than the maximum range (see fig. 6).
2.Mount the transmitter and the receiver in such a way
that surface-mounted wires do not come out from
above the units. This is to prevent water from entering
via the wire holes. If this is unavoidable, use silicone
to completely cover the area where the wires come out
the holes to prevent water from entering (see fig. 4).
3.
Once a suitable mounting location has been found,
remove the small covers of the end caps, and pull the
tamper buttons out of the end caps (one per transmitter
or receiver) and locate the mounting holes.
Using these holes as a template, mark their location
on the wall with a pencil.
4.Connect the wires (see figs. 7 and 8) before
permanently mounting the units to the wall.
Running the Wires
Run four wires (2 x power and 2 x alarm signal) from the
alarm control panel to the receiver of the curtain sensor.
Shielded cable is strongly suggested. See Table 1 for
maximum wire length. Two power wires must also be run
to the transmitter.
It may be more convenient to connect the two power
wires of the transmitter to the receiver’s power wires.
In this case, run six wires to the receiver: two wires
to the power source, two for the alarm signal and
two to the transmitter.
NOTE: If burying the wires is required, make sure to
run them through electrical conduit. Shielded cable
is strongly suggested.
NOTE: If the wires are run along the wall, the use of
an armored cable is strongly suggested. (See
“Mounting the Curtain Sensor,” point 2, for further
considerations.)
Connecting the Wires
1.Receiver:
a.Pull the end cap with the red wire leads off the
receiver, and slide the printed circuit board out
far enough to expose the wiring block.
b.Run the four wires (or six wires, if connecting
the transmitter’s power wires to the receiver)
through one or more of the three round
knockout holes in the end cap near where the
tamper button wires run, and connect them to the
wiring block (see figs. 7 and 8).
c.Program the receiver (see Table 2).
d.Carefully push the printed circuit board back into
the case and reinsert the end cap.
e.Reinsert the cap over the tamper button and
small tamper cap.
2.Transmitter:
a.Pull the end cap with the red wire leads off the
transmitter, and slide the printed circuit board out
far enough to expose the wiring block.
b.Run the two power wires through one or more of
the three round knockout holes in the end cap
near where the tamper button wires run, and
connect them to the wiring block (see fig. 8).
c.Program the transmitter (see Table 2).
d.Carefully push the printed circuit board back into
the case and reinsert the end cap.
e.Reinsert the cap over the tamper button and
small tamper cap.
+
-
To Alarm
Control Panel
12 ~ 24VDC
Note: Screw the wires tightly to avoid slipping off
the terminals, but not so tight that they
break.
Note: Unused terminal screws should be tightened.
Note: Grounding may be necessary, depending on
the location.
Removing the Lens Caps (for outdoor
use only)
For best results when the curtain sensor is mounted
outdoors, remove the transmitter lens caps.
(Important: DO NOT remove the receiver lens caps!)
To remove the lens caps (see fig. 9):
1.Slide out the circuit board of the transmitter (see
the “Connecting the Wires” section for the
procedure).
2.Carefully pull the lens caps off of all the lenses
(8 for the E-9622-4B25, 12 for the E-9644-6B25,
16 for the E-9660-8B25, 20 for the E-9680-10B25).
3.Slide back in the printed circuit board (see the
“Connecting the Wires” section for the procedure).
Table 1: Maximum Wire Length
Voltage Gauge Max. length
12VDC AWG 22 1800 feet (550 meters)
12VDC AWG 20 2600 feet (800 meters)
24VDC AWG 22 2600 feet (800 meters)
24VDC AWG 20 3900 feet (1,200 meters)
Number of beams
to interrupt to
trigger receiver.
Jumper labeled: “JMP2 .”
Table 2: Transmitter and Receiver Programming
Receiver Transmitter
Receiver triggers if any
beam is interrupted.
Receiver triggers only if
2 adjacent beams
interrupted at same
time.
!LED ON if power is present
and beams are aligned.
!LED flashes when beams
are broken.
!LED ON
if sensor is
triggered.
!LED flashes when
beams are broken.
LED operation
Jumper labeled: “JMP1”
LED ON if
power is
present.
LED OFF at
all times.
1 Beam 2 Beams
LED
ON
LED
OFF
1 C 2 1 C 2
