ENFORCER No Touch SD-927PKC-NEQ User manual

SD-927PWCQ
(English / Español / Francais)
SD-927PKC-NEQ (English)
SD-927PKC-NSQ (Español)
SD-927PKC-NFQ (Francais)
Features:
•Range up to 4” (10cm). Range for
SD-927PWCQ is up to 2” (5cm).
•Stainless steel or white plastic
single-gang plate.
•3A relay, triggers minimum 0.5 sec or as
long as hand is near the sensor.
The ENFORCER No Touch Request-To-Exit Sensor uses IR technology to request egress from a protected
area or activate a device with the simple wave of a hand. Since it is No Touch, this sensor is ideal for use
in hospitals, clinics, labs, cleanrooms (to reduce the risk of contamination), schools, factories, or offices.
Note: Products with model number that ends with "Q" or which have a round green “Q” sticker represent RoHS compliant products.
,
•LED illuminated sensor area for
easy identification.
•Quick connect screwless terminal block.
•Selectable LED colors (turns from red
to green or green to red) to show
sensor activated.
,
ENFORCER
No Touch
Request-To-Exit Sensor
Manual

Installation:
1. Run four wires through the wall to a single-gang
back-box.
2. Connect the four wires from the back-box to the quick
connect screwless terminal according to Fig. 1.
3. Screw the plate into the back-box, taking care not to crimp
thewires.
4. Remove clear protective film from the sensor before use.
2
Pasting the Decals (For SD-927PWCQ model only)
1. TheSD-927PWCQmodelincludes“NOTOUCH”and “EXIT”
decals in English, French and Spanish.
2. Select the appropriate decals according to your requirements.
3. Remove the back sheet of the decal and then set it on the
desired location. Use the thin lines on the left and right sides of
the text on the decals for alignment, see Fig. 2.
4. After the decal has been placed and set in the desired location,
scratch the front of the decal to transfer the text onto the
faceplate.
Note: The decal needs at least 24 hrs. to fully dry & bond with the
surface. Do not touch or scratch until the decal is fully dry.
11/8”
(29mm)
21/8”
(55mm)
Specifications:
12VDC
50mA @ 12VDC
Form-C dry contact, 3A@24VDC
10mS
0.5 sec. or as long as sensor is triggered
-4O~ 131OF (-20O~ 55OC)
Power
Current drain (max)
Relay type
Response time
LEDs
Output time
Range
Temperature range
Weight
SD-927PKC-NEQ
SD-927PKC-NFQ
SD-927PKC-NSQ SD-927PWCQ
4" (10cm)
Standby
2" (5cm)
3oz (85g) 2.5oz (70g)
Red*
Triggered Green*
Fig. 1 –Connections (under
back cover)
NO TOUCH
EXIT
Fig. 2 – Decal Alignment
AdjustingtheLEDColor
1. The LED color factory default setting is red (standby) and
green(triggered).
2. To reverse the LED color visual indicator to green (standby)
and red (triggered), remove the jumper located at the right
side of the terminal block as shown in Fig. 1.
*Reversible via jumper
NO TOUCH REQUEST-TO-EXIT SENSOR Installation Manual
SECO-LARM U.S.A., Inc.
Power Input Relay Output (3A max)
( ) ( )
NC COM NO
Jumper
(forLEDcoloradjustment)

Relay output
NC COM NO
12VDC
Power input
( ) (+)
EAP-5D1Q
AccessControl
PowerSupply
ENFORCERSeries
Electric Strike
2. Installation with Electric Doorstrike (Fail-Secure)
Relay output
NC COM NO
12VDC
Power input
( ) (+)
3. Installation with Electromagnetic Lock and Keypad
SK-1011-SQ(DigitalKeypad)
EAP-5D1Q
AccessControl PowerSupply
Example Installations:
1. Installation with Electromagnetic Lock (Fail-Safe)
EAP-5D1Q
AccessControl
PowerSupply
ENFORCERSeries
ElectromagneticLock
(+)
( - )
Tamper
O/P(N.C.)
NO
COM
NC
EGRESS
12VDC
Powerinput
( - )( )
Relay output
NC COM NO
ENFORCERSeries
ElectromagneticLock
(+)
( - )
3
NO TOUCH REQUEST-TO-EXIT SENSOR Installation Manual

MiSD927PKC-NxQ_122110.pmd
SECO-LARM U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: [phone] Fax: [phone]
Website:www.seco-larm.com
E-mail:sales
@ seco-larm.com
PITSW3
®
WARRANTY This SECO-LARM product is warranted against defects in material and
workmanship while used in normal service for a period of one (1) year from the date of sale to the
original consumer customer.
SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is
returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical
misuse or abuse, neglect, repair, or alteration, improper or abnormal usage, or faulty installation,
or if for any other reason SECO-LARM determines that such equipment is not operating properly
as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser’s exclusive remedy, shall be limited to
replacement or repair only, at SECO-LARM’s option. In no event shall SECO-LARM be liable for
any special, collateral, incidental, or consequential personal or property damages of any kind to
the purchaser or anyone else.
WARNING: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure
could cause a dangerous electric shock, damage the device, and void the warranty.
NOTICE: The information and specifications printed in this manual are current at the time of
publication. However, the SECO-LARM policy is one of continual development and improvement.
For this reason, SECO-LARM reserves the right to change specifications without notice.
SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2011 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be
reproduced or copied, in whole or in part, without the written permission of SECO-LARM.
4
Care and Cleaning for the SD-927P Series No-Touch:
The SD-927P Series is designed for inside use to match most interiors. The sensor and included
decals (SD-927PWCQ only) require special care to ensure reliability and a long operating life.
1. Usea soft,clean clothfor cleaning.Rough materialsmay scratchthe decalsof theSD-927PWCQ.
2. Be careful not to spray liquids directly on the unit.
3. When cleaning, spray the cleaning solution onto the cleaning cloth instead of the unit.
4. Be sure to wipe off any excess liquid from the sensor. Wet spots or areas may affect the
sensor’s performance.
5. Repeated exposure to strong cleaning chemicals may damage the decals included with the
SD-927PWCQ. Use the mildest type of cleaner available.
NO TOUCH REQUEST-TO-EXIT SENSOR Installation Manual
