EnGenius EOC5611P User manual

0
WirelessOutdoor
ClientBridge/AccessPoint
EOC5611P



UserManual
Version:1.0

1
TableofContents
1PRODUCTOVERVIEW ...........................................................................................................................................................3
1.1FEATURE.........................................................................................................................................................................3
1.2BENEFITS........................................................................................................................................................................ 5
1.3PACKAGECONTENTS ......................................................................................................................................................... 6
1.4SYSTEMREQUIREMENT ..................................................................................................................................................... 6
1.5HARDWAREOVERVIEW ..................................................................................................................................................... 6
2EOC5611PMULTI‐FUNCTIONINSTRUCTIONGUIDE.............................................................................................................8
2.1ACCESSPOINT .................................................................................................................................................................8
2.2ACCESSPOINTWITHWDSFUNCTION.................................................................................................................................. 8
2.3CLIENTBRIDGE ................................................................................................................................................................9
2.4WDSBRIDGE..................................................................................................................................................................9
2.5CLIENTROUTER .............................................................................................................................................................10
3COMPUTERSETTINGS ........................................................................................................................................................ 11
3.1ASSIGNASTATICIP......................................................................................................................................................... 11
3.2LOGGINGMETHOD......................................................................................................................................................... 12
4WIRELESSSETTINGS ...........................................................................................................................................................13
4.1SWITCHINGOPERATIONMODE(SYSTEM→SYSTEMPROPERTIES).........................................................................................13
4.2WIRELESSSETTINGS .......................................................................................................................................................14
4.2.1AccessPointMode → WirelessNetwork...................................................................................................... 14
4.2.2ClientBridgeMode → WirelessNetwork .....................................................................................................16
4.2.3WDSBridgeMode → WirelessNetwork ......................................................................................................17
4.2.4ClientRouterMode → WirelessNetwork..................................................................................................... 19
4.3WIRELESSSECURITYSETTINGS .......................................................................................................................................... 20
4.3.1WEP.................................................................................................................................................................20
4.3.2WPA‐PSK ......................................................................................................................................................... 21
4.3.3WPA2‐PSK .......................................................................................................................................................21
4.3.4WPA‐PSKMixed............................................................................................................................................... 22
4.3.5WPA ................................................................................................................................................................23
4.3.6WPA2 ..............................................................................................................................................................24
4.3.7WPAMixed...................................................................................................................................................... 25
4.3.8RadiusAccounting...........................................................................................................................................26
4.4WIRELESS→WIRELESSADVANCEDSETTINGS ................................................................................................................... 26
4.5WIRELESS→WIRELESSMACFILTER...............................................................................................................................28
4.6WIRELESS→WDSLINKSETTINGS..................................................................................................................................29
5LANSETTINGS.....................................................................................................................................................................30

2
5.1SYSTEM→IPSETTINGS ................................................................................................................................................ 30
5.2SYSTEM→SPANNINGTREESETTINGS.............................................................................................................................. 31
6ROUTERSETTINGS..............................................................................................................................................................32
6.1ROUTER→WANSETTINGS .......................................................................................................................................... 32
6.1.1WANSettings → StaticIP .............................................................................................................................32
6.1.2WANSettings → DHCP(DynamicIP)............................................................................................................35
6.1.3WANSettings → PPPoE(Point‐to‐PointProtocoloverEthernet).................................................................. 37
6.1.4WANSettings → PPTP(Point‐to‐PointTunnelingProtocol).......................................................................... 39
6.2ROUTER→LANSETTINGS ............................................................................................................................................41
6.3ROUTER→VPNPASSTHROUGH....................................................................................................................................42
6.4ROUTER→PORTFORWARDING .....................................................................................................................................43
7INFORMATIONSTATUS .......................................................................................................................................................44
7.1STATUS→MAIN ......................................................................................................................................................... 44
7.2STATUS→WIRELESSCLIENTLIST....................................................................................................................................46
7.3STATUS→SYSTEMLOG.................................................................................................................................................47
7.4STATUS→WDSLINKSTATUS ........................................................................................................................................ 48
7.5STATUS→CONNECTIONSTATUS ..................................................................................................................................... 49
7.6STATUS→DHCPCLIENTTABLE ..................................................................................................................................... 50
8MANAGEMENTSETTINGS ..................................................................................................................................................51
8.1MANAGEMENT→ADMINISTRATION ............................................................................................................................... 51
8.2MANAGEMENT→MANAGEMENTVLAN......................................................................................................................... 53
8.3MANAGEMENT→SNMPSETTINGS ...............................................................................................................................54
8.4MANAGEMENT→BACKUP/RESTORESETTINGS .................................................................................................................55
8.5MANAGEMENT→FIRMWAREUPGRADE ..........................................................................................................................56
8.6MANAGEMENT→TIMESETTINGS ..................................................................................................................................57
8.7MANAGEMENT→LOG .................................................................................................................................................58
8.8MANAGEMENT→DIAGNOSTICS..................................................................................................................................... 59
9NETWORKCONFIGURATIONEXAMPLE.............................................................................................................................. 60
9.1ACCESSPOINT ...............................................................................................................................................................60
9.2CLIENTBRIDGEMODE ....................................................................................................................................................61
9.3WDSBRIDGEMODE ......................................................................................................................................................61
9.4CLIENTROUTER .............................................................................................................................................................62
10VLANCONFIGURATIONGUIDE.........................................................................................................................................64
APPENDIXA–FCCINTERFERENCESTATEMENT....................................................................................................................68



3

1ProductOverview
ThankyouforusingEOC5611P.Itisapowerful,enhanced,enterprisescaleproductwith4+1
multi‐functionsAccessPoint,AccessPointwithWDSfunction,ClientBridge,WDSBridge,andClient
Router.

EOC5611PiseasilytoinstallalmostanywherewithPoweroverEthernetforquickoutdoorinstallation.
ExternalN‐typeantennaprovidesbetterwirelesssignalqualityandtheantennaisupgradeable.
EOC5611Puses5Gbandand2.4Gwirelesssignaltoavoidinterferenceofmostdigitalsignalsuchas
mobilephone.

EOC5611Pcanmanagepowerlevelcontrol,Narrowbandwidthselection,Trafficshapingand
Real‐timeRSSIindicator.EOC5611PisfullysupportofsecurityencryptionincludingWI‐FiProtected
Access(WPA‐PSK/WPA2‐PSK),64/12 8/152‐bitWEPEncryptionandIEEE802.1xwithRADIUS
Accounting.

Auction:Theinternalantennaisonlyavailablefor5Gbandwirelessnetwork.
1.1Feature
ThefollowinglistdescribesthedesignoftheEOC5611Pmadepossiblethroughthepowerand
flexibilityofwirelessLANs:

a) Difficult‐to‐wireenvironments
Therearemanysituationswherewirescannotbelaideasily.Historicbuildings,older
buildings,openareasandacrossbusystreetsmaketheinstallationofLANseither
impossibleorveryexpensive.
b) Temporaryworkgroups
Considersituationsinparks,athleticarenas,exhibitioncenters,disaster‐recovery,
temporaryofficesandconstructionsiteswhereonewantsatemporaryWLANestablished
andremoved.
c) Theabilitytoaccessreal‐timeinformation
Doctors/nurses,point‐of‐saleemployees,andwarehouseworkerscanaccessreal‐time
informationwhiledealingwithpatients,servingcustomersandprocessinginformation.
d) Frequentlychangedenvironments
Showrooms,meetingrooms,retailstores,andmanufacturingsiteswherefrequently

4
rearrangetheworkplace.
e) WirelessextensionstoEthernetnetworks
Networkmanagersindynamicenvironmentscanminimizetheoverheadcausedbymoves,
extensionstonetworks,andotherchangeswithwirelessLANs.
f) WiredLANbackup
NetworkmanagersimplementwirelessLANstoprovidebackupformission‐critical
applicationsrunningonwirednetworks.
g) Training/Educationalfacilities
Trainingsitesatcorporationsandstudentsatuniversitiesusewirelessconnectivitytoease
accesstoinformation,informationexchanges,andlearning.
Advantage
HighOutputPowerupto
26dBmExtendedexcellentRangeandCoverage
IEEE802.11a/b/g
CompliantFullyInteroperablewithIEEE802.11a/b/gcompliantdevices
Detachableantenna
support(SMAType)Collocatewithanyantennaforuser’senvironment
4+1Multi‐FunctionUserscanusedifferentmodeinvariousenvironment
Point‐to‐point,
Point‐to‐multipoint
WirelessConnectivity
Letuserstransferdatabetweentwobuildingsormultiplebuildings
ChannelBandwidth
SelectionUsingdifferentbandwidthtoreachvarieddistance
SupportRSSIIndicator
(CBmode)UserscanselectthebestsignaltoconnectwithAPeasily
Power‐over‐EthernetFlexibleAccessPointlocationsandcostsavings.EOC5611Pmustuses
theadapterprovidedinthepackage.
SupportMulti‐SSID
function(4SSID)inAP
mode
Allowclientstoaccessdifferentnetworksthroughasingleaccess
pointandassigndifferentpoliciesandfunctionsforeachSSIDby
manager
WPA2/WPA/WEP/IEEE
802.1xsupportFullysupportalltypesofsecuritytypes.
MACaddressfilteringin
APmodeEnsuressecurenetworkconnection
PPPoE/PPTPfunction
support(APRouter/CR
mode)
EasytoaccessinternetviaISPserviceauthentication
SNMPRemote
Configuration
Management
HelpadministratorstoremotelyconfigureormanagetheAccess
Pointeasily.
QoS(WMM)supportEnhanceuserperformanceanddensity

5

1.2Benefits
AccessPointModeUsethisfeaturetosetuptheaccesspoint’sconfigurationinformation.
Ithassupportadjustingtransmitpowerandchannel.Clientcanaccess
thenetworkwithdifferentregulatorysettingsandautomatically
changetothelocalregulations.
ClientBridgeModeUsethisfeaturetoconnecttoanAccessPointandenjoythegreat
speedofsurfinginternet.
WDSBridgeModeUsethisfeaturetolinkmultipleAPsinanetwork.Allclientsassociated
withanyAPscancommunicateeachotherlikeanad‐hocmode.
ClientRouterModeThisfeaturefunctionscompletelyoppositebutsimilarlywithAP
RouterMode.ClientRouterconnectedtoanAPwirelesslyand
transmitsinternetconnectionprotocolthroughAPtoaccessthe
internet.
MultipleSSIDsEOC5611Psupportsupto4SSIDsonyouraccesspoint.Thefollowing
optionscanbesettoeachSStoeachSSID:
-SSIDforpublicorprivatenetwork
-Authenticationisfullysupported
-VLANidentifier
-Radiusaccountingidentifier
-Profileisolationforinfrastructurenetwork
VLANSpecifyaVLANnumberforeachSSIDtoseparatetheservicesamong
clients.
QoSUsethisfeaturetolimittheincomingoroutgoingthroughput.
Wi‐FiProtectAccessWi‐FiProtectAccessisastandard‐basedinteroperablesecurity
enhancementthatincreasesthelevelofdataprotectionandaccess
controlforexistingandfuturewirelessLANsystem.Itiscompatible
withIEEE802.11istandardWPAleveragesTKIPand802.1Xfor
authenticatedkeymanagement.


6

1.3PackageContents
Openthepackagecarefully,andmakesurethatnoneoftheitemslistedbelowaremissing.Donot
discardthepackingmaterials,incaseofreturn;theunitmustbeshippedinitsoriginalpackage.

h1*WirelessOutdoorAccessPoint/ClientBridge(EOC5611P)
h1*24V/1APowerAdapter
h1*EthernetCable
h1*QIG
h1*CD(UserManual)
h2*5dBi5GHzDipoleAntennas

Auction:UsingotherPowerAdapterthantheoneincludedwithEOC5611Pmaycausedamageofthe
device.

1.4SystemRequirement
Thefollowingconditionsaretheminimumsystemrequirement.
hAcomputerwithanEthernetinterfaceandoperatingunderWindowsXP,Vista,7orLinux.
hInternetBrowserthatsupportsHTTPandJavaScript.

1.5HardwareOverview
HardwareSpecification
MCU/RFAtherosAR2313+AR5112
Memory32MBSDRAM
Flash8MB
PhysicalInterface1x10/100FastEthernetRJ‐45
1xResetButton
1xAntennaSwitch(InternalandExternalSwitch)
2xSMAConnector(Oneisfor2.4GHzandanotherisfor5GHz)
LEDindicatorsPower/Status
LAN(10/100Mbps)
WLAN(Wirelessisup)
3xLinkQuality(ClientBridgemode)
•Green:GoodQuality
•Yellow:MarginallyAcceptableQuality

7
•Red:BadQuality
PowerRequirementsActiveEthernet(PoweroverEthernet)ProprietaryPoEdesign
PowerAdapter24V/1ADC
RegulationCertificationsFCCPart15C/15B/15E,EN301893,EN300328,EN301489‐1/ ‐17,EN60950,
ICCertification




8

2EOC5611PMulti‐FunctionInstructionGuide
2.1AccessPoint
IntheAccessPointModewithWDSFunction,EOC5611Pfunctionlikesacentralconnectionforany
stationsorclientsthatsupportIEEE802.11a/b/gnetwork.StationsandClientmustconfigurethe
sameSSIDandSecurityPasswordtoassociatewithintherange.EOC5611Psupports4differentSSIDs
toseparatedifferentclientsatthesametime.




2.2AccessPointwithWDSFunction
EOC5611PalsosupportsWDSfunctioninAccessPointModewithoutlosingAP’scapabilities.
ConfigureothersAccessPoint’sWirelessMACAddressinbothAccessPointdevicestoenlargethe
wirelessareabyenablingWDSLinkSettings.WDSfunctioncansupportupto8differentAP’sMAC
addresses.
Auction:NoteveryAccessPointdevicehassupportWDSinAccessPointMode.Itisrecommended
usingEOC5611Pifyouwouldliketousethisservice.



9




2.3ClientBridge
IntheClientBridgeMode,theEOC5611Pfunctionlikesawirelessdongle.ConnectedtoanAccess
Pointwirelesslyandsurfinternetwheneveryouwant.UsingSiteSurveytoscanalltheAccessPoint
withintherangeandconfigureitsSSIDandSecurityPasswordtoassociatewithit.Connectyou
stationtotheLANportoftheEOC5611PviaEthernet.



2.4WDSBridge
IntheWDSBridgeMode,theEOC5611PcanwirelesslyconnectdifferentLANsbyjustsimply
configureeachother’sMACAddressandSecuritySettings.ThismodeisusedwhentwowiredLANs
locateinsmalldistanceandwanttocommunicateeachother.ThebestsolutionisusingEOC5611P
wirelesslyconnecttwowiredLANs.WDSBridgeModecanestablish16WDSlinks.Theconnection
diagramislikeaStar.
Auction:WDSBridgeModeisnotfunctionlikeAccessPoint.APslinkedbyWDSareusingthesame

10
frequencychannel,moreAPsconnectedtogethermaylowerthroughput.Pleasebeawaretoavoid
loopconnection,otherwiseyoumayenableSpanningTreeFunction.




2.5ClientRouter
IntheClientRouterMode,theEOC5611PhasDHCPServerbuildinsidethatallowsmanyLANs
automaticallygenerateanIPaddresstosharethesameInternet.ConnectanAP/WISPWirelesslyand
connecttoLANsviawired.ClientRouterModeisactcompletelyoppositetotheAPRouterMode.



11

3ComputerSettings
3.1AssignaStaticIP
InordertoconfigureEOC5611P,pleasefollowtheinstructionbelow:

1.IntheControlPanel,doubleclickNetwork
Connectionsandthendoubleclickontheconnectionof
yourNetworkInterfaceCard(NIC).Youwillthenseethe
followingscreen.


2.SelectInternetProtocol(TCP/IP)andthenclickonthe
Propertiesbutton.Thiswillallowyoutoconfigurethe
TCP/IPsettingsofyourPC/Notebook




3.SelectUsethefollowingIPaddressradiobuttonand
thenentertheIPaddressandsubnetmask.Ensurethat
theIPaddressandsubnetmaskareonthesamesubnet
asthedevice.


4.ClickontheOKbuttontoclosethiswindow,andthen
closeLANpropertieswindow.





Auction:IPAddressenteredintheTCP/IPPropertiesneedstobeatthesamesubnetofthe
EOC5611PIPAddress.Forexample:EOC5611P’sdefaultIPAddressis192.168.1.1sotheIPAddressin
theTCP/IPsettingscouldbe192.168.1.10.

12



3.2LoggingMethod
AftercompletetheIPsettingsfromlastsection,youcannowaccesstheweb‐basedconfiguration
menu.

1.Openwebbrowser

2.EnterIP192.168.1.1intoyouaddressfilter.

Auction:IfyouhavechangedtheEOC5611PLANIPaddress,makesureyouenterthecorrectIP
Address.


3.AfterconnectedtotheEOC5611Psuccessfully,browserwillpopoutaWindowsSecuritywindow.
PleaseenterthecorrectUsernameandPassword.

4.ThedefaultUsernameandPasswordarebothadmin.



Auction:IfyouhavechangedtheUsernameandPassword,pleaseenteryourownUsernameand
Password.


13





4WirelessSettings
4.1SwitchingOperationMode(System→SystemProperties)
TheEOC5611Psupports4differentoperationmodes:AccessPoint,ClientBridge,WDSBridge,and
ClientRouter.

ClickSystemPropertiesunderSystemSectiontobegin.
.

DeviceName:Specifyanameforthedevice,butitisnotthebroadcastSSID.Itwillbeshownin
SNMPmanagement.
Country/Region:SelectaCountry/Regiontoconformlocalregulation.
OperationMode:SelectanoperationmodeviaRadioButton.

ClickApplytosavethechanges.



Note:IfyouwouldliketouseAccessPointwithWDSFunctionmode,pleaseselectAccessPoint

14
ModeandthenenableWDSLinkSettingsfunction.


4.2WirelessSettings
4.2.1AccessPointMode→WirelessNetwork

WirelessModeEOC5611Psupports802.11a/b/gwirelessband.
Channel/FrequencyThechannelavailabilityisbasedonthecountry’sregulation.
AutoPlaceaChecktoenableAutochannelselection.
APDetectionAPDetectioncanhelptoselectabestchannelbyscannearbyarea.
CurrentProfileConfigureuptofourdifferentSSIDs,itcanhelptodividegroupofclientstoaccess
thenetwork.PressEdittoconfiguretheprofileandplaceaChecktoenableextra
SSID.
ProfileIsolationRestrictedClienttocommunicatewithdifferentVIDbySelectingtheRadiobutton.


15
Auction:Whenyouselect802.11a(5GHz)asyourwirelessmode,onlythewirelessclientwhich
supports5GHznetworkcanassociatewith.Pleasemakesureyourwirelessclientsupports5GHz
wirelessnetwork.
Note:EnableProfileIsolationwillcausewirelessclientscannotcommunicateeachother.Formore
detailspleaserefertothe“VLANManagementConfigurationGuide.


SSIDSpecifytheSSIDforcurrentprofile.
VLANIDSpecifytheVLANtagforcurrentprofile.
SuppressedSSIDPlaceaChecktohidetheSSID.ClientwillnotbeabletoseethebroadcastSSIDin
SiteSurvey.
StationSeparationSelecttheRadioButtontoallow/denyclienttocommunicateeachother.
WirelessSecurityPleaserefertotheWirelessSecuritysection.
Save/CancelPressSavetosavethechangesorCanceltoreturnprevioussettings.

Note:WhenyouenableProfileIsolation,allthepacketstransmitthroughwirelessnetworkwillcarry
VLANID.

16
4.2.2ClientBridgeMode→WirelessNetwork

WirelessModeEOC5611Psupports802.11a/b/gwirelessband.
SSIDSpecifytheSSIDifknown.SSIDtextboxwillbeautomaticallyfillinwhenselectanAP
intheSiteSurvey.
SiteSurveyUsingSiteSurveytoscannearbyAPsandthenselecttheAPtoestablishthe
connection.
PreferBSSIDSpecifytheMACaddressifknown.PreferBSSIDtextboxwillbeautomaticallyfillin
whenselectanAPintheSiteSurvey.
WDSClientPlaceaRadiobuttontoEnable/DisableWDSClient.
Apply/CancelPressApplytoapplythechangesorCanceltoreturnprevioussettings.


ProfileAfterSiteSurvey,webpagewilldisplayallnearbyarea’sAccessPoint.ClicktheBSSID
ifyouwouldliketoconnectwithit.
WirelessSecurityPleaserefertotheWirelessSecuritysection.
RefreshPressRefreshtoscanagain.
Auction:IftheAccessPointissuppresseditsownedSSID,SSIDsectionwillbeblank,theSSIDmustbe

17
filledinmanually.
4.2.3WDSBridgeMode→WirelessNetwork

WirelessModeEOC5611Psupports802.11a/b/gwirelessband.
Channel/FrequencyThechannelavailabilityisbasedonthecountry’sregulation.
Apply/CancelPressApplytoapplythechangesorCanceltoreturnprevioussettings.


18

MACAddressEntertheAccessPoint’sMACaddressthatyouwouldliketoextendthewirelessarea
intotheMACaddressfilter.
ModeSelectDisableorEnablefromthedropdownlist.
Apply/CancelPressApplytoapplythechangesorCanceltoreturnprevioussettings.
Auction:TheAccessPointthatyouwouldliketoextendthewirelessareamustenteryourAccess
Point’sMACaddress.NotallAccessPointsupportsthisfeature.MoreWDSbridgesconnected
togethermaycauselowerperformance.




19
4.2.4ClientRouterMode→WirelessNetwork

WirelessModeEOC5611Psupports802.11a/b/gwirelessband.
SSIDSpecifytheSSIDifknown.SSIDtextboxwillbeautomaticallyfillinwhenselectanAP
intheSiteSurvey.
SiteSurveyUsingSiteSurveytoscannearbyAPsandthenselecttheAPtoestablishthe
connection.
PreferBSSIDSpecifytheMACaddressifknown.PreferBSSIDtextboxwillbeautomaticallyfillin
whenselectanAPintheSiteSurvey.
WDSClientPlaceaRadiobuttontoEnable/DisableWDSClient.
Apply/CancelPressApplytoapplythechangesorCanceltoreturnprevioussettings.


ProfileAfterSiteSurvey,webpagewilldisplayallnearbyarea’sAccessPoint.ClicktheBSSID
ifyouwouldliketoconnectwithit.
WirelessSecurityPleaserefertotheWirelessSecuritysection.
RefreshPressRefreshtoscanagain.

Auction:IftheAccessPointissuppresseditsownedSSID,SSIDsectionwillbeblank,theSSIDmustbe
