7InchHeadrestwithpillowTFTLCDMonitorDVD
INSTRUCTIONS
Pleasereadtheseinstructionscarefullybeforeusingthisunit

CATALOGUES
1、GENERALINFORMATION
2、PRECAUTIONS
3、INSTALLATIONGUIDE
4、BUTTONDESCRIPTION
5、REMOTECONTROLUNITS
6.DVDSETUP
6.1.LANGUAGE
6.2.VIDEO
6.3.AUDIO
6.4.RETING
6.5.MISC
7、MenuOperation
7.1.PICTUER
7.2.AUDIO
7.3.FUNCTION
7.4.SYSTEM
7.5.CLOCK
8、SPECIFICATIONS

1、GENERALINFORMATION
ThankyouverymuchforyourpurchaseofthisheadrestwithpillowLCDMonitor
.PlayerpleaseReadthisinstructionmanualandkeepsitforfuturereferences.
2、PRECAUTIONS
1.1.Itismadeupofmanyprecisionelectronicelements,andanydismantlementor
Refitwillmakeitdamagedorbroken.
1.2. Whenoperatingtheunit,pleaseavoidcontactingwiththelCDpanel.
1.3.Keepitawayformtheplacewhereistoohotortoocold.Operatingtemperature
Oftheunitis3292degreesFahrenheit.
1.4.Donotdropthemonitororimpactitwithhardobjects.Thismaycausepermanent
netirreversibledamagetotheLCDpaneland/orthebacklightelement.
1.5.Duringoperation,iftheunitoverheatormalfunction,switchoff.Donot
Disassembletheunitbyyourself.Pleaseconsultthecompanyorthedealer.
1.6. Thebatteryoftheremotecontrolunithasanestimatedlifecycleoffivemonths.
Toensureproperfunctionality,replacethebatteryonatimelymanner.
1.7.Donotuseanychemicalsolvent,cleaningagentorcorrosivedetergentwhen
Wipingthedisplay.
3、INSTALLATIONGUIDE
Precautions
1．This unitshouldbeinstalledbyaqualified
servicetechnician.
2．This product is designed to operate with a
12VDCnegativegroundbatterysystem.
3．Disconnectthegroundwifefromthebattery
terminalpriortoconnectingthe unittothe
electricalsystem.
4．Please use accessories that come with this
unit in order to avoid fire or electrical
damagetoit.
5．This unit fitany mode ofcar; thedistance
betweentwopolescanbeadjusted.
6．Please use tools of screw to loosen the
screwsandadjustthedistanceoftwopoles
tomatchthesamedistancedistanceoftwo
poles of automobile, finally use the same
toolstotightenthescrews.

4、BUTTONDESCRIPTION
Buttonfunction
1>.USBfaucet
2>.POWERButton
3>.MODEButton
4>.VOLButton
5>.VOL+Button
6>.StopButton
7>.Play/Pause Button
8>.SDfaucet
5、REMOTECONTROL UNITS
FrequentlyButtons
Power
MUTEon/off
0~9（10＋） Digitkey(0~9)and /
TIMEOfftime
PLAY/PAUSE( )button
STOPbutton。
SETUPIntheDVDstate,entersDVDmenu.
SDDISC,MMC,USB,SDswitch。
AstheupmovingcursorwhenentertoDVD
manual,turntopreviousskipwhensetout
Asthedownmovingcursorwhenenterto
DVDmanual,turntonextskip whensetout
AstheleftmovingcursorwhenentertoDVD
manual,turntofastforwardwhensetout
As the right moving cursor when enter to
DVD manual, turn to fast forward when set
out
ENTEREnterButton
MODEDVD/AVButton
R/LTo select Left/Right/Stereo audio output
duringDVDmode
PTo the next higher program (the cursor is
movedupwards/downwards)
V+Volumeincrease(submenuadjust)
VVolumedecrease(submenuadjust)
MENUMainmenu
P．P Tensdigitchannelselect

6.DVDSETUP
Pressthe“SETUP”buttonontheRemoteControlleroenterintoDVDSetupmode.Usethe
buttonontheremote toselecttheoption，toconfirm theoptionpleasepress button.Toexit,
press button.ToexitfromDVDsetupmenu,press“SETUP”。
6.1.LANGUAGE
1>、OSDMenu
SelectOSDMenulanguages;MaychooseChinese,FrenchorEnglish。
2>、Audio
ChoosesDVDplaybacksoundlanguage;inthetableofcontents,optionsincludesEnglish,
Chinese,French,thisfunctionneedDVDsourcesupport。
3>、Subtitle
Chooses DVD playback captions language (subtitle); in the table of contents, it allows
selectioninEnglish,Chinese,French,thisfunctionneedDVDdishsupport
4>、DVDMenu
Chooses DVD playback menu language; in the table of contents has English, Chinese,
French,Russian,thisfunctionneedDVDsupport。
6.2.VIDEO

1>、Establishesdisplaymonitortoeither4:3panscan,4:3letterboxor16:9screensize。
2>、ViewMode;choosewidescreen
3>、TVSystem
EstablishoutputmodeinNTSC,PALSECAM。
6.3.AUDIO
1>、Bassmanagementsetupoff/on
2>、Digitaloutputsetupoff/on/all.
3>、Downsamplingsetupoff/on
6.4.RETING
Rating
Setthe rating for video content playback. Limiting violent and sexually explicit contents
playbackwhenduringunauthorizedplayback。
Ifthedischasnotbeengivenarating,thenthedisplaywillshow"Notrating",KidSafe ，G ，
PG ，PG13 ，PGR ，R ，NC17 ，Adult. Thisunitrequiresyoutoinputthepasswordif
you’rechosenratingislowerthantheplaybackdisc。

6.5.MISC
1>、Usedefaultsettings.Therearetwoselections:Yes/No.
Yes=Returntousedefaultsetting
No=Closesetupmenu,playdisc
2>、Screensaver:Selectionthesaversettingallowstheusertoenable/disablethescreen
saver.Thefollowingoptionsareavailable:
OFF=Disablescreensaver
ON=Enablescreensaver
3>、AutoplayDVDsetupoff/on
7、MenuOperation
PressMENUtodisplayprogramasfollows.
7.1.PICTUER
Contrast.Bright.Color.SharpandTINTdisplayonthescreenasillustratedbelow:
BRIGHT 35
COLOR 25
CONTRAST 30
SHARPNESS 32
TINT 50
1>、PressMenutodisplayprogramasfollows: Brightness,Color,Contrast,Sharpnessand
Tint.
2>、Enter into PICTURE, press CH+/CH to selecttheitemwhich needtobeset and it’s
indicatedbyarrowhead..Charactersareinred.

3>、Press VOL+/VOL to increase or reduce the number of the selected items.  It won’t
workwhenpressingVOL+tothemaximumnumber,thatis“63”;Itwon’tworkwhen pressing
VOLtotheminimumnumber,thatis“0”.
4>、Notes:OnlyNTSCcolorsystemhasTINT.Othercolorsystemsdon’thavethisitem.
7.2. AUDIO
AUDIO 33
Hereis onlyVOLUMiteminAUDIOMenu.PressVOL+/VOLtoincreaseorreduceits
number
7.3.FUNCTION
LANGVAGE
CALENDAR
GAME
NORMAL
NORMAL
ZOOM
1>、HerearesuchfunctionsinthisMenu,asfollows:Language,Calendar,Game andPicture.
2>、PressCH+/CHtoselecttheitem,whichneedtobeset,andit’sindicatedbyarrowhead.
Charactersareinred
3>、PressVOL+/VOLtosetthenumberoftheselecteditems.
4>、PressVOL+/VOLcan realize theswitchofChinese.English.
5>、RussianDiamondsGame
A.PressCH+ to change diamonds’direction.Press CHto change it’sspeed of downward
movement.
B. PressCH+ to make the diamonds to move right; press VOL to make the diamonds to
moveleft
C.Quitthegame,pleasepressMUNEandreturntoFunctionMenu.

7.4.SYSTEM
C.SYS AUTO
1>、HerearesuchfunctionsinthisMenu,asfollows:Color,System,SoundSystem,Program
Exchanging,ProgramCopyandProgramSearching.
2>、ThepressVOL+orrevolvethescreeninorderofAUTO.PAL,NTSC,SECAM,N3.58
and N4.43. Please choose this system correctly: otherwise, it may cause achromatic or inferior
color.ItisrecommendedtoselectonAUTOposition.
7.5.CLOCK
SLEEP 0
TIME : 
OFFTIME : 
ONTIME : 
ALARM : 
B.TIME : 
B.PR : 
1>、Herearesuchfunctionsarebellow:SleepTime,OFFTime,OnTime,Attention,BookedTime
andBooked Chinned.
2>、PressVOL+/VOL toset up clock, then pressCH+/CH to choose ONTime. VOLAdjust
hourVOL+AdjustmuteCH+/CHSelectitemstobesetup.
3>、AdjustmentofotheritemsisthesameasthatofClock,andsetupofclockforallitemsis24
hoursatmost.
4>、UponsetupofClock,pressCH+/CHtochooseCHTime,uponsetup,pressCH+/CHagain
tochooseposition, andpussVOL+/VOLtoadjusttillthe channel numberof desiredprogram,
theyouwillnotmissthedesired program.

8、SPECIFICATIONS
Item Specification
Supplyvoltage DC10V～15V
Currentconsumption Max3A
Workingtemperature 20℃～60℃
Inputoption 1channelsvideoinput
Screendimensions 7inches(diagonal)
Weight 1.2Kg
Dimensions 280(W)×355(L)×140(H)
Resolutions 480(H)×3（RGB）×234(V)pixels
Pixeldotpitch 0.119(H)×0.345(V)
DVDparameters
Disccompatible 12cm,DVD/VCD/MP3/CD/CDR/DVDR/DIVX/XIVD/
MPEG4
Signalnoiseratio >90dB
Distortion <0.05％
Definition >500lines
System PAL/NTSC
Amplifierparameters
Maxpoweroutput 1W
Speakerresistance 8Ω
Outputparameters
Rangeofaudiooutput 1.0App.
Rangeofvideooutput 10+0.2Vpp
Channelsofaudiooutput 2channel
Impedanceofaudiooutput 600Ω
