Eonon L0301M User manual

www.eonon.com
Model: L0301M
Please read this manual before using and
save this manual for future reference.
User manual

12
AV
MENU
P.P
TFT LCD MONITOR
4
5
6
7
1
2
38
12.3”TFT LCD COLOR MONITOR
Monitor
Remote controller
(1) Decrease Button
(2) L4:3/R4:3/L16:9/R16:9/full screen switch
(3) Timer switch
(4) Power switch
(5) AV switch
(6) Increase Button
(7) Menu
(8) Display effect selection
Connections
Parameters
Display size: 12.3"
Power supply: DC 12V
Picture resolution: 1280(W) RGB 480(H)
Fuse 3A
Red 12V
Black Grounding
Yellow Video 1
Yellow Video 2
Remote control
reception window
Increase Button
Menu
Decrease Button
Power Switch
