Eonon Headrest with pillow TFT LCD Monitor User manual

Headrest with pillow TFT LCD Monitor
INSTRUCTIONS
Please read these instructions carefully before using this unit
011

CATALOGUES
一、General information ……………………………………… 2
二、Precautions …………………………………………………… 2
三、Installation guide …………………………………………… 2
四、Monitor illustration………………………………………… 3
五、Remote control unit ……………………………………… 4
六、Trouble shooting …………………………………………… 5
七、Technical specifications ………………………………… 5
1

一、GENERAL INFORMATION
Thank you very much for your purchase of this headrest with pillow TFT LCD
Monitor. Player please read this instruction manual and keep it for future references.
二、PRECAUTIONS
1> It’s made up of many precision electronic elements, and any dismantlement or
refit will make it damaged or broken.
2> When operating the unit, please avoid contacting with the LCD panel.
3> Keep it away form the place where is too hot or too cold. Operating
temperature of the unit is 32-92 degrees Fahrenheit.
4> Do not drop the monitor or impact it with hard objects. This may cause
permanent irreversible damage to the LCD panel and/or the back light element.
5> During operation, if the unit over-heat or malfunction, switch off. Do not
disassemble the unit by yourself. Please consult the company or the dealer.
6> The battery of the remote control unit has an estimated life cycle of five
months. To ensure proper functionality, replace the battery on a timely manner.
7> Do not use any chemical solvent, cleaning agent or corrosive detergent when
wiping the display
三、INSTALLATION GUIDE
Precautions:
1> This unit should be installed by a qualified service technician.
2> This product is designed to operate with a 12V DC, negative ground battery
system.
3> Disconnect the ground wire from the battery terminal prior to connecting
the unit to the electrical system
4> Please use accessories that come with this unit in order to avoid fire or
electrical damage to it.
5> This unit fit any models of car, the distance between two poles can be adjust.
2

四、MONITOR ILLUSTRATION
8″Monitor illustration.
1、Indicator light 2、Incept window
3、Power ON/OFF button 4、MENU OSD Setting
5、V+ Volume Ascend Button 6、V- Volume Reduction Button
7、 Moving the cursor downwards 8、AV selection
9、Video/Audio Input
五、REMOTE CONTROL
1、Fast Buttons on Remote Controller
MUTE: MUTE on/off
ON/OFF: Power switch
SYS: SYS Button
CALL: Back Button
MENU: Fast Menu Button
SLEEP: Timing Shut-down
P.P Picture adjustment
AV: AV selection
P:Moved the cursor upwards
P:Moved the cursor downwards
V+: Volume increase (submenu adjust)
V-: Volume decrease (submenu adjust)
3

2、Replacement of Battery
1. Use a small coin to open the battery clip.
2. Remove old battery and replace it with the
positive “+” sign facing upward.
3. Push battery clip into compartment until it is locked
六、TROUBLE SHOOTING
Phenomenon Reason
No picture and
sound
AC adapter or automobile adapter is improperly
connected. Uncertified power is being used. Power
switch is off.
No sound Audio volume is off or in mute condition. Press
VOL+.
No color Enter into the MENU “PICTURE SYSTEM” to
adjust its system.。
Remote
Controller
Doesn’t Work
Check the battery in the remote controller, make
sure it installed correctly. The power of battery is
run out or the signal is disturbed.
Snowflake
pictures Antenna signal is weak. Make sure to connect the antenna correctly.
4

5
七、TECHNICAL SPECIFICATIONS
TYPE Headrest with pillow color TFT-LCD Monitor
Display System TFT-LCD Monitor
Source Video input 1VP-P (PAL/NTSC) *2PC
Audio input
Operating
Temperature 0℃～60℃
Operating
Humidity 20％～85％
Operating Voltage DC+12V
Power
Consumption ＜10W
