Epson STYLUS PHOTO R240 Series User manual

114
The parts to which no reference number
is assigned will not be available as
after-sale service parts.
120 101
106
106
106
106
107
108
105
104
103
102
113
112
109
110
111
127
130
129
128
126
125
124
122
123
121
PM-D600 / EPSON Stylus Photo R240/R245/R250 REV.01 C606-CASE-001

The parts to which no reference number
is assigned will not be available as
after-sale service parts.
300
204
200
202
203
201
PM-D600 / EPSON Stylus Photo R240/R245/R250 REV.01 C606-ELEC-001

The parts to which no reference number
is assigned will not be available as
after-sale service parts.
561
561
561
563
560
584
583
582
581
580
587
586
585
562
564
559 558
556
557
555
551
550
554
721
720
PM-D600 / EPSON Stylus Photo R240/R245/R250 REV.01 C606-MECH-002

The parts to which no reference number
is assigned will not be available as
after-sale service parts.
512
520
506
507
508
510
509
527
513
514
525
504
503
502
505
511
515
517
518
519
516
521
526
524
523
522
528
501
529
500
PM-D600 / EPSON Stylus Photo R240/R245/R250 REV.012 C606-MECH-0012
591

Part Code Part Name Ref No. Category Qty Remark
1288281 INK CART.UNBOXED,B-SS,DYE;F11C,WST,AS NONFIG Accessories 1
1288282 INK CART.UNBOXED,C-SS,DYE;F11C,WST,AS NONFIG Accessories 1
1288283 INK CART.UNBOXED,M-SS,DYE;F11C,WST,AS NONFIG Accessories 1
1288284 INK CART.UNBOXED,Y-SS,DYE;F11C,WST,AS NONFIG Accessories 1
2068890 POWER CABLE NONFIG Accessories 1
3100877 SOFTWARE CD,FIGD NONFIG Accessories 1
3100879 SOFTWARE CD,EPRS NONFIG Accessories 1
4103085 SETTING UP MANUAL NONFIG Accessories 1
4103087 USER'S GUIDE NONFIG Accessories 1
1410838 PAPER SUPPORT ASSY. 101 Case 1
1410785 COVER,PRINTER;EFS2 102 Case 1
1427131 HOUSING,UPPER;EDG2;B 103 Case 1
1410783 HOUSING,LOWER;EDG2 104 Case 1
1410796 COVER,INK TUBE;EDG2 105 Case 1
1108107 FOOT 106 Case 4
1410837 STACKER ASSY. 107 Case 1
1410798 LEVER,PG;EPG2 108 Case 1
1410793 COVER,CARD SLOT;EDG2 109 Case 1
1410794 LENS,CARD SLOT 110 Case 1
1410795 COVER,PB;EDG2 111 Case 1
1410807 GROUNDING PLATE,PANEL 112 Case 1
1410797 COVER,USB;EDG2 113 Case 1
1410305 LABEL,INK,POSITION 114 Case 1
1410805 COVER,LCD 120 Case 1
1410799 BUTTON,PANEL;EBCK 121 Case 1
1410803 BUTTON,LENS,RIGHT 122 Case 1
1410804 BUTTON,LENS,LEFT 123 Case 1
1410800 BUTTON,SW;EBCK 124 Case 1
1410801 BUTTON,SW,COPY UPPER;EBCK 125 Case 1
1410802 BUTTON,SW,COPY LOWER;EBCK 126 Case 1
2103651 HARNESS 127 Case 1
2104687 LCD MODULE 128 Case 1
2103647 BOARD ASSY.,PANEL 129 Case 1
1410806 SHIELD PLATE,PANEL 130 Case 1
2109432 BOARD ASSY.,MAIN 200 Electronic Parts 1
2103649 HARNESS 201 Electronic Parts 1
1282387 C.P.SCREW,3X4,F/ZN-3C 202 Electronic Parts 1
1409444 SHIELD PLATE,M/B,UPPER 203 Electronic Parts 1
1409443 SHIELD PLATE,M/B 204 Electronic Parts 1
1410835 P/S BOARD ASSY.;220V 300 Electronic Parts 1
2106580 PRINTER MECHANISM(ASP)MAK16-100 500 Mechanism Parts 1
1409897 ASF UNIT 501 Mechanism Parts 1
1427156 HOLDER,SHAFT ASSY.;B 502 Mechanism Parts 1
2104560 BOARD ASSY.,DETECTOR 503 Mechanism Parts 1
1295162 TORSION SPRING,137.7 504 Mechanism Parts 1
2104179 MOTOR ASSY.,CR 505 Mechanism Parts 1
2103443 CABLE,ENCODER,PF 506 Mechanism Parts 1
2103145 BOARD ASSY.,ENCODER,PF;B 507 Mechanism Parts 1
1408051 HOLDER,BOARD ASSY.,ENCODER,PF 508 Mechanism Parts 1

1279686 LEVER,PARALLEL ADJUSTMENT,LEFT 509 Mechanism Parts 1
1279687 TORSION SPRING,SHAFT,CR,GUIDE 510 Mechanism Parts 1
1279683 LEVER,PARALLEL ADJUSTMENT,RIGHT 511 Mechanism Parts 1
1280780 PRESSING SPRING,SHAFT,CR,GUIDE 512 Mechanism Parts 1
1261564 EXTENSION SPRING,3.289 513 Mechanism Parts 1
1279691 SCALE,CR 514 Mechanism Parts 1
1410733 INK SYSTEM ASSY. 515 Mechanism Parts 1
1279688 SHAFT,CR GUIDE 516 Mechanism Parts 1
1420663 CR SUB ASSY. 517 Mechanism Parts 1
2103442 CABLE,HEAD 518 Mechanism Parts 1
1279690 TIMING BELT,CR 519 Mechanism Parts 1
2101872 BOARD ASSY.,ENCODER;C 520 Mechanism Parts 1
2109392 BOARD ASSY.,DETECTOR,PW 521 Mechanism Parts 1
1409448 COVER,CABLE,HEAD 522 Mechanism Parts 1
2088095 BOARD ASSY.,CSIC 523 Mechanism Parts 1
2060802 CONNECTER,CSIC 524 Mechanism Parts 4
1274963 TORSION SPRING,LEVER,CARTRIDGE;B 525 Mechanism Parts 1
1290662 GUIDE,IC 526 Mechanism Parts 1
F164030 PRINT HEAD 527 Mechanism Parts 1
1279681 COVER,FFC,SUB 528 Mechanism Parts 1
1409454 COVER,CARTRIDGE 529 Mechanism Parts 1
1409445 STAY,SHIELD PLATE,M/B 550 Mechanism Parts 1
1407753 FRAME,GUIDE,CR 551 Mechanism Parts 1
1280911 SCALE,PF;B 552 Mechanism Parts 1
1212722 DOUBLE SIDED TAPE,D21 553 Mechanism Parts 1
1261589 GROUNDING SPRING,PF 554 Mechanism Parts 1
1405516 ROLLER,PF ASSY. 555 Mechanism Parts 1
1409898 PAPER GUIDE,FRONT ASSY. 556 Mechanism Parts 1
1279708 POROUS PAD,PAPER GUIDE,FRONT 557 Mechanism Parts 1
2104175 MOTOR ASSY.,PF 558 Mechanism Parts 1
1279697 SPUR GEAR,30.8 559 Mechanism Parts 1
2104178 DETECTOR ASSY.,PG 560 Mechanism Parts 1
1405284 PAPER GUIDE,UPPER ASSY. 561 Mechanism Parts 3
1410916 STARWHEEL ASSY. 562 Mechanism Parts 1
1425018 ROLLER,EJ ASSY. 563 Mechanism Parts 1
1279699 PAPER GUIDE,FRONT,SUPPORT 564 Mechanism Parts 1
1423432 SHEET,POROUS PAD,PROTECT 580 Mechanism Parts 1
1410702 POROUS PAD,INK EJECT,RIGHT,UPPER 581 Mechanism Parts 1
1410700 POROUS PAD,INK EJECT,RIGHT,MIDDLE 582 Mechanism Parts 1
1410698 POROUS PAD,INK EJECT,RIGHT,LOWER 583 Mechanism Parts 1
1404059 POROUS PAD,CAP,LOWER 584 Mechanism Parts 1
1410697 POROUS PAD,INK EJECT,MIDDLE 585 Mechanism Parts 2
1410699 POROUS PAD,INK EJECT,LEFT,UPPER 586 Mechanism Parts 1
1410696 POROUS PAD,INK EJECT,LEFT,LOWER 587 Mechanism Parts 1
1421324 LABEL,FRAME,MAIN 591 Mechanism Parts 1
1080614 GREASE G-26 (40GR)(B702600001) NONFIG Tools 1
1304682 GREASE G-71 NONFIG Tools 1
1409257 GREASE G74 NONFIG Tools 1
6022798 Shipping Cleaning Liquid,CR02,18kg NONFIG Tools 1
6022805 Shipping Cleaning Liquid,CR02,1kg NONFIG Tools 1

Part Code Part Name Ref No. Category Qty Remark
