Short-throw Wall Mount (ELPMB27)
FOR EPSON® POWERLITE® 420, 425W, 430, 435W PROJECTORS
Designed exclusively for use with Epson’s PowerLite 420, 425W, 430 and 435W short-throw projectors, this
wall mount offers an easy, affordable solution for integration with a variety of interactive or standard dry-erase
whiteboards. The wide mounting plate and telescopic extension arm offer convenient and flexible installation,
while the vertical and horizontal adjustments provide easy image alignment. And, when your short-throw
projector is attached to the wall mount, there is less shadow interference and glare, which ensures a more
optimal viewing and presenting experience.
Flexible installation — wall mount plate allows for easy installation using one or two wall studs
Easily adjustable — telescopic extension arm supports a throw distance from 27 to 47 inches
Ideal for virtually any image size — for projecting 16:10 content from 68 to 113 inches
(PowerLite 425W, 435W), or 4:3 content from 63 to 106 inches (PowerLite 420, 430)
Easy image alignment — vertical and horizontal shift adjustments, plus pitch,
roll and swivel adjustments
Protective covers included — conceals cables for a clean finish
Affordable classroom mounting solution.
Projector not included.

Short-throw Wall Mount
For EPSON® PowerLite® 420, 425W, 430, 435W Projectors
Product Name Product Code UPC
Short-throw Wall Mount V12H003Z27 0 10343 88696 4
for PowerLite 420, 425W, 430 and
435W Projectors (ELPMB27)
www.epson.com
www.epson.ca
Epson Canada Limited
185 Renfrew Drive, Markham, Ontario, L3R 6G3
Epson and PowerLite are registered trademarks, Epson Exceed Your Vision is a registered logomark and Better Products for a Better Future is a trademark of Seiko Epson Corporation. BrightLink
Solo is a registered trademark of Epson America, Inc. SmartWay is a service mark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks and/or registered
trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2011 Epson America, Inc. CPD-35094 9/11
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
SM
For more information on Epson’s environmental programs, go to eco.epson.com
Safety
Fall Prevention Wire
(inside wall plate cover)
Yes
Weight Resistance
44 lb (20 Kgf)
Hang Down Strength
132 lb (60 Kgf)
Specifications
Package Dimensions (W x D x H)
36.6" x 10.8" x 12.2"
Package Weight
30.4 lb
Short-throw Wall Mount Weight
22 lb (10 Kgf)
Support
What’s In The Box
Short-throw Wall Mount, Hardware, Installation
Manual, Warranty Statement, Document CD
Warranty
2-year limited
Projector not included.
Adjustment mechanism
Horizontal Tilt
±5 degrees (default 0°)
Horizontal Slide Adjustment Range
±45 mm (1.77 inches)
Projection Distance Adjustment Width
510 +/-3 mm (20 +/- 0.12 inches)
Vertical Slide Adjustment Range
Min. 134 mm (5.27 inches) (Arm length min.)
Min. 230 mm (9.06 inches) (Arm length max.)
Vertical Tilt
95 (-0.5/+0)~106.5 (-0/+0.5) degrees
Horizontal Rotation Adjustment Range
±5 degrees (default 0 degrees)
Horizontal Roll Adjustment Range
±5 degrees (default 0 degrees)
Vertical Tilt Adjustment Range
0 to -11 degrees (default 0 degrees)
Wall plate dimensions, mm (inches)
Projector
attachment plate
Wall plate (not pictured)
and cover
Extension arm
Interface cover
bracket
Interface cover
(not pictured)
Mount overview
Projector
attachment
plate
BrightLink Solo 3
The optional BrightLink Solo™ 3 Interactive Module (ELPIU03)
easily attaches to the Projector attachment plate
