Epson ELPMBP02 - False Ceiling Plate Guide

Model: ELPMBP02 This product is UL Listed. It must be
installed by a qualified professional
installer.
R
Installation and Assembly:
False Ceiling Plate Kit
3215 W. North Ave. • Melrose Park, IL 60160 • [phone] or [phone] • Fax: [phone] • www.peerlessmounts.com
Maximum UL Load Capacity: 50 lb (22.6 kg)
Manufactured by Peerless Industries, Inc.

ISSUED: 02-13-08 SHEET #:128-9030-2 07-16-08
2 of 6
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
Table of Contents
Parts List..............................................................................................................................................................................3
Mounting Above Ceiling Tile, Mounting inPlace of Ceiling Tile andAttaching CeilingTray to Filler Tray...............................4
AnchoringMethods ...............................................................................................................................................................5
WarrantyInformation.............................................................................................................................................................6
NOTE: Read entire instruction sheet before you start installation and assembly.
• Do not begin to install your product until you have read and understood the instructions and warnings contained in this
InstallationSheet.Ifyou have any questions regarding any of the instructions or warnings, call Peerless customer care
at1-800-729-0307.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Makesurethatthesupportingsurfacewillsafelysupport the combined load of the equipment and all attached hard-
wareand components.
• Neverexceed the Maximum ULLoadCapacity.
• If mounting to wood joists or wood beam ceilings, make sure that mounting screws are anchored into the center of the
joists or beams. Use of an "edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly,but do not overtighten.Overtighteningcan damage the items,greatlyreducing their holding
power.
• Thisproductisintendedfor indoor use only.Use of this product outdoors could lead to product failure and personal
injury.
• When installing or adjusting the ceiling mount, do not use adhesives, lubricants or oils to prevent the screws from
loosening. If you use adhesives, lubricants, or oils to prevent the screws from loosening, the casing may crack and the
projector may fall, causing serious injury and damage to the projector.
WARNING
Tools Needed for Assembly
•studfinder("edgetoedge"studfinderisrecommended)
•phillipsscrewdriver
•hammer
•wire cutters
•drill
•1/4" bit for concrete surface
•5/32" bit for wood studs

ISSUED: 02-13-08 SHEET #:128-9030-2 07-16-08
3 of 6
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
A1
NOTE: Somepartsmayappearslightlydifferentthanillustrated.
Before you begin, make sure all parts shown are included with your product.
D
BC
A
LKF
MAA BB
CC
IMPORTANT PRE-ASSEMBLY INFORMATION: Ceiling Trays (A),and(A1) are designed tofitwithin or above a
24" (610 mm) x 24" (610 mm) section of a conventional suspended ceiling system. It may also be mounted within or
above 24" x 48" conventional suspended ceiling. Ceiling runners (see DETAIL 1, page 5) should have a "T" cross
section and a minimum height of 1.5" (38 mm).
For certain installations it may be best to install ceiling anchors (step 2) before installing the ceiling tray (step 1).
Description Qt
y
. Part #
A
ceiling tray 1 128-2198
A1 filler tray 1 128-2207
B1/4"-20 x 3/8" screws 4 520-2015
C1/4"-20 nuts 4 530-9302
Dallen wrench 1 560-9706
Fturnbuckle 4 560-9620
G12 gauge x 20' (6.1m) tie wire (not shown) 1 600-2008
Keye bolt 5 580-0006
Lconcrete anchor 5 580-0005
Mflush mount tube 1 1446-014
A
A
M5 x 10 mm socket screw 4 520-1216
BB nut 4 530-9409
CC 3 mm allen wrench 1 560-0194
Parts List

ISSUED: 02-13-08 SHEET #:128-9030-2 07-16-08
4 of 6
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
1Remove 24" x 24" or 24" x 48" false ceiling tile.
If using 24" x 48" ceiling tile, cut one tile in half and add another 24" ceiling runner in order to make a 24" x 24"
section.
Place ceiling tray (A) in 24" x 24" grid with hole to center, left, or right.
Place filler (A1) tray into gap.
For Mounting in Place of Ceiling Tile
1-1
1-2
1-3
2Attach ceiling tray (A) to filler tray (A1) using four bolts (B) and
nuts (C) as shown in fig. 1.1. Hook turnbuckles (F) into ceiling
tray (A). Hook one turnbuckle through filler tray (A1) and ceiling
tray (A) where indicated by gray rectangles in illustration below.
OPTION 2: Use M5 x 10 mm socket screws (AA) and M5
nuts (BB) to attach ceiling tray (A) to filler tray (A1) in place of
fasteners 1/4"-20 x 3/8" screws (B) and 1/4"-20 nuts (C) if neces-
sary. Tighten M5 x 10 mm socket screws (AA) using
3mm allen wrench (CC).
Attaching Ceiling Tray to Filler Tray
A
F
AA1
C
or
BB
B
or
AA
Grayrectangles show correct positions for
turnbuckles(F).
AA1
For Mounting Above Ceiling Tile
Place ceiling tray (A) in grid above 24" x 24" or 24" x 48" false ceiling tile with hole to center, left or right.
Place filler (A1) tray into gap.
Once placed where needed, through hole in ceiling tray (A), mark on false ceiling tile
wherehole will be.
Cut out 2.25" hole in false ceiling tile. (Escutcheon Ring Accessory
(ACC 640) is recommended).
For flush mounting applications: From the top down, thread the flush mount
tube (M) down through the retaining collar in ceiling tray (A).
NOTE: Set screw included with projector mount will be installed
according to the instructions provided with the mount.
Skip to step 2.
1-4
1-3
1-2
1-1
1
1-5
A
M
A1
CEILING
RUNNER
fig. 1.1

ISSUED: 02-13-08 SHEET #:128-9030-2 07-16-08
5 of 6
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
Cut tie wire (G) into four pieces of equal length. Insert wires through the ends of the turnbuckles and loop to prevent
the wire from slipping. Twist each wire around itself at least six times as tightly as possible.
Drill holes for four ceiling anchors (see “VariousAnchoring Methods”). Position the holes so when the tie wires are
attached and taut the optimal angle is 15° (see figure 3.1 for reference). Unit may be mounted at an angle up to 45°
if necessary.
Pull tie wires tight and loop through turnbuckles of the ceiling anchors (or truss). Again twist each wire around itself
at least six times as tightly as possible.
When this step is complete, the weight of the ceiling tray should be supported by the tie wires.
NOTE: 20'(6.1m)oftie wire (G)isprovided.If space between the true ceiling and suspended ceiling is more than 36"
(914mm), additional wire (12 gaugeannealed,steel, black) will beneeded.
VARIOUSANCHORINGMETHODS
Wood Joists or Beams
Drill 5/32" (4 mm) dia.
holes 2" (51 mm) deep.
Fully insert eye bolts (K).
Solid Concrete
Drill 1/4" (6 mm) dia. holes 1.5" (38 mm) deep.
Hammerin ConcreteAnchor(L)usingRawl
#3250setting tool orequivalent.
KL
TrussCeiling
Noanchor required. After
attaching tie wire to turnbuckle
loopupper endaround ceiling
truss. Pull tie wire tight and
twist it around itself at least six
times as tightly as possible..
A
G
G
G
G
Knockout panels are
provided for electrical outlet
boxes and antenna leads.
A1
Suspended Ceiling Kit installation is now complete.
Afterall components (Projector Mount, Extension
Column,etc.) and equipmenthave been attached,
tension the tie wires by adjusting turnbuckles (F).
Load must be carried by tie wires - not
suspended ceiling runners.
• Installer must verify that the ceiling will safely
supportfour times the combined weight of all
attachedequipmentandhardware.
• Never attach hooks to filler tray.
WARNING
15°
fig. 3.1
3
3-1
Anchoring Methods
2" 2"
1.5"
CEILING
RUNNER
DETAIL 1

ISSUED: 02-13-08 SHEET #:128-9030-2 07-16-08
6 of 6
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
3HHUOHVV,QGXVWULHV,QFHVWDEOLVKHVDZDUUDQW\SHULRGRIÀYH\HDUVIRUSURGXFWVPDQXIDFWXUHGRUVXSSOLHGE\3HHUOHVV7KLVSHULRGFRPPHQFHVIURPWKHGDWH
RIVDOHRIWKHSURGXFWWRWKHRULJLQDOFRQVXPHUEXWZLOOLQQRFDVHODVWIRUPRUHWKDQVL[\HDUVDIWHUWKHGDWHRIWKHSURGXFWҋVPDQXIDFWXUH'XULQJWKHZDUUDQW\
SHULRGVXFKSURGXFWVZLOOEHIUHHIURPGHIHFWVLQPDWHULDODQGZRUNPDQVKLSSURYLGHGWKH\DUHLQVWDOOHGDQGXVHGLQFRPSOLDQFHZLWKWKHLQVWUXFWLRQVHVWDEOLVKHGE\
3HHUOHVV,QGXVWULHV,QF6XEMHFWWRDSSOLFDEOHOHJDOUHTXLUHPHQWVGXULQJWKHZDUUDQW\SHULRG3HHUOHVVZLOOUHSDLURUUHSODFHRUUHIXQGWKHSXUFKDVHSULFHRIDQ\
VXFKSURGXFWZKLFKIDLOVWRFRQIRUPZLWKWKLVZDUUDQW\
$Q\RWKHUZDUUDQWLHVSUHVFULEHGE\WKHODZZKLFKPD\DSSO\ZLWKUHVSHFWWRVXFKSURGXFWVDOVRDUHOLPLWHGLQGXUDWLRQWRWKHZDUUDQW\SHULRGVSHFLÀHGLQWKLV/LPLWHG
)LYH<HDU:DUUDQW\
7KLVZDUUDQW\GRHVQRWFRYHUGDPDJHFDXVHGE\DVHUYLFHRUUHSDLUVE\WKHFXVWRPHURUDSHUVRQZKRLVQRWDXWKRUL]HGIRUVXFKVHUYLFHRUUHSDLUVE\3HHUOHVV
,QGXVWULHV,QFEWKHIDLOXUHWRXWLOL]HSURSHUSDFNLQJZKHQUHWXUQLQJWKHSURGXFWFLQFRUUHFWLQVWDOODWLRQRUWKHIDLOXUHWRIROORZ3HHUOHVVҋLQVWUXFWLRQVRUZDUQLQJV
ZKHQLQVWDOOLQJXVLQJRUVWRULQJWKHSURGXFWRUGPLVXVHRUDFFLGHQWLQWUDQVLWRURWKHUZLVHLQFOXGLQJLQFDVHVRIWKLUGSDUW\DFWLRQVDQGIRUFHPDMHXUH
,QQRHYHQWVKDOO3HHUOHVVEHOLDEOHIRULQFLGHQWDORUFRQVHTXHQWLDOGDPDJHVRUGDPDJHVDULVLQJIURPWKHWKHIWRIDQ\SURGXFWZKHWKHURUQRWVHFXUHGE\DVHFXULW\
GHYLFHZKLFKPD\EHLQFOXGHGZLWKWKHSURGXFW
7KLV/LPLWHG)LYH<HDU:DUUDQW\LVLQOLHXRIDOORWKHUZDUUDQWLHVH[SUHVVHGRULPSOLHGDQGLVWKHVROHUHPHG\ZLWKUHVSHFWWRSURGXFWGHIHFWV1RUHWDLOHUGHDOHU
GLVWULEXWRULQVWDOOHURURWKHUSHUVRQLVDXWKRUL]HGWRPRGLI\RUH[WHQGWKLVZDUUDQW\RULPSRVHDQ\REOLJDWLRQRQ3HHUOHVVLQFRQQHFWLRQZLWKWKHVDOHRIDQ\SURGXFW
PDQXIDFWXUHGRUVXSSOLHGE\3HHUOHVV
7KLVZDUUDQW\JLYHVVSHFLÀFOHJDOULJKWVDQG\RXPD\DOVRKDYHRWKHUULJKWVSURYLGHGE\WKHQDWLRQDOOHJLVODWLRQRIWKHFRXQWU\LQZKLFK\RXSXUFKDVHGVXFKSURGXFW
