Epson ELPMBP03 - Structural Round Ceiling Plate Guide

Model: ELPMBP03
3215 W. North Ave. • Melrose Park, IL 60160 • [phone] or [phone] • Fax: [phone] • www.peerlessmounts.com
Maximum UL Load Capacity: 150 lb (68 kg)
This product is UL Listed. It must be
installed by a qualified professional
installer.
R
Installation and Assembly:
Structural Round Ceiling Plate
Manufactured by Peerless Industries, Inc.
ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
Visit the Peerless Web Site at www.peerlessmounts.com 2 of 7 For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
Table of Contents
Parts List..............................................................................................................................................................................3
ExtensionColumnandFlushMounting Applications ............................................................................................................4
Installation to Wood Joist Finished Ceilings, Exposed Wood Joists or Wood Beam Ceilings...............................................5
InstallationtoSolid Concrete ................................................................................................................................................6
WarrantyInformation.............................................................................................................................................................7
NOTE: Read entire instruction sheet before you start installation and assembly.
• Do not begin to install your product until you have read and understood the instructions and warnings contained in this
InstallationSheet.Ifyou have any questions regarding any of the instructions or warnings, call Peerless customer care
at1-800-729-0307.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Makesurethatthesupportingsurface will safely support the combined load of the equipment and all attached hard-
wareand components.
• Neverexceed the Maximum ULLoadCapacity.
• If mounting to wood joists or wood beam ceilings, make sure that mounting screws are anchored into the center of the
joists or beams. Use of an "edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screwsfirmly, but do notovertighten.Overtightening can damage theitems,greatly reducing their holding
power.
• Thisproductisintended for indoor use only.Use of this product outdoors could lead to product failure andpersonal
injury.
• When installing or adjusting the ceiling mount, do not use adhesives, lubricants, or oils to prevent the screws from
loosening. If you use adhesives, lubricants, or oils to prevent the screws from loosening, the casing may crack and the
projector may fall, causing serious injury and damage to the projector.
WARNING
Tools Needed for Assembly
•studfinder("edgetoedge"studfinderisrecommended)
•phillipsscrewdriver
•3/8" (10 mm) socket wrench
•drill
•1/4" bit for concrete surface
•5/32" bit for wood studs

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
3 of 7
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
NOTE: Somepartsmayappearslightlydifferentthanillustrated.
Before you begin, make sure all parts shown are included with your product.
ABCDE
FG
Description Qty. Part #
Around ceiling plate 1 055-2798
B#14 x 2.5" wood screw 4 5S1-015-C04
CM5 x .8 x 10 mm phillips screw 1 520-2005
DM5 x .8 x 10 mm socket pin screw 1 520-2031
E4 mm allen wrench 1 560-9646
Frubber grommet 1 530-9401
Gconcrete anchor 4 590-0097
Parts List

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
Visit the Peerless Web Site at www.peerlessmounts.com 4 of 7 For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
SLOT
THREADED
FITTING A
C
Insertendofextensioncolumn into threaded fitting of
ceilingplate (A). Tighten four or five complete turns.
Align slot in extension column with one of the small
holes in the side of the threaded fitting. Insert and
tighten one M5 x 10 mm phillips screw (C) into hole to
lock extension column to threaded fitting.
NOTE: For security option, use M5 socket pin screw (D)
in place of screw (C). Tighten using 4 mm allen
wrench(E).
2
Place grommet (F) into hole of ceiling plate (A).
NOTE: Makesure grommetoverlaps retaining
collar. Grommet may require some force to fit in
holeand will appearslightly deformed.
F
A
RETAINING
COLLAR
1
Screw flush mount from top of ceiling plate (A) as
shownin fig. 2. Tighten four or five complete turns.
Align slot in flush mount tube with one of the small
holes in the side of the threaded fitting. Insert and
tighten one M5 x 10 mm phillips screw (C) into hole to
lock flush mount tube to threaded fitting.
NOTE: For security option, use M5 socket pin
screw (D) in place of screw (C). Tighten using 4 mm
allenwrench (E). A
FLUSHMOUNT
TUBE(SOLD
SEPARATELY)
fig. 2
2
Flush Mounting Applications
Extension Column Applications
• For safety, extension column must be locked to threadedfittingwith screw.
WARNING
ULLISTEDELPMBC01AND
EXTORADJSEIRIES
(SOLDSEPARATELY)

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
5 of 7
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
A
B
Drill two 5/32" (4 mm) dia. holes to a minimum depth of 2.5" (64 mm). Attach ceiling plate (A) to the joist center
using two #14 x 2.5" wood screws (B) as shown. Tighten wood screws (B) using 3/8" (10 mm) socket wrench so
ceiling plate (A) is firmly attached.
• Installermust verify that the supporting surface will safelysupport the combined load of the equipment andall
attachedhardware andcomponents.
• Tightenwood screws so that ceiling plateis firmly attached, but do notovertighten.Overtightening can damage
thescrews, greatly reducing theirholding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the wood joist or wood beam. The use of an
"edgeto edge" stud finder is highly recommended.
• Hardwareprovided is for attachment ofmount through standard thickness drywallorplaster into wood joist or
woodbeam ceilings. Installers areresponsible to provide hardwareforother types of mountingsituations.
WARNING
3
Installation to Wood Joist Finished Ceilings, Exposed Wood Joists,
or Wood Beam Ceilings

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
Visit the Peerless Web Site at www.peerlessmounts.com 6 of 7 For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
Drill holes and insert anchors (G).
Use ceiling plate (A) as a template to mark holes.
Drill four 1/4" (6 mm) dia. holes to a minimum depth
of 2.5" (64 mm). Insert four anchors (G) in holes
flush with ceiling as shown in figure 3.1.
Placeceilingplate (A) over anchors (G) and secure
with #14 x 2.5" (6 mm x 65 mm) wood screws (B).
Tighten wood screws (B) using 3/8" (10 mm) socket
wrench to firmly attach ceiling plate (A).
Seefigures 3.2 and 3.3.
CONCRETE
CEILING
fig. 3.2 A
fig. 3.1
fig. 3.3
B
3
• Alwaysattach concrete anchors directly to load-bearing
concrete.
• Neverattach concrete anchorsto concrete coveredwith
plaster, drywall, or otherfinishing material. If mounting
toconcrete surfaces covered with a finishingsurfaceis
unavoidable,the finishingsurface mustbe counterbored
as shown below. Be sure concrete anchors do not pull
awayfrom concrete when tightening screws.If plaster/
drywall is thicker than 5/8", custom fasteners must be
supplied by installer. (Notevaluatedby UL)
WARNING
• Tighten screws so that ceiling plate is firmly attached,
butdo notovertighten.Overtightening candamage
screws,greatly reducing theirholding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
WARNING
A
B
CUTAWAYVIEW
INCORRECT
CORRECT
ceiling
plate
plaster/
drywall
concrete ceiling
plate concrete
plaster/
drywall
Tighten all fasteners.
Place ceiling plate (A) over anchors (G) and secure with
screws (B).
G
G
G
Installation to Solid Concrete
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Makesurethatthesupportingsurface will safely support the combined load of the equipment and all attached hard-
wareand components.
WARNING

ISSUED: 02-13-08 SHEET #: 054-9126-2 07-10-08
7 of 7
Visit the Peerless Web Site at www.peerlessmounts.com For Technical Support Contact Peerless Mounts at 1-800-729-0307 or 708-865-8870.
