93320-001 Flue Gas Recirculation
eHACK
Operating Instructions

ETA Heiztechnik
Gewerbepark 1
A-4716 Hofkirchen an der Trattnach
Tel: [phone] / 22 88 -0
Fax: [phone] / 22 88 -22
[email protected]
www.eta.co.at

General information
3
1 General information
Copyright
All contents of this document are property of ETA
Heiztechnik GmbH and are protected by copyright.
Any reproduction, transfer to third parties or use for
other purposes is prohibited without written permission
from the owner.
Software Description
The software version described in this documentation
corresponds to the version valid at the time of publica-
tion. The software version installed on your product
may differ from that described in this documentation.
A software update to a more recent version can
always be performed. With the appropriate au-
thorisation, the required files can be found at
"www.eta.co.at".
Subject to technical changes
We reserve the right to make technical modifications
without notice. Printing and typesetting errors or
changes of any kind made in the interim are not cause
for claims. Individual configurations depicted or
described here are only available optionally. In the
event of contradictions between individual documents
regarding delivery scope, the information in our current
price list applies.
Explanation of symbols
Instructions and information
Layout of safety instructions
SIGNAL WORD!
Type and source of danger
Possible effects
• Measures for avoiding the danger
Types of safety instruction
CAUTION!
On non-compliance withthis safety instruction, there is
a risk of material damage.
WARNING!
On non-compliance withthis safety instruction, there is
a risk of physical injury.
DANGER!
On non-compliance with this safety instruction, there is
a risk of major physical injury.

4 www.eta.co.at
Installation
2 Installation
Assembly and installation only by qualified
specialist personnel
The assembly and installation may be performed
by specialist personnel with the corresponding
qualifications only.
DANGER!
Electric shock
There are live parts on the circuit boards. If
touched, they can cause injury and
property damage.
Before beginning any work, isolate the system
completely from all power sources, ensure that it
cannot be switched back on, and verify that it is
safely isolated from supply.
Remove existing maintenance cover
Remove the panel on the top of the boiler.
Fig. 2-1: Panel
Remove the insulation over the maintenance cover.
Fig. 2-2: Insulation
Remove the maintenance cover.
Fig. 2-3: Maintenance cover
Mount the maintenance cover with the actuator for
flue gas recirculation
Mount the maintenance cover with the actuator for flue
gas recirculation on the boiler. Tighten the screws
evenly and cross-wise.
Fig. 2-4: Maintenance cover with actuator for flue gas recir-
culation

Installation
5
Remove the precut cut-out in the insulation.
Fig. 2-5: Insulation
Place the insulation over the maintenance cover.
Connect the actuator
Connect the cable to the circuit board [GM-C] and
connect it to terminals [S506] and [S513].
Fig. 2-6: Connect the actuator
Mount panel on the top
Break out the cut-out in the panel for the actuator.
Fig. 2-7: Cut-out

6 www.eta.co.at
Installation
Remount the panel on the top of the boiler again.
Fig. 2-8: Panel
Slide the cover over the actuator and fasten.
Fig. 2-9: Cover

Configuration
7
3 Configuration
Content of this configuration
Only the steps required for the configuration of this
product are described below.
The configuration of the complete heating system is
described in the "Configuration" manual supplied with
the boiler.
Software version X.36.0 or later
The configuration requires software version X.36.0 or
later. An update must be performed if an older software
version is installed.
Starting the configuration assistant
In the system settings, increase the authorization
to [Service], and open the system configuration menu
with the [Systems configuration] button.
Fig. 3-1: System configuration menu
Start the configuration assistant with the [Starting
the assistant] button.
Adjusting options in the function block [Boiler]
Select the required function block from the [Selected
function blocks] column:
Open the option and enable the following:
Press the [Accept] button to save.
Further configuration and installation
Continue with configuration and installation ofthe
heating system as described in the "Configura-
tion" manual supplied with the boiler.
Selected function blocks
HA-C 0
Boiler
Flue gas recirculation
