TriangleTube PSRKIT84 User manual

Venturi Replacement Kit
for PRE TIGE 399
1
Kit Part Number: P RKIT84
Parts Kit (Fig. 1):
1 - Venturi 001 Blower O-Ring Gasket
2 - (6) T-40 M8 Screws
3 - T-40 Torx Wrench
4 - Venturi / Gas Pipe Gasket
5 - Venturi
6. Gas Pipe/Venturi Gasket
Recommended Tools:
1. Phillips Screwdriver
2. Flat Blade Putty Knife
3. 10mm Socket and/or 10mm Wrench
and/or Adjustable Wrench
For your safety, the boiler may be extremely
hot. Ensure the boiler has properly cool prior
to servicing. Failure to do so can cause severe
personal injury.
Failure to follow instructions below can
result in severe personal injury or damage if
ignored.
• Instructions are for a qualified installer/
service technician.
• Read all instructions before proceeding.
• Follow instructions in proper order.
WARNINGWARNING
5
6
3
1
2
4
Fig. 1: Kit Components
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
WARNING NOTICE

Venturi Replacement Kit
for PRE TIGE 399
Instructions
1. Turn power to the unit “OFF”.
2. Remove the front jacket panel. Swing away the
Control Module panel (MCBA). Tilt down the
Control Module panel (TriMax).
3. Shut off gas supply to the Prestige boiler at the
main manual shutoff valve.
4. Disconnect the gas piping at the union located just
before the gas valve inside the boiler enclosure.
5. Disconnect wires to the gas valve.
6. Remove the air inlet elbow from the venturi.
Note the orientation of the venturi / gas valve
assembly in relation to the blower housing
when disassembling the venturi / gas valve
assembly.
7. Using the T-40 Torx wrench from the kit,
remove the 6 screws securing the venturi
assembly to the blower, see Fig. 2. Remove the
venturi / gas valve assembly from the blower.
8. Remove the 4 screws securing the gas valve
outlet pipe to the venturi.
9. Install the new venturi to the gas valve outlet
pipe using the original 4 mounting screws.
Ensure the new gaskets are in place and the
screws are tight.
Ensure the brass orifice (natural or propane)
is in place prior to the assembly ot the ven-
turi to the gas outlet pipe.
10. Install the new venturi O-ring gasket on the
blower. Reassemble the venturi / gas valve
assembly to the blower housing using the 6 sup-
plied T-40 Torx screws. Make sure all screws
are tight and secure.
11. Reconnect the gas supply piping using two
wrenches. Open the manual gas shut off valve
to check and test all gas connections for leaks
before placing the PRESTIGE unit back into
operation. Repair leaks if found.
NOTICE
WARNING
2
Venturi Mounting
Screw
Gas Valve
Fig. 2: Venturi/Gas Valve Assembly
Gas Outlet
Pipe
Blower
Venturi / Blower
O-Ring Gasket
Venturi / Gas Pipe
Gasket
Venturi
Fig. 3: Venturi/Blower/Gas Valve Assembly

Venturi Replacement Kit
for PRE TIGE 399
3
Do not check for gas leaks with an open
flame. Use a bubble test. Failure to check for
gas leaks can cause severe personal injury,
death or substantial property damage
12. Reconnect the wires to the gas valve as shown
in Fig.4.
13. Reattach the air inlet elbow to the venturi.
14. Reposition the Control Module panel and reat-
tach the front jacket panel.
15. Turn power supply to the Prestige “O ” and
return the unit to service.
COMBU TION TE T/ADJU TMENT
The installer MUST perform a complete combus-
tion check to ensure the following combustion lev-
els are met at high and low input firing rates and the
burner is operating at optimum conditions.
The combustion testing and adjustments
must be performed by a qualified installer,
service agency or the gas supplier. All com-
bustion measurements must be perform with
calibrated equipment to ensure proper read-
ings and accuracy.
Failure to perform a complete combustion
test at both high and low input rates may
result in incomplete combustion and the pro-
duction of carbon monoxide, which can
cause severe personal injury, death or sub-
stantial property damage.
MCBA Instructions
1. Manually place the boiler into High fire mode
by pressing the MODE button with “+” button
simultaneously on the control panel display
while in the standby (STBY) mode.
The control panel will display an H followed
by the current boiler temperature when
placed into High fire test mode.
2. If the combustion levels during High fire are
outside the recommended combustion settings
adjust the THROTTLE SCREW (see Fig. 4) as
follows:
Counter-clockwise adjustment of the THROT-
TLE CREW at high fire:
O2decreases and C02increases
Clockwise adjustment of the THROTTLE
CREW at high fire:
O2increases and CO2decreases
Table 1: Recommended Combustion Levels
3. Once the combustion level is set at High fire,
manually place the boiler into Low fire mode by
pressing the MODE button with “-” button
simultaneously on the control display while in
the standby (STBY) mode.
The control panel will display a L followed
by the current boiler temperature when
placed into low fire test mode.
WARNING
WARNING
NOTICE
WARNING
NOTICE
Natural Gas Propane
O2 Min. 2.30% 3.70%
O2 Max. 5.30% 5.20%
CO2 Min. 8.80% 10.00%
CO2 Max. 10.50% 11.00%
CO Max. 100 ppm 100 ppm

Venturi Replacement Kit
for PRE TIGE 399
4
4. If the combustion level during Low fire is not
within +/-0.2% of the combustion level measured
at High fire, adjust the OFFSET SCREW below
the cap on the gas valve (see Fig. 4) as follows.
Counter-clockwise adjustment of OFF ET
CREW at low fire:
O2increases and CO2decreases
Clockwise adjustment of OFF ET CREW at
low fire:
O2decreases and CO2increases
5. Press the “+” and “-” buttons simultaneously to
shutdown the burner.
Trimax Instructions
1. Press the round I STALLER button. See Fig. 5.
2. Enter the installer access code “054” by using
the LEFT and RIGHT buttons to select a digit
and the UP and DOWN buttons to change the
digit. Press the OK button to enter the access
code.
3. Press the RIGHT button to highlight the
Manual Operation icon then press the OK
button.
4. Press the OK button while the FA icon is
highlighted to manually fire the burner and
power the CH circulator.
An adequate CH load must be present to dis-
sipate the heat generated during the combus-
tion test. If an adequate CH load is not avail-
able, an indirect water heater can be used to
dissipate the heat by creating a DHW call
which will enable the DHW circulator.
NOTICE
4
1
2
2
3
1
5
Fig. 4: Venturi Gas Valve Assembly
1. Brown (MCBA) Black (TriMax) wire
2. Blue (MCBA) White (TriMax)wire
3. Throttle screw
4. Offset screw
5. Inlet Pressure Tap
Installer
Button
Fig. 5: Trimax Navigation Buttons
Manual Operation
Released
O
O
O
CH
CH1
FAN
DHW
SYS
CH2

Venturi Replacement Kit
for PRE TIGE 399
Date: 5/30/12 2011-52 Venturi Repl. Kit Prestige 399
5. Press the RIGHT button to adjust the firing rate
to 100%. Hold down the RIGHT button to
rapidly increase the firing rate.
6. If the combustion levels during High fire are
outside the recommended combustion settings
adjust the THROTTLE SCREW (see Fig. 4) as
follows:
Counter-clockwise adjustment of the THROT-
TLE CREW at high fire:
O2decreases and C02increases
Clockwise adjustment of the THROTTLE
CREW at high fire:
O2increases and CO2decreases
7. Once the combustion level is set at High fire,
manually place the boiler into Low fire mode by
pressing the LEFT button to adjust firing rate
down to 0%.
8. If the combustion level during Low fire is not
within +/-0.2% of the combustion level mea-
sured at High fire, adjust the OFFSET SCREW
below the cap on the gas valve (see Fig. 4) as
follows:
Counter-clockwise adjustment of OFF ET
CREW at low fire:
O2increases and CO2decreases
Clockwise adjustment of OFF ET CREW at
low fire:
O2decreases and CO2increases
9. Press the OK button while the fan icon is high-
lighted to shutdown the burner.
10. Press the LEFT or RIGHT button to highlight
the home screen icon to exit the service
mode.
