Eterna Super Kontiki User manual

USER MANUAL

1
KonTiki - Date Ø 42 mm
Super KonTiki - Date Ø 45 mm
Super KonTiki 1973 Ø 44 mm
Lady KonTiki - Diver Ø 38 mm
Super KonTiki - Black Ø 45 mm
Royal KonTiki -
Chronograph 'Flyback' GMT Manufacture Ø 45 mm
1

3
TABLE OF CONTENTS
4 KonTiki - Date Ø 42 mm
Super KonTiki - Date Ø 45 mm
Super KonTiki 1973 Ø 44 mm
Lady KonTiki - Diver Ø 38 mm
Super KonTiki - Black Ø 45 mm
8 Royal KonTiki -
Chronograph 'Flyback' GMT Manufacture Ø 45 mm
14 Important Advice
ENGLISH
3

A
5
BC
4
3
1
2
4
1. DISPLAY – FUNCTIONS
1 Hour hand
2 Minute hand
3Central seconds hand
4Date indicator
5Setting crown
ENGLISH
4

5
2. WINDING – SETTINGS
2.1 GENERAL POINTS
To ensure optimum water resistance, your watch has a
screw-in setting crown. This one oers one waterproof-
ness to your watch, assured until 200 m (20 bar) of depth
To enable watch winding and settings, you first need to
release the screw-in crown 5. To do so, undo the crown a
few turns. Once winding or setting is complete, push the
crown back in against the case, and screw it back in fully.
Never operate the crown underwater or when it is still
wet. The crown 5has 3 positions:
ARest and manual winding position
BRapid date correction position
CTime-setting position with stop seconds and
date change at midnight
NOTES
Once the setting is complete, always push the
crown back in against the case to safeguard the
watch's water resistance. Never operate the crown
underwater or when it is still wet.
2.2 WINDING
CROWN 5IN REST POSITION A
Your watch has an automatic mechanical movement
which is wound by the motion of your wrist when you
ENGLISH
5

6
are wearing the watch. It is therefore not normally neces-
sary to manually wind the watch. However, if your watch
should stop, simply turn the crown 5through a few turns
clockwise to restart it. When fully wound, your watch has
a power reserve of approximately 38 hours.
NOTE
There is no end of winding stop. A protective
mechanism prevents excessive winding of the
movement.
2.3 SETTING THE TIME
CROWN 5PULLED OUT TO POSITION C
To set the time, pull the crown 5out two notches to posi-
tion C. Turn it in either direction to position the hands to
the desired time. When the hour hand passes the 12 o'clock
position, you will see whether it is indicating midnight (the
date changes) or midday (the date does not change). Check
that the date set previously has not changed. Once the
setting is complete, push the crown back in against the
case to the rest position A. The hands will restart.
NOTE
For a time setting accurate to the second, we
recommend pulling the crown out to position C
when the central seconds hand 3is at precisely 12
o'clock, and pushing it back in to synchronise with
an ocial time signal.
ENGLISH
6

7
2.4 RAPID DATE CORRECTION
CROWN 5 PULLED OUT TO INTERMEDIATE POSITION B
Pull the crown 5out one notch to position B. Turn it
clockwise until the correct date appears in the window 4.
Then push the crown 5back in against the case to the
rest position A.
NOTE
During this operation your watch continues to run
normally, hence the time does not need to be
corrected.
IMPORTANT
Never correct the date between 8:00 p.m. and 2:00
a.m. The movement is in the date change process,
and could be damaged.
ENGLISH
7

A
6
BC
3
7B.
5
2
9
A.
4
8
1
8
1. DISPLAY – FUNCTIONS
WATCH
1Hour hand
2Minute hand
3Small seconds hand
424 h/GMT hand
5Date indicator
6Setting crown
CHRONOGRAPH
7 Chronograph seconds hand
8 30-minute counter
9 12-hour counter
A. Start-stop push-button
B. Chronograph reset / flyback
push-button
ENGLISH
8

9
2. WINDING – SETTINGS
2.1 GENERAL POINTS
To ensure optimum water resistance, your watch has a
screw-in setting crown. This one oers one waterproof-
ness to your watch, assured until 100 m (10 bar) of depth.
To enable watch winding and settings, you first need to
release the screw-in crown 6. To do so, undo the crown a
few turns. Once winding or setting is complete, push the
crown back in against the case, and screw it back in fully.
Never operate the crown underwater or when it is still
wet. The crown 6has 3 positions:
ARest and manual winding position
BRapid date correction and 2nd time zone time-
setting position
CLocal time-setting position with stop seconds
and date change at midnight
2.2 WINDING
CROWN 6IN REST POSITION A
Your watch has an automatic mechanical movement
which is wound by the motion of your wrist when you are
wearing the watch. It is therefore not normally necessary
to manually wind the watch.
ENGLISH
9

10
However, if your watch should stop, simply turn the
crown 6through a few turns clockwise to restart it.
When fully wound, your watch has a power reserve of
approximately 60 hours.
NOTE
There is no end of winding stop. A protective mecha-
nism prevents excessive winding of the movement.
2.3 SETTING THE TIME
CROWN 6PULLED OUT TO POSITION C :
LOCAL TIME
CROWN 6PULLED OUT TO POSITION B :
2ND TIME ZONE HOUR
Local time: pull the crown 6 out two notches to position
C. The small seconds hand 3will stop. Then turn it in
either direction to position the hands 1 and 2 to the desi-
red local time. When the hour hand passes the 12 o'clock
position, you will see whether it is indicating midnight
(the date changes) or midday (the date does not change).
Check that the date set previously has not changed.
2nd time zone time: pull the crown 6out to the interme-
diate position B. Then turn it clockwise to position the 4
2nd time zone hour hand to the desired reference time.
Then push the crown 6 back in against the case to the
rest position A. The small seconds hand 3will restart.
ENGLISH
10

11
NOTE
For a time setting accurate to the second, we re-
commend pulling the crown out to position C
when the small seconds hand 3is at precisely 12
o'clock, and pushing it back in to synchronise with
an ocial time signal.
2.4 RAPID DATE CORRECTION
CROWN 6 PULLED OUT TO INTERMEDIATE POSITION B
Pull the crown 6out one notch to position B. Turn it anti-
clockwise until the correct date appears in the window 5.
Then push the crown 6back in against the case to the
rest position A.
NOTE
During this operation your watch continues to run
normally, hence the time does not need to be corrected.
IMPORTANT
Never correct the date between 8:00 p.m. and 2:00
a.m. The movement is in the date change process,
and could be damaged.
ENGLISH
11

12
3. CHRONOGRAPH FUNCTIONS
With the chronograph you can measure times of up to
12 hours.
3.1 STARTING THE CHRONOGRAPH
Pressing push-button A. starts the chronograph central
seconds hand 7. It completes a full turn of the dial in 60 se-
conds. The chronograph minute counter 8 and hour coun-
ter 9at 3 o'clock record the time elapsed since starting.
3.2 STOPPING THE CHRONOGRAPH
Pressing push-button A. again stops the chronograph
central seconds hand 7and the chronograph counter
hands 8and 9, enabling you to read the elapsed time.
3.3 RESETTING THE CHRONOGRAPH
Pressing push-button B. resets the chronograph, rea-
dying it for a new timing operation.
3.4 SUCCESSIVE TIMING OPERATIONS (LAP TIMES)
To measure successive times, you need only activate and
pause the chronograph at will using the push-button A.
at 2 o'clock. The corresponding hands are not reset, but
restart directly from their stop position. The chrono-
graph is reset using the push-button B. at 4 o'clock.
ENGLISH
12

13
3.5 FLYBACK
With the timing operation underway, when you press
push-button B., the hour, minute and seconds hands will
return to their initial position, while continuing to count
the time.
ENGLISH
13

14
IMPORTANT ADVICE
WATER RESISTANCE
The waterproofness of your watch is assured according
to specification quoted in the paragraph 2.1 majorities.
Nevertheless, it is important to understand that repea-
ted handling of the case, ageing of the sealing compo-
nents and high temperature variations (e.g. from hot
sun to cold water) may get the better of the most water-
resistant case.
Since water and moisture infiltration may lead to costly
repairs, you are strongly advised to have your watch's
water resistance checked regularly by an Eterna autho-
rised retailer or an approved Eterna general agent.
ENGLISH
14

15
CARE AND MAINTENANCE
Your watch was manufactured with the utmost care.
Observing the recommendations below will help
preserve its rate accuracy and as-new appearance for as
long as possible.
If your watch is equipped with a leather strap, we
recommend avoiding any contact with water, to
optimise the leather’s longevity. We also recommend
cleaning your watch regularly using a damp soft cloth.
After bathing in seawater, rinse the watch in fresh water
and leave it to dry out completely.
Avoid leaving your watch in places exposed to high
variations in temperature or humidity, extreme
temperatures, bright sunlight or strong magnetic
fields. Avoid direct contact with solvents, detergents,
perfumes, cosmetics, etc. They may damage the wristlet,
case or gaskets. Avoid thermal shocks, or impacts: they
could damage your watch. In case of violent impact,
please have your watch checked by an Eterna authorised
retailer or an approved Eterna general agent.
ENGLISH
15

16
SERVICING
It is advisable to have your watch overhauled and fully
cleaned at least once every 4 years, and in particular to
have the movement overhauled, since its operation may
be disrupted due to ageing of the oil and grease.
To ensure irreproachable maintenance service and
safeguard the warranty validity, always entrust your
watch to an Eterna authorised retailer or an approved
Eterna general agent.
For any questions, please contact your Eterna authorised
retailer or the Eterna general agent for your country. You
can find the addresses and a host of information on our
website: www.eterna.com
ENGLISH
16

17
END-OF-LIFE COLLECTION AND TREATMENT
OF QUARTZ WATCHES*
This symbol indicates that this product must
not be disposed of with household waste.
It must be taken to an approved collection
point. By following this procedure, you will
contribute to protecting the environment and
human health. Recycling of materials helps conserve
natural resources.
* applicable in European Community member countries,
and in countries with comparable legislation.
ENGLISH
17
