MGBS-P-I-AP… Unicode/Multicode

Operating Instructions
Safety System MGBS-P-I-AP…
2(Translation of the original operating instructions) 2527247-01-09/19
Contents
1. About this document............................................................................................. 4
1.1. Scope............................................................................................................................................4
1.2. Target group ..................................................................................................................................4
1.3. Key to symbols...............................................................................................................................4
1.4. Supplementary documents ..............................................................................................................4
2. Correct use .......................................................................................................... 5
3. Description of the safety function .......................................................................... 6
4. Exclusion of liability and warranty ......................................................................... 7
5. General safety precautions ................................................................................... 7
6. Function............................................................................................................... 8
6.1. Door monitoring output (OD)............................................................................................................8
6.2. Diagnostic output (OI)......................................................................................................................8
6.3. Version MGBS Extended..................................................................................................................8
6.4. Switching states .............................................................................................................................8
7. System overview................................................................................................... 9
7.1. MGBS-P-I-…....................................................................................................................................9
7.2. MGBS-H-… .....................................................................................................................................9
7.3. MGB-E-… (optional) .........................................................................................................................9
7.4. Dimension drawing (example illustration).........................................................................................10
7.5. Drilling pattern (example illustration) ...............................................................................................11
8. Manual release................................................................................................... 12
8.1. Escape release MGB-E-… (optional)................................................................................................12
8.1.1. Preparing escape release ..............................................................................................12
8.2. Lockout mechanism......................................................................................................................13
9. Changing actuating direction of the interlocking module...................................... 14
10. Mounting............................................................................................................ 15
10.1. Mounting examples.......................................................................................................................15
11. Electrical connection .......................................................................................... 16
11.1. Notes about .........................................................................................................................16
11.2. Safety in case of faults..................................................................................................................17
11.3. Fuse protection for power supply...................................................................................................17
11.4. Requirements for connecting cables...............................................................................................17
11.5. Connector assignment of interlocking modules MGBS-…-AP-…-SA-…
with plug connector M12, 8-pin......................................................................................................18
11.6. Connection of MGBS-I-AP...............................................................................................................19
11.7. Notes on operation with safe control systems.................................................................................20

3
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
12. Setup ................................................................................................................. 21
12.1. LED displays ................................................................................................................................21
12.2. Teach-in function for handle module (only for unicode evaluation) ......................................................21
12.2.1. Teaching in handle module.............................................................................................22
4.1. Functional check...........................................................................................................................22
4.1.1. Mechanical function test ................................................................................................22
4.1.2. Electrical function test...................................................................................................22
5. System status table ............................................................................................ 23
6. Technical data .................................................................................................... 24
6.1. Technical data for interlocking module MGBS-P-I-AP .........................................................................24
6.1.1. Typical system times.....................................................................................................25
6.2. Switching distances ......................................................................................................................25
6.3. Radio frequency approvals.............................................................................................................26
6.4. Dimension drawings of variants......................................................................................................27
7. Ordering information and accessories................................................................. 28
8. Inspection and service ........................................................................................ 28
9. Service .............................................................................................................. 28
10. Declaration of conformity ................................................................................... 29

Operating Instructions
Safety System MGBS-P-I-AP…
4(Translation of the original operating instructions) 2527247-01-09/19
1. About this document
1.1. Scope
These operating instructions are valid for all MGBS-P-I-AP… from version V1.0.0. These operating instructions, the document
“Safety information and maintenance” and any enclosed data sheet form the complete user information for your device.
1.2. Target group
Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing
special expertise in handling safety components.
1.3. Key to symbols
Symbol/depiction Meaning
Printed document
Internet
www Document is available for download at www.euchner.com
Document on CD
MEM This section is applicable only if the memory card is used
DANGER
WARNING
CAUTION
Safety precautions
Danger of death or severe injuries
Warning about possible injuries
Caution slight injuries possible
NOTICE
Important!
Notice about possible device damage
Important information
Tip Useful information
1.4. Supplementary documents
The overall documentation for this device consists of the following documents:
Document title
(document number) Contents
Safety Information and
Maintenance MGBS
(2519732)
Basic information for safe setup and service
Operating instructions
(2527247) (this document)
Possibly enclosed data
sheet Item-specic information about deviations or additions
Important!
Always read all documents to gain a complete overview of safe installation, setup and use of the
device. The documents can be downloaded from www.euchner.com. For this purpose enter the doc.
no. in the search box.

5
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
2. Correct use
The safety system MGBS consists at minimum of one interlocking module MGBS-P-I-… and one handle module MGBS-H…
and is an interlocking device without guard locking (type 4). Devices with unicode evaluation possess a high coding level,
devices with multicode evaluation possess a low coding level.
In combination with a movable guard and the machine control, this safety component prevents dangerous machine functions
from occurring while the guard is open. A stop command is triggered if the guard is opened during the dangerous machine
function.
This means:
ÌStarting commands that cause a dangerous machine function must become active only when the guard is closed.
ÌOpening the guard triggers a stop command.
ÌClosing a guard must not cause automatic starting of a dangerous machine function. A separate start command must
be issued. For exceptions, refer to ENISO12100 or relevant C-standards.
Before the device is used, a risk assessment must be performed on the machine, e.g. in accordance with the following
standards:
ÌENISO13849-1
ÌENISO12100
ÌIEC62061
Correct use includes observing the relevant requirements for installation and operation, particularly based on the following
standards:
ÌENISO13849-1
ÌENISO14119
ÌEN60204-1
The interlocking module is allowed to be operated only in conjunction with the intended EUCHNER handle module and the
related connection components from EUCHNER. On the use of other handle modules or other connection components,
EUCHNER provides no warranty for safe function.
Important!
ÌThe user is responsible for the proper integration of the device into a safe overall system. For this
purpose, the overall system must be validated, e.g. in accordance with ENISO13849-2.
ÌCorrect use requires observing the permissible operating parameters (see chapter 6. Technical
data on page 24).
ÌIf a data sheet is included with the product, the information on the data sheet applies.
ÌIt is only allowed to use components that are permissible in accordance with the table below.

Operating Instructions
Safety System MGBS-P-I-AP…
6(Translation of the original operating instructions) 2527247-01-09/19
Table 1: Possible combinations for MGBS components
Interlocking module
Handle module
MGBS-H…
MGBS…
Key to symbols Combination possible
3. Description of the safety function
Devices from this series feature the following safety functions:
Monitoring of the guard position
(interlocking device according to ENISO14119)
ÌSafety function (see chapter 6.4. Switching states on page 8):
- The safety outputs are switched off when the guard is open (monitoring of the door position).
ÌSafety characteristics: category, Performance Level, PFHD(see chapter 6. Technical data on page 24).
The following applies to devices with emergency stop:
Emergency stop (emergency stop device according to EN ISO 13850)
ÌSafety function: emergency stop function
ÌSafety characteristics: B10D value (see data sheet enclosed)

7
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
4. Exclusion of liability and warranty
In case of failure to comply with the conditions for correct use stated above, or if the safety regulations are not followed,
or if any servicing is not performed as required, liability will be excluded and the warranty void.
5. General safety precautions
Interlocking modules fulll personnel protection functions. Incorrect installation or tampering can lead to fatal injuries to
personnel.
Check the safe function of the guard particularly
Ìafter any setup work
Ìafter the replacement of a system component
Ìafter an extended period without use
Ìafter every fault
Independent of these checks, the safe function of the guard should be checked at suitable intervals as part of the mainte-
nance schedule.
WARNING
Danger to life due to improper installation or due to bypassing (tampering). Safety components perform
a personnel protection function.
ÌSafety components must not be bypassed, turned away, removed or otherwise rendered ineffec-
tive. On this topic pay attention in particular to the measures for reducing the possibility of bypass-
ing according to ENISO14119:2013, section 7.
ÌThe switching operation may be triggered only by handle modules designated for this purpose.
ÌPrevent bypassing by means of replacement handle modules (only for multicode evaluation). For
this purpose, restrict access to handle modules and to keys for releases, for example.
ÌMounting, electrical connection and setup only by authorized personnel possessing the following
knowledge:
- specialist knowledge in handling safety components
- knowledge about the applicable EMC regulations
- knowledge about the applicable regulations on operational safety and accident prevention.
Important!
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating
instructions are always available during mounting, setup and servicing. EUCHNER cannot provide any
warranty in relation to the readability of the CD for the storage period required. For this reason you
should archive a printed copy of the operating instructions. You can download the operating instruc-
tions from www.euchner.com.

Operating Instructions
Safety System MGBS-P-I-AP…
8(Translation of the original operating instructions) 2527247-01-09/19
6. Function
The device monitors the position of movable guards.
The system consists of the following components: coded handle module (transponder)
and interlocking module.
Whether the device learns the complete transponder code (unicode) or not (multicode)
depends on the respective version.
ÌDevices with unicode evaluation: The handle module must be assigned to the
interlocking module by a teach-in operation so that it is detected by the system. This
unambiguous assignment ensures a particularly high level of protection against tam-
pering. The system thus possesses a high coding level.
ÌDevices with multicode evaluation: Unlike systems with unique code detection,
on multicode devices a specic code is not requested but instead it is only checked
whether the handle module is of a type that can be detected by the system (mul-
ticode detection). There is no exact comparison of the transponder code with the
taught-in code in the interlocking module (unique code detection). The system pos-
sesses a low coding level.
The tongue on the handle module is inserted in the interlocking module as the guard is closed. When the switch-on distance
is reached, power is supplied to the transponder in the handle module by the interlocking module and data are transferred.
If a permissible code is detected, the safety outputs are switched on.
The safety outputs are switched off when the guard is opened.
In the event of a fault in the interlocking module, the safety outputs are switched off and the DIA LED illuminates red. The
occurrence of faults is detected at the latest on the next demand to close the safety outputs (e.g. on starting).
6.1. Door monitoring output (OD)
The door monitoring output is switched on as soon as the bolt tongue of the handle module is inserted in the interlocking
module (state: guard closed).
6.2. Diagnostic output (OI)
The diagnostic output is switched on in the event of a fault (switch-on condition as for DIA LED).
6.3. Version MGBS Extended
Some versions contain additional controls/indicators in the housing cover. Please refer to the enclosed data sheet for
further information.
6.4. Switching states
The detailed switching states for your interlocking module can be found in the system status table. All safety outputs, mon-
itoring outputs and display LEDs are described there.
Guard closed
(Bolt tongue fully inserted in interlock-
ing module)
Guard open
Safety outputs FO1A and FO1B on off
Door monitoring output OD on off
Transponder coded handle
module
Interlocking module

9
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
7. System overview
7.1. MGBS-P-I-…
1
2
Key:
1Interlocking module
2Optionally with Extended version
NOTICE
ÌDepending on the version, additional controls and
indicators may be integrated.
ÌDepending on the version, a mounting plate can
be included. See enclosed data sheet.
7.2. MGBS-H-…
6
1
4
4
3
5
2
Key:
1Door handle
2Marking for adjustment
3Locking pin for changing the direction of rotation of the
door handle
4Locking screws T10 for housing cover
5Bolt tongue
6Fixing screw
NOTICE
ÌDepending on the version, a mounting plate can
be included. See enclosed data sheet.
7.3. MGB-E-… (optional)
4
1
2
3
A
Key:
A Snap ring
1Actuation axis
2Door handle
3Fixing screw
4Protective sleeve
NOTICE
ÌDepending on the version, a mounting plate can
be included. See enclosed data sheet.

Operating Instructions
Safety System MGBS-P-I-AP…
10 (Translation of the original operating instructions) 2527247-01-09/19
7.4. Dimension drawing (example illustration)
107
8
40 11,5
2,4
109,4
55,5
40 56
90
5,7.nim
5,21.xam
183
13044
115,5
63
42
22,262,3
110,6
min. 1
max, 6
114,2
114,3
130,05
40
286
min. 7,5
max.12,45
40 115,584,5
14
120
266
40
105
73,7
16,5
14,8
6,3
89,4
4,15
18
11
6,2
89,4
6,4
7,5
2475
68
6,4
62,5
114
Square drive
Prole

11
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
7.5. Drilling pattern (example illustration)
13040
40 40
15
114
286
184
1,3
ZU
CLOSED
AUF
OPEN
40
89,4
7,5
16,514,8
120
6,2
18
266
73,5
146
13,7
14,5
24
6,6
89,4
86,5 7,5
21
30
37,5
min.
6
A 1 : 2
max.
10
ZU
CLOSED
AUF
OPEN
A 1 : 2
max.
10
MGBS-P-...
MGB-E-...
MGBS-H-...

Operating Instructions
Safety System MGBS-P-I-AP…
12 (Translation of the original operating instructions) 2527247-01-09/19
8. Manual release
8.1. Escape release MGB-E-… (optional)
+ +
MGBS-H...-L-...
MGB-E-...
MGBS-H...-R-...
MGBS-P-I-AP...
8.1.1. Preparing escape release
Prole width Length required for actuation
axis
Which EUCHNER parts are required? Necessary work steps
Without
mounting
plates
With mounting
plates
(4 mm each)
D D+9 D+17
30 mm 39 mm 47 mm Standard escape release
with 107 mm axis
(order no. 100465)
Shorten to required length
40 mm 49 mm 57 mm Standard escape release
with 107 mm axis
(order no. 100465)
If necessary,
extended actuation axis (order no. 106761)
Without mounting plates:
None
With mounting plates:
Use extended actuation axis and protective sleeve and
shorten to required length
45 mm 54 mm 62 mm Standard escape release
with 107 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length
50 mm 59 mm 67 mm Standard escape release
with 107 mm axis
(order no. 100465)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length

13
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
1Insert actuation axis.
The snap ring A must be in contact
with the inner door handle B.
2Fit door handle.
3Tighten xing screw to 2Nm.
4Fit protective sleeve.
4
1
2
3
A
182
D - 1 *
107
39,5
D
11,5 55,5
55,5
M4
250
D + 9
Example without mounting plates
Standard
protective
sleeve
Extended
protective
sleeve
Standard
actuation axis
Extended
actuation axis
Escape release
Handle module
+4mm per mounting plate
8.2. Lockout mechanism
The lockout mechanism can be secured with padlocks (see Figure 1). This is intended to prevent people from being locked
in unintentionally. The lockout mechanism does not fulll any safety function.
¨To pivot out, press the grooved part (possible only with bolt tongue retracted).
2
Key:
1Automatically extending lockout mechanism (optional)
Padlock ∅min. 6mm, ∅max. 10 mm
Notice:
You can t up to three locks ∅8mm per lockout mechanism.
Figure 1: Lockout mechanism secured with padlock

Operating Instructions
Safety System MGBS-P-I-AP…
14 (Translation of the original operating instructions) 2527247-01-09/19
9. Changing actuating direction of the interlocking module
NOTICE
ÌPlease read the operating instructions of the device before use!
ÌIf a data sheet is included with the product, the information on the data sheet applies.
ÌWhen using sliding doors, you are recommended to use the door knob AY-DKB…
ÌWhen changing the actuating direction please use a screwdriver (TX20).
ÌThe actuating direction of handle module MGBS-H-… cannot be changed.
1,8 Nm
1,8 Nm
MGBS-H-...-R-...
MGBS-H-...-L-...

15
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
10. Mounting
CAUTION
Interlocking modules must not be bypassed (bridging of contacts), turned away, removed or otherwise
rendered ineffective.
ÌObserve ENISO14119:2013, section 7, for information about reducing the possibilities for by-
passing an interlocking device.
NOTICE
Risk of damage to equipment and malfunctions as a result of incorrect installation.
ÌInterlocking modules and handle module must not be used as an end stop.
ÌObserve ENISO14119:2013, sections 5.2 and 5.3, for information about fastening the interlock-
ing module and the handle module.
ÌProtect the interlocking module against damage, as well as penetrating foreign objects such as
swarf, sand and blasting shot, etc.
ÌObserve the min. door radii (see chapter 7.4. Dimension drawing (example illustration) on page
10).
ÌObserve the tightening torque for fastening the interlocking module (max.1.4Nm).
10.1. Mounting examples
6 Nm
1 Nm
Figure 2: Mounting situation without escape release
6 Nm
6 Nm
1 Nm
Figure 3: Mounting situation with escape release

Operating Instructions
Safety System MGBS-P-I-AP…
16 (Translation of the original operating instructions) 2527247-01-09/19
11. Electrical connection
WARNING
If there is a mistake, loss of the safety function due to incorrect connection.
ÌTo ensure safety, both safety outputs (FO1A and FO1B) must always be evaluated.
ÌMonitoring outputs must not be used as safety outputs.
ÌLay the connecting cables with protection to prevent the risk of short circuits.
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connection.
ÌThe device generates its own test pulses on the output lines FO1A/FO1B. A downstream control
system must tolerate these test pulses, which may have a length of up to 0.35ms.
Depending on the inertia of the downstream device (control system, relay, etc.), this can lead to
short switching processes.
ÌThe inputs on an evaluation unit connected must be positive switching, as the two outputs on the
interlocking module deliver a level of +24V in the switched-on state.
ÌAll the electrical connections must either be isolated from the mains supply by a safety transformer
according to IEC 61558-2-6 with limited output voltage in the event of a fault, or by other equivalent
isolation measures (PELV).
ÌAll electrical outputs must have an adequate protective circuit for inductive loads. The outputs
must be protected with a free-wheeling diode for this purpose. RC interference suppression units
must not be used.
ÌPower devices which are a powerful source of interference must be installed in a separate location
away from the input and output circuits for signal processing. The cable routing for safety circuits
should be as far away as possible from the cables of the power circuits.
ÌTo avoid EMC interference, the physical environmental and operating conditions at the in-
stallation site of the device must comply with the requirements according to the standard
EN60204-1:2006, section 4.4.2 (EMC).
Please pay attention to any interference elds from devices such as frequency converters or induction
heating systems. Observe the EMC instructions in the manuals from the respective manufacturer.
Important!
If the device does not appear to function when operating voltage is applied (e.g. green STATE LED
does not ash), the interlocking module must be returned unopened to the manufacturer.
11.1. Notes about
Important!
ÌFor use and operation as per the requirements 1), a power supply with the feature “for use in
class 2 circuits” must be used.
Alternative solutions must comply with the following requirements:
Electrically isolated power supply unit in combination with fuse as per UL248. This fuse should be
designed for max. 3.3A and should be integrated into the 30V DC voltage section.
ÌFor use and applications as per the requirements 1), a connecting cable listed under UL cate-
gory code CYJV/7, min. 24AWG, min. 80°C, must be used.
1) Note on the scope of the UL approval: The devices have been tested as per the requirements of UL508 and CSA/C22.2 no. 14 (protection against electric shock
and re).

17
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
11.2. Safety in case of faults
ÌThe safety outputs FO1A/FO1B are short circuit-proof.
ÌA short circuit between FO1A and FO1B is detected by the interlocking module.
ÌA short circuit in the cable can be excluded by laying the cable with protection.
11.3. Fuse protection for power supply
The power supply must be provided with fuse protection depending on the number of interlocking modules and the current
required for the outputs. The following rules apply:
Max. current consumption of an individual interlocking module Imax
Imax = IUB + IFO1A+FO1B + IOD
IUB = Operating current of interlocking module (40mA)
IOD = Load current of monitoring outputs (max. 50mA per monitoring output)
IFO1A+FO1B = Load current of safety outputs FO1A + FO1B (2 x max. 150mA)
11.4. Requirements for connecting cables
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connecting cables.
ÌUse connection components and connecting cables from EUCHNER.
ÌOn the use of other connection components, the requirements in the following table apply.
EUCHNER provides no warranty for safe function in case of failure to comply with these require-
ments.
Observe the following requirements with respect to the connecting cables:
For interlocking modules MGBS-…-AP-…-SAB-… or MGBS-…-AP-…-SII-… with plug connectors 2 x M12
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8 x 0.25mm² or 5 x 0.34mm²
For interlocking modules MGBS-…-AP-…-SH-… with plug connector M23 (RC18)
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIFY11Y min. 19-core
For interlocking modules MGBS-…-AP-…-SA-… with plug connector M12, 8-pin
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8 x 0.25mm²

Operating Instructions
Safety System MGBS-P-I-AP…
18 (Translation of the original operating instructions) 2527247-01-09/19
11.5. Connector assignment of interlocking modules MGBS-…-AP-…-SA-…
with plug connector M12, 8-pin
Plug connector
(view of connection side) Pin Designation Function Conductor coloring Connecting cable 1)
1 x M12
8
5
6
7
2
4
3
1
1 n.c. - WH
2 UB Operating voltage of AP electronics 24 V DC BN
3 FO1A Safety output, channel 1 GN
4 FO1B Safety output, channel 2 YE
5 OI Diagnostic output GY
6 OD Door monitoring output PK
7 0 V Operating voltage of AP electronics 0V BU
8 n.c. - RD
1) Only for standard EUCHNER connecting cable.

19
2527247-01-09/19 (Translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-I-AP…
EN
11.6. Connection of MGBS-I-AP
Connect the device as shown in Figure 4. The monitoring outputs can be routed to a control system.
WARNING
If there is a mistake, loss of the safety function due to incorrect connection.
ÌTo ensure safety, both safety outputs (FO1A and FO1B) must always be evaluated.
Important!
ÌThe example shows only an excerpt that is relevant for the connection of the MGBS system.
The example illustrated here does not show complete system planning. The user is responsi-
ble for safe integration into the overall system. Detailed application examples can be found at
www.euchner.com. Simply enter the order number of your interlocking module in the search box.
All available connection examples for the device can be found in “Downloads.”
Connected load
Safety Outputs
Door
Monitoring
Read Head
Actuator
Monitoring Outputs
FO1B
4
OI
5
Diagnostic
-B1 UB
2
1
n.c. n.c.
8
0 V
UB
7
OD
6
FO1A
3
MGBS
1
2
-F1
24V DC
0 V
24V DC
0 V
Figure 4: Connection example, version with plug connector M12

Operating Instructions
Safety System MGBS-P-I-AP…
20 (Translation of the original operating instructions) 2527247-01-09/19
11.7. Notes on operation with safe control systems
Please observe the following requirements for connection to safe control systems:
ÌUse a common power supply for the control system and the connected interlocking modules.
ÌThe device tolerates voltage interruptions on UB of up to 5ms. Tap the supply voltage directly from the power supply
unit. If the power supply is connected to a terminal of a safe control system, this output must provide sufcient electri-
cal current.
ÌThe safety outputs (FO1A and FO1B) can be connected to the safe inputs of a control system. Prerequisite: the input
must be suitable for pulsed safety signals (OSSD signals, e.g. from light grids). The control system must tolerate test
pulses on the input signals. This normally can be set up by parameter assignment in the control system. Observe the
notes of the control system manufacturer. For the pulse duration of your interlocking module, please refer to chapter 6.
Technical data on page 24.
A detailed example of connecting and setting the parameters of the control system is available for many devices at
www.euchner.com in the area Download ¨Applications ¨MGBS. The features of the respective device are dealt with there
in greater detail.
4/8 F-DI
PWR
Supply of
the control
Safety Outputs
Door
Monitoring
Read Head
Actuator
Monitoring Outputs
FO1B
4
OI
5
Diagnostic
-B1 UB
2
1
n.c. n.c.
8
0 V
UB
7
OD
6
FO1A
3
MGBS
1
2
-F2
-X1
DI4 DI0DC24V M
1
2
-F1
24V DC
0 V
24V DC
0 V
Figure 5: Connection example for the connection to ET200
