EUCHNER MGBS-P-L1H-AR-U-L-SH-161564 User manual

EN
Operating Instructions
Safety System
MGBS-P-L.-AR… Unicode/Multicode

Operating Instructions
Safety System MGBS-P-L.-AR…
2(translation of the original operating instructions) 2527246-03-06/23
Contents
1. About this document............................................................................................. 4
1.1. Scope............................................................................................................................................4
1.2. Target group ..................................................................................................................................4
1.3. Key to symbols...............................................................................................................................4
1.4. Supplementary documents ..............................................................................................................4
2. Correct use .......................................................................................................... 5
3. Description of the safety function .......................................................................... 6
4. Exclusion of liability and warranty ......................................................................... 8
5. General safety precautions ................................................................................... 8
6. Function............................................................................................................... 9
6.1. Guard lock monitoring.....................................................................................................................9
6.2. Door position monitoring output (OD)................................................................................................9
6.3. Diagnostic monitoring output (OI) .....................................................................................................9
6.4. Guard lock monitoring output (OL)....................................................................................................9
6.5. Version MGBS Extended ..................................................................................................................9
6.6. Guard locking for version MGBS-L1 ..................................................................................................9
6.7. Guard locking for version MGBS-L2 ................................................................................................10
6.8. Switching states ...........................................................................................................................10
7. System overview................................................................................................. 11
7.1. MGBS-P-… (optionally with escape release).....................................................................................11
7.2. MGBS-H-… ...................................................................................................................................11
7.3. AE-R-S1-... (for versions with escape release)..................................................................................11
7.4. Dimension drawing (example illustration).........................................................................................12
7.5. Drilling pattern (example illustration) ...............................................................................................13
8. Manual release................................................................................................... 14
8.1. Auxiliary release and auxiliary key release .......................................................................................14
8.1.1. Actuating auxiliary release ..............................................................................................14
8.1.2. Actuating auxiliary key release ........................................................................................14
8.2. Emergency release .......................................................................................................................15
8.2.1. Actuating emergency release..........................................................................................15
8.3. Escape release (optional) ..............................................................................................................15
8.3.1. Inner door handle AE-R-S1 (for variants with escape release) .............................................15
8.3.2. Preparation for inner door handle AE-R-S1........................................................................16
8.4. Lockout mechanism......................................................................................................................17
8.5. Wire front release (bowden) ...........................................................................................................17
8.5.1. Laying wire front release.................................................................................................17
9. Changing actuating direction of the locking module............................................. 18

3
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
10. Mounting............................................................................................................ 19
10.1. Mounting examples.......................................................................................................................19
10.2. Actuating escape release ..............................................................................................................20
11. Electrical connection .......................................................................................... 21
11.1. Notes about .........................................................................................................................22
11.2. Safety in case of faults..................................................................................................................22
11.3. Fuse protection for power supply...................................................................................................22
11.4. Requirements for connecting cables...............................................................................................23
11.5. Maximum cable lengths.................................................................................................................24
11.5.1. Determining cable lengths using the example table...........................................................25
11.6. Connector assignment of locking module MGBS-…-AR-…-SAB-…
with plug connectors 2xM12........................................................................................................26
11.7. Connector assignment of locking module MGBS-…-AR-…-SH-…
with plug connector M23 (RC18)....................................................................................................26
11.8. Connector assignment for Y-distributor...........................................................................................27
11.9. Connection of a single MGBS-AR ....................................................................................................28
11.10. Connection of several MGBS-AR in a switch chain .............................................................................. 28
11.11. Notes on operation on an AR evaluation unit ..................................................................................30
11.12. Notes on operation with safe control systems.................................................................................30
11.13. Connection of guard locking control ...............................................................................................31
11.13.1. Guard locking control for variants with IMM connection .....................................................31
11.13.2. Guard locking control for variants without IMM connection.................................................31
12. Setup ................................................................................................................. 32
12.1. LED displays ................................................................................................................................32
12.2. Teach-in function for handle module (only for unicode evaluation) ......................................................32
12.2.1. Teaching-in handle module ..............................................................................................33
12.2.2. Teach-in function with series connection, replacing and teaching-in device ..........................33
12.3. Functional check...........................................................................................................................34
12.3.1. Mechanical function test .................................................................................................34
12.3.2. Electrical function test....................................................................................................34
13. System status table ............................................................................................ 35
14. Technical data .................................................................................................... 37
14.1. Technical data for locking module MGBS-AR....................................................................................37
14.1.1. Typical system times......................................................................................................39
14.2. Radio frequency approvals.............................................................................................................40
14.3. Dimension drawings of variants......................................................................................................41
15. Ordering information and accessories................................................................. 43
16. Inspection and service ........................................................................................ 43
17. Service .............................................................................................................. 43
18. Declaration of conformity ................................................................................... 43

Operating Instructions
Safety System MGBS-P-L.-AR…
4(translation of the original operating instructions) 2527246-03-06/23
1. About this document
1.1. Scope
These operating instructions are valid for all MGBS-P-L.-AR… of version V1.1.X. These operating instructions, the document
Safety information and maintenance and any available data sheet form the complete user information for your device.
NOTICE
Make sure to use the operating instructions valid for your product version. Please contact our Service
department if you have any questions.
1.2. Target group
Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing
special expertise in handling safety components.
1.3. Key to symbols
Symbol/depiction Meaning
Printed document
Internet
www Document is available for download at www.euchner.com
MEM This section is applicable only if the memory card is used
DANGER
WARNING
CAUTION
Safety precautions
Danger of death or severe injuries
Warning about possible injuries
Caution slight injuries possible
NOTICE
Important!
Notice about possible device damage
Important information
Tip Useful information
1.4. Supplementary documents
The overall documentation for this device consists of the following documents:
Document title
(document number) Contents
Safety information
(2525460) Basic safety information
Operating instructions
(2527246) (this document)
Internet
www
Declaration of conformity Declaration of conformity
Internet
www
Possibly available data
sheet Item-specic information about deviations or additions
Internet
www
Important!
Always read all documents to gain a complete overview of safe installation, setup and use of the
device. The documents can be downloaded from www.euchner.com. For this purpose enter the doc.
no. in the search box.

5
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
2. Correct use
The safety system MGBS consists at minimum of one locking module MGBS-P-L.-AR… and one handle module MGBS-H… and
is an interlocking device with guard locking (type4). Devices with unicode evaluation possess a high coding level, devices
with multicode evaluation possess a low coding level.
In combination with a movable guard and the machine control, this safety component prevents the guard from being opened
while a dangerous machine function is being performed.
This means:
ÌStarting commands that cause a dangerous machine function must become active only when the guard is closed and locked.
ÌThe guard locking must not be released until the dangerous machine function has ended.
ÌClosing and locking a guard must not cause automatic starting of a dangerous machine function. A separate start command
must be issued. For exceptions, refer to ENISO12100 or relevant C-standards.
Devices from this series are also suitable for process protection.
Before the device is used, a risk assessment must be performed on the machine, e.g. in accordance with the following
standards:
ÌENISO13849-1
ÌENISO12100
ÌIEC62061
Correct use includes observing the relevant requirements for installation and operation, particularly based on the following
standards:
ÌENISO13849-1
ÌENISO14119
ÌEN60204-1
The safety system MGBS is only allowed to be operated in conjunction with the intended EUCHNER handle modules and the
related connection components and accessories from EUCHNER.
On the modication of system components, EUCHNER provides no warranty for function.
Locking modules with the conguration MGBS-P-….-AR can be integrated into an AR switch chain. Connection of several
devices in an AR switch chain is permitted only using devices intended for series connection in an AR switch chain. Check the
operating instructions for the related device. A maximum of 20 safety switches are allowed to be operated in a switch chain.
Important!
ÌThe user is responsible for the proper integration of the device into a safe overall system. For this
purpose, the overall system must be validated, e.g. in accordance with ENISO13849-2.
ÌCorrect use requires observing the permissible operating parameters (see chapter 14. Technical
data on page 37).
ÌIf a data sheet is included with the product, the information on the data sheet applies.
ÌIt is only allowed to use components that are permissible in accordance with the table below.

Operating Instructions
Safety System MGBS-P-L.-AR…
6(translation of the original operating instructions) 2527246-03-06/23
Table 1: Possible combinations for MGBS components
Locking module
Handle module
MGBS-H…
MGBS…
Key to symbols Combination possible
NOTICE
For information about combination with an AR evaluation unit, please refer to chapter 11.10. Connection
of several MGBS‑AR in a switch chain on page 28.
3. Description of the safety function
Devices from this series feature the following safety functions:
Monitoring of guard locking and the position of the guard
(interlocking device with guard locking according to ENISO14119)
ÌSafety function (see chapter 6.8. Switching states on page 10):
- The safety outputs are switched off when guard locking is released (monitoring of the locking element).
- The safety outputs are switched off when the guard is open (monitoring of the door position).
- The guard locking can be activated only if the handle module is located in the switch head (prevention of inadvertent
locking position (faulty closure protection)).
- The following additionally applies in an AR series connection: the safety outputs are switched on only when the device
receives a corresponding signal from its predecessor in the chain.
ÌSafety characteristics: category, Performance Level, PFHD(see chapter 14. Technical data on page 37).
NOTICE
You can regard the complete AR device chain as one subsystem during calculation. The following
calculation method applies to the PFHDvalue:
#1
PFHD,1 PFHD,ext
AR-Device #1 ... n External Evaluation
(e.g. PLC)
PFHDges =∑ PFHD,k + PFHD,ext
n
k=1
#2
PFHD,2
#n
PFHD,n
Alternatively, the simplied method according to section 6.3 of EN 13849-1:2015 can be used for
calculation.

7
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
Control of guard locking (applies only to guard locking devices according the closed-circuit current principle)
If the device is used as guard locking for personnel protection, control of guard locking must be regarded as a safety function.
The device does not feature a safety characteristic for control of guard locking, because the guard locking solenoid is
completely disconnected from outside the device (no control function within the device). It therefore does not contribute to
the failure probability.
The safety level for control of guard locking is dened only by the external control (e.g. PFHD, ext. for the standstill monitor).
Guardlocking Device
PFHDext.
(e.g. standstill
monitor)
(locking mean)
The following applies to devices with emergency stop:
Emergency stop (emergency stop device according to EN ISO 13850)
ÌSafety function: emergency stop function
ÌSafety characteristics: B10D value (see data sheet enclosed)

Operating Instructions
Safety System MGBS-P-L.-AR…
8(translation of the original operating instructions) 2527246-03-06/23
4. Exclusion of liability and warranty
In case of failure to comply with the conditions for correct use stated above, or if the safety regulations are not followed,
or if any servicing is not performed as required, liability will be excluded and the warranty void.
5. General safety precautions
Locking modules fulll personnel protection functions. Incorrect installation or tampering can lead to fatal injuries to personnel.
Check the safe function of the safeguard particularly
Ìafter any setup work
Ìafter the replacement of a system component
Ìafter an extended period without use
Ìafter every fault
Independent of these checks, the safe function of the safeguard should be checked at suitable intervals as part of the
maintenance schedule.
WARNING
Danger to life due to improper installation or due to bypassing (tampering). Safety components perform
a personnel protection function.
ÌSafety components must not be bypassed, turned away, removed or otherwise rendered ineffective.
On this topic pay attention in particular to the measures for reducing the possibility of bypassing
according to ENISO14119:2013, section 7.
ÌThe switching operation may be triggered only by handle modules designated for this purpose.
ÌPrevent bypassing by means of replacement handle modules (only for multicode evaluation). For this
purpose, restrict access to handle modules and to keys for releases, for example.
ÌMounting, electrical connection and setup only by authorized personnel possessing the following
knowledge:
- specialist knowledge in handling safety components
- knowledge about the applicable EMC regulations
- knowledge about the applicable regulations on operational safety and accident prevention.
Important!
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating
instructions are always available during mounting, setup and servicing. EUCHNER cannot provide any
warranty in relation to the readability of the CD for the storage period required. For this reason you
should archive a printed copy of the operating instructions. You can download the operating instruc-
tions from www.euchner.com.

9
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
6. Function
The device permits the locking of movable guards.
The system consists of the following components as a minimum: coded handle module
(transponder) and locking module.
Whether the locking module learns the complete transponder code (unicode) or not
(multicode) depends on the respective version.
ÌDevices with unicode evaluation: The handle module must be assigned to the locking
module by a teach-in operation so that it is detected by the system. This unambiguous
assignment ensures a particularly high level of protection against tampering. The system
thus possesses a high coding level.
ÌDevices with multicode evaluation: Unlike systems with unicode evaluation, on multi-
code devices a specic code is not requested but instead it is only checked whether the
handle module is of a type that can be detected by the system (multicode evaluation).
There is no exact comparison of the transponder code with the taught-in code in the
safety switch (unicode evaluation). The system possesses a low coding level.
The tongue on the handle module is inserted into the locking module when the guard is
closed. When the operating distance is reached, power is supplied to the handle module by the locking module and data
are transferred.
If a permissible code is detected, the safety outputs are switched on.
The safety outputs and the monitoring output (OL) are switched off when the guard is released.
In the event of a fault in the locking module, the safety outputs are switched off and the DIA LED illuminates red. The
occurrence of faults is detected at the latest on the next demand to close the safety outputs (e.g. on starting).
6.1. Guard lock monitoring
All versions feature two safe outputs for monitoring guard locking. The safety outputs (FO1A and FO1B) are switched
off when guard locking is released.
6.2. Door position monitoring output (OD)
The door position monitoring output is switched on as soon as the door handle is inserted into the switch head (state: guard
closed and not locked). The door position monitoring output also remains switched on when guard locking is active.
6.3. Diagnostic monitoring output (OI)
The diagnostic monitoring output is switched on in the event of a fault (switch-on condition as for DIA LED).
6.4. Guard lock monitoring output (OL)
The guard lock monitoring output is switched on when guard locking is active.
6.5. Version MGBS Extended
Some versions contain additional controls/indicators in the housing cover. Please refer to the corresponding data sheet for
further information.
6.6. Guard locking for version MGBS-L1
(guard locking actuated by spring force and released by power-ON)
Activating guard locking: close guard; no voltage at the solenoid.
Releasing guard locking: apply voltage to the solenoid.
The spring-operated guard locking functions in accordance with the closed-circuit current principle. If the voltage is interrupted
at the solenoid, the guard locking remains active and the guard cannot be opened directly.
Transponder coded handle
module
Locking module

Operating Instructions
Safety System MGBS-P-L.-AR…
10 (translation of the original operating instructions) 2527246-03-06/23
Important!
If the guard is open when the power supply is interrupted and is then closed, guard locking is activated.
This can lead to persons being locked in unintentionally.
The tongue on the handle module cannot be pulled out of the locking module and the guard is locked as long as the guard
locking pin is extended.
If a voltage is applied to the guard locking solenoid, the guard locking pin is retracted and the tongue on the handle module
is released. The guard can be opened.
6.7. Guard locking for version MGBS-L2
(guard locking actuated by power-ON and released by spring force)
Important!
ÌGuard locking devices according to the open-circuit current principle are not intended for protecting
personnel.
ÌUse as guard locking for personnel protection is possible only in special cases, after strict assessment
of the accident risk (see ENISO14119:2013, section 5.7.1)!
Activating guard locking: apply voltage to the solenoid.
Releasing guard locking: disconnect voltage from the solenoid.
The magnetically actuated guard locking operates in accordance with the open-circuit current principle. If the voltage is
interrupted at the solenoid, the guard locking is released and the guard can be opened directly!
The guard can be opened as long as no voltage is applied to the guard locking solenoid.
If a voltage is applied to the guard locking solenoid, the guard locking pin is held in the extended position and the guard is
locked.
6.8. Switching states
The detailed switching states for your locking module can be found in the system status table. All safety outputs, monitoring
outputs and display LEDs are described there.
Guard closed and locked
IMP
IMM
Guard closed and not locked
IMP
IMM
Guard open
IM
P
IM
M
Voltage on guard locking solenoid
MGBS-L1 off on (irrelevant)
Voltage on guard locking solenoid
MGBS-L2 on off (irrelevant)
Safety outputs FO1A and FO1B on off off
Guard lock monitoring output OL on off off
Door position monitoring output OD on on off

11
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
7. System overview
7.1. MGBS-P-… (optionally with escape release)
1
3
2
Key:
Locking module or interlocking module
Optionally with escape release
Optionally with Extended version
NOTICE
ÌDepending on the version, additional controls and
indicators may be integrated.
ÌDepending on the version, a mounting plate can be
included. See associated data sheet.
7.2. MGBS-H-…
6
1
4
4
3
5
2
Key:
Door handle
Marking for adjustment
Locking pin for changing the rotating direction of the door
handle
Locking screws T10 for housing cover
Bolt tongue
Fixing screw
NOTICE
ÌDepending on the version, a mounting plate can be
included. See associated data sheet.
7.3. AE-R-S1-... (for versions with escape release)
4
1
2
3
A
Key:
A Snap ring
Actuation axis
Door handle
Fixing screw
Protective sleeve
NOTICE
ÌDepending on the version, a mounting plate can be
included. See associated data sheet.

Operating Instructions
Safety System MGBS-P-L.-AR…
12 (translation of the original operating instructions) 2527246-03-06/23
7.4. Dimension drawing (example illustration)
11
18
6,2
120
266
40
4,65
14,8
16,5
6,3
89,4
73,7
154
115,54084,5
14
14
34 / 64 / 84
min. 11,5
max. 16,5
40 130
114
286
42
63
115,5
40 56
90
min. 1 max. 6
44
m ni 5,7.
ma .x 1 5,2
130
182
40
110,6
5
29
22,2
62,3
114,2
7,524
89,4
6,4
114
68
75
6,4
104,4
83
62,5
107
8
55,5 11,5
2,4
40
~ 5
Square drive
Prole

13
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
7.5. Drilling pattern (example illustration)
13040
40 40
15
114
286
184
1,3
ZU
CLOSED
AUF
OPEN
40
89,4
7,5
16,514,8
120
6,2
18
266
73,5
146
13,7
14,5
24
6,6
89,4
86,5 7,5
21
30
37,5
min.
6
A 1 : 2
max.
10
ZU
CLOSED
AUF
OPEN
A 1 : 2
max.
10
MGBS-P-...
AE-R-S1
MGBS-H-...

Operating Instructions
Safety System MGBS-P-L.-AR…
14 (translation of the original operating instructions) 2527246-03-06/23
8. Manual release
Important!
S1
S2
S3
No further release functions can be retrotted on Extended variants with control elements in position
1 (S1) and position 2 (S2).
Some situations require the guard locking to be released manually (e.g. malfunctions or an emergency). A function test
should be performed after release.
More information on this topic can be found in the standard ENISO14119:2013, section 5.7.5.1. The device can feature
the following release functions:
8.1. Auxiliary release and auxiliary key release
In the event of malfunctions, the guard locking can be released with the auxiliary release or the auxiliary key release irre-
spective of the state of the solenoid.
The safety outputs are switched off when the auxiliary release or the auxiliary key release is actuated. Use the safety
outputs to generate a stop command.
The monitoring output OL is switched off; OD can assume an undened state. Open the guard and close it again after re-
setting the auxiliary release. The device will then operate normally again.
Important!
ÌThe tongue on the handle module must not be under tensile stress during
manual release.
ÌAfter use, reset the auxiliary release and screw in and seal the locking
screw (with sealing lacquer, for example).
ÌThe auxiliary key release must not be used to lock the locking module
during servicing to prevent activation of guard locking, for example.
ÌLoss of the release function due to mounting errors or damage during
mounting.
ÌCheck the release function every time after mounting.
ÌObserve the notes on any associated data sheets.
8.1.1. Actuating auxiliary release
1. Unscrew locking screw.
2. Using a screwdriver, turn the auxiliary release to in the direction of the arrow.
¨Guard locking is released.
8.1.2. Actuating auxiliary key release
On devices with auxiliary key release (can be retrotted), simply turn the key to release. Function as
for auxiliary release. For mounting, see the auxiliary key release supplement.
Auxiliary re-
lease
Locking screw

15
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
8.2. Emergency release
This permits opening of a locked guard from outside the danger zone without tools. For mounting, see the mounting sup-
plement.
Important!
ÌIt must be possible to operate the emergency release manually from outside the protected area
without tools.
ÌThe emergency release must possess a marking indicating that it may be used only in an emergency.
ÌThe handle module must not be under tensile stress during manual release.
ÌThe emergency release must be sealed or the misuse of the release function must be prevented in
the control system.
ÌThe release function meets all other requirements from ENISO14119.
ÌThe emergency release meets the requirements of Category B according to ENISO13849-1:2015.
ÌLoss of the release function due to mounting errors or damage during mounting.
ÌCheck the release function every time after mounting.
ÌObserve the notes on any associated data sheets.
8.2.1. Actuating emergency release
ÌTurn the emergency release clockwise until it clicks into place.
¨Guard locking is released.
To reset, press the snap-in bolt inward using a small screwdriver or similar tool and turn the
emergency release back.
The safety outputs are switched off when the emergency release is actuated. Use the safety
outputs to generate a stop command.
The monitoring output OL is switched off; OD can assume an undened state. Open the guard and
close it again after resetting the emergency release. The device will then operate normally again.
8.3. Escape release (optional)
8.3.1. Inner door handle AE-R-S1 (for variants with escape release)
+ +
MGBS-H...-L-...
AE-R-S1
MGBS-H...-R-...
Snap-in bolt

Operating Instructions
Safety System MGBS-P-L.-AR…
16 (translation of the original operating instructions) 2527246-03-06/23
8.3.2. Preparation for inner door handle AE-R-S1
NOTICE
Various inner door handles with different axis lengths are available, as well as mounting plates and
door handles/door knobs. You will nd further information at www.euchner.com.
Prole width
Length required for actuation
axis
Which EUCHNER parts are required? Necessary work steps
Without
plates
With mount-
ing plates
(4mm each)
D D+9 D+17
30mm 39mm 47mm Standard inner door handle
with 107mm axis (order no.158322) Shorten to required length
40mm 49mm 57mm
Standard inner door handle
with 107mm axis (order no.158322)
If necessary,
extended actuation axis (order no. 106761)
Without mounting plates:
none
With mounting plates:
Use extended actuation axis and protective sleeve and
shorten to required length
45mm 54mm 62mm
Standard inner door handle
with 107mm axis (order no.158322)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length
50mm 59mm 67mm
Standard inner door handle
with 107mm axis (order no.158322)
and
extended actuation axis (order no. 106761)
Use extended actuation axis and protective sleeve and
shorten to required length
Insert actuation axis.
The snap ring A must be in contact
with the inner door handle B.
Fit door handle.
Tighten xing screw to 2Nm.
Fit protective sleeve.
4
1
2
3
A
182
D - 1 *
107
39,5
D
11,5 55,5
55,5
M4
250
D + 9
Example without mounting plates
Standard
protective
sleeve
Extended
protective
sleeve
Standard actua-
tion axis
Extended actua-
tion axis
Escape release
Handle module
+4mm per mounting plate

17
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
8.4. Lockout mechanism
The lockout mechanism can be secured with padlocks (see Fig. 1). This is intended to prevent people from being locked in
unintentionally. The lockout mechanism does not fulll any safety function.
2
1
Key:
Fold-out lockout mechanism
Padlock ∅min. 2mm, ∅max. 10 mm
Automatically extending lockout mechanism (optional)
Padlock ∅min. 6mm, ∅max. 10 mm
Notice:
You can t up to 3 locks ∅8mm per lockout mechanism.
Fig. 1: Lockout mechanism secured with padlock
8.5. Wire front release (bowden)
Release via a pull wire. Depending on the type of attachment, the wire front release can be used as an emergency release
or escape release.
The following applies to non-latching wire front releases.
If the release is to be used as an emergency release, one of the following measures must be
taken (see EN ISO 14119:2013, section 5.7.5.3):
ÌInstall the release so that it can be reset only with the aid of a tool.
ÌAlternatively, the reset can be performed at the control system level. E.g. by means of a plau-
sibility check (status of the safety outputs does not match the guard locking control signal).
The emergency-release specications in chapter 8.2 on Page 15apply irrespective of this
information.
Important!
ÌThe wire front release meets the requirements of CategoryB according to ENISO13849-1:2015.
ÌThe correct function depends on the laying of the pull wire and the attachment of the pull handle, and
this is the responsibility of the plant manufacturer.
ÌThe handle module must not be under tensile stress during manual release.
8.5.1. Laying wire front release
Important!
ÌLoss of the release function due to mounting errors, damage or wear.
ÌCheck the release function every time after mounting.
ÌWhen routing the wire front release, ensure that it operates smoothly.
ÌObserve the min. bending radius (100mm) and minimize the number of bends.
ÌThe locking module must not be opened.
ÌObserve the notes on the associated data sheets.

Operating Instructions
Safety System MGBS-P-L.-AR…
18 (translation of the original operating instructions) 2527246-03-06/23
9. Changing actuating direction of the locking module
NOTICE
ÌPlease read the operating instructions of the device before use!
ÌIf a data sheet is included with the product, the information on the data sheet applies.
ÌWhen using sliding doors, you are recommended to use the door knob AY-DKB…
ÌWhen changing the actuating direction please use a screwdriver (TX20).
ÌThe actuating direction of handle module MGBS-H-… cannot be changed.
1,8 Nm
1,8 Nm
MGBS-H-...-R-...
MGBS-H-...-L-...

19
2527246-03-06/23 (translation of the original operating instructions)
Operating Instructions
Safety System MGBS-P-L.-AR…
EN
10. Mounting
CAUTION
Locking modules must not be bypassed (bridging of contacts), turned away, removed or otherwise
rendered ineffective.
ÌObserve ENISO14119:2013, section 7, for information about reducing the possibilities for bypassing
an interlocking device.
NOTICE
Risk of damage to equipment and malfunctions as a result of incorrect installation.
ÌLocking modules and handle module must not be used as an end stop.
ÌObserve ENISO14119:2013, sections 5.2 and 5.3, for information about mounting the locking
module and the handle module.
ÌProtect the switch head against damage, as well as penetrating foreign objects such as swarf, sand
and blasting shot, etc.
ÌObserve the min. door radii (see chapter 7.4. Dimension drawing (example illustration) on page 12).
ÌObserve the tightening torque for fastening the locking module (max.1.4Nm)
10.1. Mounting examples
6 Nm
1 Nm
Fig. 2: Mounting without escape release and without inner door handle
6 Nm
6 Nm
1 Nm
Fig. 3: Mounting with escape release and inner door handle

Operating Instructions
Safety System MGBS-P-L.-AR…
20 (translation of the original operating instructions) 2527246-03-06/23
10.2. Actuating escape release
Press the red release knob to the end stop.
¨Guard locking is released.
Actuate inner door handle
