EVOLV Pro User manual

RIDES
RIDE
S
EVOLV Rides
www.evolvrides.com
USER MANUAL
#evolvpro

Contents
Key Features .......................................... 1
Dashboard Instructions ........................... 2
How to Unfold .......................................... 5
How to Fold ............................................. 6
Safe Driving Tips ..................................... 7
How to Charge ........................................ 8
Battery Safety ......................................... 9
Care & Maintenance ............................... 11
Product Specication .............................. 14
Limited Warranty .................................... 15
Charge Up Your Journey

2
LCD + Throttle
Front + Rear
Brake Lever
Dual Folding
Clamps
Front Spring
Suspension
Rear Spring
Suspension
Front Pneumatic Tire
Dual
Headlights
EVOLV Pro / Pro Plus / Pro - R
1
Dual Charging
Ports
Front Disc Brake
Power Switch
Press and hold the power button for 3 seconds to turn on scooter. The scooter turns
off automatically if not used for 90 seconds.
Speed Control
While stationary, and with the power on, press and release the MODE button to cycle
through the three different speed levels 1 to 3. Use the throttle to control the speed
within each speed level.
Hold down the MODE button to turn on the headlights and taillights. The taillights will
ash automatically when braking.
Power Indication
The number of bars indicates the remaining power of the lithium battery.
Note: Recharge when there is only one bar because emptying the scooter of power
(zero bars) is damaging to the battery over time.
LCD Screen
While stationary, and with the power on, press and release the POWER
button to cycle through the following data: ODO: Accumulated Mileage
TRIP: Current Mileage, V: Current Voltage Level
To reset the TRIP mileage, while TRIP mileage is displayed, hold down
MODE button for 3 seconds.
Dashboard Instructions
Rear Pneumatic Tire
Rear Disc Brake
Dual
Taillights
ECO / Turbo
Button (Yellow)
Single / Dual
Button (Red)
+

Dashboard Instructions
Voltage meter
Keyed ignition switch
ECO / TURBO SINGLE / DUAL
Voltage Meter Display
The voltage meter displays how much power the scooter holds. A full charge is close
to 58V. If the voltage reading is below 50V, this signals that it’s time to
charge the scooter.
ECO / TURBO
ECO: Maximizes range. Limits riders to 30 km/h but enables you to ride for longer.
Eco mode is turned on when the yellow button is depressed.
TURBO: Maximizes power and allows riders to reach top speed. Turbo mode is turned
on when the yellow button is not pushed down.
1. Do not press ECO mode when riding fast because the scooter will slow
down immediately.
2. Press ECO mode while at rest or riding at speed level 1.
SINGLE / DUAL
DUAL: Engages the front motor allowing riders to use both motors. Dual mode is
turned on when the red button is depressed.
1. Do not start riding on DUAL mode. Engage DUAL mode when riding at a high
speed, level 2 or 3 so you are accustomed to the power change.
CAUTION:
CAUTION:
Dashboard Instructions
34

How to Unfold
Raise the steering column and slide the quick release collar downward.
Alternate between each locking clamp to apply even pressure when tightening
the locking mechanism.
You should feel minimal play in the steering column if secured properly.
1.
2.
3.
5
Turn off the power.
Alternate between loosening each locking clamp before sliding the quick release
collar upward to fold steering column.
Push down the steering column toward kick plate to fold.
Tip: Once folded, use a bungee cord to keep the handle bars in place.
How to Fold
1.
2.
3.
6

Safe Driving Tips
To prevent injury, wear safety gear such as comfortable shoes, a helmet, and
knee / elbow padding.
The scooter is not waterproof. Never use it in the rain or snow. Do not use it if the
road is wet or icy. Water damage is not covered by warranty.
Changing the dashboard settings may result in malfunction. If you need to
change the settings, please ask for help from an expert or authorized dealer.
When turning left and right, make sure that there are no obstacles and then turn
slowly, keeping a wide turning radius.
Before riding at night, check the position of the headlights and state of the
taillights by depressing the brake lever.
An operating age of 16 years old and over is strongly recommended.
1.
2.
3.
4.
5.
6.
7
Always plug the charger into a household outlet before connecting to the scooter,
to safely start charging. Sparks may occur due to the voltage difference when
attaching the connector to the charging port, but this is normal.
Open scooter charging port cover to connect the charger to the scooter.
Charging status indicator.
Red: Charging Green: Fully charged
If the charging indicator is green, the scooter is fully charged and can be
disconnected.
It doesn’t matter which charging port you plug the charger into.
1.
2.
3.
4.
5.
1.
2.
3.
4.
How to Charge
CAUTION:
We recommend that you always use the original charger. Performance and safety
may be compromised when using a different charger.
Charger failure may cause a re while charging.
Do not leave your scooter charging unattended.
After unplugging the charger, charging connectors may be hot.
8

Battery Safety
Only use the original charger that was supplied with your product to charge the
lithium-ion battery. The use of a third party charger could cause serious damage
to the battery and can cause a re.
To prevent overcharging, unplug the charger once the charger light indicates the
battery is fully charged. Do not charge the scooter overnight. Instead, resume
charging when you are available to unplug the charger once the battery is
fully charged.
Do not leave the lithium-ion battery exposed to direct sunlight or high
temperature. Do not store it in wet places. Always store it in dry places.
Charge lithium-ion batteries in dry, open, and well-ventilated places. Do not
charge the battery near ammable goods.
In the winter, keep the scooter stored inside, away from extreme temperatures.
Do not let the battery run at. The scooter must have at least 20% charge on it at
all times. Please see page 11 of user manual for storage instructions.
If the battery protection circuit is damaged, the battery may emit an unusual
smell. Contact your authorized service center immediately for technical support.
Do not reverse the polarity on a battery and short-circuit. Exposing the battery to
excessive shock can result in an explosion of the battery.
Do not try stunts or jumps on the product on bumpy surfaces. Exposing a battery
pack to excessive shock can result in a battery re. If in an accident contact your
service center to ensure that the battery is not compromised.
1.
2.
3.
4.
5.
6.
7.
8.
9
Battery Safety
Connecting the charger when the product is waterlogged will run the risk of an
electric shock and possible re. Do not charge the battery and contact your
service center.
Do not disassemble or incinerate the lithium-ion battery. To safely dispose of the
lithium-ion battery, label it as industrial waste and be careful of a short-circuit
occurring in terminals.
If the battery requires replacement after long-term use, always replace it with one
that is purchased from an authorized dealer.
Do not use the battery if it leaks or gives off an odor. Avoid charging the battery
without proper care.
Depending on the model, riding conditions, and rider’s weight, range will vary on
a full charge. Please note that batteries operate optimally at around 25 degrees
Celsius. In colder weather, it is normal for your scooter to experience a shorter
than normal range on a full charge.
When the scooter needs to be stored for a long period of time, make sure the
scooter has at least 20% charge at all times.
If a product with a lithium-ion battery overheats and there is smoke or ignition,
you should stop charging or using it immediately. Move the product outdoors and
use a re extinguisher to diffuse it. Do not spray or immerse the product in water
to diffuse the re.
9.
10.
11.
12.
13.
14.
15.
10

Care & Maintenance
Cleaning
To clean the scooter, wipe or scrub with a damp cloth. Do not use a hose to spray it
with water.
Note: Make sure the electric scooter is powered off and the cover of the charging port
is closed when cleaning.
Storage
During the winter months store the scooter indoors in a cool, dry place, and away
from extreme temperatures. Do not let the battery run at. The scooter must have at
least 20% charge on it at all times. When storing for a long period, place the scooter
on a stool or lie it on its side to take weight off the tires. Keep the tires pumped to the
recommended PSI.
Note: Recommended PSI can usually be found on scooter tires.
Folding
Turn the electric scooter off. Please see page 5 and 6 of the user manual for
instructions on folding and unfolding.
11
Care & Maintenance
Lifting and Transportation
The steering column of the scooter does not lock into place when folded. To carry the
scooter, lift from just below the kick-plate and just under the front turning arm. The
scooter is heavy, so lift with caution.
12
Inating Tires
Please keep the tires inated to 50 - 55 PSI to avoid punctures and damage
to the tires.
Note: PSI level can usually be found on scooter tires.

Care & Maintenance
13
Adjusting Brakes
EVOLV Pro / Pro Plus
Small adjustments can be made at the barrel adjuster on the brake lever, but all major
adjustments should be made at the opposite end of the cable at the brake caliper.
With the barrel adjuster on the brake lever threaded almost all the way in, adjustments
can then be made to the front or rear caliper. If your brakes are too loose, you will
need to increase tension on the brake cable.
To do this, using a 5mm hex tool, loosen the screw holding down the cable near the
caliper. While holding the cable, rotate the brake arm in the direction of the scooter
until it can’t go any further, making sure to keep tension on the brake cable. Once the
arm stops rotating, rotate in the opposite direction a small amount and tighten down
the screw.
If your brakes are too tight, check that nothing is interfering with the brake cable
between the handlebars and the caliper. Follow the directions listed above, only
remove tension on the brake cable instead of introducing it.
EVOLV Pro - R
Hydraulic brake systems require less maintenance, but do need to be bled from time
to time in order to stay at peak performance levels. Bleeding the system involves
removing any built up air in the hoses and topping off the hydraulic uid and requires a
hydraulic brake bleeding kit.
If you are not comfortable doing this yourself, reach out to your dealer for further
directions.
Product Specication
Product Name EVOLV Pro / Pro Plus / Pro - R
Motor (Individual) 52V Dual 1000Watt per Motor (Pro and Pro Plus)
60V Dual 1200Watt per Motor (Pro - R)
Motor Cover Material Aluminum Alloy
Peak Power Output
(Combined)
2600W Peak (Pro and Pro Plus) / 3000W peak (Pro - R)
Max Speed 65 km/h / 40 mph (Pro and Pro Plus)
70 km/h / 44 mph (Pro - R) (Check local laws before use)
Max Mileage 60 - 65 km / 37 - 40 mi (Pro)
80 - 85 km / 50 - 53 mi (Pro Plus)
65 - 70 km / 40 - 43 mi (Pro - R)
Battery Type Lithium-ion Battery
Battery Capacity 52V 18.2AH (Pro) / 52V 23Ah (Pro Plus)
60V 21 AH (Pro - R)
Lights Dual Head Lights & Dual LED Taillight
Braking Front and Rear Mechanical Disc Brake System (Pro and Pro Plus)
Front and Rear Hydraulic Disc Brake System (Pro - R)
Tires 10 Inch Pneumatic Front and Rear Tires
Suspension Front and Rear Spring
Dashboard Blue Smart Display
Display Functions Battery, Trip, ODO, Speed, Mode, and Voltage
Folding Dual Lever Clamp
Body Frame Aluminum Alloy
Covers Material Polypropylene
Max Rider Weight 150 kg / 330 lbs
Product Size 128 * 50 * 25.4 cm
Product Weight 35 kg / 77 lbs (Pro and Pro Plus)
36 kg / 80 lbs (Pro - R)
Box Size 106 * 26 * 44 cm
14

Limited Warranty
BY USING THIS PRODUCT YOU AGREE TO THIS LIMITED WARRANTY. PLEASE
READ THIS LIMITED WARRANTY CAREFULLY.
To benet from the Limited Warranty, the customer is advised to read EVOLV Rides.
Limited Warranty terms together with the “care and maintenance” sections provided
in the user manual. This Limited Warranty applies to the extent permitted by law and
unless restricted or prohibited by law.
Limited Warranty Details
1.
2.
EVOLV Rides warrants that EVOLV Rides scooter products (“Products” or
“Product”) are free from defects in materials and workmanship, according to the
following terms and conditions:
This Limited Warranty extends to the original purchaser of the product warranted
under this warranty and to each transferree of the product during the rst
_______________ months beginning on (date) ___________________ as stated
below (“Warranty Period”).
This Limited Warranty covers the Product and each of its following component parts
(“Components”) only:
Hub motor;
Battery packs (except if the battery was short-circuited or seals of the battery
enclosure or cells were broken or were tempered or the battery was used in
equipment other than its intended use);
Controller;
Throttle and battery indicator unit;
Charger unit; and
All other electrical wiring and components.
a.
b.
c.
d.
e.
f.
15
Limited Warranty
During the Warranty Period, EVOLV Rides or its authorized service centers will
repair or replace, at EVOLV Rides’ option and without costs to the customer,
any defective Components with new or factory rebuilt replacement items, and
return the Products to the customer in working condition, provided that the
terms and conditions of this Limited Warranty are met. All defective Products or
Components that have been replaced shall become the properties of EVOLV
Rides.
Products and/or Components that have been repaired or replaced according to
the paragraph above will be covered by this Limited Warranty for the balance of
the Warranty Period.
This Limited Warranty will only be effective when presented together, to either
EVOLV Rides or its authorized centers, with proof of date and place of purchase
of Products such as the purchase receipt.
3.
4.
5.
What this Limited Warranty does not cover:
Products used for commercial purpose(s) including but not limited to leasing/
hiring, use in competitions, etc.
Any logistical costs of returning the Product to EVOLV Rides or its authorized
service centers for servicing or the cost of returning the Product to the customer
after servicing.
Defects or damages resulting from use of the Product(s) other than its normal
and customary manner as stated in the user manuals accompanying the
Products.
Defects or damages from improper storage, exposure to moisture or dampness,
modications, connections, repairs (except as carried out by EVOLV Rides or
its authorized centers), misuse, neglect, abuse, accident, alteration, improper
installation, or other acts which are not the fault of EVOLV Rides, including
damage caused by dropping, blown fuses, spills of food, or liquid.
Defects or malfunctions of the product not communicated by the customer during
the Warranty Period.
1.
2.
3.
4.
5.
16

Products which have had their serial numbers removed or tampered with.
This Limited Warranty is in lieu of all other warranties, express or implied either
in fact or by operations of law, statutory or otherwise, including, but not limited to
any implied warranty of marketability for a particular use.
6.
7.
Disclaimer:
The customer understands the risk of serious injury or death in the operation of
such products and shall agree to take the necessary precautions and exercise
good judgment to avoid hazards and dangerous situations which may result in
serious injury or death.
The customer shall agree to indemnify and hold harmless EVOLV Rides from all
injuries or death arising from the operation of the product.
The use of safety and protective gear such as bicycle helmets is strongly
encouraged. And so is the use of good judgment.
The customer is advised to take the following precautions:
Do not ride on wet ground or in heavy rain;
Take corners slowly and look out for pedestrians;
Avoid potholes, curbs, and debris on the ground;
Keep tires pumped to the specied pressure;
Dismount in places with heavy human trafc and push the scooter manually;
Service the product every 3 months of regular usage, 6 months for non-frequent
usage;
Do not use the product on public roads and respect local road regulations.
1.
2.
3.
4.
a.
b.
c.
d.
e.
f.
g.
Limited Warranty
17
How to request service under this Limited Warranty:
To request EVOLV Rides to repair and/or replace the Product or its Components under
this Limited Warranty, the customer must, during the Warranty Period:
1.
2.
Limited Warranty
Bring this Limited Warranty, proof of purchase and the product to your
authorized dealer.
Provide your authorized dealer with a written description
of the problem.
This warranty does not cover the shipping costs associated with the transportation
of the scooter to and from our service center, and a fee will be charged for return
shipping or pick up and delivery service.
The consumer and EVOLV Rides agree that in the event of a dispute arising from the
material and workmanship of the Product; or this Limited Warranty, parties will attempt
to rst resolve the matter by negotiating in good faith. If this fails, parties agree to
submit the dispute to the Small Claims Tribunal of British Columbia and agree to be
bound by any order made by the aforementioned Tribunal.
18
