EXFO bv10 User manual

Installation Guide
Performance Endpoint Unit
BV10

ii BV10
Copyright © 2010–2014 EXFO Inc. All rights reserved. No part of this
publication may be reproduced, stored in a retrieval system or transmitted
in any form, be it electronically, mechanically, or by any other means such
as photocopying, recording or otherwise, without the prior written
permission of EXFO Inc. (EXFO).
Information provided by EXFO is believed to be accurate and reliable.
However, no responsibility is assumed by EXFO for its use nor for any
infringements of patents or other rights of third parties that may result from
its use. No license is granted by implication or otherwise under any patent
rights of EXFO.
EXFO’s Commerce And Government Entities (CAGE) code under the North
Atlantic Treaty Organization (NATO) is 0L8C3.
The information contained in this publication is subject to change without
notice.
Trademarks
EXFO’s trademarks have been identified as such. However, the presence
or absence of such identification does not affect the legal status of any
trademark.
Units of Measurement
Units of measurement in this publication conform to SI standards and
practices.
December 4, 2014
Version number: 5.0.0.1

Certification Information
BV10-100 and BV10-1000 iii
Certification Information
North America Regulatory Statement
This unit was certified by an agency approved in both Canada and the
United States of America. It has been evaluated according to applicable
North American approved standards for product safety for use in Canada
and the United States.
Electronic test and measurement equipment is exempt from FCC part 15,
subpart B compliance in the United States of America and from ICES-003
compliance in Canada. However, EXFO Inc. makes reasonable efforts to
ensure compliance to the applicable standards.
The limits set by these standards are designed to provide reasonable
protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the user guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
European Community Declaration of Conformity
An electronic version of the declaration of conformity for your product is
available on our website at www.exfo.com. Refer to the product’s page on
the Web site for details.
Laser
This product complies with 21 CFR 1040.10 except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007 and with IEC/EN 60825-1.

iv BV10
Installation Instructions
Installation Instructions
This document describes the basic steps for installing the BV10. Refer to
the BV10 user guide for more information.
Contents
Page
Getting Started 1
Installing the BV10 in a Rack 1
Connecting the Power 2
Physical Interfaces, LEDs, and Buttons 7
BV10 Models 7
Port Availability on BV10 8
Connecting the TEST Port Interface 8
Connecting the Management Interfaces 10
LEDs 12
RESET and DEFAULT Buttons 13

BV10-100 and BV10-1000 1
1 Getting Started
Installing the BV10 in a Rack
The BV10 can be mounted in a rack using the rack mount accessory kit
(ordered separately). The accessory kit shelf holds up to four BV10.
To install the BV10 in a rack:
1. Attach the brackets of the supplied shelf unit to your rack using the
supplied screws.
2. If cables have been attached to the BV10, disconnect all of them as
well as the ground lug from the unit.
3. Slide the unit into the desired slot from front to back.
4. With the unit completely inserted into the slot, tighten the thumb screw
at the back of the unit.
5. Connect all cables and the ground lug, as explained in the next
sections.
