EXFO RTU-2 User manual

User Guide
RTU-2
www.EXFO.com

ii RTU-2
Copyright © 2017–2023 EXFO Inc. All rights reserved. No part of this
publication may be reproduced, stored in a retrieval system or transmitted
in any form, be it electronically, mechanically, or by any other means such
as photocopying, recording or otherwise, without the prior written
permission of EXFO Inc. (EXFO).
Information provided by EXFO is believed to be accurate and reliable.
However, no responsibility is assumed by EXFO for its use nor for any
infringements of patents or other rights of third parties that may result from
its use. No license is granted by implication or otherwise under any patent
rights of EXFO.
EXFO’s Commerce And Government Entities (CAGE) code under the North
Atlantic Treaty Organization (NATO) is 0L8C3.
The information contained in this publication is subject to change without
notice.
Trademarks
EXFO’s trademarks have been identified as such. However, the presence
or absence of such identification does not affect the legal status of any
trademark.
Where applicable, the Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
EXFO Inc. is under license. Where applicable, the MTP® mark is a
registered trademark of US Conec Ltd. Other third party trademarks and
trade names are those of their respective owners.
Units of Measurement
Units of measurement in this publication conform to SI standards and
practices.
Patents
The exhaustive list of patents is available at EXFO.com/patent.
Version number: 8.0.0.1

Contents
RTU-2 iii
Contents
Regulatory Information ..........................................................................................................v
1 Introducing the RTU-2 .................................................................................. 1
Main Features .........................................................................................................................1
LED Indicators Description ......................................................................................................4
Product Registration ...............................................................................................................6
Technical Specifications ..........................................................................................................6
Conventions ............................................................................................................................7
2 Safety Information ....................................................................................... 9
Other Safety Symbols on Your Unit ......................................................................................11
Laser Safety Information .......................................................................................................12
Electrical Safety Information .................................................................................................13
Automatic Fan Speed Management ......................................................................................16
3 Getting Started with Your Unit ................................................................. 17
Preparing for Installation ......................................................................................................17
Installing the Optional Access (Junction) Panel .....................................................................18
Installing Your Unit and the Optional Front Access Panel in a Rack ......................................27
Grounding Your Unit ............................................................................................................31
Connecting a Monitoring Device to the Dry Contact Relays ..................................................33
Inserting and Removing Test Modules ..................................................................................37
Connecting RTUe-9110/RTUe-9120 External Switches to Your Unit ......................................40
Connecting Your Unit to a Power Source ..............................................................................42
Turning on Your Unit ...........................................................................................................50
Turning off Your Unit ...........................................................................................................51
Working With Your Unit for the First Time ............................................................................54
4 Maintenance ............................................................................................... 67
Accessing Your Unit Locally ..................................................................................................68
Accessing Your Unit Remotely ..............................................................................................69
Changing the Administrator Password .................................................................................70
Upgrading the Firmware .......................................................................................................72
Updating Your Unit With Local Firmware .............................................................................74
Replacing Fuses ....................................................................................................................77
Recalibrating Your Modules ..................................................................................................79
Recycling and Disposal .........................................................................................................79

Contents
iv RTU-2
5 Troubleshooting ..........................................................................................81
Solving Common Problems ...................................................................................................81
Restoring Your Unit to Normal Operation .............................................................................83
Accessing the User Documentation ......................................................................................87
Retrieving Logs .....................................................................................................................88
Contacting the Technical Support Group ..............................................................................90
Sharing Nova Fiber Connection Information With the Technical Support Group ..................91
Transportation ......................................................................................................................93
6 Warranty ......................................................................................................95
General Information .............................................................................................................95
Gray Market and Gray Market Products ................................................................................96
Liability .................................................................................................................................97
Exclusions .............................................................................................................................97
Certification ..........................................................................................................................97
Service and Repairs ...............................................................................................................98
EXFO Service Centers Worldwide ..........................................................................................99
Index ...............................................................................................................101

Regulatory Information
RTU-2 v
Regulatory Information
USA Electromagnetic Interference Regulatory
Statement
Electronic test and measurement equipment is exempt from FCC part 15,
subpart B compliance in the United States of America. However, EXFO Inc.
makes reasonable efforts to ensure compliance to the applicable
standards.
The limits set by these standards are designed to provide reasonable
protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the user documentation, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
Canada Electromagnetic Interference Regulatory
Statement
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference.
Cet équipement génère, utilise et peut émettre de l'énergie
radio-fréquence et, s'il n'est pas installé et utilisé conformément à la
documentation de l'utilisateur, il peut occasionner une interférence néfaste
aux communications radio. L'utilisation de cet équipement dans une zone
résidentielle est susceptible d'occasionner une interférence néfaste.

Regulatory Information
vi RTU-2
Caution: This equipment is not intended for use in residential
environments and may not provide adequate protection to radio reception
in such environments.
Attention : Cet appareil n'est pas destiné à être utilisé dans des
environnements résidentiels et peut ne pas assurer la protection adéquate
à la réception radioélectrique dans ce type d'environnements.
This is a class A, group 1 product.
Ceci est un produit de classe A, groupe 1.
Class A equipment: Equipment that is, by virtue of its characteristics,
highly unlikely to be used in a residential environment, including a
home business shall be classified as class A and shall comply with the
class A limits specified in the applicable ICES standard. Characteristics
considered in this assessment include price, marketing and advertising
methodology, the degree to which the functional design inhibits
applications suitable to residential environments, or any combination
of features that would effectively preclude the use of such equipment
in a residential environment.
Classe A : Matériel qui, en raison de ses caractéristiques, ne sera fort
probablement pas utilisé dans un milieu domiciliaire ni par des
entreprises établies à domicile. Parmi les caractéristiques considérées
dans cette évaluation, il y a le prix, les méthodes de commercialisation
et de publicité, la mesure dans laquelle les fonctions de l'appareil font
qu'il ne se prête pas à des applications convenant au milieu
domiciliaire ou toute combinaison de ces caractéristiques qui aurait
pour conséquence d'en prévenir effectivement l'utilisation à domicile.
Utilisé également pour indiquer les limites d'émission correspondantes
qui s'appliquent à un tel matériel.
Class B equipment: Equipment that cannot be classified as Class A
shall comply with the Class B limits specified in the applicable ICES
standard.

Regulatory Information
RTU-2 vii
Classe B : Matériel qui ne peut pas être inclus dans la classe A. Utilisé
également pour indiquer les limites d'émission correspondantes qui
s'appliquent à un tel matériel.
Group 1 equipment: group 1 contains all equipment which is not
classified as group 2 equipment, and includes equipment such as
laboratory and scientific equipment, industrial process, measurement
and control equipment.
Group 2 equipment: group 2 contains all ISM RF equipment in which
radio-frequency energy in the frequency range 9 kHz to 400 GHz is
intentionally generated and used or only used locally, in the form of
electromagnetic radiation, inductive and/or capacitive coupling, for the
treatment of material for inspection/analysis purposes, or for transfer of
electromagnetic energy.
Appareils du groupe 1 : le groupe 1 réunit tous les appareils compris
dans le domaine d’application de la présente Norme, qui ne sont pas
classés comme étant des appareils du groupe 2. Le groupe 1 inclut les
appareils scientifiques et de laboratoire, les processus industriels,
appareils de mesure ou de contrôle.
Appareils du groupe 2 : le groupe 2 réunit tous les appareils ISM à
fréquences radioélectriques dans lesquels de l’énergie à fréquences
radioélectriques dans la plage de fréquences comprises entre 9 kHz et
400 GHz est produite et utilisée volontairement ou uniquement utilisée
localement sous forme de rayonnement électromagnétique, de
couplage inductif et/ou capacitif, pour le traitement de la matière, à
des fins d’examen ou d’analyse ou pour le transfert d’énergie
électromagnétique.
Supplier’s Declaration of Conformity (SDoC)
The SDoC for your product is as follows:
CAN ICES-001 (A) / NMB-001 (A)

Regulatory Information
viii RTU-2
EU and UK Electromagnetic Compatibility
Regulatory Statement
Warning: This is a class A product. In a domestic environment, this product
may cause radio interference in which case the user may be required to
take adequate measures. Your product is suitable for use in industrial
electromagnetic environments.
Simplified EU and UK Declaration of Conformity
The full text of the declaration of conformity is available at the following
Internet address: www.exfo.com/en/resources/legal-documentation.
EU Economic Operator
EXFO Solutions SAS
2, rue Jacqueline Auriol,
Saint-Jacques-de-la-Lande,
35091 Rennes Cedex 9
FRANCE

RTU-2 1
1 Introducing the RTU-2
The RTU-2 is a modular remote test unit that can be seamlessly integrated
with Nova Fiber Monitoring System (FMS). FMS is the central management
software for all EXFO's fiber monitoring probes such as the RTU-2, FG-750,
and RTU-2 for point-to-point (P2P) and point-to-multipoint (P2MP)
networks.
Main Features
Your unit, which could be part of various EXFO solutions, offers the
following:
Two module slots
Six USB 3.0 host ports
LAN/WAN Ethernet port (10/100/1000 Base-T)
Front and rear management Ethernet ports (10/100/1000 Base-T) for
local access
Installation in 19-inch racks or cabinets (with the provided brackets)
Possibility to install an optional panel allowing to access the ports and
connectors located on the back panel of the unit from the front of the
rack instead
Possibility to use with the RTUe-9110 and RTUe-9120 external switches
Easy software updates

Introducing the RTU-2
2RTU-2
Main Features
USB 3.0 host port
On/Off button (see Turning on Your Unit on page 50
and Turning off Your Unit on page 51)
LEDs
Front panel – RTU-2
Ethernet (RJ-45) management port for local access
(to connect a portable computer to the unit)
Built-in display
Module slots

Introducing the RTU-2
RTU-2 3
Main Features
Note: You can also connect the unit to AC power with the AC/DC power adapter
sold by EXFO.
Note: Depending on your particular setup needs, you can install an optional
panel allowing you to access the ports and connectors of the back panel of
the unit from the front of the rack instead. For more information,
see Installing the Optional Access (Junction) Panel on page 18.
DC power inlet (dual feed)
Ethernet (RJ-45) port
(for LAN/WAN connection)
Dry contact relays
(reserved for future use)
Grounding lug
Back panel – RTU-2
Main power switch USB 3.0 host ports
Ethernet (RJ-45) management port
(for local access)

Introducing the RTU-2
4RTU-2
LED Indicators Description
Note: You can also connect the unit to AC power with the AC/DC power adapter
sold by EXFO.
LED Indicators Description
There are LED indicators located on the front panel of your unit, providing
you with information about the power and system statuses.
The table below presents the possible statuses once the initial startup
sequence is complete.
LED Status Meaning
Power
Green Unit is on.
Yellow One of the unit’s fuses is blown
(see Replacing Fuses on page 77).
Off Unit is off.
DC power inlet (dual feed)
Ethernet (RJ-45) port
(for LAN/WAN connection)
Grounding lug
Front view – Optional access panel
USB 3.0 host ports

Introducing the RTU-2
RTU-2 5
LED Indicators Description
Systema
Green The unit is working properly and is ready.
Green, blinking The initialization of the unit or its shutdown is
underway.
Yellow Non-critical hardware error detected.
The temperature of the room where the unit
is located could be slightly too low or too
high, or there could be a hardware
malfunction.
Ensure that the temperature falls within the
specified operating temperature range (see
Electrical Safety Information on page 13).
If the problem persists, contact EXFO.
Red Critical hardware error detected.
The temperature of the room where the unit
is located is critically too low or too high, or
there could be a hardware malfunction.
Ensure that the temperature falls within the
specified operating temperature range (see
Electrical Safety Information on page 13).
If the problem persists, contact EXFO.
Off Unit is off.
a. If more than one error is detected at the same time, the color of the LED will be set according to the most
severe error (red as the most severe, followed by yellow).
LED Status Meaning

Introducing the RTU-2
6RTU-2
Product Registration
Product Registration
You can now register your new EXFO products online and benefit from
every possible opportunity to optimize their performance. By doing so, you
will always be notified of the latest software updates, key product
enhancements and up-to-date support information related to your
products.
To register your product online:
1. From a computer, open a Web browser and go to www.exfo.com.
2. Log in to your EXFO account.
3. Click Support > Product registration.
4. Under My Products, click Register.
5. Follow the on-screen instructions.
Technical Specifications
To obtain this product’s technical specifications, visit the EXFO Web site at
www.exfo.com.

Introducing the RTU-2
RTU-2 7
Conventions
Conventions
Before using the product described in this guide, you should understand
the following conventions:
WARNING
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury. Do not proceed unless you
understand and meet the required conditions.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. Do not proceed unless you
understand and meet the required conditions.
CAUTION
Indicates a potentially hazardous situation which, if not avoided,
may result in component damage. Do not proceed unless you
understand and meet the required conditions.
IMPORTANT
Refers to information about this product you should not overlook.

RTU-2 9
2 Safety Information
WARNING
Do not install or terminate fibers while a light source is active.
Never look directly into a live fiber and ensure that your eyes are
protected at all times.
WARNING
The use of controls, adjustments and procedures, namely for
operation and maintenance, other than those specified herein may
result in hazardous radiation exposure or impair the protection
provided by this unit.
WARNING
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
WARNING
Use only accessories designed for your unit and approved by EXFO.
For a complete list of accessories available for your unit, refer to its
technical specifications or contact EXFO.

Safety Information
10 RTU-2
IMPORTANT
Refer to the documentation provided by the manufacturers of any
accessories used with your EXFO product. It may contain
environmental and/or operating conditions limiting their use.
IMPORTANT
When you see the following symbol on your unit , make sure
that you refer to the instructions provided in your user
documentation. Ensure that you understand and meet the required
conditions before using your product.
IMPORTANT
When you see the following symbol on your unit , it indicates
that the unit is equipped with a laser source, or that it can be used
with instruments equipped with a laser source. These instruments
include, but are not limited to, modules and external optical units.
IMPORTANT
Other safety instructions relevant for your product are located
throughout this documentation, depending on the action to
perform. Make sure to read them carefully when they apply to your
situation.

Safety Information
RTU-2 11
Other Safety Symbols on Your Unit
Other Safety Symbols on Your Unit
One or more of the following symbols may also appear on your unit.
Symbol Meaning
Direct current
Alternating current
The unit is equipped with an earth (ground) terminal.
The unit is equipped with a protective conductor terminal.
The unit is equipped with a frame or chassis terminal.
On (Power)
Off (Power)
OR On/off (Power)
Fuse

Safety Information
12 RTU-2
Laser Safety Information
Laser Safety Information
Your instrument is in compliance with standard IEC 60825-1: 2014.
The following label indicates that a product contains a Class 1M source:
Laser radiation may be encountered at the optical output port of the
modules or instruments that you use with your unit.
Refer to the user documentation of the different modules for the relevant
laser safety information.
The modules and instruments that you use with your unit may have
different laser classes. Refer to their user documentation for the exact
information.
WARNING
Viewing the laser output with telescopic optical instruments (for
example, telescopes and binoculars) may pose an eye hazard and
thus the user should not direct the beam into an area where such
instruments are likely to be used.
