2 contents

or
english 3
2 x N x M8 nut 2 x N x M8 plain
washer
2 x N x M8x100
dowel screw
2 x N x foot 2 x N x plug 12x60
FLOOR FASTENING
OPTIONAL
10/12 x M5x12 countersunk bolt 10 x spacer N - 1 x reinforcement prole
(if distance between legs is greater
than about 2300 mm)
10/12 x N x M6x20 hexagon socket bolt 12 x N x M6x16 hexagon socket bolt 12 x N x M6 lock nut
2 x N x table leg 2 x N x table leg long 2 x N x adjustable foot with M10 nut
5/6 x proles 2 x tabletop end piece N x tabletop connection
N = number of legs
- length between 1,95m - 4,05m = 2 legs
- length between 4,75m - 7,55m = 3 legs
- length between 8,25m - 11,05m = 4 legs
- length 11,75m = 5 legs
CONTENTS

2. Now screw the adjustable feet into the legs. Repeat step
1 through 2 for each table leg assembly and put them
aside.
3. Put the 5/6 tabletop proles on the oor, with the slots
facing upwards, and make sure that the crosses are
facing the same way. Insert a spacer between each
prole at +/- 40 cm from the end.
1. Insert the table legs into the tabletop connection, aligning the 3 holes, and
use 12 M6x16 hexagon socket bolts and 12 lock nuts to fasten them. First
push all the bolt shas through the holes and make sure that the bolts are
on the outside. en thread the nuts onto the shas of the bolts and tighten
them rmly.
ASSEMBLY MARINA TABLE
WHAT YOU NEED
no. 3 - 4 hex key
no. 10 - 17 spanner
min. 2 people
+/- 45 min. (depending
on the length of the
table)
4 assembly marina (high) table

6. Turn over the table. Level the table by screwing the
adjustable feet in or out and fasten the feet by turning
the nu until it sits against the leg.
4. Insert the tabletop end piece with the lips into the slots
from le to right. Fasten them using 5/6 M5 x 12
countersunk bolts. Repeat this operation on the other
side, this time from right to le.
5. Now fasten the table leg assembly with the tabletop
connection to the proles, each time at the intended
place, using 10/12 M6x20 hexagon socket bolts +
reinforcement proles (also use 10/12 M6x20 hexagon
socket bolts). Remove the spacers.
english 5

L
B
L
BL
Attention! If the oor fastening set
was ordered later, it is likely that the
nuts are still in the legs.
Drill the nuts out of the legs with
a ø12 drill. Now continue with the
next steps.
2. Use an electric drill to drill 12 mm
diameter holes on the spots you
marked and insert a 12 x 60 plug
in each hole.
B (5 proles) = 620 mm
B (6 proles) = 765 mm
L = distance between the legs
1. Mark the spot on the ground where you want to put the table. ere are two anchor points per leg frame (see
diagram above).
L = distance between the legs
B = width of the leg frame
ASSEMBLY FLOOR FASTENING
6 assembly floor fastening

3. Screw the dowel screws into the plugs so that it
protrudes 55 mm.
4. Align the feet with the dowel screws and put the table
on top of them. Now fasten the table to the ground
using the supplied plain washers M8 & nuts M8.
english 7

8 maintenance
MAINTENANCE
TABLETOP
Use common kitchen cleaning
products. Avoid using aggressive
products. ese surfaces are best
cleaned with a neutral cleaning
product diluted in water.
In case of stubborn stains, we
recommend using a magic sponge.
Stubborn stains can also be removed
using acetone.
To provide extra protection, place a
dirt-repellend lm on the proles by
applying silicone spray and carefully
spreading it with a rubbing motion.
POWDER COATED LEGS
Clean with warm water and non-
abrasive cleaning product. en
dray with a so cloth.
DO NOT USE abrasive scouring
powders or scourers as they will
scratch the surface.
MAGIC SPONGE
Only use the Miraclean sponge when
normal cleaning with lukewarm
water, so soap and a normal sponge
isn’t sucient!
If stubborn stains remain visible
aer treatment according to the
instructions (see product manual),
you can use the MiraClean sponge
provided. Dip the sponge in water
and rub it over the stain. Do not
rub too hard with this sponge as
this might cause dull patches on a
surface.
ere is no need to use cleaning
products. Water alone is sucient.
is sponge is made of melamine
resin and wears away with use. e
sponge is very easy to use and gives
results up to 26 times more quickly
than a traditional microbre cloth.
e magic sponge gets rid of most
stubborn stains without extra eort.
Never use this sponge on high-
gloss surfaces as it may cause dull
patches.
e magic sponge is the solution for
getting rid of stubborn stains such
as felt-tip pens, grease, scu marks,
limescale marks or coee and tea
stains. e magic sponge can be used
on tarpaulin fabric, plastic proles,
glass, steel, chrome, aluminium,
porcelain, articial leather and
many types of oor.
For more information, contact
Extremis: [e-mail]
IMPORTANT
Stains should be removed
immediately with a clean, so cloth,
particularly in case of dark-coloured
liquids such as wine, ink, coee,
coke, oil and bird droppings. If
le to dry, these liquids may cause
permanent damage!
CAUTION
We strongly advise against using
power tools given the risk of thread
galling on the stainless steel bolts.
For tables with 3 legs or move, we
recommend using trestles to attach
the table leg assemblies to the
tabletop, instead of keeping it upside
down.
We strongly advise you against
standing on top of the table! A
concentrated load can cause small
perceptible cracks in the proles
that might be visually annoying,
although they do not aect the
strength of the table in any way.

english 9
