FAAC TAS250 User manual

FAAC International Inc. Headquarter &
East Coast Operations
5151 Sunbeam Road Suites 9-11
Jacksonville, FL 32257
Tel. [phone]
www.faacusa.com
FAAC International Inc.
West Coast Operations
357 South Acacia Avenue Unit 357
Fullerton, CA 92831
Tel. [phone]

Table of Contents
General Description ....................................................................................................................... 1
Pre-Installation Information................................................................................................................................................ 1
Safety Instructions............................................................................................................................................................. 1
Technical Support.............................................................................................................................................................. 2
Compliance Specifications ................................................................................................................................................. 3
Overview............................................................................................................................................................................ 5
Features ............................................................................................................................................................................ 6
Optional Accessories......................................................................................................................................................... 7
1 - System Architecture...................................................................................................................................... 11
2 - Technical Specifications............................................................................................................................... 15
3 - Electrical Specifications ............................................................................................................................... 16
4 - Installing the TAS250 ..................................................................................................................................... 17
4.1 Preparing to Install the TAS250 .................................................................................................................................. 17
4.2 Installation ................................................................................................................................................................... 17
5 - Troubleshooting ............................................................................................................................................ 25
6 - Heartbeat Patterns......................................................................................................................................... 26
7 - Hardware Default initialization ..................................................................................................................... 27
7.1 How to reset the FAAC Telephone Access System for Factory Default..................................................................... 27
8 - Maintenance Recommendations.................................................................................................................. 28
Appendix A - Installation Checklist ............................................................................................... 29
WARRANTY ……………………………. ............................................................................................... 30
iii

iv

General Description
Pre-Installation Information
To the Installer: If you are familiar with the installation, you can jump to section 4 - Installing the TAS250 or use the
Appendix A - Installation Checklist on page 31 of this manual.
Safety Instructions
Important: NEVER INSTALL THE EQUIPMENT DURING A LIGHTNING STORM!
This equipment, FAAC Telephone Access System, shall be installed and used within an environment that provides
the pollution degree max 2 and over voltages category II NON HAZARDOUS LOCATIONS, INDOOR and
OUTDOOR. The equipment is FIXED and PERMANENTLY CONNECTED and is designed to be installed by
Service Persons only; [service person is defined as a person having the appropriate technical training and
experience necessary to be aware of hazards to which that person may be exposed in performing a task and of
measures to minimize the risks to that person or other persons.] The equipment is installed in a metallic cabinet
that meets the applicable requirements for a FIRE ENCLOSURE.
1.The connection to the mains supply must be made as per the local authorities rules and regulations
An appropriate disconnect device must be provided as part of the building installation . Where it is
not possible to rely on the identification of the NEUTRAL in the AC MAINS SUPPLY, the disconnecting device must
disconnect both poles simultaneously (LINE and NEUTRAL).
• Be permanently connected, fail safe, with double or reinforced insulation between primary and secondary
circuits.
• The ground connection must be provided by the TERMINAL BLOCK at the PE (IEC 60417-5019 symbol)
marked connection. It is the installer’s responsibility to provide protection against a short circuit on the
input (bridge rectifier, C2, etc.).
• The system requires the integrity of the subscribed telephone line to be operational at all times. If the
telephone line is cut off, placed out of service, or shared with other interconnect telephone devices other
than the TAS250, the unit will not be able to perform its function when required.
2.AVOID
setting up the equipment near heaters, air conditioners, ventilators . DO NOT select a place that exposes
the TAS250 to vapors, chemicals or dust.
3.If during the installation a knockout on the cabinet is removed, it is the installer's responsibility to ensure that the
same degree of protection for the cabinet is provided by the use of bushings, fittings, adequate sealant, etc.
4.The metallic
cabinet must be secured to the building structure before operation.
5.The ground connection must be as shown within the included diagram, or equivalent.
6.Internal wiring must be routed in a manner that prevents:
• Excessive strain on wire and on terminal connections;
• Loosening of terminal; connections;
• Damage of conductor insulation.
7.It is the end-user and/or installer's responsibility to ensure that the disposal of the used batteries is made according
to the waste recovery and recycling regulations applicable to the intended market.
8.There are no serviceable parts within the equipment ; For any issues regarding the equipment please contact
your installer.
9.CAUTION: To reduce the risk of fire, use only AWG #26 or larger telecommunication line cord.
10. CAUTION : Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructions.
11. Sealant application is required on all mounting holes and removed knockouts . The draining holes must not be
blocked by any excess of sealant.
12.DISCONNECT POWER BEFORE SERVICING
1

Technical Support
For technical assistance with the FAAC Telephone Access System and other FAAC products, contact technical
support, Monday to Friday from 8AM to 5PM Eastern.
2

Compliance Specifications
FCC & IC Compliance
• This device complies with FCC 2000 Part 15 Class B (Radiated Emissions, Residential, USA). Operation
is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received including interference that may cause undesired operation.
This class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment
Regulations. The FAAC Telephone Access System is also compliant with EN55022:1998, amendment
1:1995, Class B and CISPR 22.
• TIA968 (FCC part 68) Direct Connection to the PSTN (Public Switched Telephone Network) USA.
• FCC Registration Number: ACTA US: V85OT01BTAS250125 REN: 01B
• DOC - CANADA: The Canadian Department of Communications label identifies certified equipment. This
certification means that the equipment meets certain telecommunications network protective, operational,
and safety requirements. The Department does not guarantee the equipment will operate to the users
satisfaction.
-Before installing this equipment, users should ensure that it is permissible to be connected to the facilities
of the local telecommunications company. The equipment must also be installed using an acceptable
means of connection. The customer should be aware that compliance with the above conditions may not
prevent degradation of service in some situations.
-Repairs to certified equipment should be made by an authorized Canadian maintenance facility
designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to request the user to disconnect the
equipment.
-Users should ensure, for their own protection, that the electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe system, if present, are connected together. This
precaution may be particularly important in rural areas.
-CAUTION: Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority, or electrician, as appropriate.
-In addition, the FAAC Telephone Access System complies with the CS-03 (Direct Connection to the Public
Switched Telephone Network, Canada).
-DOC registration Number: IC: 5690B-TAS250125
3

UL Compliance for the TAS250-125US and the TAS250-125CDN Models only
The FAAC Telephone Access System (TAS250) complies with the UL 294 which is described by the following: UL
Standard for Access Control Equipment, USA. The TAS250 enables users to grant access to the building, to their
visitors, via their own telephone line or cellular telephone. The TAS250 also supports basic schedule operations for
the postal lock supervision and automatic relay activation.
• The TAS250 can be connected to the PC via IP or RS-485 or internal PTSN to the phone line, these are all
supplementary. The TAS250 must be connected to one of the compatible controllers (KT-300, or KT-400).
• Use only a UL listed transformer available through FAAC distributors or dealers, please refer to the
Technical Support contact information to obtain the specific transformer, see page 2.
• FAAC part number TR1640P/UL (manufacturer part number Codex model SEP-1640U)
• FAAC part number TR1640P/CSA(manufacturer part number Codex model SEP/G-1640)
• For UL 294:
• Only models TAS250-125US (for installation in the USA) and TAS250-125CDN (for installation in
Canada) are UL listed.
• If the TAS250 door lock output is used in fail-secure mode, a listed panic hardware device shall be used
to allow emergency exit from the protected area.
• Electrical specifications, refer to Table 1 on page 15 and Table 2 on page 16.
• For class 1 installation, the optional camera need to be installed.
• Each TAS250 will be battery backed up with a KT-BATT-12, 12V/7Ah battery.
• The optional accessories allowed in a UL installation are:
• Heater kit (part number TAS250-HEAT)
• Postal lock (part number TAS250-POSTAL)
• Color camera (part number TAS250-CAM-N)
• The TAS250 is an access control accessory.
• Humidity test conducted at 90%.
• Compatible card readers are: P225, P325, P600 and Polaris.
• The TAS250 has an on-board capability of monitoring 4 input points. Each onboard input is supervised with
or without end-of-line resistors (5.6K ohm). The maximum distance of one line is 600 m (2,000 ft) with
AWG #22 in a single or double EOL configuration.
4

Overview
The FAAC Telephone Access System enables users to grant access to the building, to their visitors, via their own
telephone line or cellular telephone. This telephone line can also serve, via an integrated modem, as a
programming link and/or a monitoring link. Programmed alarms and troubles can be reported to a pager. The
TAS250 also supports basic schedule operations for the postal lock supervision, automatic door unlock, automatic
relay activation, pager and dialup reporting.
The TAS250 is designed to be a stand-alone unit as well as a part of a complete access control system such as
EntraPass from FAAC. The TAS250 can be connected to a PC via IP or RS-485 or internal PSTN to the phone
line. It can communicate with EntraPass through a Corporate gateway for programming and monitoring.
This manual will describe the installation procedures required to install and power up the TAS250. For the
configuration of the TAS250, refer to the TAS250 Programming Manual.
Figure 1: Front Panel Description
5

Features
Compatible with any Access Controller Supporting a Wiegand Interface Port
• Any access controller with Wiegand reader port(s)
Compatible with all EntraPass Special, Corporate and Global Editions
The FAAC Telephone Access System is compatible with all EntraPass Editions v4.02 and higher:
• EntraPass Special Edition
• EntraPass Corporate Edition with a Corporate Gateway
• EntraPass Global Edition with a Corporate Gateway
Multiple Configuration Options
• Visual User Interface (VUI):The TAS250 can be configured locally with the VUI, refer to the Programming
Manual, for details concerning the VUI.
• EntraPass: The TAS250 can be configured and monitored through the EntraPass system, refer to the
corresponding EntraPass Reference Manual, for additional details.
Communication Ports
• 1 10/100Base-T Ethernet for network connection with the EntraPass Gateway
• 1 (TIP and RING) terminal block for phone line connections and for multiple TAS250 sharing the same
telephone line
• 1 RS-485 (COM1) for RS-485 communication with the EntraPass Gateway
Inputs
There are four (4) onboard inputs on the TAS250. They are configurable with EOL (End-of-Line) resistor, without
EOL resistor, or with double EOL resistors. Respective alarm response timers are also programmable. By default,
Input 1 is assigned to the door contact and Input 2 is assigned to the postal lock. Each input can be individually
configured for one of the following applications:
• Door Contact
• Postal Lock
• Rex (Request to Exit) Device
• General Supervised Input
DC Powered Lock Output
There is one (1) onboard DC powered lock output and it is supervised.
Relay Outputs
There are three (3) onboard relay controlled outputs. The locking function can also be performed by any onboard
relay configured for lock output functionality.
Reader Interfaces
There are two (2) onboard reader interfaces. They can be programmed for one (1) Wiegand input port and one (1)
Wiegand output port.
Automatic Port Detection
The TAS250 can automatically detect the site communication RS-485 speed set by EntraPass as well as the
communication port which can be IP (ETHERNET #1), RS-485 (COM1) or Dialup modem.
Upgradable Firmware
The firmware program can be downloaded from any EntraPass workstation to the TAS250. The firmware program,
stored in the TAS250 flash memory, is upgraded without having to change any parts.
Trouble and Reporting
The TAS250 constantly supervises ac power and battery condition and reports “AC Lost”, “Normal Battery”, “Low
Battery”, or “No Battery”, status to the EntraPass system. Power outputs are supervised and electronically
protected against circuits surges
. The locking device is also supervised for short to common and open circuit.
6

Event Buffer
The event buffer can hold up to 4000 events.
Visual Status Indicators (LEDs)
The TAS250 has multiple status indicators such as for troubleshooting, network activity, power status and outputs
activity. See Figure 8: for their locations.
• HEARTBEAT (BLUE):This LED indicates the working status of the TAS250. Refer to Table 6 for a
description of the heartbeat patterns.
• COM1 RX, COM1 TX (YELLOW): The RS-485 port LEDs are transmit/receive activity indicators.
• COM2 RX and COM2 TX (YELLOW): For future use.
• OFF-HOOK (RED): This LED turns ON when the TAS250 is either dialing or answering a call.
• LOCK (RED): This LED turns ON when the lock output is activated.
• RELAY1, RELAY2 and RELAY3 (RED): Each relay output has an indicator which turns ON each time the
corresponding relay is activated.
• AC POWER and DC POWER (GREEN): These LEDs are on when AC and DC power are present.
• TXRX (YELLOW): This LED is OFF when there is no Ethernet network or the cable is disconnected;
FLASHING when there is an Ethernet cable and network activity; and ON when the network is present.
• 100 (GREEN):This LED is ON when the TAS250 is connected to a 100 Base-T Ethernet network.
Optional Accessories
The TAS250 can be mounted indoor or outdoor directly on the wall (surface mount) or recessed (flush mount). The
surface mount is described 4 - Installing the TAS250. The following figures describes the options available with the
TAS250. Each option has its own install sheet included.
Figure 2: TAS250 Flush Mounted with Box and Trim Ring
7

Matching Paper Directory
The TAS250 itself does not support a paper directory but has an optional matching enclosure designed just for that
purpose. This illuminated enclosure supports the letter format 216 x 279 mm (8.5 x 11 in) and A4 format 210 x
297 mm (8.3 x 11.7 in).
Figure 3: Paper Index Flush Mounted
Camera
The TAS250 offers the possibility to install a color camera in the back of the front door.
Figure 4: Camera Position in Back of Front Door
8

Postal Lock
This option fits in the product enclosure. Its role is to allow postal service personnel access to the building. For
added security purpose its usage may be limited by a schedule.
Figure 5: Postal Lock Mounting Location
9

Goose Neck
The TAS250 can be mounted on a goose neck stand.
Figure 6: Goose Neck Mounting Plate with Gaskets (Goose Neck not Included)
10

1 - System Architecture
The TAS250 can be configured and monitored through various means:
• Locally with the Visual User Interface (VUI).
• Remotely with EntraPass over an Ethernet network.
• Remotely with EntraPass over RS-485.
• Remotely with EntraPass over the telephone line with a dialup modem.
Figure 7: TAS250 Configurations with EntraPass
Note: For the UL 294 Compliance, the TAS250-125US and TAS250-125CDN models must be integrated with an access control
system over a Wiegand connection.
11
TAS250
Integrated with FAAC Access Control
System
TAS250
TAS250
TAS250

Figure 8: PCB view of main board
12

Figure 9: TAS250 Wiring Example with an External Controller - UL Compliant (North America)
13

Figure 10: TAS250 Wiring Example with Reader (Stand Alone Application) - North America
14

16.5 VAC, 40 VA, 1.9 Amps class 2 transformer, see Table 3 on page 25 for the part
numbers
19 VDC, 3.15 Amps, see
Table 3 on page 25 for the part numbers
11.2 to 13.75 VDC, 450 mA
11.2 to 13.75 VDC, 650 mA
• 3 Form C Relay controlled outputs
• 30 VDC, 3 Amps max each, or
• 24 VAC, 3 Amps max each
3 options with jumpers (JP9):
• 5 VDC, 175 mA, or
• 12 VDC, 175 mA, or
• from external controller
2 outputs per reader (LED and BUZ), 25 mA max . each, open collector outputs
Wiegand interface
• 4 monitored points (Z1 to Z4), NO/NC, with or without EOL resistor
• 1 fixed-function tamper switch input
AWG #22 - 600 m (2,000 ft.)
7.0 kg (15.4 lb)
7.0 kg (15.4 lb)
4 lines x 20 Characters LCD module with controllable LED backlighting
.
The text on the 4th line cant be edited, but can be changed with the navigation buttons.
Without heater kit: -10°C to 55°C (14°F to 131°F)
With heater kit: -40°C to 55°C (-40°F to 131°F)
Indoor and outdoor: 0 to 90%
Temperature: -40°C to 70°C (-40°F to 158°F)
Telephone Line: 305 m (1,000 ft.) maximum
RS-485 Bus: 1219 m (4,000 ft.) maximum
Ethernet network: 91 m (300 ft.) maximum
29.21 cm (11 1/2 in.) Wide x 37.46 cm (14 3/4 in.) High x 9.91 cm (3.9 in.) Deep
10/100 Base-T Ethernet Port (RJ-45 connector)
1 x RS-485 (COM1)
Global Data Access Arrangement (DAA) interface for the telephone line
• Ethernet: 10/100 Base-T
• RS-485: from 1200 to 115,200 Baud (automatic detection)
• Dialup Modem: Up to 2400 Baud
30.33 cm (12 in.) Wide, 38.42 cm (15 1/8 in.) High, 7.15 cm (2 7/8 in.) Deep
29.21 cm (11 1/2 in.) Wide, 37.46 cm (14 3/4 in.) High, 2.82 cm (1 1/8 in.) Deep
2 - Technical Specifications
Table 1: Technical Specifications
Specification Description
AC Power Input (UL)
DC Power Input (CE)
DC Auxiliary Output
Lock Output
Relay Controlled Outputs
Reader Power Outputs
(JP9)
Auxiliary Reader Outputs
Reader types
Monitored Points
(Zone Inputs)
Points maximum wiring
Weight (UL Listed)
Weight (CE Compliant)
Visual User Interface (VUI)
Characteristics
Operating Temperatures
Humidity Level
Storage Conditions
Multiple TAS250 Cabling
TAS250 Dimensions
(Surface Mount)
Communication ports
Communication speed
Flush Mount Box
Paper Index Flush Mount
15

3 - Electrical Specifications
Table 2: Electrical Specifications
AUXILIARY OUTPUTS MAXIMUM CURRENT COMBINED MAXIMUM
CURRENT
LED for each door reader 25 mA (each)
Buzzer (BUZ) for each door reader
25 mA (each)
OUTPUTS MAXIMUM CURRENT
Table 1: Technical Specifications
Specification Description
Paper Index Surface Mount
Paper Index Black Trim
Ring
Goose Neck Mounting
Plate
29.21 cm (11 1/2 in.) Wide, 37.46 cm (14 3/4 in.) High, 9.93 cm (4 in.) Deep
35.72 cm (14 in.) Wide, 44.13 cm (17 3/8 in.) High, 0.92 cm (3/8 in.) Deep
25.30 cm (10 in.) Wide, 36.50 cm (14 3/8 in.) High, 3.30cm (1 1/4 in.) Deep
1 for Auxiliary Power (11.2 to 13.75 VDC)
2 for Controlled Readers (11.2 to 13.75 VDC)
2 for Controlled Readers (5 VDC)
1 for Lock Output (11.2 to 13.75 VDC)
16
450 mA
175 mA
175 mA
650 mA
1.1 Amps
