FabiaTech Fanless Series User manual

FabiaTech Corporation
IPC Solution
Website: http://www.fabiatech.com
Email: [e-mail]
Panel PC System
Fanless Series
FP8152 User’s Manual
MAR 2017
Version: 1.2
Part Number: FP8152

Copyright
Copyright © 2016 FabiaTech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
service engineer for service, or send email to sup[email protected].
Returning Your Board For Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of your software (operating system, version, application
software, etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us at
www.fabiatech.com
ii

Table of Contents
FP8152 User’s Manual ...........................................................................................................i
Chapter 1 Introducing the FP8152 Panel PC............................................................................. 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................4
Packing List..............................................................................................................................6
Chapter 2 Hardware Installation ............................................................................................... 7
Before Installation...................................................................................................................7
To install hardware- Remove the Side Cover.................................................8
I/O Peripheral Connectors ..............................................................................13
Connecting the DC Power and Power Button ............................................16
Chapter 3 BIOS Setup............................................................................................................... 17
Overview................................................................................................................................17
Boot Manager Setup........................................................................................18
Device Manager Setup ...................................................................................19
SCU Setup...........................................................................................................23
Keyboard Convention ..............................................................................................24
Main Setup ............................................................................................................................25
Advanced Setup..................................................................................................................26
Boot Configuration...........................................................................................27
Peripheral Configuration .................................................................................28
SATA Configuration...........................................................................................29
Video Configuration.........................................................................................31
USB Configuration.............................................................................................34
Chipset Configuration......................................................................................36
Console Redirection Setup..............................................................................38
Chipset PCIE Controller....................................................................................41
Security setup........................................................................................................................42
Power Setup..........................................................................................................................44
Advanced CPU Controller ..............................................................................45
iii

Boot Setup.............................................................................................................................50
Legacy > Boot Device Priority.........................................................................52
Chapter 4 Software Installation ............................................................................................... 53
System Driver.........................................................................................................................53
Windows 7/8/8.1 X86/X64- System Driver ...............................................................53
VGA Driver.............................................................................................................................54
WIN7/8/8.1 X86/X64 Driver........................................................................................54
USB Driver...............................................................................................................................54
WIN7 X86/X64 Driver ..................................................................................................54
Audio Driver...........................................................................................................................55
WIN7/8/8.1 X86/X64 Driver........................................................................................55
LAN Driver (Intel I210AT & RTL8111F) ..................................................................................55
WIN7/8 X86/X64 Driver...............................................................................................55
BIOS Flash Utility.....................................................................................................................55
Touch Screen Driver.............................................................................................................56
WIN WES7/WIN7/WIN8.1 Driver........................................................................56
Configure PenMount driver Utility...................................................................59
Watchdog Timer...................................................................................................................67
Watchdog Timer Setting..................................................................................68
Watchdog Timer Enabled ...............................................................................69
Watchdog Timer Trigger ..................................................................................69
Watchdog Timer Disabled...............................................................................69
Digital I/O (GPIO) programming........................................................................................70
Chapter 5 Technical Reference .............................................................................................. 71
Trouble Shooting...................................................................................................................71
Touch Screen..............................................................................................................71
LCD Display is unstable .............................................................................................72
Technical Reference............................................................................................................72
Physical and Environmental.....................................................................................72
Serial Ports ...................................................................................................................73
Appendix................................................................................................................................... 77
Dimension..............................................................................................................................77
iv

v

FabiaTech Corporation
Chapter1IntroducingtheFP8152PanelPC
Overview
The FP8152 is 15-inch TFT Panel PC, this panel PC with Intel® Core™ i5 -4422E
(Haswell) CPU module inside and touch screen device, this user’s manual provides
information on the physical features, installation, and BIOS setup.
Built to unleash the total potential of the 4th generation Intel® Core™ i5 Processor,
Able to support 1.8 GHz CPU, this unit supports two 10/100/1000 Base –TX LAN port,
GPIO-4In/4Out digital I/O, one PCIe mini card socket, one free PCIe slot, four USB-
2.0, one USB 3.0, SATA/ CFAST socket, audio, two So-DIMM socket up to 16GB
DDR3L RAM, VGA and HD display.
Each FP8152 has six ports for I/O communication. Four RS-232 and two RS232 /
RS422/RS485 ports are available. There is also a watchdog timer that can be
configured from software to automatically reset the system. And for easy
configuration, AMI BIOS are available.
The FP8152 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, banking and Thin
Client and small Embedded Control. The unit is only 400mm (W) x 64.9mm (D) x
307mm (H).
1

FabiaTech Corporation
SeriesComparisonTable
Model FP8152T
System Processor Intel ® i5-4422E™ (HasWell)
Clock Speed 1.8 GHz
Intel® Turbo Boost
Technology4 2.0:
(Max Frequency)
2.9 GHz
Memory
204 Pin-DIMM*2(Max.)
DDR3L/1333,1600/1.35V
8GB/16GB
Multi I/O Two RS232/RS422/RS485 and
Four RS232
USB 2.0 / 3.0 Four / One
Audio Mic-In and Ear-Phone
RJ45 LAN port
(10/100/1000 Mbps) One Intel I210 One Realtek RTL8111F
GPIO 4-In/4-Out
PCIe Mini-Card Socket One
SIM Card Socket One
Storage One FAST and SATA
Panel Display Type 15’ TFT LED LCD
Max. Resolution 1024x768
Max. Colors 16.2M(RGB 8-Bit)
Luminance(cd/ ㎡ ) 500 cd/
㎡
Dot Size(mm) 0.297*0.297
Viewing Angle(H/V) 80°/80°
Lamp Life 50,000Hrs
Touch Screen (w/T) 5 Wire, Analog Resistive
Resolution 2048x2048
Light Transmission 80%±%5
Life Time 10 Million Activations
Operating Temperature 0 ~+50℃(32~122℉)
Storage Temperature -20~+60℃(4~140℉)
Dimensions (Unit: mm) 400(W) x 64.9(D) x 307(H)
2

FabiaTech Corporation
3
Layout
DIGITAL IO COM1COM3COM5USBUSB
EAR-PHONESLOT COM2 CRT
LAN1 LAN2
+
-
DC12~24V1
1
2
35
10101
46
2
2
1
-
12~40V
30
3
2101
2
+
DODIDC
POWER BUTTON RESET
MIC COM4COM6
DISPLAY2 DC IN
ANTENNA
ANTENNA
FP8152

FabiaTech Corporation
Specifications
Processor Board –
4th Generation Intel® Core™ i5-4422E (Dual Core 1.8GHz,3MB L3 Cache, 25
Watts and support Intel® Turbo Boost Technology up to 2.9GHz) low power
processor with 8GB DDR3L-RAM
I/O Outlets –
Two PCIe 10/100/1000 base-TX Ethernet LAN ports with RJ45
Two RS-232/RS422/RS485 port and four RS232 ports with DB9
One HD display port and VGA display with DB15
Five USB ports (Include one 3.0 port)
Audio connector for Earphone and Mic-in
One terminal block for 4-In and 4-Out Isolated Digital I/Os
One PCIe Mini card socket modules, especially for WLAN/GPRS module
One terminal block for DC-In Power and one power Button
Storage Bay-
CFAST Compact Flash socket for CFAST Compact Flash modules
One 2.5" SATA hard disk space
LCD Display-
Front panel with 15-inch color LVDS TFT LCD panel.
Supports up to XGA 1024x768 16.2M colors
Resistive Touch screen –
5-wire analog resistive touch screen device with USB interface.
The USB interface Software support Windows 7/ 8/ 8.1/ 10, WES7
Power requirement –
+12V ~ +24V DC, 3.00A Maximum (2.00A typical) with DC19V Input
4

FabiaTech Corporation
Dimensions –
400mm (D) x 64.9mm (W) x 307mm (H)
Certifications-
EMC: CE/FCC
Others-
Front panel protection Approval: IP65 Compliant
Weight: 7.6 Kg (Standard packing)
5

FabiaTech Corporation
PackingList
Upon receiving the package, verify the following things. Should any of the
mentioned happens, contact us for immediate service.
•Unpack and inspect the FP8152package for possible damage that may
occur during the delivery process.
•Verify the accessories in the package according to the packing list and see
if there is anything missing or incorrect package is included.
•If the cable(s) you use to install the FP8152is not supplied from us, please
make sure the specification of the cable(s) is compatible with the FP8152
system.
Note: After you install the FP8152, it is recommended that you keep the diskette or
CD that contains drivers and document files, and keep the document
copies, or unused cables in the carton for future use.
The following lists the accessories that may be included in your FP8152 package.
Some accessories are optional items that are only shipped upon order.
•One FP8152T industrial Panel PC.
•One pack of (4+4+4) screws for 2.5” SATA hard disk installation, mini-card
installation, and spare parts.
•One pack of 2 apartable terminal blocks, 2-pin for power input and 10-pin
for isolated digital I/Os.
•One pack of embedded Mount kit. ( 8 metals with 8 screws)
•One compact disc includes software utility and manuals.
Optional:
•AK1006 (P/N: 060610028G) – For Half size mini PCIe module adapter kits.
•FP8152K1 (PN: 0606010042R) – For Wall Mounting Kit.(VESA 75x75/100x100)
•FP8152K2 (PN: 0606010043R) – Slot Guide Kit for Add-On Card.
•FB4757 (PN: 0153020012G) – PCIe to PCI Riser Card.
6

FabiaTech Corporation
Chapter2HardwareInstallation
This chapter introduces the system connectors and guides you to apply them for
field application.
BeforeInstallation
Before you install the system, make sure you follow the following descriptions.
1. Before removing the cover, shut down the operation System and disconnect
power switch to off and unplug AC cable.
2. Install or unplug any connector, PCIe card (Mini-PCI), CFAST Compact Flash,
and hard disk be sure that the power is disconnected or power switch to off
from the system. If not, this may damage the system.
3. The ESD (Electricity Static Discharge) may be created from human body that
touches the board. It may do damage to the board circuit.
4. When using the screwdriver on screws, before make sure the screws size and
type, if uses the not correct unscrews or screws of system, the screwdriver may
break the screws.
7

FabiaTech Corporation
To install hardware- Remove the Side Cover
If you are installing following hardware items, you can remove the side cover.The
following figure will guide you how to install SATA 2.5" HDD, CFAST Compact Flash,
mini PCIe WLAN or GPRS module to the FP8152T and how to install the FP8152T fixers.
(Please see the spots circled.)
a. Unscrew Side Cover
Use a cross-head screwdriver to remove ten screws that secure the side cover.
M3*P0.5
8

FabiaTech Corporation
9
b. Installing SATA Hard disk and CFAST
Faster Screws up the Hard disk device to HDD metal frame then insert to SATA slot
and screws up metal frame to system. See following figure.
b1: Fasten Screws the SATA HDD into the HDD Metal Frame
M3*P0.5
M2*P0.4
b2: Installing CFAST Compact Flash
M3*P0.5
M2*P0.4
Note: Use caution when handling the hard disk to prevent damage to SATA
connector as you inserts hard disk. Gently slide the hard disk into the SATA
connector and stop when you feel resistance.

FabiaTech Corporation
10
c. Installing PCIe Mini Card Module
FP8152T supports PCIe mini card socket; you may extend additional PCIe mini card
module and SIM card to system. Connect to the antenna cable from side cover
antenna holes to GPRS or Wireless LAN module and install the SIM card for GPRS.
See following figures.
c1. Installing PCIe Mini Card and SIM card
M2*P0.4
c2. Installing AK1006 kit (Optional) - for Half Size Mini PCIE module
Note: 1. When installing PCIe GPRS Mini card on system these is need the
installing the SIM Card to SIM socket.
2. The insert SIM card into the SIM card socket. Make sure that the SIM card
is properly inserted and that golden contact area on the card is facing
downwards.

FabiaTech Corporation
11
d. To installing Expansion Card – PCI/PCIE Card
If you are installing Expansion PCIE or PCI hardware interface card, you can
remove the side cover.The following figure will guide you how to install PCIE
interface card inside the FP8152 and screw the L-Type Metal on the PCIE card
Bracket and expansion card holder. (Please see the spots circled.)
d1. Installing PCIE Expansion Card
M3*P0.5
168mmREF(6.6inch)
PCIExpress half_lengthCARD
d2. Installing FP8152K2 Kit (Optional) – Add-On card holder
M3*P0.5
FP8152K2(OPTION)
Note: The PCIE bus supports x1/x2/x4 lane via PCIE x16 slot.
Note: The FP8152K2 kit- Add-On card holder can length range is 125 ~ 188 mm.

FabiaTech Corporation
12
e. Installing the universal fixers on FP8152
Please refer to the back side figure for installing the FP8152T with universal fixers.
e1. FP8152K1 (Optional) – Mounting Kit with VESA 75/100 mm Standards
M3*P0.5
e2. Embedded Wall mounting
WALL
Step 1 Step 2
M4*P0.7
Cut out dimension 355 x 265 mm
e3.

FabiaTech Corporation
I/O Peripheral Connectors
View from the bottom side, if you are connecting the monitor, LAN, COM, Digital
I/O, Audio, VGA, HD-Display Port, and USB to the FP8152. See following figure and a
side pictures.
a. Bottom Side of FP8152 Panel PC
COM5
POWER BUTTON
EAR-PHONESLOT MIC
DIGITAL IO RESET
LAN1 LAN2 COM6
DISPLAY2USB USB
COM4 COM2 CRT
COM1COM3 DC IN
1. Connecting the Display-1: VGA (CRT)
DB15 Signal
1 Red
2 Green
3 Blue
13 Hsync
14 Vsync
12 DDC Data(*)
15 DDC Clock(*)
5 & 10 Digital Ground
6,7,8 Analog Ground
Others Not Used
2. Connecting the Display2: HD
3. Connecting the COM ports
The DB9 (COM3~COM6) is standard serials port connector. The COM1 and
COM2 are designed for multiple proposes; its can select RS232/RS422/RS485
by BIOS CMOS setting. The following tables show the signal connections of
these connectors.
DB-9 RS-232 RS-422 RS-485
1 -DCD TX- 485-
6 -DSR
2 RXD TX+ 485+
7 -RTS
3 -TXD RX+
8 -CTS
4 -DTR RX-
9 -RI
5 Ground
Metal Case Ground
13

FabiaTech Corporation
14
4. Connecting the LAN ports
The RJ45 connector with 2 LED’s for WAN/LAN. The left side LED (orange) indicates
data is being accessed and the right side LED (green) indicates on-line status. (On
indicates on-line and off indicates off-line)The following lists the pin assignment of
RJ45. (LAN2 Support Wake-On-LAN)
5. Connecting the USB Ports
The system supports a five port USB connectors. Any USB device can be attached
to USB ports as plug-and-play function is supported. The rear panel of right side port
USB # 1~4 support USB 2.0, and USB #5 can support USB2.0/3.0.
6. Connecting the Audio
RJ45 LAN RJ45 LAN
1 MDI0+ 5 MDI2+
2 MDI0- 6 MDI2-
3 MDI1+ 7 MDI3+
4 MDI1- 8 MDI3-
USB Signal
1 USBV
2 USBD- (V2.0)
3 USBD+(V2.0)
4 USBG
5 StdA_SSRX-(V3.0)
6 StdA_SSRX+(V3.0)
7 USBG (V3.0)
8 StdA_SSTX-(V3.0)
9 StdA_SSTX+(V3.0)
8 1
(Front View)
RJ45 connector
Mic-In EAR-Phone
(Front View)
1
4
59
USB 3.0
1
4
USB 2.0

FabiaTech Corporation
15
7. Digital I/O Connector
The FP8152 provides 4-in and 4-out isolated digital I/O, output port is an open
collector, you will need connections external voltage of Digital (+) and digital (-)
connector.
DI/O Signal Bit Location
+ Digital Voltage
- Digital Ground
DI-0 Digital-IN0
DI-1 Digital-IN1
DI-2 Digital-IN2
DI-3 Digital-IN3
DO-0 Digital-Out0
DO-1 Digital-Out1
DO-2 Digital-Out2
Please refer to
Chapter 4-
Digital I/O -
Software
programming
example
DO-3 Digital-Out3
Note: Digital inputs accept DC12~40V Signal with isolated input. Digital
outputs are active-low open collector output, and can drive up to
60V/400mA maximum.
D I/O
32103210
12~40V
DO DI
