Fanvil X210i User manual

X210i
Quick Installation Guide
V1.0
Fanvil Technology Co., Ltd
www.fanvil.com
Rev: B-V2

Screen icon
Keys features
Soft keys
Message waiting indicator
Left and right navigation keys, Return key
Up navigation key, Shortcut to call log
Down navigation key, Shortcut to Status
OK key, Shortcut to Menu
Return key, Go back to the previous
directory
Hold key, Hold/Resume the call
Call transfer key
Phonebook key
In idle mode: activate/deactivate silent
mode
In communication mode: mute/un-mute a
call
In idle mode or during ringing: increase or
decrease ringer volume
In communication: increase or decrease
handset, headset or hands-free volume
Voice message key
Headset key, Activate/deactivate Headset
DSS keys, It can be set as line key/function
key/speed dial key, etc.
Redial key, access to redial the last record
Hand-free key, activate/deactivate hands
free
Page-Jump key, It can switch the vice
screen DSS pages
Long press to lock keypad.
Enter PIN to unlock keypad (default 123)
Handset Cord
Ethernet Cable
Quick Installation Guide
IP Phone
Handset
Stand
Gooseneck MIC
Power Adapter
(Optional)
In hands-free mode
Call is on hold
Internet connected
Missed call(Status
bar)
In headset mode
Auto-answering
activated
New SMS
Received call
In handset mode
Call forward activated
New VM messages
Dialed call
Mute activated
Keypad locked
Do not disturb
activated (red)
Missed call(s)
Ringer off
Internet is
disconnected
Do not disturb
disabled (Blue)
Forward call
Packaging list

Installation the device
Bracket desktop installation
Gooseneck MIC installation
After aligning the gooseneck microphone with the port, load it and
tighten the nut.
Connecting to the device
Please connect power adapter, network, PC, handset, and headset to
the corresponding ports as described in below picture.
①USB port: connect USB device (U disk, WIFI adapter)
②Power port: connect the power adapter.
③Network port: connecting local area network or internet.
④PC port: the network port connect to the computer.
⑤Headset port: connect headset.
⑥Handset port: connect IP Phone handset.
Configuration
Configuration via Phone
1．Press Menu > Advanced (Default password 123)
1．Select Network: To configure the Network Settings
(IPv4/IPv6/IPv4&IPv6, DHCP/Static/PPPoE)
2．Select Accounts: To configure enable the account, fill the SIP
server address, port, user name, password etc.
Configuration via Web
1．Get the IP address from the phone: Press key, or Menu >
Status > IP.
2．Login: Input the IP address in the web browser. The PC and
phone should be in the same IP address segment(The default
username and password are both ‘admin’.)
3．Configure: Select network/Account etc, and fill the relevant
content.
Language setting
1．Press Menu key > Basic > Language.
2．Select the desired language and press OK soft key.
Making a call
1．Pre-dialing: enter the phone number and pick up the handset.
2．Direct dialing: lift the handset and enter the phone number.
3．Handsfree: enter phone number and press or vice versa.
4．Headset: enter phone number and press or vice versa.
5．Designated line: press line key, enter phone number and press
dial key.
Accepting a call
1．Using the handset: pick up the handset.
2．Using the headset: press .
3．Using the handsfree: press .
Putting a call on hold
1．Press key or Hold soft key, caller is put on hold.
2．To retrieve the call press key or Resume soft key.
Note: with more than one active call, select desired call with the
navigator keys and use the corresponding soft key to hold or resume.
6-party conference
1．Once in line with 1st caller, press Conference soft key, 1st caller is
put on hold.
2．Then call the 2nd number.
3．After, 2nd call is established, press Conference soft key to set up
the conference.

Call transfer
Attended transfer:
1．Press key or Xfer soft key during the active conversation, the
call is put on hold.
2．Dial the second telephone number.
3．When the call is answered, then press key or Xfer soft key to
complete the operation.
Blind transfer:
1．Press key or Xfer soft key during the active conversation, the
call will be on hold.
2．Then enter the 2nd telephone number and press key or Xfer
soft key.
Call forward
1．Press Menu > Features > Call Forward.
2．Select the line, the type of forward, enter the destination number
and status and press OK.
Call Mute
1．Press to Mute the microphone during the call.
2．Press again to un-mute the conversation.
Call list
1．Press key or Menu > Call Log > Local Call Logs
2．Scroll through the list using
3．To dial an entry, press Dial soft key or pickup handset or press
headset key (DSS key) or .
Phonebook
Access Phonebook:
1．Press Contact soft key or Menu > PhoneBook > Local Contacts.
2．Select All Contacts or other group.
3．To dial an entry, press Dial soft key or pickup handset or press
or .
Add new entry:
1．Press Contact soft key, Press All Contacts or other group > Press
Add.
2．Enter name and number and press OK soft key.
Programmable keys
DSS keys :
1．You can use the phone web interface to configure the keys of the
main and secondary screen.
2．You can press any keys which is still blank or long press the key
that have configured, select a type and value, press OK key.
3．Press Menu > Basic > Keyboard > DSS Key settings. Select the
key, type and value, press OK key.
Other keys :
1．You can also configure shortcuts for the navigation keys, and
which will be available in idle mode.
2．Press Menu > Basic > Keyboard, select among the configurable
items, and select your desired type and value, press OK key.
Redial
1．Press , redial a call number.
Do not disturb
1．Press key > Move to the icon > OK key, or Menu >
Features > DND.
2．Select the Mode, and press OK soft key.
Voice mail
1．To access your voice mailbox, press Voice message or
Menu > Message > Voice Message, number of messages will be
indicated if provided by your server or PBX.
2．Select the line and press Play to call.
Bluetooth
1．Press Menu > Basic > Bluetooth
2．Press ok to enter the bluetooth open interface. After opening,
press scan to display the list of bluetooth scanned. Select any
device and press connect.
