Federal Signal Corporation Integrity Series Manual

25500063
REV. B2 0820
© Copyright 2014-2020 Federal Signal Corporation
Installation, Maintenance,
and Service Manual
Integrity Light Bar

blank page
Limited Warranty
This product is subject to and covered by a limited warranty, a copy of which can be found at
www.fedsig.com/SSG-Warranty. A copy of this limited warranty can also be obtained by written request to Federal
Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to [email protected] or call
[phone].
This limited warranty is in lieu of all other warranties, express or implied, contractual or statutory, including, but
not limited to the warranty of merchantability, warranty of fitness for a particular purpose and any warranty against
failure of its essential purpose.
2645 Federal Signal Drive
University Park, Illinois 60484-3167
www.fedsig.com
Customer Support
Police/Fire-EMS: 800-264-3578 • [phone]
Work Truck: 800-824-0254 • [phone]
Technical Support 800-433-9132 • [phone]

3
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Contents
Safety Messages.............................................................................................................................. 6
Safety Message to Installers and Service Personnel of Warning Lights...........................................6
Safety Messages to Operators of Federal Signal Sound/Light Systems ..........................................9
An Overview of the Integrity®Light Bar ...................................................................................... 10
LED Lights, Colors, and Flash Patterns.................................................................................................... 10
Electrical System............................................................................................................................................10
Controller Options .........................................................................................................................................10
Ambient Light Sensor/AutoDim Option ...................................................................................................10
Product Specifications................................................................................................................................... 11
Reprogramming the Light Bar...................................................................................................... 12
Reprogramming the Light Bar .................................................................................................................... 12
SignalMaster Operation: Internal (Factory Default) or External ................................................... 12
MODE 1, 2, 3, and INTERSECTION ..................................................................................................... 12
FRONT and REAR lights: CUTOFF (default) or ENABLE ................................................................ 12
Making the Electrical Connections for Reprogramming................................................................ 12
Switch Settings and Connectors on the Serial Interface Module ............................................... 13
Selecting External SignalMaster Control ........................................................................................... 14
Selecting Internal SignalMaster Control (Factory Default)............................................................ 15
Identifying the Control Wires for Flash Patterns.............................................................................. 15
Entering Program Mode......................................................................................................................... 16
Exiting Program Mode ............................................................................................................................ 18
Wiring the Integrity Light Bar in the Vehicle .............................................................................. 19
Planning the Electrical Installation............................................................................................................. 19
Connecting Power to the Light Bar .........................................................................................................20
Installing the Serial Interface Module....................................................................................................... 21
Wiring the Serial Interface Module........................................................................................................... 23
Priority Modes 1, 2, and 3...................................................................................................................... 23
Steady Burn .............................................................................................................................................. 23
Front Cuto............................................................................................................................................... 23
Rear Cuto................................................................................................................................................ 23
Intersection............................................................................................................................................... 24
Flash Takedown/Alley............................................................................................................................ 24
Left and Right Alley Lights.................................................................................................................... 24
Takedown Lights ..................................................................................................................................... 24
Scene Light, Left and Scene Light, Right.......................................................................................... 24

4Integrity Light Bar
Federal Signal www.fedsig.com
Figures
Figure 1 Electrical connections for reprogramming the light bar..................................................... 13
Figure 2 DIP switch settings in Serial Interface Module..................................................................... 14
Figure 3 Power and cable connections.................................................................................................. 21
Figure 4 Relay for isolating devices with large filter capacitors......................................................22
Figure 5 SignalMaster 331105 controller (external SignalMaster control) ....................................26
Figure 6 SmartSiren SS2000SM Series controller (external SignalMaster control) ..................26
Figure 7 SignalMaster control functions wired to ground for external SIM control ................... 27
Figure 8 SignalMaster control functions wired to 12 Vdc for Internal control..............................29
Figure 9 Typical connections with a SignalMaster controller (external control) ......................... 30
Figure 10 Typical connections with a Model SW400SS Switch Module (internal control) ......... 31
Figure 11 Typical connections with a SmartSiren Model SS2000SM controller.......................... 32
Figure 12 Typical connections with a non-SignalMaster controller................................................ 33
Figure 13 Typical connections with a Model PA640 (PA64000) controller .................................. 34
Figure 14 Locations of ROC PCBs ........................................................................................................... 35
Figure 15 Locations of the barrel nuts in lens (numbers indicate tightening sequence).......... 37
Figure 16 Locations of ROC PCBs ........................................................................................................... 38
Low Power or Optional AutoDim ........................................................................................................ 24
Ignition .......................................................................................................................................................25
SignalMaster Connections....................................................................................................................25
Maintaining and Servicing the Integrity ...................................................................................... 35
Installing the Filler Strips (Sponge Cords) .............................................................................................. 35
Cleaning the Light Bar Lens....................................................................................................................... 36
Removing and Reinstalling the Light Bar Lens...................................................................................... 36
Removing the Lens................................................................................................................................. 36
Reinstalling the Lens .............................................................................................................................. 37
Replacing a PCB............................................................................................................................................ 37
Removing a PCB...................................................................................................................................... 38
Reinstalling a ROC PCB......................................................................................................................... 38
Resetting the Controller .............................................................................................................................. 39
Troubleshooting the Light Bar................................................................................................................... 40
Getting Technical Support and Service....................................................................................... 42
Getting Repair Service................................................................................................................................. 42
Ordering Replacement Parts ..................................................................................................................... 43

5
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Tables
Table 1 Dimensions....................................................................................................................................... 11
Table 2 Light Specifications....................................................................................................................... 11
Table 3 Electrical and Temperature ......................................................................................................... 11
Table 4 SW-2 DIP Switch Settings........................................................................................................... 14
Table 5 Control wires from the Serial Interface Module ................................................................... 15
Table 6 Switch settings for INTERSECTION operation...................................................................... 18
Table 7 Cross reference for controller leads (external Serial Interface Module control)......... 26
Table 8 SignalMaster control wires and warning patterns (internal SM control)) ..................... 27
Table 9 Troubleshooting tips................................................................................................................... 40
Table 10 Replacement parts..................................................................................................................... 43

Safety Messages
6Integrity Light Bar
Federal Signal www.fedsig.com
Safety Messages
For your safety, read and understand this manual thoroughly before installing, operating,
and servicing the Integrity®light bar. The safety messages presented in this section
and throughout the manual are reminders to exercise extreme care at all times. Read
and understand the safety instructions and keep them close at hand for reference. To
download copies of this manual, go to www.fedsig.com or call the Federal Signal Service
Department at 1-800-433-9132, 7  to 5 , Monday through Friday (CT).
Safety Message to Installers and Service Personnel of Warning Lights
Before Installation or Service
Qualifications
• To properly install or service this equipment, you must have a good understanding of
automotive mechanical and electrical procedures and systems, along with proficiency
in the installation and service of safety warning equipment. Always refer to the vehicle’s
service manuals when performing equipment installations on a vehicle.
Light Hazards
• In order to be an eective warning device, this product produces bright light that can
be hazardous to your eyesight when viewed at a close range. Do not stare directly
into this lighting product at a close range, or permanent damage to your eyesight may
occur.
• Do not install the light system in an area that would block, impair, or blind the driver’s
vision. Ensure that the light system is mounted in a position that is outside of the
driver’s field of vision so the driver can maintain safe vehicle operation.
• Federal Signal power supplies and light heads are designed to work together as
a system. Combining light heads and a power supply from dierent manufacturers
may reduce the warning eectiveness of the lighting system and may damage the
components. Verify or test your combination to make sure the system works together
and meets federal, state, and local standards or guidelines.
Electrical Hazards
• Strobe systems present a shock hazard because they use high voltage to operate.
Do not handle strobe cables, the power supply or bulbs or remove the lens while the
equipment is connected. Strobe systems can also hold their charge even after they
have been turned o. After disconnecting power to the unit, wait five minutes before
handling any parts of the strobe system.
• A light system is a high current system. In order for the system to function properly,
a separate negative (-) connection and positive (+) connection must be made. All
negative connections should be connected to the negative battery terminal and a
suitable fuse should be installed on the positive battery terminal connection as close
to the battery as possible. Ensure that all wires and fuses are rated correctly to handle
the device and system amperage requirements.

Safety Messages
7
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
• Never attempt to install aftermarket equipment that connects to the vehicle wiring,
without reviewing a vehicle wiring diagram available from the vehicle manufacturer.
Ensure that your installation will not aect vehicle operation or mandated safety
functions or circuits. Always check the vehicle for proper operation after installation.
• The lighting system components, especially light bulbs, strobe tubes, LEDs, and the
outer housing, get hot during operation. Disconnect power to the system and allow
the system to cool down before handling any components of the system.
• Halogen light bulbs and strobe tubes are pressurized and, if broken, can burst and
result in flying glass. Always wear gloves and eye protection when handling these
components.
• Do not mount a radio antenna within 18 inches of the lighting system. Placing
the antenna too close to the lighting system could cause the lighting system to
malfunction or be damaged by strong radio fields. Mounting the antenna too close to
the lighting system may also cause the radio noise emitted from the lighting system to
interfere with the reception of the radio transmitter and reduce radio reception.
• Do not attempt to wash this or any other electrical device while it is connected to its
power source. Exposure to liquid while the product is connected to the power source
may result in an electrical shock and personal injury and may short circuit and damage
the product.
During Installation and Service
• DO NOT get metal shavings inside the product. Metal shavings in the product can
cause the system to fail. If drilling must be done near the unit, place an ESD approved
cover over the unit. Inspect the unit after mounting to ensure there are no shavings
present in or near the unit.
• To avoid a battery explosion, always disconnect the negative battery cable first and
reconnect it last. Avoid causing a spark when connecting near or to the battery. The
gases produced by a battery can cause a battery explosion that could result in vehicle
damage and serious injury.
• DO NOT connect this system to the vehicle battery until ALL other electrical
connections are made, mounting of all components is complete, and you have verified
that no shorts exist. If the wiring is shorted to the vehicle body or frame, high current
conductors can cause hazardous sparks, resulting in electrical fires or flying molten
metal.
• DO NOT install equipment or route wiring (or the plug in cord) in the deployment path
of an airbag.
• If a vehicle seat is temporarily removed, verify with the vehicle manufacturer if the
seat needs to be recalibrated for proper airbag deployment.
• Before mounting any components, check the manual to verify that the component you
are installing is suitable for use in that area of the vehicle. Many components are not
suitable for use in the engine compartment or other extreme environmental exposure
areas.

Safety Messages
8Integrity Light Bar
Federal Signal www.fedsig.com
• The service life of light bulbs and strobes tubes will be shortened if the
glass portion is touched during installation. Use gloves when handling these
components. If the glass portion has been touched, clean the glass carefully with
isopropyl alcohol.
• When drilling into a vehicle structure, ensure that both sides of the surface are
clear of anything that could be damaged. Remove all burrs from drilled holes. To
prevent electrical shorts, grommet all drilled holes through which wiring passes.
Ensure that the mounting screws do not cause electrical or mechanical damage to
the vehicle.
• To avoid denting the roof of the vehicle, place the light bar mounting feet as close
to outer edge of the roof as possible.
• Roof damage can occur if the hook adjustment bolts are over-tightened. Torque
the adjustment bolts to 6 ft-lb to 7 ft-lb. Install keeper plates.
• Locate the light system controls so the VEHICLE and CONTROLS can be operated
safely under all driving conditions.
After Installation or Service
• After installation, test the light system to ensure that it is operating properly.
• If a seat is temporarily removed, verify with the vehicle manufacturer if the seat
needs to be recalibrated for proper airbag deployment.
• Test all vehicle functions, including horn operation, vehicle safety functions, and
vehicle light systems, to ensure proper operation. Ensure that the installation has
not aected the vehicle operation or changed any vehicle safety function or circuit.
• Scratched or dull reflectors, mirrors, or lenses will reduce the eectiveness of
the lighting system. Avoid heavy pressure and use of caustic or petroleum based
products when cleaning the lighting system. Replace any optical components that
may have been scratched or crazed during system installation.
• Do not attempt to activate or deactivate the light system control while driving in a
hazardous situation.
• Frequently inspect the light system to ensure that it is operating properly and that it
is securely attached to the vehicle.
• After installation and testing are complete, provide a copy of these instructions to
instructional sta and all operating personnel.
• Do not use a pressure washer to clean the light bar. Failure to heed this notice will
damage the light bar.
• File these instructions in a safe place and refer to them when maintaining and/or
reinstalling the product.
Failure to follow all safety precautions and instructions may result in property damage,
serious injury, or death.

Safety Messages
9
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Safety Messages to Operators of Federal Signal Sound/Light Systems
People’s lives depend on your safe operation of Federal Signal products. It is important
to read and follow all instructions shipped with the products. Listed below are some other
important safety instructions and precautions you should follow:
• Do not attempt to activate or deactivate the light system control while driving in a
hazardous situation.
• Although your warning system is operating properly, it may not be completely
eective. People may not see or heed your warning signal. You must recognize this
fact and continue to drive cautiously.
• Situations may occur that obstruct your warning signal when natural and man made
objects are between your vehicle and others, such as raising your hood or trunk lid. If
these situations occur, be especially careful.
• All eective sirens and horns produce loud sounds that may cause, in certain
situations, permanent hearing loss. You and your passengers should consider taking
appropriate safety precautions, such as wearing hearing protection.
• The eectiveness of an interior mounted warning light depends on the clarity, the
tinting, and the angle of the glass it is being placed behind. Tinting, dirt defects, and
steeply angled glass reduce the light output of the warning light. This may reduce the
eectiveness of the light as a warning signal. If your vehicle has dirty, tinted, or steeply
angled glass, use extra caution when driving your vehicle or blocking the right of way
with your vehicle.
• To be an eective warning device, this product produces bright light that can be
hazardous to your eyesight when viewed at a close range. Do not stare directly into
this lighting product at a close range, or permanent damage to your eyesight may
occur.
• It is important that you fully understand how to safely operate this warning system
before use.
• Operate your vehicle and the light/sound system in accordance with your
department’s Standard Operating Procedures.
• If a selected function does not perform properly or if any of the lamps remain illuminated
when the control is o, disconnect the power connector from the control unit and
contact the nearest service center.
• At the start of your shift, ensure that the entire warning light system and the siren
system is securely attached and operating properly.
Failure to follow all safety precautions and instructions may result in property damage,
serious injury, or death.

An Overview of the Integrity® Light Bar
10 Integrity Light Bar
Federal Signal www.fedsig.com
An Overview of the Integrity®Light Bar
The Integrity light bar is a single-level LED light bar with ROCTM (Reliable On-Board
Circuitry) and Solaris®LED technologies. ROC eliminates approximately 85 percent of
potential failure points by incorporating a printed circuit board (PCB) in one assembly
to substantially reduce the number of electrical connections. Solaris S2 LED modules
use oset, complex reflector surfaces for accurate beam-shaping and the highest
optical eciency. The reflectors’ overlapping, 360-degree lighting eliminates weak
spots and provides o-axis warning around the light bar.
LED Lights, Colors, and Flash Patterns
The microprocessor inside the light bar supplies three priority operational modes and a
library of 27 flash patterns. To increase the safety of ocers, pedestrians, and motorists,
the light bar has standard front and rear cuto, dimming, and intersection warning. Bright
white LED takedown and alley lights that are horizontally adjustable are also available
with the HotFoot™configured option.
Multi-color heads are available with up to three dierent colored LEDs, eliminating the
loss of primary warning colors in takedown, alley, and directional warning positions.
Individual Integrity light heads can flash between red, blue, amber, or white.
Electrical System
The Integrity light bar is protected against reversed polarity damage. The Integrity
Light Bar can be installed in any vehicle with a 12-volt negative-ground electrical
system.
Controller Options
Flash patterns are controlled through the light bar CAT5 communication cable.
The cable connects to Federal Signal Convergence network controllers, the Serial
Interface Module (Part Number 8583446), or the Federal Signal Six-Button Serial
Controller.
With the Serial Interface Module, the Integrity Light Bar can be activated by Federal
Signal light bar controllers, SignalMaster directional-light controllers, or by individual
low-current switch boxes.
Ambient Light Sensor/AutoDim Option
The Integrity light bar can be ordered with an optional ambient light sensor. The sensors
that detect the ambient light and automatically dim flashing lights during nighttime are
located on the ROC boards at each end of the light bar. If used with a controller that has
a dedicated dim button, the user has the option to temporarily override the dimming.
AutoDim is disabled in MODE 3 and is enabled when MODE 3 is removed.
Other advanced features of the Integrity light bar include:
• A high degree of reliability through the use of advanced microprocessors and other
integrated circuits.
• One-piece seamless construction that eliminates leaking bulkhead gaskets.
• High output, long-life LEDs with no bulbs to change.

An Overview of the Integrity® Light Bar
11
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Product Specications
Operating and technical specifications for the Integrity light bar are listed in this section
by model.
Table 1 Dimensions
Model Integrity44 Integrity51
SIze (L x W x H) 43.7 x 9.7 x 1.96 inches
(111.0 x 246.4 x 5.0 cm)
51.3 x 9.7 x 1.96 inches
(130.3 x 9.7 x 5.0 cm)
Weight* 21.5 lb (9.8 kg) 24.5 lb (11.1 kg)
*with standard mounting feet
Table 2 Light Specications
Lighting Option Current Draw Lamp Technology Reector Style
LED (all heads) 1.0 A in Steady-Burn Mode High-brightness LED O󰀨set, compound curve,
polished reector
*with standard mounting feet
Table 3 Electrical and Temperature
Model Electrical
Potential
Current Draw
(50 % Flash Rate)
Operating Temp.
Integrity44 12.8 Vdc 11.0 A
13.0 A with HotFoot
-40°F to 149°F (-40°C 50 to 65°C)
Integrity51 12.8 Vdc 13.0 A
15.0 A with HotFoot
-40°F to 149°F (-40°C 50 to 65°C)

Reprogramming the Light Bar
12 Integrity Light Bar
Federal Signal www.fedsig.com
Reprogramming the Light Bar
HEAVY OBJECT: Use lifting aids and proper lifting techniques when removing or
replacing this product. Failure to heed this warning may cause personal injury.
Carefully unpack the light bar assembly and any other products included in the shipment.
Inspect them for damage that may have occurred during shipping. If a product has been
damaged, do not install or operate it. Immediately file a claim with the carrier describing
the damage.
Carefully check all envelopes, shipping labels, and tags before removing or destroying
them. If you are missing any parts, contact Customer Support at 1-800-264-3578, 7 to
5 , Monday through Friday (CT).
Reprogramming the Light Bar
Although the Integrity light bar is configured and programmed at the factory, you may
want to change the default settings and flash patterns before installation. Before you
begin, decide if you want to change these default settings.
SignalMaster Operation: Internal (Factory Default) or External
• Internal operation uses the on-board SignalMaster controller in the light bar
to generate directional warning patterns. With Internal operation, an external
SignalMaster controller is not needed. A standard low current switch box can activate
the internal SignalMaster controller.
MODE 1, 2, 3, and INTERSECTION
• MODES 1 through 3 are most often selected by a progressive slide switch, which
enables the driver to turn on the light bar without looking down. You can select a
pattern for each mode from the light bar’s library of 26 patterns.
• The INTERSECTION flash pattern is typically a high activity pattern that attracts attention
to the vehicle as it approaches an intersection. You can select a pattern from the library
and choose one of three ways to turn on and o the pattern. The INTERSECTION flash
pattern overrides the three priority modes.
NOTE: If the SignalMaster flash pattern is turned on, it overrides the current flash pattern.
FRONT and REAR lights: CUTOFF (default) or ENABLE
• Set these options after you change the default settings for MODE and INTERSECTION
flash patterns. CUTOFF turns OFF the front or rear LEDs when 12 Vdc is applied to the
FRONT or REAR light control wire. ENABLE turns ON the front or rear LEDs when 12
Vdc is applied.
Making the Electrical Connections for Reprogramming
To supply power to the light bar, use a fully-charged 12-volt automotive battery and follow
these steps:
1. Place the light bar on a sturdy, flat surface.
2. Plug the CAT5 communication cable (1) from the light bar into the Serial Interface
Module (J1). See Figure 1.

Reprogramming the Light Bar
13
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Figure 1 Electrical connections for reprogramming the light bar
Serial
Interface
Module
Power Line (Red)
Ground Power Line (Black)
Black Wire
Black/White Wire
White Wire 24-Pin Harness
5
290A7448
+ –
12 Vdc
Vehicle
Battery
4
3
1
2
6
Fuse
1 A
Fuse
40 A Maxi
Passenger
Side
Driver
Side
CAT5 Com.
Cable (Gray)
3. Plug the 24-pin harness (2) into the Serial Interface Module.
4. Attach the black ground power line (3) to the negative battery (–GND) terminal.
5. Attach the red power line (4) through a 40 A MAXI®fuse to the positive battery (+BAT)
terminal.
6. Attach the white wire (5) from the 24-pin harness through a 1 A fuse to the positive
battery (+BAT) terminal.
7. Attach the black wire and the black/white wire (6) from the 24-pin harness to the
negative battery (–GND) lug.
Switch Settings and Connectors on the Serial Interface Module
The switches to select flash patterns and light bar functions are accessible through the
PCB on the Serial Interface Module. Figure 2 shows the locations of the switches and
connectors. See Table 4 for a description of switch settings and functions.

Reprogramming the Light Bar
14 Integrity Light Bar
Federal Signal www.fedsig.com
Figure 2 DIP switch settings in Serial Interface Module
J3 Connector for
Serial Cable from
Light Bar
J1 Connector For 24-Conductor Cable
Supplied With Serial Interface Module
SW2 DIP Switches (See
Table 5 on page 15)
Programming Header for Cloning Flash
Patterns from Vehicle to Vehicle (See the
instructions included with the programmer)
SW1 Button for Selecting
Flash Patterns
290A7703
Table 4 SW-2 DIP Switch Settings
SW-2
Switch
Number
Switch
Setting
Function
Up
(OFF)
Down
(ON)
1
X
FRONT/REAR LEDs cut o󰀨 (turn o󰀨) when 12 Vdc is applied
their control wires (Table 5 on page 15).
1
X
FRONT/REAR LEDs enable (turn on) when 12 Vdc is
applied to their control wires
2
X
Keep in OFF position
3
3
X
X
Intersection
Scene light
4
X
SignalMaster, External controller
4
X
SignalMaster, Internal controller
5
X
Cycle forward through the selection of ash patterns
5
X
Cycle backward through the selection of ash patterns
6
X
Operation Mode
6
X
Program Mode
7 Switch for INTERSECTION operational settings (Table 6 on page 18)
8 Switch for INTERSECTION operational settings (Table 6)
Selecting External SignalMaster Control
To select External SignalMaster control:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. Move Switch 4 on SW-2 to the up (OFF) position.
3. Plug the 24-pin harness into the Serial Interface Module.

Reprogramming the Light Bar
15
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Selecting Internal SignalMaster Control (Factory Default)
To select Internal SignalMaster control:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. Move Switch 4 on SW-2 to the down (ON) position.
3. Plug the 24-pin harness into the Serial Interface Module.
Identifying the Control Wires for Flash Patterns
This section describes how to program flash patterns by applying 12 Vdc to the control
wires in the 24-pin harness of Serial Interface Module. Table 5 shows the control wires
and colors. The first color is the predominant color, and additional colors are stripes.
Table 5 Control wires from the Serial Interface Module
Light Bar Controls Wire Color Description
MODE 1 Blue Lowest priority
MODE 2 Blue/White Overrides MODE 1
MODE 3 Black/Red Overrides MODES 1 and 2
STEADY BURN Red/White One or more LEDs steadily burn when 12 Vdc is
applied to the control wire for a MODE and the
control wire for STEADY BURN
FRONT CUTOFF Green/White Turns OFF the FRONT of the light bar
FRONT ENABLE Turns ON the FRONT of the light bar
REAR CUTOFF Orange/Black Turns OFF the REAR of the light bar
REAR ENABLE Turns ON the REAR of the light bar
INTERSECTION Blue/Black Typically a high-activity pattern. Overrides all three
priority modes.
FLASH
TAKEDOWN/
ALLEY
Red/Black Flashes the ALLEY and TAKEDOWN lights in
MODES 1, 2, or 3
LEFT ALLEY Green/Black Turns on LEFT ALLEY lights. Overrides the FLASH
TAKEDOWN/ALLEY lights
RIGHT ALLEY Orange/Red Turns on RIGHT ALLEY lights. Overrides the FLASH
TAKEDOWN/ALLEY lights.
TAKEDOWN White/Black Provides white light to the front. Overrides FLASH
TAKEDOWN/ALLEY lights and FRONT CUTOFF.
LOW POWER White/Black/
Red
Dims the lights approximately 50 percent to prevent
blinding approaching drivers. LOW POWER is only
available in MODES 1 and 2 and is disabled when
switched to another ash pattern, including MODE 3
and INTERSECTION.
LIGHT BAR TEST
PATTERN
Black/White/
Red
Flashes the LEDs sequentially and then ashes the
TAKEDOWN and ALLEY lights

Reprogramming the Light Bar
16 Integrity Light Bar
Federal Signal www.fedsig.com
Entering Program Mode
To switch the module from Operation Mode to Program Mode:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. On the Serial Interface Module, move Switch 6 on SW-2 to the down (ON) position.
3. Plug the 24-pin harness into the Serial Interface Module.
NOTE: When you press and release the SW-1 button on the Serial Interface Module to
select a pattern, the light bar briefly turns o and then displays the next pattern. To cycle
backwards to a previous pattern, move Switch 5 to ON (up position) on SW-2.
SW-2 DIP Switch Settings in the Serial Interface Module
For the location of SW-2, see Figure 2 on page 15. Table 4 on page 14 lists the DIP
switch settings in the Serial Interface Module for programming flash patterns.
Programming Priority MODES 1, 2, 3, and INTERSECTION
The three modes operate with MODE 3 having the highest priority: MODE 3 overrides
MODE 2, and MODE 2 overrides MODE 1. When the light bar operates in one of these
modes, the SignalMaster modules keep sequence with the flash pattern.
You can change default MODE flash patterns by programming each mode with one of 26
patterns in the light bar’s library. A typical setup would be:
• MODE 1: REAR LEDs
• MODE 2: FRONT/REAR LEDs
• MODE 3: Siren (SmartSiren
®
or Federal Signal compatible), and FRONT/REAR LEDs and
FLASH TAKEDOWN/ALLEY LEDs on the main bar
• MODES 1 and 2: FRONT/REAR CUTOFF
NOTE: If you are reprogramming the light bar after you have connected a progressive slide
switch, the programming sequence must be MODE 3, MODE 2, MODE 1, INTERSECTION.
Mode 3
1. Apply 12 Vdc (+BAT) to the MODE 3 control wire (black/red) from the Serial Interface
Module to display the assigned pattern.
2. On the Serial Interface Module, press and release the SW-1 button until the pattern
you want appears on the light bar.
3. Remove 12 Vdc from the MODE 3 control wire.
Mode 2
1. Apply 12 Vdc (+BAT) to the MODE 2 control wire (blue/white) from the Serial Interface
Module to display the assigned pattern.
2. On the Serial Interface Module, press and release the SW-1 button until the pattern
you want appears on the light bar.

Reprogramming the Light Bar
17
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
3. Remove 12 Vdc from the MODE 2 control wire.
Mode 1
1. Apply 12 Vdc (+BAT) to the MODE 1 control wire (blue) from the Serial Interface Module
to display the assigned pattern.
2. On the Serial Interface Module, press and release the SW-1 button until the pattern
you want appears on the light bar.
3. Remove 12 Vdc from the MODE 1 control wire.
Intersection
The INTERSECTION flash pattern overrides all three priority modes when activated. To
select a new pattern, you must apply 12 Vdc to the control wire for either MODE 1, 2, or 3
(Table 5 on page 15) and the blue/black control wire for INTERSECTION.
NOTE: This procedure only programs the INTERSECTION pattern. It does not assign the
pattern to a MODE.
1. Apply 12 Vdc (+BAT) to a control wire for either MODE 1, 2, or 3, and the control wire
for INTERSECTION from the Serial Interface Module.
2. On the Serial Interface Module, press and release the SW-1 button until the pattern
you want displays on the light bar.
3. Remove 12 Vdc from the MODE and INTERSECTION control wires.
Intersection Operational Settings
Select one of three options to turn on the INTERSECTION pattern:
• HIGH with +BAT power maintained (default): The light bar displays the INTERSECTION
pattern until power is removed.
• TAP II (push-on/push-o): The INTERSECTION flash pattern is turned on and o by
pressing a momentary contact switch, such as a horn button. Momentary 12 Vdc turns
on the pattern; a second momentary 12 Vdc signal turns it o.
• 8-SECOND TIMEOUT activated by +BAT: Momentary 12Vdc turns on the
INTERSECTION flash pattern for eight seconds.
To change from HIGH to TAP II or 8-SECOND TIMEOUT:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. On the Serial Interface Module, set Switch 7 and Switch 8 on SW-2 to select a method
of operation (Table 6). Each setting is independent of the other.
3. Plug the 24-pin harness into the Serial Interface Module.

Reprogramming the Light Bar
18 Integrity Light Bar
Federal Signal www.fedsig.com
Table 6 Switch settings for INTERSECTION operation
Operational Settings
SW-2
SW7 SW8
HIGH (+BAT maintained) OFF (up) OFF (up)
TAP II (+BAT, push on/push o󰀨 ) ON (down) OFF (up)
8-SECOND TIMEOUT (activated by +BAT) OFF (up) ON (down)
Front/Rear Enable or Cuto
The operational setting for FRONT/REAR ENABLE or CUTOFF must be programmed after
MODE and INTERSECTION. The default setting is for CUTOFF in which the FRONT or
REAR LEDs turn o when 12 Vdc (+BAT) is applied to their control wires (Table 5 on
page 15). In contrast, FRONT/REAR ENABLE turns on these LED modules when +BAT
is applied to their control wires. Both FRONT and REAR share the same operational
setting and are not independent.
To program the light bar for FRONT/REAR ENABLE or CUTOFF:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. On the Serial Interface Module, move Switch 1 on SW-2 to:
• the down (on) position for Front/Rear Enable.
• the up (o) position for Front/Rear Cuto.
3. Plug the 24-pin harness into the Serial Interface Module.
NOTE: When set to ENABLE, 12 Vdc must be applied to a MODE control wire and the
FRONT and/or REAR ENABLE control wire for the light bar to operate.
In a typical installation, if you want only the REAR LED modules to flash in MODE 1, set
the operation for ENABLE. Connect the green/white and blue/white control wires to
the MODE 2 connection and the orange/black and blue control wires to the MODE 1
connection.
Exiting Program Mode
When you are finished, switch the Serial Interface Module from Operation Mode to
Program Mode:
1. Unplug the 24-pin harness from the Serial Interface Module.
2. On the Serial Interface Module, move SW-2 Switch 6 to the up (OFF) position.
3. Plug the 24-pin harness into the Serial Interface Module.

Wiring the Integrity Light Bar in the Vehicle
19
Installation, Maintenance, and Service Manual
Federal Signal www.fedsig.com
Wiring the Integrity Light Bar in the Vehicle
Before proceeding, ensure that the light bar has been installed on the vehicle roof in
accordance with the instructions included with the mounting kit. Depending on the type
of vehicle and mounting system feature, there are two options available for installing the
light bar to the roof of the vehicle: hook-on mounting or permanent mounting.
INSTALLATION PRECAUTION: Do not mount a radio antenna within 18 inches of
the lighting system. Placing the antenna too close to the lighting system could
cause the lighting system to malfunction or be damaged by strong radio elds.
Mounting the antenna too close to the lighting system may also cause the radio
noise emitted from the lighting system to interfere with the reception of the radio
transmitter and reduce radio reception.
Planning the Electrical Installation
The light bar is completely wired at the factory and does not require any additional
internal wiring. All the conductors necessary for control of any and all basic and optional
functions are contained in the CAT5 cable. The basic light functions of the Integrity must
be controlled by a installer-supplied control head.
To prevent damage to the light bar and vehicle and to ensure that all equipment operates
properly, carefully plan where to mount and wire the light bar and controlling equipment:
1. Verify that the light bar and mounting hardware fit the vehicle.
2. Determine where to mount the light bar on the vehicle.
3. Determine where to mount the controlling equipment:
• Trunk or remote location
• Console
AIRBAG DEPLOYMENT: Do not install equipment or route wiring in the
deployment path of an airbag. Failure to observe this warning will reduce the
eectiveness of the airbag or potentially dislodge the equipment, causing serious
injury or death.
4. Decide where to route wiring around airbag areas.
5. Decide where to route the light bar power and ground wires.
6. To make wiring easier, remove the seats, spare tire, and pull down the headliner
where needed.
7. Separate all electronic equipment wiring from two-way radio equipment wiring.
8. To avoid interference, keep two-way radio antennas a minimum of 18 in (45.7 cm) away
from warning equipment.
9. Whenever possible, run full wire lengths. DO NOT splice the wires.

Wiring the Integrity Light Bar in the Vehicle
20 Integrity Light Bar
Federal Signal www.fedsig.com
10. Do not coil excess wire. Leave a drain loop for servicing.
11. After drilling holes for wires, de-burr them, smooth sharp edges, and insert grommets
to protect the wires from chafing.
12. When you frame ground the equipment, use the manufacturer-supplied ground
locations in the vehicle.
IMPORTANT: After the installation, frequently inspect the light bar and mounting feet to
ensure that all fasteners and brackets are tight.
Connecting Power to the Light Bar
NOTE: Plan the location of the wire routing hole in the vehicle roof so that the power
and communication cables do not have tight bends and have some slack to allow
disconnection on removal.
BATTERY EXPLOSION: To avoid a battery explosion, always disconnect the
negative battery cable rst and reconnect it last. Avoid causing a spark when
connecting near or to the battery. The gases produced by a battery can cause a
battery explosion that could result in vehicle damage and serious injury.
SEAT REMOVAL PRECAUTION: If a vehicle seat is temporarily removed, verify
with the vehicle manufacturer if the seat needs to be recalibrated for proper airbag
deployment. Failure to follow this warning cause serious injury or death.
REVERSE POLARITY / MISWIRING: Reverse polarity or incorrect voltage may
damage the light. To avoid damage to the light, ensure that the battery voltage
is the same as the voltage rating of the light and that the correct polarity is
observed. If you are connecting to a cigarette lighter plug or 12 V outlet, connect
the positive wire to the center terminal and connect the negative wire to the outer
terminal.
To make the power connections:
1. Ensure that the lines are adequately fused as shown in Figure 3 on page 21.
2. From the light bar, route the CAT5 control cable into the vehicle cab or trunk near the
eventual location of the Serial Interface Module. An input cable is also provided with
the Interface Module.
3. Route and connect the black lead from the light bar to the vehicle battery’s ground
(–GND) terminal.
4. Route and connect the red lead from the light bar through a 40 A MAXI®fuse at the
source, which is the positive battery terminal (+BAT).
