Federal Signal Corporation VISION Quick guide

VISION®
WARNING SYSTEM
OPERATION AND CONFIGURATION INSTRUCTIONS
GENERAL SOFTWARE
Version 2.0
Price $15.00

TABLE OF CONTENTS
Paragraph Page
SECTION I - OPERATION
1-1 General ........................................................................................................................ 1-2
1-2 Power-up ...................................................................................................................... 1-2
1-3 Led Illumination Intensity Adjustment. .................................................................... 1-3
1-4 Foot Switch .................................................................................................................. 1-3
1-5 SS2000 SmartSiren® Interface. ................................................................................. 1-3
1-6 Keyboard Configurations
A. Keyboard Configuration 2 (POLICE A) ........................................................ 1-4
B. Keyboard Configuration 3 (POLICE B) ........................................................ 1-5
C. Keyboard Configuration 4 (FIRE A) ............................................................. 1-7
D. Keyboard Configuration 5 (FIRE B) ............................................................. 1-8
E. Keyboard Configuration 6 (RECOVERY)..................................................... 1-9
F. Keyboard Configuration 7 (CLEARBOARD) ............................................... 1-11
G. Keyboard Configuration 8 (DEMO) .............................................................. 1-11
SECTION II - CONFIGURATION
2-1 General ........................................................................................................................ 2-1
2-2 Sample Configuration Session
A. Enter Configuration Mode ............................................................................ 2-1
B. Level 1 Configuration .................................................................................... 2-2
C. Level 2 Configuration .................................................................................... 2-3
2-3 Configuration Restrictions .......................................................................................... 2-8
2-4 Configuration Worksheet ............................................................................................ 2-9
2-5 Test After Configuration ............................................................................................. 2-9
2-6 Configuration Mode Disable/Enable
A. Disable............................................................................................................ 2-9
B. Enable ............................................................................................................ 2-9
2-7 Configuration Quick Reference
A. Level 1 Configuration .................................................................................... 2-9
B. Level 2 Configuration .................................................................................... 2-11
SECTION III - MICROPROCESSOR INSTALLATION
3-1 General ........................................................................................................................ 3-1
3-2 Installation
A. Control Head .................................................................................................. 3-1
B. Interface/Relay Unit ...................................................................................... 3-1
C. Bar Controller ................................................................................................ 3-1
3-3 Software Revision Label Installation ......................................................................... 3-2
i

SECTION I
OPERATION
SAFETY MESSAGE TO OPERATORS OF
FEDERAL SIGNAL LIGHT SYSTEMS
WARNING
The lives of people depend on your safe opera-
tion of Federal products. It is important to read and
follow all instructions shipped with the products. In
addition, listed below are some other important
safety instructions and precautions you should
follow:
QUALIFICATIONS
• To properly use a light system: you must have a
good understanding of general vehicle operation, a
high proficiency in the use of safety warning equip-
ment, and thorough knowledge of state and federal
UNIFORM TRAFFIC CODES.
SIGNALING LIMITATIONS
• Be aware that the use of your visual signaling
devices does not give you the right to force your way
through traffic. Your emergency lights and actions
are REQUESTING the right-of-way.
• Although your warning system is operating
properly, it may not alert everyone. People may not
hear, see, or heed your warning signal. You must
recognize this fact and continue driving cautiously.
• Situations may occur which obstruct your
warning signal when natural or man-made objects
are between your vehicle and others, such as when
you raise your hood or trunk lid. If these situations
occur, be especially careful.
• The control head’s LED display simulates the
light pattern(s) being executed by the warning
system. The display is intended ONLY as a guide and
NOT as an indication of proper warning system
operation. Before using the warning system, its
operation should be observed from outside the
vehicle.
DRIVING LIMITATIONS
• At the start of your shift, you should ensure that
the light system is securely attached to the vehicle
and operating properly.
• If the unique combination of emergency vehicle
equipment installed in your vehicle has resulted in
the light/siren controls being installed in a position
that does not allow you to operate them by touch
only, OPERATE CONTROLS ONLY WHILE YOUR
VEHICLE IS STOPPED.
• If driving conditions require your full attention,
you should avoid operating the light/siren controls
while the vehicle is in motion.
CONTINUING EDUCATION
• File these instructions in a safe place and refer
to them periodically. Give a copy of these instructions
to new recruits and trainees.
Failure to follow these safety precautions may
result in property damage, serious injury, or death to
you, to passengers, or to others.
1-1

1-1. GENERAL.
IMPORTANT
Since most Vision features are programmable,
operation is described only for the “standard”
keyboard configurations. System configura-
tion and any changes to the “standard” key-
board configurations (if any) MUST be provided
to the operator by the installer or person re-
sponsible for programming. It is the operator’s
responsibility to understand how his particular
system is configured (programmed) to operate.
The Vision control head is designed to assist the
operator’s selection of functions. Each control head
switch is recessed and aids guiding the operator’s
finger to the switch’s center for activation. When a
switch is pressed, “tactile feedback” provides function
selection indication as follows: a click is felt, a beep is
heard, the selected function’s LED is illuminated,
and the control head’s V-shaped LED display indi-
cates which warning system lights are illuminated. If
the optional SignalMaster directional light is in-
stalled, the control head display simulates the
directional light pattern being executed.
The control head switches are grouped and
color-coded red, amber, and green to indicate the
priority level. Switches that are color-coded red have
the highest priority. Amber color-coded switches have
a lower priority than the red switch group, and the
green color-coded switches have the lowest priority.
Seven selectable “standard” keyboard configura-
tions are available. Each keyboard configuration has
a different function assigned to the keyboard
switches. Only one keyboard configuration can be
selected at a time. System operation is different for
each keyboard configuration. Keyboard configuration
selection (described in Section II) is performed, if
required, when the warning system is installed.
The seven keyboard configurations’ names
suggest a possible application as follows:
• Keyboard Configuration 1 (Federal Signal
use only).
• Keyboard Configuration 2 (POLICE A).
• Keyboard Configuration 3 (POLICE B).
• Keyboard Configuration 4 (FIRE A).
• Keyboard Configuration 5 (FIRE B).
• Keyboard Configuration 6 (RECOVERY).
• Keyboard Configuration 7 (CLEAR-
BOARD).
• Keyboard Configuration 8 (DEMO - sales
use only).
WARNING
Peoples’ lives depend on your safe operation
of this warning system. Ensure that you are
thoroughly familiar with the selected keyboard
configuration’s function selection and warning
system operation.
1-2. POWER-UP.
The Vision warning system does not have a
separate on-off switch. It is usually wired to the
vehicle’s ignition switch and is enabled when the
vehicle’s ignition switch is “on”.
If a user-supplied switch is installed, enable the
system by operating the switch to its “on” position.
CAUTION
The Vision warning system draws approxi-
mately 2.5A (all functions deactivated) and
will eventually discharge the vehicle battery.
Do not leave the system powered-up unless
the vehicle engine is running.
After power is applied, the system will power-up
as follows:
A. The RESET LED will flash for approxi-
mately four seconds to indicate that the system is
performing a self-test. During the self-test, the
keyboard will not operate the warning system and
the reflectors in the lightbar will rotate to the “home”
position.
B. After the self-test is completed, the RESET
LED changes from flashing to steady illumination. In
addition, the control head will sound a beep to
indicate the warning system is now ready for use.
NOTE
If the self-test is unsuccessful, the V-shaped
LED display and directional SignalMaster
LED display will flash and a beeping self-test
failure signal will sound. This failure indica-
tion may be caused by lamp failure, communi-
cation link failure, or other failure.
Press the RESET switch to clear the failure
indication. If the failure indication is cleared,
observe for proper warning system operation
from outside the vehicle. Lamps are tested
only once during power-up and should be
observed from outside the vehicle. If the fail-
ure indication is persistent, the warning sys-
tem should be serviced before use.
1-2

1-5. SS2000 SMARTSIREN INTERFACE.
If the SS2000 SmartSiren interface is installed,
operate switch 8 (usually Mode 3) or the foot switch
to activate the SS2000 pursuit function. The
SS2000’s Mode 3 will be activated and sound the
selected siren tone. Operate switch 8, or the foot
switch, again to deactivate Mode 3 and the SS2000
pursuit function.
Refer to the Installation and Operating Instruc-
tions supplied with the SS2000 for additional infor-
mation.
CAUTION
Improper warning system operation may re-
sult if the SS2000 Mode 3 switch is operated
when the SS2000 SmartSiren interface is
installed. Do not operate the SS2000 Mode 3
switch when the SS2000 SmartSiren interface
is installed.
1-6. KEYBOARD CONFIGURATIONS.
IMPORTANT
The control head’s LED display simulates the
light pattern(s) being executed by the warning
system. The display is intended ONLY as a
guide and NOT as an indication of proper
warning system operation.
Before using the warning system, its operation
should be observed from outside the vehicle.
The available “standard” keyboard configura-
tions are as follows:
• Keyboard Configuration 2 (POLICE A).
• Keyboard Configuration 3 (POLICE B).
• Keyboard Configuration 4 (FIRE A).
• Keyboard Configuration 5 (FIRE B).
• Keyboard Configuration 6 (RECOVERY).
• Keyboard Configuration 7 (CLEAR-
BOARD).
• Keyboard Configuration 8 (DEMO - sales
use only).
Determine which keyboard configuration is
selected. The installer or person responsible for
configuration will provide this information. Read and
understand the applicable keyboard configuration
description below.
1-3. LED ILLUMINATION INTENSITY ADJUSTMENT.
The bright LED’s provide maximum visibility in
high ambient lighting conditions. The RESET LED
illumination intensity can be adjusted from bright
illumination to dimmed, dimmer, or extinguished for
night operations. The backlighting illumination
intensity does not change, but does extinguish when
the RESET LED is extinguished.
To adjust, proceed as follows:
A. If any functions are activated, press the
RESET switch. The RESET LED should be illumi-
nated.
B. Press the RESET switch again to decrease
the LED illumination intensity.
C. Continue to press the RESET switch until
the desired LED illumination intensity and back-
lighting are achieved.
NOTE
Operating the foot switch (if installed), or
pressing any control head switch (except
RESET) will cause the LED illumination in-
tensity to revert to bright illumination.
Also, the LED illumination intensity will
revert to bright illumination when the vehicle
ignition switch, or user-supplied switch, is
switched “off” and switched “on”.
1-4. FOOT SWITCH.
Operating the optional foot switch will alternate
between the switch 8 function (usually Mode 3) and
the switch 7 function (usually Mode 2). If installed,
operate the foot switch to activate the switch 8
function. Operate the foot switch again to deactivate
the switch 8 function and activate the switch 7
function. Operating the foot switch a third time does
not deactivate the warning system; it will deactivate
the switch 7 function and reactivate the switch 8
function.
To deactivate a foot switch activated function,
operate the corresponding control head switch.
NOTE
Since the SS2000 SmartSiren® interface is
associated with the switch 8 function, the
siren will deactivate when the switch 7 func-
tion is activated.
1-3

A. Keyboard Configuration 2 (POLICE A).
NOTE
Refer to figure 1-1 while reading paragraph
1-6.A.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switch 2 (SignalMaster).
NOTE
This switch may be labeled “LRC-O” indicat-
ing—Left, Right, Center out, and Off.
Pressing this switch controls the
SignalMaster directional signal (if installed). It
provides a flashing arrow signal directing traffic to
move to the left, right, or around both sides of the
vehicle. In this keyboard configuration, the Signal-
Master switch utilizes “step through” activation.
Each press of switch 2 steps through the various
directional signals.
Switch 2 LED illuminates when the
SignalMaster is activated. Also, the row of LED’s
under the V-shaped display simulates the light
pattern being executed by the directional signal.
a. Press switch 2 to activate a left
arrow directional signal.
b. Press switch 2 a second time to
activate a right arrow signal.
c. Press switch 2 a third time to
activate a center out signal.
Figure 1-1. Keyboard Configuration 2.
d. Press switch 2 a fourth time to
deactivate the SignalMaster directional signal and
the switch 2 LED will extinguish.
3. Switch 3 (TAKE-DOWN).
Press switch 3 to activate the take-
down lights. The two lights fitted with clear domes
illuminate and rotate to the take-down (straight
ahead) position. Two LED’s in the V-shaped display
(which represent the take-down lights) will illumi-
nate and the switch 3 LED illuminates. Press switch
3 again to deactivate the take-down lights. The
LED’s in the V-shaped display and switch 3 LED will
extinguish. The take-down lights will return to the
previously activated function, if any.
NOTE
Take-down lights and alley lights can be aimed
or rotated horizontally. Refer to the descrip-
tions for the JOG LEFT and JOG RIGHT
switches below.
4. Switch 4 (RELAY A).
Press switch 4 to activate the auxiliary
device, such as headlight flashers or grille lights,
connected to the relay A output. The installer should
inform you what device (if any) is connected to the
relay A output. The switch 4 LED will illuminate.
Press switch 1 again to deactivate the auxiliary
device and extinguish the switch 4 LED.
5. Switch 5 (RELAY B).
Press switch 5 to activate the auxiliary
device connected to the relay B output. The installer
should inform you what device (if any) is connected to
the relay B output. The switch 5 LED will illuminate.
Press switch 5 again to deactivate the auxiliary
device and extinguish the switch 5 LED.
6. Switch 6 (MODE 1).
Press switch 6 to activate Mode 1. In
this keyboard configuration; a four-light, alternating,
oscillating pattern to the rear is activated. The LED’s
in the V-shaped display will flash indicating the
lights are activated and the switch 6 LED illumi-
nates. Press switch 6 again to deactivate Mode 1. The
LED’s in the V-shaped display and the switch 6 LED
will extinguish.
7. Switch 7 (MODE 2).
Press switch 7 to activate Mode 2. In
this keyboard configuration, four lights rotate at 90
FPM and three lights oscillate to the front. Also, the
auxiliary device (if any) connected to the relay C
output will activate. The installer should inform you
1-4
RESET 2 3 4 5 6 7 8
910 11
12
1 - Reset
2 - SignalMaster "step through"
3 - Takedown (pods 3 & 5)
4 - Relay A (push-on/push-off)
5 - Relay B (push-on/push-off)
6 - Mode 1 (pattern #42)
7 - Mode 2 (pattern #26 + Relay C)
8 - Mode 3 (pattern #27 + Relay C)
9 - Jog Left (pattern #86)
10 - Left Alley (pod 3 - pattern #76)
11 - Right Alley (pod 5 - pattern #73)
12 - Jog Right (pattern #87)

what device (if any) is connected to the relay C
output. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 7
LED will illuminate. Press switch 7 again to deacti-
vate Mode 2. The LED’s in the V-shaped display and
the switch 7 LED will extinguish.
8. Switch 8 (MODE 3).
Press switch 8 to activate Mode 3. In
this keyboard configuration, all seven lights rotate in
synchronization at 90 FPM creating a center-out
pattern. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 8
LED will illuminate. Press switch 8 again to deacti-
vate Mode 3. The LED’s in the V-shaped display and
the switch 8 LED will extinguish.
9. Switch 9 (JOG LEFT).
Press switch 9 to manually position
activated take-down/alley lights for use as a spot-
light. Each time switch 9 is pressed with a take-down
light activated, the light will move one step to the left
and the switch 9 LED will illuminate momentarily.
Each time switch 9 is pressed with the alley light(s)
activated, the light(s) will move one step to the rear
and the switch 9 LED will illuminate momentarily.
Press and hold switch 9 until the activated light(s)
rotates left or rear to the desired position.
NOTE
If switch 9 is pressed and held allowing the
activated take-down/alley light to rotate more
than approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
10. Switch 10 (LEFT ALLEY).
Press switch 10 to activate the left
alley light. The LED in the V-shaped display illumi-
nates to indicate which light is activated and the
switch 10 LED illuminates. Press switch 10 again to
deactivate the left alley light and extinguish the
switch 10 LED.
11. Switch 11 (RIGHT ALLEY).
Press switch 11 to activate the right
alley light. The LED in the V-shaped display illumi-
nates to indicate which light is activated and the
switch 11 LED illuminates. Press switch 11 again to
deactivate the right alley light and extinguish the
switch 11 LED.
12. Switch 12 (JOG RIGHT).
Press switch 12 to manually position
activated take-down/alley lights for use as a spot-
light. Each time switch 12 is pressed with a take-
down light activated, the light will move one step to
the right and the switch 12 LED will illuminate
momentarily. Each time switch 12 is pressed with
the alley light(s) activated, the light(s) will move one
step to the front and the switch 12 LED will illumi-
nate momentarily. Press and hold switch 12 until the
activated light(s) rotates right or forward to the
desired position.
NOTE
If switch 12 is pressed and held allowing the
activated take-down/alley light to rotate more
than approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
B. Keyboard Configuration 3 (POLICE B).
NOTE
Refer to figure 1-2 while reading paragraph
1-6.B.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switch 2 (JOG LEFT).
Press switch 2 to manually position
activated take-down lights for use as a spotlight.
Each time switch 2 is pressed, the activated lights
will move one step to the left and the switch 2 LED
will illuminate momentarily. Press and hold switch 2
until the activated lights rotate left to the desired
position.
1-5
Figure 1-2. Keyboard Configuration 3.
RESET 2 345678
910 1112
1 - Reset
2 - Jog Left (pattern #86)
3 - Takedown (pods 2 & 6)
4 - Jog Right (pattern #87)
5 - Relay A (push-on/push-off)
6 - Mode 1 (pattern #42)
7 - Mode 2 (pattern #26 + Relays B&C)
8 - Mode 3 (pattern #27 + Relays B&C)
9 - SignalMaster - Left
10 - SignalMaster - Center Out
11 - SignalMaster - Alternate
12 - SignalMaster - Right

NOTE
If switch 2 is pressed and held allowing the
activated take-down lights to rotate more
than approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
3. Switch 3 (TAKE-DOWN).
Press switch 3 to activate the take-
down lights. The two lights fitted with clear domes
illuminate and rotate to the take-down (straight
ahead) position. Two LED’s in the V-shaped display
(which represent the take-down lights) will illumi-
nate and the switch 3 LED illuminates. Press switch
3 again to deactivate the take-down lights. The
LED’s in the V-shaped display and switch 3 LED will
extinguish. The take-down lights will return to the
previously activated function, if any.
NOTE
Take-down lights can be aimed or rotated hori-
zontally. Refer to the switch operation descrip-
tions JOG LEFT (above) and JOG RIGHT
(below).
4. Switch 4 (JOG RIGHT).
Press switch 4 to manually position
activated take-down lights for use as a spotlight.
Each time switch 4 is pressed, the activated light will
move one step to the right and the switch 12 LED
will illuminate momentarily. Press and hold switch 4
until the activated light rotates right to the desired
position.
NOTE
If switch 4 is pressed and held allowing the
activated take-down lights to rotate more
than approximately 1-1/2 revolutions, an
error indication will occur. Press switch 1
(RESET) to clear the error indication and
start over.
5. Switch 5 (RELAY A).
Press switch 5 to activate the auxiliary
device, such as headlight flashers or grille lights,
connected to the relay A output. The installer should
inform you what device (if any) is connected to the
relay A output. The switch 5 LED will illuminate.
Press switch 5 again to deactivate the auxiliary
device and extinguish the switch 5 LED.
6. Switch 6 (MODE 1).
Press switch 6 to activate Mode 1. In
this keyboard configuration; a four-light, alternating,
oscillating pattern to the rear is activated. The LED’s
in the V-shaped display will flash indicating the
lights are activated and the switch 6 LED illumi-
nates. Press switch 6 again to deactivate Mode 1. The
LED’s in the V-shaped display and the switch 6 LED
will extinguish.
7. Switch 7 (MODE 2).
Press switch 7 to activate Mode 2. In
this keyboard configuration, four lights rotate at 90
FPM and three lights oscillate to the front. Also, the
auxiliary devices (if any) connected to the relay B and
C outputs will activate. The installer should inform
you what devices (if any) are connected to the relay B
and C outputs. The LED’s in the V-shaped display
will flash indicating the lights are activated and the
switch 7 LED will illuminate. Press switch 7 again to
deactivate Mode 2. The LED’s in the V-shaped
display and the switch 7 LED will extinguish.
8. Switch 8 (MODE 3).
Press switch 8 to activate Mode 3. In
this keyboard configuration, all seven lights rotate in
synchronization at 90 FPM creating a center-out
pattern. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 8
LED will illuminate. Press switch 8 again to deacti-
vate Mode 3. The LED’s in the V-shaped display and
the switch 8 LED will extinguish.
9. Switch 9 (SignalMaster LEFT).
Press switch 9 to activate a left arrow
directional signal directing traffic around the left side
of the vehicle. The switch 9 LED illuminates and the
row of LED’s under the V-shaped display simulates
the light pattern being executed by the directional
signal. Press switch 9 again to deactivate the left
arrow directional signal and extinguish the switch 9
LED.
10. Switch 10 (SignalMaster CENTER
OUT).
Press switch 10 to activate a center out
directional signal directing traffic around both sides
of the vehicle. The switch 10 LED illuminates and
the row of LED’s under the V-shaped display simu-
lates the light pattern being executed by the direc-
tional signal. Press switch 10 again to deactivate the
center out directional signal and extinguish the
switch 10 LED.
1-6

11. Switch 11 (SignalMaster
ALTERNATE).
Press switch 11 to activate an alter-
nating flash pattern(four lamps in the center, then
two outer lamps on both sides). The switch 11 LED
illuminates and the row of LED’s under the V-shaped
display simulates the light pattern being executed by
the directional signal. Press switch 11 again to
deactivate the alternating flash pattern and extin-
guish the switch 11 LED.
12. Switch 12 (SignalMaster RIGHT).
Press switch 12 to activate a right
arrow directional signal directing traffic around the
right side of the vehicle. The switch 12 LED illumi-
nates and the row of LED’s under the V-shaped
display simulates the light pattern being executed by
the directional signal. Press switch 12 again to
deactivate the right arrow directional signal and
extinguish the switch 12 LED.
C. Keyboard Configuration 4 (FIRE A).
NOTE
Refer to figure 1-3 while reading paragraph
1-6.C.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switch 2 (Blank).
In this keyboard configuration, this
switch is not assigned a function. The installer/
programmer MUST inform you what function (if any)
is assigned to this switch.
Figure 1-3. Keyboard Configuration 4.
3. Switch 3 (RELAY A).
Press switch 3 to activate the auxiliary
device, such as headlight flashers or grille lights,
connected to the relay A output. The installer should
inform you what device (if any) is connected to the
relay A output. The switch 3 LED will illuminate.
Press switch 3 again to deactivate the auxiliary
device and extinguish the switch 3 LED.
4. Switch 4 (RELAY B).
Press switch 4 to activate the auxiliary
device connected to the relay B output. The installer
should inform you what device (if any) is connected to
the relay B output. The switch 4 LED will illuminate.
Press switch 4 again to deactivate the auxiliary
device and extinguish the switch 4 LED.
5. Switch 5 (RELAY C).
Press switch 5 to activate the auxiliary
device connected to the relay C output. The installer
should inform you what device (if any) is connected to
the relay C output. The switch 5 LED will illuminate.
Press switch 5 again to deactivate the auxiliary
device and extinguish the switch 5 LED.
6. Switch 6 (MODE 1).
Press switch 6 to activate Mode 1. In
this keyboard configuration; the center light oscil-
lates to the front, one light oscillates to the left, and
one light oscillates to the right. The LED’s in the V-
shaped display will flash indicating the lights are
activated and the switch 6 LED will illuminate. Press
switch 6 again to deactivate Mode 1. The LED’s in
the V-shaped display and the switch 6 LED will
extinguish.
7. Switch 7 (MODE 2).
Press switch 7 to activate Mode 2. In
this keyboard configuration, four lights rotate at 90
FPM and three lights oscillate to the front. The
LED’s in the V-shaped display will flash indicating
the lights are activated and the switch 7 LED will
illuminate. Press switch 7 again to deactivate Mode
2. The LED’s in the V-shaped display and the switch
7 LED will extinguish.
8. Switch 8 (MODE 3).
Press switch 8 to activate Mode 3. In
this keyboard configuration, all seven lights rotate in
synchronization at 90 FPM creating a center-out
pattern. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 8
LED will illuminate. Press switch 8 again to deacti
1-7
RESET 2 345678
910 11
12
1 - Reset
2 - No function assigned
3 - Relay A (push-on/push-off)
4 - Relay B (push-on/push-off)
5 - Relay C (push-on/push-off)
6 - Mode 1 (pattern #48)
7 - Mode 2 (pattern #26)
8 - Mode 3 (pattern #27)
9 - V-Bar - Left (pattern #63)
10 - V-Bar - Center Out (pattern #64)
11 - V-Bar - Alternate (pattern #65)
12 - V-Bar - Right (pattern #62)

vate Mode 3. The LED’s in the V-shaped display and
the switch 8 LED will extinguish.
9. Switch 9 (V-BAR LEFT).
Press switch 9 to activate a lightbar
generated, left arrow directional signal to the front of
the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch 9
LED will illuminate. Press switch 9 again to deacti-
vate the directional signal. The LED’s in the V-
shaped display and the switch 9 LED will extinguish.
10. Switch 10 (V-BAR CENTER OUT).
Press switch 10 to activate a lightbar
generated, center out directional signal to the front of
the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch
10 LED will illuminate. Press switch 10 again to
deactivate the directional signal. The LED’s in the V-
shaped display and the switch 10 LED will extin-
guish.
11. Switch 11 (V-BAR ALTERNATE).
Press switch 11 to activate a lightbar
generated, alternating flash pattern (four lights in
the center, then two outer lights on both sides) to the
front of the vehicle. The LED’s in the V-shaped
display simulate the pattern being executed and the
switch 11 LED will illuminate. Press switch 11 again
to deactivate the directional signal. The LED’s in the
V-shaped display and the switch 11 LED will extin-
guish.
12. Switch 12 (V-BAR RIGHT).
Press switch 12 to activate a lightbar
generated, right arrow directional signal to the front
of the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch
12 LED will illuminate. Press switch 12 again to
deactivate the directional signal. The LED’s in the V-
shaped display and the switch 12 LED will extin-
guish.
D. Keyboard Configuration 5 (FIRE B).
NOTE
Refer to figure 1-4 while reading paragraph
1-6.D.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switch 2 (JOG LEFT).
Press switch 2 to manually position
activated take-down lights for use as a spotlight.
Each time switch 2 is pressed, the activated light will
move one step to the left and the switch 2 LED will
illuminate momentarily. Press and hold switch 2
until the activated lights rotate left to the desired
position.
NOTE
If switch 2 is pressed and held allowing the
activated take-down lights to rotate more
than approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
3. Switch 3 (TAKE-DOWN).
Press switch 3 to activate the take-
down lights. The two lights fitted with clear domes
illuminate and rotate to the take-down (straight
ahead) position. Two LED’s in the V-shaped display
(which represent the take-down lights) will illumi-
nate and the switch 3 LED illuminates. Press switch
3 again to deactivate the take-down lights. The
LED’s in the V-shaped display and switch 3 LED will
extinguish. The take-down lights will return to the
previously activated function, if any.
NOTE
Take-down lights can be aimed or rotated hori-
zontally. Refer to the switch operation descrip-
tions JOG LEFT (above) and JOG RIGHT
(below).
4. Switch 4 (JOG RIGHT).
Press switch 4 to manually position
activated take-down lights for use as a spotlight.
1-8 Figure 1-4. Keyboard Configuration 5.
RESET 2 345678
910 11
12
1 - Reset
2 - Jog Left (pattern #86)
3 - Takedown (pods 2 & 6)
4 - Jog Right (pattern #87)
5 - Relay A (push-on/push-off)
6 - Mode 1 (pattern #52)
7 - Mode 2 (pattern #26 + Relays B&C)
8 - Mode 3 (pattern #27 + Relays B&C)
9 - V-Bar - Left (pattern #63)
10 - V-Bar - Center Out (pattern #64)
11 - V-Bar - Alternate (pattern #65)
12 - V-Bar - Right (pattern #62)

Each time switch 4 is pressed, the activated light will
move one step to the right and the switch 12 LED
will illuminate momentarily. Press and hold switch 4
until the activated light rotates right to the desired
position.
NOTE
If switch 4 is pressed and held allowing the
activated take-down lights to rotate more
than approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
5. Switch 5 (RELAY A).
Press switch 5 to activate the auxiliary
device, such as headlight flashers or grille lights,
connected to the relay A output. The installer should
inform you what device (if any) is connected to the
relay A output. The switch 5 LED will illuminate.
Press switch 5 again to deactivate the auxiliary
device and extinguish the switch 5 LED.
6. Switch 6 (MODE 1).
Press switch 6 to activate Mode 1. In
this keyboard configuration, three lights rotate at 90
FPM. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 6
LED will illuminate. Press switch 6 again to deacti-
vate Mode 1. The LED’s in the V-shaped display and
the switch 6 LED will extinguish.
7. Switch 7 (MODE 2).
Press switch 7 to activate Mode 2. In
this keyboard configuration, four lights rotate at 90
FPM and three lights oscillate to the front. Also, the
auxiliary devices (if any) connected to the relay B and
C outputs will activate. The installer should inform
you what devices (if any) are connected to the relay B
and C outputs. The LED’s in the V-shaped display
will flash indicating the lights are activated and the
switch 7 LED will illuminate. Press switch 7 again to
deactivate Mode 2. The LED’s in the V-shaped
display and the switch 7 LED will extinguish.
8. Switch 8 (MODE 3).
Press switch 8 to activate Mode 3. In
this keyboard configuration, all seven lights rotate in
synchronization at 90 FPM creating a center-out
pattern. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 8
LED will illuminate. Press switch 8 again to deacti-
vate Mode 3. The LED’s in the V-shaped display and
the switch 8 LED will extinguish.
9. Switch 9 (V-BAR LEFT).
Press switch 9 to activate a lightbar
generated, left arrow directional signal to the front of
the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch 9
LED will illuminate. Press switch 9 again to deacti-
vate the directional signal. The LED’s in the V-
shaped display and the switch 9 LED will extinguish.
10. Switch 10 (V-BAR CENTER OUT).
Press switch 10 to activate a lightbar
generated, center out directional signal to the front of
the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch
10 LED will illuminate. Press switch 10 again to
deactivate the directional signal. The LED’s in the V-
shaped display and the switch 10 LED will extin-
guish.
11. Switch 11 (V-BAR ALTERNATE).
Press switch 11 to activate a lightbar
generated, alternating flash pattern(four lights in the
center, then two outer lights on both sides) to the
front of the vehicle. The LED’s in the V-shaped
display simulate the pattern being executed and the
switch 11 LED will illuminate. Press switch 11 again
to deactivate the directional signal. The LED’s in the
V-shaped display and the switch 11 LED will extin-
guish.
12. Switch 12 (V-BAR RIGHT).
Press switch 12 to activate a lightbar
generated, right arrow directional signal to the front
of the vehicle. The LED’s in the V-shaped display
simulate the pattern being executed and the switch
12 LED will illuminate. Press switch 12 again to
deactivate the directional signal. The LED’s in the V-
shaped display and the switch 12 LED will extin-
guish.
E. Keyboard Configuration 6
(RECOVERY).
NOTE
Refer to figure 1-5 while reading paragraph
1-6.E.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
1-9

Figure 1-5. Keyboard Configuration 6.
1-10
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switch 2 (JOG LEFT).
Press switch 2 to manually position
activated work lights for use as a spotlight. Each
time switch 2 is pressed, the activated work lights
will move one step toward the passenger side and the
switch 2 LED will illuminate momentarily. Press and
hold switch 2 until the activated lights rotate to the
desired position.
NOTE
If switch 2 is pressed and held allowing the
activated work lights to rotate more than
approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
3. Switch 3 (WORK LIGHT).
Press switch 3 to activate the work
lights. The two lights fitted with clear domes illumi-
nate and rotate to the rear. Two LED’s in the V-
shaped display (which represent the work lights) will
illuminate and the switch 3 LED illuminates. Press
switch 3 again to deactivate the work lights. The
LED’s in the V-shaped display and switch 3 LED will
extinguish. The work lights will return to the previ-
ously activated function, if any.
NOTE
Work lights can be aimed or rotated horizon-
tally. Refer to the switch operation descriptions
JOG LEFT (above) and JOG RIGHT (below).
4. Switch 4 (JOG RIGHT).
Press switch 4 to manually position
activated work lights for use as a spotlight. Each
time switch 4 is pressed, the activated work lights
will move one step toward the driver’s side and the
switch 12 LED will illuminate momentarily. Press
and hold switch 4 until the activated light rotates to
the desired position.
NOTE
If switch 4 is pressed and held allowing the
activated work lights to rotate more than
approximately 1-1/2 revolutions, an error
indication will occur. Press switch 1 (RESET)
to clear the error indication and start over.
5. Switch 5 (RELAY A).
Press switch 5 to activate the auxiliary
device, such as headlight flashers or grille lights,
connected to the relay A output. The installer should
inform you what device (if any) is connected to the
relay A output. The switch 5 LED will illuminate.
Press switch 5 again to deactivate the auxiliary
device and extinguish the switch 5 LED.
6. Switch 6 (MODE 1).
Press switch 6 to activate Mode 1. In
this keyboard configuration; the center light rotates
at 90 FPM and a four-light, alternating, oscillating
pattern to the rear is activated. The LED’s in the V-
shaped display will flash indicating the lights are
activated and the switch 6 LED illuminates. Press
switch 6 again to deactivate Mode 1. The LED’s in
the V-shaped display and the switch 6 LED will
extinguish.
7. Switch 7 (MODE 2).
Press switch 7 to activate Mode 2. In
this keyboard configuration, four lights rotate at 90
FPM and three lights oscillate to the front. The
LED’s in the V-shaped display will flash indicating
the lights are activated and the switch 7 LED will
illuminate. Press switch 7 again to deactivate Mode
2. The LED’s in the V-shaped display and the switch
7 LED will extinguish.
8. Switch 8 (MODE 3).
Press switch 8 to activate Mode 3. In
this keyboard configuration, all seven lights rotate in
synchronization at 90 FPM creating a center-out
pattern. The LED’s in the V-shaped display will flash
indicating the lights are activated and the switch 8
LED will illuminate. Press switch 8 again to deacti-
vate Mode 3. The LED’s in the V-shaped display and
the switch 8 LED will extinguish.
9. Switch 9 (SignalMaster LEFT).
Press switch 9 to activate a left arrow
directional signal directing traffic around the left side
RESET 2345678
910 11
12
1 - Reset
2 - Jog Left (pattern #86)
3 - Work Light (pods 2 & 6)
4 - Jog Right (pattern #87)
5 - Relay A (push-on/push-off)
6 - Mode 1 (pattern #43)
7 - Mode 2 (pattern #26)
8 - Mode 3 (pattern #27)
9 - SignalMaster - Left
10 - SignalMaster - Center Out
11 - SignalMaster - Alternate
12 - SignalMaster - Right

of the vehicle. The switch 9 LED illuminates and the
row of LED’s under the V-shaped display simulates
the light pattern being executed by the directional
signal. Press switch 9 again to deactivate the left
arrow directional signal and extinguish the switch 9
LED.
10. Switch 10 (SignalMaster
CENTER OUT).
Press switch 10 to activate a center out
directional signal directing traffic around both sides
of the vehicle. The switch 10 LED illuminates and
the row of LED’s under the V-shaped display simu-
lates the light pattern being executed by the direc-
tional signal. Press switch 10 again to deactivate the
center out directional signal and extinguish the
switch 10 LED.
11. Switch 11 (SignalMaster
ALTERNATE).
Press switch 11 to activate an alter-
nating flash pattern(four lamps in the center, then
two outer lamps on both sides). The switch 11 LED
illuminates and the row of LED’s under the V-shaped
display simulates the light pattern being executed by
the directional signal. Press switch 11 again to
deactivate the alternating flash pattern and extin-
guish the switch 11 LED.
12. Switch 12 (SignalMaster RIGHT).
Press switch 12 to activate a right
arrow directional signal directing traffic around the
right side of the vehicle. The switch 12 LED illumi-
nates and the row of LED’s under the V-shaped
display simulates the light pattern being executed by
the directional signal. Press switch 12 again to
deactivate the right arrow directional signal and
extinguish the switch 12 LED.
F. Keyboard Configuration 7
(CLEARBOARD).
NOTE
Refer to figure 1-6 while reading paragraph
1-6.F.
1. Switch 1 (RESET).
Press this switch to extinguish all
lights (if activated) in the lightbar. The RESET LED
will illuminate and the reflectors rotate to the “home”
Figure 1-6. Keyboard Configuration 7.
1-11
position. All other LED’s will extinguish and acti-
vated functions will deactivate.
NOTE
The RESET switch may be pressed at any time
to deactivate any previously selected function(s).
2. Switches 2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
and 12.
In this keyboard configuration, these
switches are not assigned functions. The installer/
programmer MUST inform you which functions are
assigned to the switches.
G. Keyboard Configuration 8 (DEMO).
WARNING
Property damage, serious injury, or death to
you, to passengers, or to others may result
from improper warning system use. DO NOT
use this keyboard configuration for warning
system activation.
See figure 1-7. This keyboard configuration
is intended ONLY for sales demonstrations and NOT
for emergency vehicle warning system applications.
Figure 1-7. Keyboard Configuration 8.
RESET 2345678
910 11
12
1 - Reset
2 - No function assigned
3 - No function assigned
4 - No function assigned
5 - No function assigned
6 - No function assigned
7 - No function assigned
8 - No function assigned
9 - No function assigned
10 - No function assigned
11 - No function assigned
12 - No function assigned
RESET 2345678
910 11
12
1 - Reset
2 - SignalMaster "step through"
3 - Pattern #35
4 - Pattern #56
5 - Pattern #28
6 - Pattern #42
7 - Pattern #26
8 - Pattern #63
9 - Pattern #86
10 - Pattern #76
11 - Pattern #83
12 - Pattern #87
Note: This keyboard configuration is for demonstration purposes ONLY.

2-1
SECTION II
CONFIGURATION
2-1. GENERAL.
WARNING
Property damage, serious injury, or death to
you or others may result if the Vision warning
system is improperly configured. Configura-
tion, if required, is to be performed at the time
of installation. It is NOT intended for opera-
tors to “customize” the Vision’s operation for
their individual preferences. It is the USER’s
responsibility to determine compatibility,
suitability, and ensure proper configuration
of the Vision warning system.
The person responsible for configuration
MUST be familiar with local codes and proce-
dures for safe emergency vehicle warning
system operation.
NOTE
After configuration is completed and all func-
tions thoroughly tested, reconfiguration by
unauthorized individuals can be prevented by
performing the procedure described in
paragraph 2-6.
The Vision is an extremely versatile and config-
urable warning system. Take-down lights, alley
lights, secondary and primary warning light pat-
terns, and the optional SignalMaster directional
warning signals are all available with the “standard”
keyboard configurations. Also, control of auxiliary
devices (headlight flashers, grille lights, etc.) is
available.
Selecting one of the seven “standard” keyboard
configurations is referred to as Level 1 Configuration.
Most warning system operational requirements can
be satisfied by Level 1 Configuration.
When one of the “standard” keyboard configura-
tions will not provide the necessary warning system
functions, Level 2 Configuration will allow changing
individual switch functions within the selected
keyboard configuration. Also, Level 2 Configuration
can be used to design a completely new keyboard
configuration.
Level 2 Configuration will allow assigning up to
four functions to individual switches within a se-
lected keyboard configuration. Functions which are
configurable/selectable without disassembly, tools, or
special equipment are as follows:
A. Pre-programmed patterns executed by the
Vision’s seven pods.
B. SignalMaster patterns executed by the
optional SignalMaster rear directional light.
C. Three auxiliary relay outputs to control
auxiliary lights and/or accessories.
D. Each switch can be configured for push-on/
push-off, momentary, or eight-second timed opera-
tion.
IMPORTANT
When determining keyboard configuration
changes, keep in mind the configuration re-
strictions described in paragraph 2-3.
NOTE
Before proceeding, the person responsible for
configuration should read and understand
Section I Operation.
It is recommended that you perform the sample
configuration session described in paragraph 2-2.
below. The sample configuration session describes
the two configuration techniques and illustrates the
warning system’s capabilities. In addition, it will
provide you with the necessary training to properly
configure the warning system.
2-2. SAMPLE CONFIGURATION SESSION.
NOTE
If the warning system was previously in-
stalled, configured, and the procedure in
paragraph 2-6.A. was performed, the configu-
ration mode will be disabled. Refer to para-
graph 2-6.B. to enable the configuration mode.
A. Enter Configuration Mode.
1. Power-up the system and wait for the
self-test to complete. The Reset/Save LED changes
from flashing to steady illumination and a beep
sounds indicating the system is ready for use.
2. Disconnect the modular connector at
the control head. Press and hold the Reset/Save
switch. Replace the modular connector at the control
head. The Reset/Save LED should be flashing.

3. Release the Reset/Save switch. A
single beep should be heard, switch 9 and 10 LED’s
should be illuminated, and the Reset/Save LED
should still be flashing, to indicate that the system is
in the configuration mode.
4. The three options now available are as
follows:
a. Pressing switch 9 will activate
the Level 1 Configuration mode (keyboard configura-
tion selection).
b. Pressing switch 10 will activate
the Level 2 Configuration mode (individual switch
configuration).
c. Pressing the Reset/Save switch
will save the present configuration and exit configu-
ration mode.
5. Proceed to Level 1 Configuration.
B. Level 1 Configuration.
NOTE
A short beep sounds when a switch is pressed
and a second short beep sounds when the
switch is released.
1. See figure 2-1. Press switch 9 to enter
the Level 1 Configuration mode. The Reset/Save LED
should still be flashing. The LED (2 through 8) which
corresponds to the keyboard configuration (2 through
8) currently selected will illuminate. (Keyboard
Configuration 2 is the default.) Refer to Section I for
keyboard configuration descriptions.
NOTE
The Reset/Save LED will remain flashing
while in the configuration mode.
2. To change the keyboard configuration
to Keyboard Configuration 3 (POLICE B), proceed as
follows:
a. See figure 2-2. Press switch 3.
Switch 2 LED will extinguish and switch 3 LED will
illuminate indicating Keyboard Configuration 3 is
selected.
b. Press the Reset/Save switch to
save the keyboard configuration selection and exit
the Level 1 Configuration mode.
3. The control head display will now
indicate that the system is in the configuration mode.
The Reset/Save LED is flashing and switch 9 and 10
LED’s are illuminated. Again, the three available
options are as follows:
a. Pressing switch 9 will activate
the Level 1 Configuration mode (keyboard configura-
tion selection).
b. Pressing switch 10 will activate
the Level 2 Configuration mode (individual switch
configuration).
c. Pressing the Reset/Save switch
will save the present configuration and exit configu-
ration mode.
4. Return to Level 1 Configuration and
verify that Keyboard Configuration 3 is selected as
follows:
a. Press switch 9. The Reset/Save
LED should be flashing and the switch 3 LED should
be illuminated indicating Keyboard Configuration 3
is the currently selected keyboard configuration.
b. Leave Keyboard Configuration 3
selected. Press the Reset/Save switch to exit the
Level 1 Configuration mode.
5. Press the Reset/Save switch again to
exit the configuration mode. A longer beep will sound
and the Reset/Save LED will change from flashing to
steady illumination indicating the system is ready for
use.
6. Refer to Section I Operation. Thor-
oughly test ALL functions to ensure that the selected
keyboard configuration (Keyboard Configuration 3)
operates the warning system as described.
7. Repeat the Level 1 Configuration
process and testing for Keyboard Configurations 4, 5,
6, 7, and 8.
Reset/
Save 2 345678
Keyboard Configuration Numbers
Figure 2-1. Configuration Mode Select. Figure 2-2. Keyboard Configuration Numbers
Reset/
Save 2 345678
910
Level 1
Select Level 2 Select
11 12
2-2

Figure 2-3. Keyboard Configuration 2. Figure 2-4. Level 2 Configuration.
Reset/
Save 2 345678
910 1112
1 - Reset/Save
2 - SignalMaster "step through"
3 - Takedown (pods 3 & 5)
4 - Relay A (push-on/push-off)
5 - Relay B (push-on/push-off)
6 - Mode 1 (pattern #46)
7 - Mode 2 (pattern #26)
8 - Mode 3 (pattern #28)
9 - Jog Left (pattern #86)
10 - Left Alley (pod 3 - pattern #76)
11 - Right Alley (pod 5 - pattern #73)
12 - Jog Right (pattern #87)
Reset/
Save 2 345678
10 11 129 ABCO
M
T
Pattern Numbers
SignalMaster
Pattern Select Relay Select Switch Operation Select
2-3
NOTE
If you get “lost” during the configuration ses-
sion, continue to press the Reset/Save switch
until a longer beep sounds and the Reset/Save
LED changes from flashing to steady illumi-
nation (indicates run mode). The configuration
session can then be repeated.
8. When you feel proficient with Level 1
Configuration, select Keyboard Configuration 2 and
proceed to Level 2 Configuration.
C. Level 2 Configuration.
IMPORTANT
The following configuration changes are for
training purposes only and are NOT intended
as a recommendation for configuration.
1. General.
Configuration changes should be
determined before performing Level 2 Configuration.
For this sample configuration session, changes will
be made to Keyboard Configuration 2. Keyboard
Configuration 2’s “standard” configuration is shown
in figure 2-3.
The configuration changes that will be
performed in this sample configuration session are as
follows:
a. Change 1—change auxiliary relay
output A (switch 4) to momentary operation.
b. Change 2—change auxiliary relay
output B (switch 5) to eight-second timed operation.
c. Change 3—add auxiliary relay
output C to Mode 1 (switch 6).
d. Change 4—add a SignalMaster
pattern to Mode 2 (switch 7).
e. Change 5—change Mode 3
(switch 8) from pattern #27 to pattern #35.
f. Change 6—change the pods used
for utility patterns from pods 3 & 5 to pods 2 & 6.
Perform the configuration changes as
described below.
NOTE
The Reset/Save LED will remain flashing
while in the configuration mode. Also, a short
beep sounds when a switch is pressed and a
second short beep sounds when the switch is
released.
2. Change 1—change switch 4 to momen-
tary operation.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode (see figure 2-1). A beep is heard
and the Reset/Save LED will be flashing. The two
options now available are: pressing the switch to be
reconfigured, or pressing the Reset/Save switch to
save the current configuration and exit Level 2
Configuration mode.
c. Press switch 4. See figure 2-4.
The control head display will indicate the currently
selected switch configuration as follows:
(1). Switch 2 LED through
switch 8 LED’s indicate the pattern (if any). The
steadily illuminated LED indicates the pattern
number’s tens digit; the flashing LED indicates the
pattern number’s ones digit.
(2). The row of LED’s below the
V-shaped display will emulate the SignalMaster
pattern (if any).
(3). The first three LED’s on the
left of the V-shaped display indicate which relay
output (if any) is activated by this switch.
(4). The last three LED’s on the
right of the V-shaped display indicate switch opera-
tion: push-on/push-off (O), momentary (M), and
eight-second timed (T).
Therefore; switch 4 is configured
with no pattern, no SignalMaster pattern, auxiliary
relay A activation, and push-on/push-off switch
operation.

2-4
d. Press switch 12 (switch operation
select) to change switch operation. Continue to press
switch 12 until the “M” LED in the V-shaped display
is illuminated. The control head display now indi-
cates that switch 4 is configured with no pattern, no
SignalMaster pattern, auxiliary relay A activation,
and momentary switch operation.
e. Press the Reset/Save switch to
save this configuration. The control head display will
indicate the last switch configured. Therefore, switch
4 LED is illuminated.
f. To exit Level 2 Configuration,
press the Reset/Save switch a second time.
g. Press the Reset/Save switch a
third time to exit the configuration mode. A longer
beep will sound and the Reset/Save LED will change
from flashing to steady illumination indicating the
system is ready for use.
h. Press switch 4 and ensure that it
is now configured for momentary operation. If switch
4 is not configured for momentary operation, repeat
Change 1 as described above; if switch 4 is configured
for momentary operation, proceed to Change 2 below.
3. Change 2—change switch 5 to eight-
second timed operation.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode. A beep is heard and the Reset/
Save LED will be flashing. The two options now
available are: pressing the switch to be reconfigured,
or pressing the Reset/Save switch to save the current
configuration and exit Level 2 Configuration mode.
c. Press switch 5. See figure 2-4.
The control head display will indicate that switch 5 is
configured with no pattern, no SignalMaster pattern,
auxiliary relay B activation, and push-on/push-off
switch operation.
d. Press switch 12 to change switch
operation. Continue to press switch 12 until the “T”
LED in the V-shaped display is illuminated. The
control head display now indicates that switch 5 is
configured with no pattern, no SignalMaster pattern,
auxiliary relay B activation, and eight-second timed
switch operation.
e. Press the Reset/Save switch to
save this configuration. The control head display will
indicate the last switch configured. Therefore, switch
5 LED is illuminated.
f. To exit Level 2 Configuration,
press the Reset/Save switch a second time.
g. Press the Reset/Save switch a
third time to exit the configuration mode. A longer
beep will sound and the Reset/Save LED will change
from flashing to steady illumination indicating the
system is ready for use.
h. Press switch 5 and ensure that it
is now configured for eight-second timed operation.
Proceed to Change 3 below.
4. Change 3—add auxiliary relay output
C to Mode 1.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode. A beep is heard and the Reset/
Save LED will be flashing. The two options now
available are: pressing the switch to be reconfigured,
or pressing the Reset/Save switch to save the current
configuration and exit Level 2 Configuration mode.
c. Press switch 6. See figure 2-4.
The control head display will indicate the currently
selected switch configuration as follows:
(1). Switch 2 LED through
switch 8 LED’s indicate the pattern (if any). The
steadily illuminated LED indicates the pattern
number’s tens digit; the flashing LED indicates the
pattern number’s ones digit.
(2). The row of LED’s below the
V-shaped display will emulate the SignalMaster
pattern (if any).
(3). The first three LED’s on the
left of the V-shaped display indicate which relay
output (if any) is activated by this switch.
(4). The last three LED’s on the
right of the V-shaped display indicate switch opera-
tion: push-on/push-off (O), momentary (M), and
eight-second timed (T).
Therefore; switch 6 is configured
with pattern #46, no SignalMaster pattern, no
auxiliary relay, and push-on/push-off switch opera-
tion.
d. Press switch 11 to add an auxil-
iary relay output to the switch 6 configuration.
Continue to press switch 11 until the “C” LED in the
V-shaped display is illuminated. The control head
display now indicates that switch 6 is configured

Figure 2-5. SignalMaster Patterns.
8
1
4
7
2
3
6
3
2
5
4
1
4
5
1
3
6
2
2
7
3
1
8
4
12
1122
81234567
18765432
44321123
22211112
Driver
Side Passenger Side
Left Arrow
Right Arrow
Center Out
Alternating 1
Alternating 2
Alternating 3
Step Through
2-5
with pattern #46, no SignalMaster pattern, auxiliary
relay C activation, and push-on/push-off operation.
e. Press the Reset/Save switch to
save this configuration. The control head display will
indicate the last switch configured. Therefore, switch
6 LED is illuminated.
f. To exit Level 2 Configuration,
press the Reset/Save switch a second time.
g. Press the Reset/Save switch a
third time to exit the configuration mode. A longer
beep will sound and the Reset/Save LED will change
from flashing to steady illumination indicating the
system is ready for use.
h. Press switch 6 and ensure that
auxiliary relay output C was added to the configura-
tion. Proceed to Change 4 below.
5. Change 4—add a SignalMaster pat-
tern to Mode 2.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode. A beep is heard and the Reset/
Save LED will be flashing. The two options now
available are: pressing the switch to be reconfigured,
or pressing the Reset/Save switch to save the current
configuration and exit Level 2 Configuration mode.
c. Press switch 7. See figure 2-4.
The control head display will indicate that switch 7 is
configured with pattern #26, no SignalMaster pat-
tern, auxiliary relay C activation, and push-on/push-
off switch operation.
d. Press switch 10 to add a Signal-
Master pattern to the switch 7 configuration. Con-
tinue to press switch 10 until the desired SignalMas-
ter pattern (see figure 2-5) is displayed. The control
head display now indicates that switch 7 is config-
ured with pattern #26, a SignalMaster pattern,
auxiliary relay C activation, and push-on/push-off
switch operation.
e. Press the Reset/Save switch to
save this configuration. The control head display will
indicate the last switch configured. Therefore, switch
7 LED is illuminated.
f. To exit Level 2 Configuration,
press the Reset/Save switch a second time.
g. Press the Reset/Save switch a
third time to exit the configuration mode. A longer
beep will sound and the Reset/Save LED will change
from flashing to steady illumination indicating the
system is ready for use.
h. Press switch 7 and ensure that it
is now configured with the desired SignalMaster
pattern. Proceed to Change 5 below.
6. Change 5—change Mode 3 pattern
from #27 to #35.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode. A beep is heard and the Reset/
Save LED will be flashing. The two options now
available are: pressing the switch to be reconfigured,
or pressing the Reset/Save switch to save the current
configuration and exit Level 2 Configuration mode.
c. Press switch 8. See figure 2-4.
The control head display will indicate that switch 8 is
configured with pattern #27, no SignalMaster pat-
tern, auxiliary relay C activation, and push-on/push-
off switch operation.

2-6
d. Before a pattern can be changed,
it is necessary to first clear (remove) the current
pattern. Press a switch (2 through 8) to clear (re-
move) the current pattern and extinguish LED’s 2
through 8. The Reset/Save LED will be flashing.
NOTE
All available patterns are shown in figure 2-6.
e. Press switch 3 to select the
pattern number’s tens digit. Switch 3 LED is illumi-
nated.
f. Press switch 5 to select the
pattern number’s ones digit. Switch 5 LED is flash-
ing. The control head’s display now indicates switch 8
is configured with pattern #35, no SignalMaster
pattern, auxiliary relay C activation, and push-on/
push-off switch operation.
g. Press the Reset/Save switch to
save this configuration. The control head display will
indicate the last switch configured. Therefore, switch
8 LED is illuminated.
h. To exit Level 2 Configuration,
press the Reset/Save switch a second time.
i. Press the Reset/Save switch a
third time to exit the configuration mode. A longer
beep will sound and the Reset/Save LED will change
from flashing to steady illumination indicating the
system is ready for use.
j. Press switch 8 and ensure that it
is now configured with pattern #35. Proceed to
Change 6 below.
7. Change 6—change the pods used for
utility patterns from pods 3 & 5 to pods 2 & 6.
NOTE
All utility patterns must use the same set of
pods. Refer to the configuration restrictions
described in paragraph 2-3.
a. Enter the configuration mode as
described in paragraph 2-2.A.
b. Press switch 10 to enter Level 2
Configuration mode. A beep is heard and the Reset/
Save LED will be flashing. The two options now
available are: pressing the switch to be reconfigured,
or pressing the Reset/Save switch to save the current
configuration and exit Level 2 Configuration mode.
c. Press switch 3. See figure 2-4.
The control head display will indicate that switch 3 is
configured with pattern #83 (take down lights using
pods 3 & 5), no SignalMaster pattern, no auxiliary
relay, and push-on/push-off switch operation.
d. Press a switch (2 through 8) to
clear (remove) the pattern and extinguish LED’s 2
through 8. The Reset/Save LED will be flashing.
NOTE
Utility patterns are shown in figure 2-6. Also,
see figure 2-7 to determine the pod numbers.
e. Press switch 8 to select the
pattern number’s tens digit. Switch 8 LED is illumi-
nated.
f. Press switch 4 to select the
pattern number’s ones digit. Switch 4 LED is flash-
ing. The control head’s display now indicates switch 3
is configured with pattern #84 (take down lights
using pods 2 & 6), no SignalMaster pattern, no
auxiliary relay, and push-on/push-off switch opera-
tion.
g. Press the Reset/Save switch to
save switch 3’s configuration. The control head
display will indicate the last switch configured.
Therefore, switch 3 LED is illuminated.
h. Press switch 10. See figure 2-4.
The control head display will indicate that switch 10
is configured with pattern #76 (left alley light using
pod 3), no SignalMaster pattern, no auxiliary relay,
and push-on/push-off switch operation.
i. Press a switch (2 through 8) to
clear (remove) the pattern and extinguish LED’s 2
through 8. The Reset/Save LED will be flashing.
j. Press switch 7 to select the
pattern number’s tens digit. Switch 7 LED is illumi-
nated.
k. Press switch 8 to select the
pattern number’s ones digit. Switch 8 LED is flash-
ing. The control head’s display now indicates switch
10 is configured with pattern #78 (left alley light
using pod 2), no SignalMaster pattern, no auxiliary
relay, and push-on/push-off switch operation.
l. Press the Reset/Save switch to
save switch 10’s configuration. The control head
display will indicate the last switch configured.
Therefore, switch 10 LED is illuminated.
