Fein ASCM 12 C User manual

ASCM 12
Technical data
C-SC_CSSM
Version 1.0
2016-05-04
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 / 1
Technical data
All the technical data can be found in the operating instructions for the model.
Tests
Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants / Auxiliary substances
The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com

ASCM 12
Notes and requirements
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 / 1
Please note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts.
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act [ProdSG] applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed.

ASCM 12
Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 / 1
Please note
No lubricants and auxiliary substances are required for fitting the ASCM 12 machines.

ASCM 12
Troubleshooting
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 / 2
Fault Cause Remedy
LED not lighting up
Cable defective Check cable
LED defective Check LED
Electronics defective Replace electronics
Rotor not moving
Mechanical defect Replace rotor/ stator
Cable defective Replace cable
Toggle switch defective Replace toggle switch
Switch defective Replace switch
Battery plug contacts have come loose Check components
Electronics defective Replace electronics
Rotor only turns in one direction Toggle switch defective Replace toggle switch
Switch defective Replace switch
Unusual noise from gearbox (rattling) Gearbox defective Replace gearbox
Torque shut-off cannot be adjusted Adjusting ring defective Replace gearbox
Slide switch stiff Slide switch dirty
Slide switch defective
Clean and lubricate slide switch
Replace gearbox

ASCM 12
Troubleshooting
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
2 / 2
Fault Cause Remedy
Drill chuck jaws stuck Drill chuck opened using machine drive Replace drill chuck

ASCM 12
Removal
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 / 9
Removing the holder
1. Unscrew the screw (1).
2. Remove the holder (2).
Tools:
- PH2 cross-tip
screwdriver
2
1

ASCM 12
Removal
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
2 / 9
Removing the battery
1. Press and hold the catch (1).
2. Pull off the battery.
1

ASCM 12
Removal
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
3 / 9
Removing the drill chuck
1. Pull out and hold the bottom of the drill chuck (1).
2. Pull off the drill chuck.
1

ASCM 12
Removal
C-SC_CSSM
Version 1.0
2016-05-03
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
4 / 9
Removing the motor housing
1. Unscrew the ten screws (1).
2. Cut through the type plate (2).
3. Remove the motor housing (3).
Tools:
- Torx T10
- Blade
1
2
3
