Fenix CESM-TR3 User manual

CESM-TR3
Lifting kit for motor support for TR3
CSM-TR
SM-TR
SQ-29200
AC-657
x4
AC-654
x4
STEP 1
Place the four TR3 towers at the corner to mount
the truss perimeter and stabilize the towers.
STEP 2
Place horizontally the stair-truss that you want to
raise just above the perimeter, mount the top at
the end of the stair-truss and attach it to the two
hinges from the 0,5m truss. Make the same in the
4 towers.
STEP 3
Assembly all items for the support motor as
shown in the pictures, place the electrical chain
hoist and pass the chain. Ensure the hook to the
stair-truss using a sling or similar product.
TI-CSM
AP-CSM

6°
STEP 4
Switch on the electrical chain hoist and
raise the stair-truss from horizontal to
vertical position. To easily lift the stair-
truss, it is required to raise it manually up
to 6º in horitzontal position. Afterwards,
switch on the electrical chain hoist.
STEP 5
Once the tower is up, put the safety pins to
the hinges, remove the truss along with the
following accessories: CSM-TR, TI-CSM and
AP-CSM. Assembly SM-TR to the clamps of
the sleeveblock, as shown in image. Once
this step is done, you can start raising the
structure.
