Ferax BUC-260 User manual

lnstruktionsbok


Manual

Code no. 19694- 0308

16
ENGLISH
Original instructions
CONTENTS
1. Introduction..........................................16
2. Technical specifications.......................16
3. Package contents..................................16
4. Features ................................................16
5 Safety instructions................................17
5.1 Special safety instructions ...................17
5.2 Electrical safety....................................17
6 Assembly and operation.......................17
6.1 Mounting accessories...........................17
6.2 Fitting/replacing sandpaper..................17
7 Maintenance.........................................18
7.1 Cleaning ...............................................18
7.2 Lubrications ..........................................18
7.3 Faults....................................................18
7.4 Environment.........................................18
Spare parts list...............................................28
EC conformity declaration............................29
1. INTRODUCTION
Warning! Always read the instruc-
tions for electrical products carefully
befor use. It will help you understand
your product more easily and avoid unneces-
sary risks. Keep this instruction manual in a
safe place for future use.
Intended use
This machine is intended for dry sanding of
small areas, sawing and scraping with various
tool accessories, as well as for polishing,
rasping, cutting and separating various
materials.
2. TECHNICAL SPECIFICATIONS
Mains voltage............................. V 230
Frequency................................. Hz 50
Power input............................... W 260
No-load speed ...................... r/min 22000
Weight....................................... kg 1.48
LpA (sound pressure level)..dB(A) 87.9
.............................................dB(A) K=3
LpW (sound power level)....dB(A) 98.9
.............................................dB(A) K=3
Vibration ................................ m/s27.0006+1.5
3. PACKAGE CONTENTS
The package contains:
1 Universal saw
10 Accessories
1 Users manual
1 Safety instructions
Check the machine, loose parts and accessories
for transport damage.
4. FEATURES (Fig. 1)
3
2
4
5
1
Fig. 1
1. On/Off switch 4. Scraper
2. Sanding sole 5. Saw blad
3. Sandpaper

17
5. SAFETY INSTRUCTIONS
The following pictograms are used in these
instructions for use:
Denotes risk of personal injury, loss
of life or damage to the tool in case
of non-observance of the instructions
in this manual.
Indicates electrical shock hazard.
5.1 Special safety instructions
• Compare the maximum number of revo-
lutions allowed of the accessories with the
number of revolutions of the machine.
• Whenyouputthemachineawaytheengine
must be switched off and moving parts must
have reached a standstill.
• Never attach an assembly spanner to your
machine with a piece of string or anything
similar.
• Do not use sandpaper intended for larger
sanding pads. Larger sandpaper will extend
beyond the sanding pad causing snagging,
tearingofthepaperorkick-back.Extrapaper
extending beyond the sanding pad can also
cause serious lacerations.
• Useaclampingdeviceforsecuringthework
piece.
• Keepyourhandsawayfromtheworkpiece.
5.2 Electrical safety
When using electric machines always observe
the safety regulations applicable in your coun-
try to reduce the risk of fire, electric shock and
personal injury. Read the following safety
instructions and also the enclosed safety
instructions. Keep these instructions in a safe
place!
Always check that the power supply
corresponds to the voltage on the
rating plate.
The machine is double insulated;
therefore no earth wire is required.
Replacing cables or plugs
If the mains cable becomes damaged, it must be
replaced with a special mains cable available
from the manufacturer or the manufacturer’s
customer service. Dispose of old cables or
plugs immediately after replacing them with
new ones. It is dangerous to connect the plug
of a loose cable to a socket.
6. ASSEMBLY AND OPERATION
6.1 Mounting accessories
For saw blades, scrapers and disc cutters and
cutting discs use the clamping screw in combi-
nation with the retaining ring.
• Removetheclampingscrew usinganAllen
key.
• Replace the tool and tighten it using the
clamping screw. Check that the tool is secure
in the chuck and that the machine is correctly
secured and supported.
6.2 Fitting/replacing sandpaper
Using velcro system.
• Placethesandpaperinthemiddleofthesan-
ding disc and press it firmly with your hand.
• Pressthesandpaperfirmlyontotheplatewith
brief, firm pressure and then switch on the
machine. This ensures that the disc is cor-
rectlysecuredandpreventsexcessivewear.
• Ifthesandpaperisworninaparticularspot,
you can remove it, turn it 120° and refit it or
replace it.

18
7. MAINTENANCE
The machines have been designed to operate
over a long period of time with a minimum of
maintenance. Continuous satisfactory opera-
tion depends upon proper machine care and
regular cleaning.
7.1 Cleaning
Keep the ventilation slots of the machine clean
to prevent overheating of the engine. Regularly
clean the machine housing with a soft cloth,
preferably after each use. Keep the ventilation
slots free from dust and dirt. If the dirt does not
come off use a soft cloth moistened with soapy
water. Never use solvents such as petrol, alco-
hol, ammonia water, etc. These solvents may
damage the plastic parts.
7.2 Lubrication
The machine requires no additional lubrication.
7.3 Faults
Should a fault occur, e.g. after wear of a part,
please contact the service address on the war-
ranty card. In the back of this manual you find
anexplodedviewshowingthepartsthat
can be ordered.
7.4 Environment
To prevent damage during transport, the app-
liance is delivered in a solid packaging which
consists largely of reusable material. Therefore
please make use of options for recycling the
packaging.
Faulty and/or discarded electrical or
electronic apparatus have to be col-
lected at the appropriate recycling
locations.

28
BUC- 260 DIAGRAM
1
2
3
4
5
6
8
9
1 0
1 2
1 3
1 4
1 5
1 6
1 7
2 6
2 7 2 8 2 9
3 0
3 1
3 2
3 3
2 3
2 4 2 5
2 7
2 8
2 9
3 0
3 4
3 5
3 6
3 7
3 8
3 1
2 1
2 0
1 8
1 9
3 9
4 0
7
2 2
1 1
4 1

29
BUC- 260 PART LIST
No. Description Specication Qty
1 Screw M8×16 1
2 Output shaft 1
3 Dust ring 1
4 Check ring 26 1
5 Wave washer Ø19×25× 0.5 1
6 Bearing 80100 1
7 Swing preset 1
8 Axlepreset  1
9 Screw ST4.2×30 4
10 Gearbox  1
11 Check ring 3.5 1
12 Bearing 625R8 1
13 O-ring 2×30 1
14 Bearing base 1
15 Bearing 80018 1
16 Armature 1
17 Bearing 80017 1
18 Bearing cover 1
19 Wind baffle 1
20 Screw ST4.2×48 2
21 Stator 1
No. Description Specication Qty
22 Spring 1
23 Pin Ø1.5×24 1
24 Switch knob 1
25 Small switch knob 1
26 Pull rod 1
27 Brush holder 2
28 Spring 2
29 Brush 2
30 Screw ST2.9×8 5
31 Screw ST4.2×16 3
32 Cable clump 1
33 Cable jacket 1
34 Cable plug 1
35 Rear cover 1
36 Switch 1
37 Capacitor 0.22μF 1
38 Stator housing 1
39 Clump 1
40 Hexkey 6 1
41 Plate 1


�TM
ARETE S UPP LIES S . L .
www.aretesupplies.co m
Universal saw
BUC-260
