Ferno 24 MAXX User manual

Users’ Manual
May 2011 GLO
Pub. No. 234-3307-04
Read this Manual
and Retain for
Future Reference
Mortuary Cots
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®

2© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
Serial Number _________________________
Location: Crosstube at loading end of cot.
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.
Disclaimer
This manual contains general instructions for the use, operation
and care of this product. The instructions are not all-inclusive. Safe
and proper use of this product is solely at the discretion of the
user. Safety information is included as a service to the user. All
other safety measures taken by the user should be within and under
consideration of applicable regulations. It is recommended that
training on the proper use of this product be provided before using
this product in an actual situation.
Retain this manual for future reference. Include it with the product
in the event of transfer to new users. Additional free copies are
available upon request from Customer Relations.
Ferno Technical Support
Customer service and product support are important aspects of each
Ferno product. Please have the product serial number available
when calling, and include it in all written communications. For
technical support questions:
Telephone (Toll-free) 1.800.733.3766 ext. 1010
Telephone [phone] ext. 1010
Email quality[email protected]
Ferno Customer Relations
For ordering assistance or general information:
CANADA AND THE U.S.A.
Telephone (Toll-free) 1.877.733.0911
Telephone [phone]
Fax (Toll-free) 1.888.388.1349
Fax [phone]
Internet www.ferno.com
ALL OTHER LOCATIONS
For assistance or information, please contact your Ferno
distributor. If you do not have a Ferno distributor, please contact
Ferno Customer Relations:
Ferno-Washington, Inc.
70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone [phone]
Fax [phone]
Internet www.ferno.com
Proprietary Notice
The information disclosed in this manual is the property of Ferno-
Washington, Inc., Wilmington, Ohio, USA. Ferno-Washington, Inc.
reserves all patent rights, proprietary design rights, manufacturing
rights, reproduction use rights, and sales use rights thereto, and
to any article disclosed therein except to the extent those rights
are expressly granted to others or where not applicable to vendor
proprietary parts.
Limited Warranty Statement
The products sold by Ferno are covered by a limited warranty,
which is printed on all Ferno invoices. The complete terms and
conditions of the limited warranty, and the limitations of liability
and disclaimers, are also available upon request by calling Ferno at
1.800.733.3766 or 1.937.382.1451.
© Copyright Ferno-Washington, Inc. All Rights Reserved.

3
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
TABLE OF CONTENTS
Ferno Technical Support _______________________ 2
Ferno Customer Relations______________________ 2
Table of Contents ______________________________ 3
1 -Safety Information ___________________________ 4
1.1 Warning________________________________ 4
1.2 Important_______________________________ 4
1.3 Bloodborne Disease Notice_________________ 4
1.4 Cot and Fastener Compatibility _____________ 4
1.5 Safety and Instruction Labels _______________ 5
1.6 Symbol Glossary_________________________ 5
2 - Operator Skills And Training __________________ 6
2.1 Skills __________________________________ 6
2.2 Training ________________________________ 6
2.3 Height and Strength Considerations __________ 6
3 - About The Cot ______________________________ 7
3.1 Description _____________________________ 7
3.2 Cot Options _____________________________ 7
3.3 Components ____________________________ 8
3.4 Specications ___________________________ 9
3.5 Measurement Reference Points______________ 9
3.6 Cot Positions ___________________________ 10
4 - Cot Setup _________________________________ 10
4.1 Setup _________________________________ 10
5 - Using The Features _________________________ 11
5.1 Bed Panel Slots _________________________ 11
5.2 Restraints______________________________ 12
5.3 Control Handles ________________________ 13
5.4 Mattress_______________________________ 14
5.5 Wheel Locks ___________________________ 14
5.6 Sidearms (Optional) _____________________ 14
5.7 Side-Lift Handles (Optional) ______________ 15
6 - Using The Cot______________________________ 16
6.1 Before Placing the Cot in Service___________ 16
6.2 General Guidelines for Use________________ 16
6.3 Changing Cot Levels With Two Operators ____ 17
6.4 Changing Cot Levels With One Operator_____ 18
6.5 Rolling the Cot _________________________ 19
6.6 Transferring the Body Onto the Cot _________ 20
6.7 ManeuveringtheCotInaConnedArea _____ 20
6.8 Loading the Cot_________________________ 21
6.9 Unloading the Cot_______________________ 22
6.10 Loading or Unloading
With Two Trained Operators_______________ 23
6.11 Using Additional Help ___________________ 24
7 - Maintenance _______________________________ 25
7.1 Maintenance Schedule ___________________ 25
7.2 Disinfecting and Cleaning the Restraints _____ 25
7.3 Disinfecting and Cleaning the Mattress ______ 25
7.4 Disinfecting and Cleaning the Cot __________ 25
7.5 Waxing the Cot _________________________ 26
7.6 Inspecting the Cot _______________________ 26
7.7 Lubricating the Cot ______________________ 27
8 - Accessories ________________________________ 28
9 - Parts And Service___________________________ 28
9.1 U.S.A. and Canada ______________________ 28
9.2 Worldwide_____________________________ 28
9.3 Parts List 24-MAXX_____________________ 29
9.4 Parts List 24-miniMAXX,24H-miniMAXX___ 30
Training Record ______________________________ 31
Maintenance Record___________________________ 31

4© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
Safety Information
1 SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation
which, if not avoided, could result in injury or death.
1.2 Important
Important notices emphasize important usage or maintenance
information.
Important
1.3 Bloodborne Disease Notice
To reduce the risk of exposure to bloodborne diseases
such as HIV-1 and hepatitis when using the cot, follow the
disinfecting and cleaning instructions in this manual.
1.4 Cot and Fastener Compatibility
Combining different manufacturers’products into a “mixed-
component” cot/cot fastener system can increase the user’s
risk of injury and damage.
Ferno-Washington, Inc. strongly recommends that only
Ferno-manufactured cots be used in Ferno-manufactured cot
fasteners, and that only Ferno-manufactured cot fasteners be
used for securing Ferno-manufactured cots in vehicles.
ANY COMBINATION OF A FERNO COT OR COT
FASTENER WITH A NON-FERNO COT OR COT
FASTENER IS MISUSE OF THE FERNO PRODUCT.
Responsibility for the outcome of know, intentional misuse
rests squarely on the misuser.
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to operate the cot.
Improper use of the cot can cause injury. Use the cot only
for the purpose described in this manual.
Improper operation can cause injury. Operate the cot
only as described in this manual.
An unrestrained body can fall o the cot. Use restraints to
secure the body on the cot.
Rolling the 24H-miniMAXX in the loading position can
cause it to tip. Use a rolling position when rolling the cot.
Helpers can cause injury or be injured. Maintain control
of the cot, operate the controls, and direct all helpers.
Improper maintenance can cause injury. Maintain the cot
only as described in this manual.
Attaching improper items to the cot can cause injury. Use
only Ferno-approved items on the cot.
Improper parts and service can cause injury. Use only
Ferno parts and Ferno-approved service on the cot.
Modifying the cot can cause injury and damage. Use the
cot only as designed by Ferno.

5
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
1.5 Safety and Instruction Labels
Safety and instruction labels place important information from the users’ manual on the cot. Read and follow label instructions.
Replace worn or damaged labels immediately. New labels are available from EMSAR (in the U.S.A. and Canada, page 28) or
fromyourFernodistributor(page2).Thefollowinglabelsareafxedtothecot.
Safety Information
Identication and Load-Limit Label: One of the labels shown
aboveisafxedtotheoperatorendofthecot.Thelabelidenties
the cot model and load limit.
1.6 Symbol Glossary
The symbols dened in this section are used on the cot and/or in this users’ manual. Ferno uses symbols recognized by the
International Standards Organization (ISO), the American National Standards Institute (ANSI), and the mortuary services industry.
Loading-end Leg Control
Handle, afxed near the black
control handle at the loading end
of the cot. The handle unlocks
the loading-end leg for raising or
lowering the cot.
Loading-end Leg Control
Handle, afxed near the black
control handle at the operator end
of the cot. The handle unlocks the
loading-end leg for loading the
cot into a vehicle.
Users’ Manual Label: This label
reminds the operator to read the
users’ manual and tells how to
obtain additional manuals.
Operator-end Leg Control
Handle, afxed near the red
control handle at the operator end
of the cot. The handle unlocks
the operator-end leg for raising
or lowering the cot.
Cot May Be Operated
by One Trained Operator
General Warning of
Potential Injury
Read the Users’
Manual
Unlocked LockedDo Not
Lubricate
Lubricate
Load Limit
1000 lb
454 kg
Pinch Point:
Keep Hands Clear
Product meets European
Union Standards

6© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
2  OPERATOR SKILLS AND TRAINING
Operator Skills and Training
2.2 Training
Operator trainees need to:
● read and understand this manual.
● be trained on the use of the cot.
● practice with the cot before using it with a body.
● record their training information. A sample training record
sheet is provided on page 31.
2.1 Skills
Operators using the cot need:
● a working knowledge of mortuary-service procedures.
● a complete understanding of the procedures described in this
manual.
The cot is designed so that during unloading, the operator lifts
the cot only until the rear set of legs unfolds and locks.
Be aware that if the vehicle is parked in a low area or on an incline,
the operator (and any helpers) may need to lift the operator end of
the cot off the ground to provide clearance for the operator-end legs
to unfold completely and lock (see illustration above).
When the operator-end legs have locked, set the cot on the ground.
After the loading-end legs unfold, test that they have locked by
pushing them against the bumper — the legs should not fold. If
they do, lift the cot high enough to allow both sets of legs to unfold
completely and lock.
Supporting the weight of the cot and body
requires greater strength from a short operator
than from a tall operator, because a short operator
must raise his or her arms higher in relation to the
shoulders.
ote:Use additional help as needed to lift the
weight of the cot and body (see Using Additional
Help, page 24).
2
1
2.3 Height and Strength Considerations
Clearance
2
1
Important
The weight of an extremely heavy body may
compress the vehicle shocks, lowering the
vehicle and requiring the operator and helpers
to lift the cot higher than normal in order to
allow the legs to lock.
WARNING
Untrained operators can cause injury or be
injured. Permit only trained personnel to
operate the cot.

7
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
3  ABOUT THE COT
3.1 Description
The Ferno®Models 24-MAXX®Cot, 24-miniMAXX®Cot,
and 24H-miniMAXX®Cot are mortuary-service products
designed for body transport.
In this manual, the term “cot” refers to all three versions of
the cot. Use of all three versions is identical. The cots differ
only in width and loading height. Where width or loading
height is discussed, the model name of the cot is used.
The cot is for professional use by one or more trained
operators. The cot is designed for use with a Ferno®Model
5 Mortuary Cot Fastener (not included). Two 7-foot, 2-piece
restraints and a 1-inch-thick, locking mattress are included
with the cot.
About the Cot
3.2 Cot Options
The cot may be ordered from Ferno with the accessories
shown below factory-installed. The accessories are also
available separately. To order, see Accessories, page 28.
WARNING
Improper use of the cot can cause injury. Use the cot
only for the purpose described in this manual.
Sidearms Side Lift Handles
Load Limit
Inspect the cot if the load limit has
been exceeded (See Inspecting the
Cot, page 26).
COT FEATURES:
● 1,000 lb (454 kg) load capacity
● 7 transfer positions
● 6 in. (152 mm) Swivel transport wheels with wheel
locks (operator end)
● 6 in. (152 mm) Fixed transport wheels (loading end)
● 5 in. (127 mm) Loading wheels at loading end; loading
ramp at operator end
● Footrest
● Independent locking legs reduce the lifting required
for loading and unloading
● Legs can be locked at different heights at each end of
cot
● Bed Width:
○25 in./635 mm (24-MAXX)
○22in./559mm(24-miniMAXX,24H-miniMAXX)
● Loading Height:
○26 in./660 mm (24-MAXX, 24-miniMAXX)
○32 in./813 mm (24H-miniMAXX)
● Leg Color:
○Burgundy (24-MAXX)
○Gloss-black (24-miniMAXX, 24H-miniMAXX)
VEHICLE INFORMATION
If the vehicle has a bumper extension, the extension should
not exceed 14 in. (356 mm). The rear compartment should
have a level oor large enough for the folded cot, and a
Ferno®cot fastener installed.

8© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
About the Cot
3.3 Components
The components of the three cot models are identical. The cots differ only in their widths and loading height (see Specications,
page 9).
Restraints (Set of 2 Included)
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno Customer Relations, your
Ferno distributor, or visit www.ferno.com.
Mattress (Bottom Side Shown)
Anchor (4)
OPERATOREND SLIDES/GRIPS
Cots beginning with Serial Number 11N-183015 feature
operator-end loading ramps and posts (above, left) to ease
loading, unloading, and managing the cot on stairs. Cots
before this have only the loading posts (above, right).
Ramps and Posts Posts
Footrest
Loading
Wheel (2)
Fixed Transport
Wheel (2)
Loading Ramp
and Post (2)
Loading-end Leg
Control Handle (black)
Operator-End
Legs
Bumper Glide (2)
Swivel Transport Wheel
with Wheel Lock (2)
Loading-end
Leg Control
Handle (Black)
Operator-end Leg
Control Handle (Red)
Loading-End
Legs
LOADING END OPERATOR END

9
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
3.4 Specications
Mostgeneralspecicationsareroundedtothenearestwhole
number. Metric conversions are calculated before rounding
the Imperial measurements. For more information, contact
Ferno Customer Relations (page 2) or your Ferno distributor.
Ferno reserves the right to change specications without
notice.
Construction Tubular aluminum
Wheels
Diameter 6 in./152 mm
Width 1-¾ in./44 mm
Wheel Bearings Sealed/greaseless
Bed Surface Aluminum panel
Overall Height
Highest Position 40 in (1016 mm)
In Folded (Vehicle) Position 13-¾ in (349 mm)
Bed Height1
 Highestposition 33-⅝in(854mm)
Lowest transfer position 13 in (330 mm)
Folded (vehicle) position 9 in (229 mm)
Loading Height1
24H-miniMAXX 32 in (813 mm)
24-miniMAXX 26 in (660 mm)
24-MAXX 26 in (660 mm)
Length
Overall Frame Length 76 in (1930 mm)
Bed Surface Length 72 in (1835 mm)
Overall Folded Length 79-½ in (2019 mm)
Overall Cot Width
 24-miniMAXX 23-⅝in(600mm)
 24H-miniMAXX 23-⅝in(600mm)
24-MAXX 26 in (660 mm)
Bed Surface Width
24-miniMAXX 22 in (559 mm)
24H-miniMAXX 22 in (559 mm)
24-MAXX 25 in (635 mm)
Weight2
24-miniMAXX 76 lb (34 kg)
24H-miniMAXX 76 lb (34 kg)
24-MAXX 78 lb (35 kg)
Load Limit 1000 lb (454 kg)
ote:All Ferno®mattresses for the 24-MAXX and
24-miniMAXX series are heat-sealed.
1Height measurements are as follows: Bed Position is the distance
from the ground to the patient surface, measured at the center of
the bed surface. Loading Position is the distance from the ground
to the bottom of the loading wheel.
2Weight is without mattress, restraints and optional features.
About the Cot
3.5 Measurement Reference Points
Overall Folded Length
Loading Height
24H-miniMAXX
24-miniMAXX and 24-MAXX
Overall Frame Length
Bed Surface Length
Length Measurements
Bed Height
Height Measurements
Overall Height

10 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
About the Cot, Cot Setup
3.6 Cot Positions
Vehicle Position (Folded)
Legs
Transfer/Rolling Positions
Legs
7 Level Positions
4  COT SETUP
4.1 Setup
Before using the cot, set the position of the footrest. The
footrest is shipped in a folded position but should be
positioned upright for use.
1. Raise the footrest until it is upright and perpendicular
to the bed frame.
2. Use a #2 Phillips screwdriver to fully and evenly
tighten the two footrest screws (Figure 1).
3. Attach the mattress, restraints, and any accessories
before placing the cot in service. Follow installation
instructions in the restraint and accessory manuals,
and the restraint-placement information in this manual
(page 11 and page 12). Figure 1 - Securing the Footrest

11
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
5  USING THE FEATURES
Using the Features
5.1 Bed Panel Slots
Several slots and notches have formed into the cot bed
panel. They are designed for attaching the restraints and
accessories to the cot. Figure 2 shows a top-down view of
the cot bed panel and main frame.
● The four slots for the restraints are narrow and are
designed for only the restraints.
● The optional sidearms attach to the four large slots
nearest the ends of the cot.
● The optional side-lift handles attach to any of the six
large slots (Figure 2).
ote:The sidearm slots are large enough to allow sidearms
AND side-lift handles to be attached if desired. Cots before
serial number 07041779 have smaller slots that allow only
one accessory at these locations.
Figure 2 - Restraint and Accessory Slots
Restraint Slot
Restraint Slot
Restraint SlotRestraint Slot
Sidearm Mounts
Here if Used
Sidearm Mounts
Here if Used
Sidearm Mounts
Here if Used
Sidearm Mounts
Here if Used

12 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
Using the Features
5.2 Restraints
A set of two 7-foot, 2-piece restraints is supplied with the cot
(Figure 3). Always use both restraints to secure the body to
the cot. Attach and adjust restraints so they properly secure
the body without damaging it. Use additional restraints if
needed.
Keep restraints fastened when not in use to prevent them
from interfering with cot operation (Figure 4).
To attach, use, and maintain restraints, see the restraint
users’ manuals included with the restraints. Additional
free manuals are available from Ferno Customer Relations
(page 2).
The cot bed panel has four slots for use with the two
restraints provided (see Figure 2 on page 11).
Restraints may also be attached to any unused sidearm or
side lift handle slots. This allows for different strapping
congurationsorfortheuseofadditionalrestraints.Follow
your protocols to properly restrain the body on the cot.
Figure 3 - Restraints
Figure 4 - Restraints Attached and Fastened

13
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX® Using the Features
5.3 Control Handles
The cot has three control handles. Use the controls to unlock
the legs to raise or lower the cot, to load the cot into a
vehicle, or to unload the cot from a vehicle.
RAISING OR LOWERING THE COT
LOADIG ED: Use the (black) loading-end leg control
handle at the loading end of the cot (Figure 5) to raise or
lower the loading end of the cot.
ote:If you have a Model 24H-miniMAXX, remember there
is an extra position at the loading end. The loading position
is used only to load the cot into the vehicle. See the Loading
Height reference points on page 9.
OPERATOR ED: Use the (red) operator-end leg control
handle at the operator end of the cot (Figure 6) to raise or
lower the operator end of the cot.
TWO OPERATORS: Two operators can raise or lower
both ends of the cot simultaneously. See Changing Cot
Levels With Two Operators, page 17.
LOADING/UNLOADING THE COT
To load the cot into a vehicle, the operator uses both
operator-end control handles in sequence.
As the cot is pushed into the vehicle, the operator uses
rsttheblack,loading-endlegcontrolhandle(Figure6)to
unlock the loading-end legs. As the cot is pushed further
into the vehicle, the operator uses the red operator-end leg
control handle to unlock the operator-end legs. See Loading
the Cot, page 21.
When unloading the cot from a vehicle, the operators
uses only the red operator-end leg control handle. See
Unloading the Cot, page 22.
ote:Model 24H-miniMAXX users must raise the loading
end of the cot to the loading position before the cot can be
loaded into a vehicle. See the Loading Height reference
points on page 9.
Important
CONTROLHANDLE REMINDER
Both control handles for the loading-end legs are black.
The control handle for the operator-end legs is red.
Figure 6 - Operator-End Control Handles
Loading-end Leg Control
Handle (Black)
Used to Load Cot Only
Operator-end Leg Control
Handle (Red)
Figure 5 - Loading-end Leg Control Handle
Loading-end
Leg Control Handle (Black)

14 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
Using the Features
5.5 Wheel Locks
Theoperator-endswivelwheelsarettedwithwheellocks.
Use the wheel locks to help keep the cot stationary while
transferring a body onto or off from the cot.
Do not use the wheel locks as brakes.
Remain with the cot and maintain control of it at all times.
To engage a wheel lock, press down on the red lock lever
with your toe (Figure 8). To disengage, slide your toe under
the lock lever and left it up.
5.4 Mattress
The four hooks on the bottom of the mattress (Figure 7)
anchor the mattress to the cot and limit its movement during
body transfer.
Attach the mattress by laying it on the cot and feeding each
hook through a hole in the bed panel.
To remove the mattress, slide one hand under the mattress
and apply slight upward pressure while unfastening a hook
from the bed surface with your other hand. Repeat for the
remaining three hooks.
Figure 7 - Mattress (Bottom View)
Hook (4)
5.6 Sidearms (Optional)
If installed, the two sidearms provide additional security by
helping to keep the body from sliding on the cot. Keep the
sidearms raised except when transferring a body onto or off
from the cot.
Sidearms may be factory-installed, or are available as an
accessory. See Accessories, page 28.
To lower, pull the sidearm release pin (Figure 9) and lower
the sidearm. To raise, rotate the sidearm upward until the pin
locks in place.
Important
Sidearms are not designed for lifting. Grasp only the
main frame or (accessory) side lift handles to lift the cot.
Figure 8 - Engaging a Wheel Lock
Figure 9 - Pulling the Sidearm Release Pin

15
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
5.7 Side-Lift Handles (Optional)
The optional side-lift handles provide additional grasping
points for helpers to assist raising or lowering the cot,
loading the cot into a vehicle or unloading it from a vehicle.
The side-lift handles can also be used to help steer and
maneuver the cot.
Up to six side lift handles (three pairs) may be attached to
the cot. See Bed Panel Slots, page 11.
Each side-lift handle has three potential locking positions:
● Unfolded for use, perpendicular to the cot frame
(Figure 10)
● Folded for storage parallel with the cot frame (toward
the operator end or loading end of the cot, Figure 11)
USING THE SIDELIFT HANDLES
To unfold a side-lift handle for use: in a continuous
motion, pull the spring-loaded handle in line with the cot
frame to disengage the lock (Figure 11, Step 1), then swing
the handle perpendicular to the cot frame (Figure 11, Step
2). Release the handle to lock it in the unfolded position.
Using the Features
Be Aware
● The overall width of the cot increases when the
handles are unfolded for use. Fold the handles
when working in narrow areas.
● At the loading-end and operator ends of the cot,
interference with cot structures limits the handle
to only one storage position (see below).
Figure 10 - Using the Side Lift Handle
Figure 11 - Unfolding the Handle
1
2
To fold a handle for storage: in a continuous motion,
pull the spring-loaded handle outward to disengage the
lock (Figure 12, Step 1), then swing the handle right or left
(Figure 12, Step 2) until it is parallel with the cot frame and
locks in a storage position. Release the handle to lock it in
the folded position.
2
Figure 12 - Folding the Handle
1
2
2

16 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
6  USING THE COT
6.1 Before Placing the Cot in Service
● Personnel who will work with the cot need to read this
manual.
● Set up the cot. Attach the mattress, restraints and any
accessories.
● Conrm that the cot operates properly. Follow the
instructions in Inspecting the Cot, page 26.
● The vehicle must have a Ferno cot fastener installed.
6.2 General Guidelines for Use
● Follow standard mortuary-service procedures when
operating the cot.
● The cot can be operated and maneuvered by one
person, but operates and maneuvers more easily when
controlled by two operators.
● The operator or operators must maintain control
of the cot at all times.
● Lift only the weight you can safely handle. Use
additional help when a heavy body is on the cot.
For placement of help, see Using Additional Help,
page 24.
● Operator(s) and helpers must work together. Com-
municate with one another and operate the cot using
coordinated movements.
● Stay with the cot at all times.
● Always use restraints to secure the body on the cot.
● Read the cot fastener users’ manual for instructions on
using the fastener.
● When using a 24H-miniMAXX cot, do not roll the cot
in the loading position. This can cause the cot to tip,
causing operator injury or damage to the body. Use
only a rolling position to roll the cot.
Using the Cot
WARNING
Improper operation can cause injury. Operate the
cot only as described in this manual.
WARNING
An unrestrained body can fall of the cot. Use
restraints to secure the body on the cot.
WARNING
Rolling the 24H-miniMAXX in the loading position
can cause it to tip. Use a rolling position when
rolling the cot.
Read the Users’ Manual Cot May Be Operated
By One Trained Operator

17
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX® Using the Cot
6.3 Changing Cot Levels
With Two Operators
When raising or lowering the cot with two operators,
communicate with one another and use coordinated
movements to change the cot from one level to another.
Maintain control of the cot at all times.
1. Both Operators: Stand at opposite ends of the cot,
facing each other. Grasp the cot main frame using an
underhand grip (palms up).
2. Both Operators: Slightly lift the cot to ensure you are
holding the weight of the body and cot (Figure 13), then
squeeze the leg-control handle for your end of the cot
and begin raising or lowering the cot (Figure 14).
○Loading-End Operator: If the cot is empty or
has a light body, you may need to push downward
slightly to begin lowering the loading-end legs.
3. Both Operators: Raise or lower the cot until it nears
the desired height, then release the control handles and
continue raising or lowering the cot until both sets of
legs lock into place.
4. Both Operators: Lift the cot until all four transport
wheels come off the ground to ensure that both sets of
legs have locked at the new position, then set the cot
on the ground.
Important
Slightly lift your end of the cot before raising or
lowering it. This ensures that you have assumed the
weight of the cot before you squeeze a control handle.
Figure 13 - Lift the Cot Slightly
Before Squeezing the Control Handles
Loading-End
Operator
Operator-End Operator
Figure 14 - Work Together and
Use Coordinated Movements

18 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
6.4 Changing Cot Levels
With One Operator
To change cot levels with only one operator, raise or lower the
cot in stages, repeating until the cot is at the desired height.
Maintain control of the cot at all times.
Keep in mind that placing the cot at too great a tilt can cause
the body to slide off.
LOWERING THE COT WITH ONE OPERATOR
1. Begin at the loading end of the cot and grasp the main
frame using an underhand grip (palms up).
2. Slightly lift the end of the cot to assure you are holding
the weight of the cot and body, then squeeze the leg
control handle and lower the loading end of the cot
one or two positions (Figure 15).
ote:If the cot is empty or is carrying a light body, you
may need to push downward slightly to begin lowering the
loading-end legs.
3. Release the control handle and verify that the loading-
end legs have locked in the new position.
4. Move to the operator end of the cot and grasp the main
frame using an underhand grip.
5. Slightly lift the end of the cot to assume the load, then
squeeze the red operator-end leg control handle and
lower the operator end of the cot to a level position, or
one or two positions lower.
6. Release the control handle and verify that the operator-
end leg has locked in the new position.
7. Repeat Steps 1-6 as needed until the cot is level and at
the desired height.
Using the Cot
RAISING THE COT WITH ONE OPERATOR
1. Begin at the operator end of the cot and grasp the cot
main frame using an underhand grip (palms up).
2. Slightly lift the end of the cot to assure you are holding
the weight of the cot and body, then squeeze the red
operator-end leg control handle and raise the operator
end by one or two positions (Figure 16).
3. Release the handle and verify that the operator-end leg
has locked in the new position.
4. Move to the loading end of the cot and grasp the
main frame using an underhand grip (palms up).
5. Slightly lift the loading end of the cot to assume the
weight of the cot and body, then squeeze the control
handle and raise the loading end of the cot to a level
position, or one or two positions higher.
6. Release the control handle and verify that the loading-
end leg has locked in the new position.
7. Repeat Steps 1-6 as needed until the cot is level and at
the desired height.
Important
Placing the cot at too great a tilt can cause the body to
slide o. Raise or lower the cot only one or two levels
at a time.
Important
When only one operator is present, lower the loading
end of the cot rst, before lowering the operator end.
Important
Slightly lift your end of the cot before raising or
lowering it. This ensures that you have assumed the
weight of the cot before you squeeze a control handle.
Important
Always raise the operator end of the cot before raising
the loading end.
Figure 15 - Lower the Loading End First
Loading EndOperator End
Figure 16 - Raise the Operator End First
Loading End
Operator End

19
© Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX® Using the Cot
6.5 Rolling the Cot
GENERAL GUIDELINES
● Maintain control of the cot at all times.
● Rolling a Model 24H-miniMAXX cot
in the loading position can increase the
chance for the cot to tip. Use only a rolling
position to roll the cot.
● Roll the cot on smooth, unobstructed
surfaces whenever possible.
● To cross a low obstacle such as a door sill,
lift the cot slightly to take the weight off
the wheels so the wheels roll smoothly
over the obstacle.
● Two or more operators/helpers lift and
carry the cot over a high obstacle such
as a curb. Do not apply downward force
on one end of the cot in order to raise the
other end of the cot.
● Use help as needed to safely control
the weight of the body and cot (Using
Additional Help, page 24).
● When rolling over rough terrain, two
operators are suggested. Operator(s) and
helpers should grasp the cot with both
hands. Figure 17 - Rolling the Cot
Loading End
Operator End
WARNING
Rolling the 24H-miniMAXX in the loading position can cause it
to tip. Use a rolling position when rolling the cot.
ROLLING THE COT
1. Verify that the restraints are securely fastened around
the body.
2. Raise the cot to its highest level position.
Model 24H-miniMAXX: Do not use the loading
position to roll the cot. Use a level position.
3. Grasp the main frame at the operator end of the cot and
push and steer the cot (Figure 17).
If two or more operators or helpers are present, position
helpers in pairs to maintain cot balance and control.
See Using Additional Help, page 24 for recommended
placement of operators and helpers.
ote:Although the swivel wheels are only at the operator
end, steering may be easier from the loading end under
certain circumstances. Follow your mortuary protocols.

20 © Ferno-Washington, Inc 234-3307-04 May 2011
24•MAXX®, 24•miniMAXX®, 24H•miniMAXX®
6.6 Transferring the Body
Onto the Cot
1. Roll the cot as close to the body as possible.
2. Raise or lower the cot so it is level with the body.
3. Unfasten the restraints.
4. Place the body in a body pouch or use an accessory
such as a transfer board to ease transferring the body
onto the cot. For a list of accessories, see page 28.
ote:Ferno recommends that you position the body with
the head at the operator end of the cot, if possible. This
orientation will place the body in a ‘heads-up’ position if
you need to tilt the cot in a conned area (see “Maneuvering
theCotinaConnedArea,” below).
5. Fasten the restraints. Cover the body with a body
cover if desired.
6. Raise the cot to the highest rolling position before
rolling.
6.7 Maneuvering the Cot
In a Conned Area
The cot can be rolled in a tilted position for easier
maneuveringinconned spaces such asnarrowhallways,
elevators, or stairways.
Maintain control of the cot at all times.
To roll the cot in a tilted position:
1. Fasten and adjust the restraints to secure the body on
the cot. Use additional restraints if necessary (follow
your mortuary protocols).
2. Lower the cot to the lowest transfer position (Figure 18).
3. Stand at the operator end of the cot, grasp the main
frame, and lift the cot onto its loading wheels and front
transport wheels (Figure 19 and Figure 20). Roll the
cot in this position.
4. Use additional help as needed to help lift, hold, and
push the cot (see Using Additional Help, page 24).
Using the Cot
Figure 18 - Cot in Lowest Transfer Position
Figure 19 - Rolling Using the Loading Wheels and
Front Transport Wheels
Figure 20 - Rolling in a Tilted Position
