Ferno COMPACT 1 CARRY CHAIR User manual

Users’ Manual
FERNO/MAN/10/18/104-R04/UK
Stock Code 2003-0006
Read this Manual and Retain for Future Reference
COMPACT CARRY
CHAIR
MODELS INCLUDE:
COMPACT 1 CARRY CHAIR
COMPACT 1-S CARRY CHAIR
COMPACT 1-S CARRY CHAIR
(with Height Adjustable Handle)
COMPACT 2 CARRY CHAIR
Compact 2 Carry Chair
Compact 1-S Carry Chair
Compact 1 Carry Chair

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
2
© Copyright Ferno UK. All Rights Reserved.
The Serial Number identication labels are displayed in
dierent locations dependant of the model of your chair.
The serial number can be located on either if the bars as
displayed above.
Chair Serial Number: ______________________________
USERS’ MANUAL
To request additional free users’ manuals,
contact Ferno UK Customer Service, your
Ferno distributor, or visit www.ferno.co.uk.
Disclaimer
This manual contains general instructions for the use, operation
and care of this product. The instructions are not all-inclusive.
Safe and proper use of this product is solely at the discretion of
the user. Safety information is included as a service to the user.
All other safety measures taken by the user should be within and
under consideration of applicable regulations. It is recommended
that training on the proper use of this product be provided before
using this product in service.
Retain this manual for future reference. Include it with the product
in the event of transfer to new users. Additional free copies are
available upon request from Ferno Customer Service.
Proprietary Notice
The information disclosed in this manual is the property of Ferno
UK. Ferno UK reserves all patent rights, proprietary design rights,
manufacturing rights, reproduction use rights, and sales use
rights thereto, and to any article disclosed therein except to the
extent those rights are expressly granted to others or where not
applicable to supplier proprietary parts.
Limited Warranty Statement
The products sold by Ferno UK are covered by a limited warranty.
The complete terms and conditions of the limited warranty, and
the limitations of liability and disclaimers, are also available upon
request by calling Ferno UK on [phone].
Ferno Technical Support
Customer Service and product support are important
aspects of each Ferno product. Please have the product serial
number available when calling, and include it in all written
communications. For technical support questions:
Service Telephone [phone]
Service Fax [phone]
Email [e-mail]
Ferno Customer Service
For ordering assistance or general information:
FERNO UK
Telephone [phone]
Fax [phone]
Internet www.ferno.co.uk
USA HEADQUARTERS
Ferno-Washington, Inc.
70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone [phone]
Fax [phone]
Internet www.ferno.com

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK 3
TABLE OF CONTENTS
Ferno Contact information_____________________ 2
1 - Safety Information __________________________ 4
1.1 Warning _______________________________ 4
1.2 Important ______________________________ 4
1.3 Caution ________________________________ 4
1.4 Essential Requirements ___________________ 4
1.5 Safety and Instruction Labels_______________ 4
1.6 Symbol Glossary _________________________ 4
2 - Operator Skills and Training __________________ 5
2.1 Intended Use ___________________________ 5
2.2 Skills __________________________________ 5
2.3 Operator Training ________________________ 5
2.4 Safety Precautions _______________________ 5
3 - About the Chair _____________________________ 6
3.1 General Specications ____________________ 6
3.2 Checking the Chair_______________________ 6
4 - Operational Features ________________________ 7
4.1 Unfolding the Chair ______________________ 7
4.2 Restraints ______________________________ 7
4.3 Folding Foot rest ________________________ 7
4.4 Three Position Upper Handle_______________ 8
4.5 Removable Head rest _____________________ 8
4.6 Accessories _____________________________ 8
5 - Operating Procedure______________________ 9
5.1 General Principles________________________ 9
5.2 Placing the Patient _______________________ 9
5.3 Securing the Patient______________________ 9
5.4 Rolling the Patient and Chair _______________ 9
5.5 Carrying the Patient and Chair______________ 9
6 - Care of the Compact Chair ___________________ 10
6.1 General ________________________________10
6.2 Maintenance Schedule____________________10
6.3 Cleaning of the Chair _____________________10
6.4 Disinfecting the Chair_____________________10
7 - Service, Support and Warranty _______________ 11
7.1 UK Service Support ______________________11
7.2 Worldwide _____________________________11
7.3 Terms and Conditions ____________________11
7.4 Warranty and Service _____________________11
7.5 Service Maintenance History _______________11
Section Page

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
4
Safety Information
1  SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation which,
if not avoided, could result in injury or death.
WARNING
Improper use of the chair can cause injury. Use the chair
only for the purpose described in this manual.
Untrained operators can cause injury or be injured. Permit
only trained personnel to operate the chair.
Improper operation can cause injury. Operate the chair
only as described in this manual.
An unattended patient can be injured. Stay with the
patient at all times.
An unrestrained patient can fall o the chair and be
injured. Use restraints to secure the patient on the chair.
Helpers can cause injury or be injured. Maintain control of
the chair, whilst directing all helpers.
Improper maintenance can cause injury. Maintain the
chair only as described in this manual.
Non Ferno parts and service can cause injury. Use only
Ferno parts and Ferno approved service on the chair.
Modifying the chair can cause injury and damage. Use the
chair only as designed by Ferno.
Attaching Non Ferno items to the chair can cause injury.
Use only Ferno approved items on the chair.
1.5 Safety and Instruction Labels
Safety and instruction labels place important information from
the users’manual on the Chair.
Read and follow label instructions. Replace worn or damaged
labels immediately. Replacement labels are available from Ferno
UK.
1.6 Symbol Glossary
The symbols dened to the right are used on the Chair and/
or in this users’ manual. Ferno uses symbols recognised by the
International Standards Organisation (ISO).
Safe Working Load
Do Not
Lubricate
440 lb
200 kg
32.5 st
WARNING
It is recommended NOT to carry occupant with the
rear handle FULLY EXTENDED. (applies to Compact
1-S with height adjustable backrest only)
The upper handle is to be used for descending
stairs only at the maximum extended position.
WARNING
Do NOT exceed the safe working load of 200 kg
1.4 Essential Requirements
Every three months lubricate the hinge pins with light oil paying
particular attention to the cross section pins.
The CE mark on this product demonstrates conformity with the
requirements of the EC Directive 93/42/EEC for Medical Devices
and support by an ISO 9001 Quality Management System.
1.3 Caution
Bleach, phenols and iodine can cause damage. Do not apply
products containing these chemicals to the Chair.
Improper lubricants can cause damage. Use a liquid lubricant oil
such as " 3-IN-ONE Multi-purpose drip oil" to lubricate the Chair
where specied.
Trapping hazards are unavoidable in the design of this equipment
due to its folding action. Operate the folding mechanism with
care.
Trapping hazards are unavoidable in this design of chair due to
its folding action, operate the folding mechanism with care.
1.2 Important
Blood borne Disease Notice
To reduce the risk of exposure to blood borne diseases such as
HIV-1 and hepatitis when using the chair, follow the disinfecting
and cleaning instructions in this manual.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK 5
Operator Skills and Training
2  OPERATOR SKILLS AND TRAINING
2.2 Skills
Minimum recommended skills are as follows:
● The strength, balance, coordination and common
sense to safely operate the Chair.
● The ability to select the proper equipment and
procedures for the circumstances.
● Operators should have operator certication (or
equivalent).
● The ability to understand and follow the procedures
described in this manual.
WARNING
Untrained operators can cause injury or be
injured. Permit only trained personnel to operate
the Chair.
Only qualied personnel trained in the use of the
Carrying Chair should use it.
For safety purposes, it is essential that patients
should always be secured with restraints.
Never leave a patient unattended.
Never exceed the maximum load capacity of
200 kg.
Establish regular inspection procedures and
responsibilities to ensure proper maintenance as
described.
2.3 Operator Training
Minimum recommended skills are as follows:
● A training plan approved by an EMS training ocer (or
equivalent).
● Read and understand the instructions in this manual.
● Practice using the fully equipped Chair with weight and
under simulated conditions.
● Trainees should be tested to verify their understanding of
Chair Operation.
● Keep training records. Annual refresher training for all Chair
operators is recommended.
2.1 Intended Use
The Ferno Compact 1, Compact 1-S and Compact 2 Carrying Chairs are designed to aid the movement of a patient in a seated position by
carrying. They should be used in circumstances where transfer devices such as trolleys or stretchers cannot be manoeuvred.
2.4 Safety Precautions
To ensure safety and satisfaction with your new Carrying Chair, all users should read these instructions and the individual portions of
recognised emergency care manuals that relate to the application and use of Carrying Chairs.
WARNING
Improper use can cause injury and damage. Use
only Ferno-approved parts and service.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
6
About the Chair
3  ABOUT THE CHAIR
WARNING
Improper use of the Chair can cause injury. Use the
Chair only for the purpose described in this manual.
3.1 General Specications
Most general specications below are rounded to the nearest
whole number. For more information, contact Ferno Customer
Service (page 2).
Ferno reserves the right to change specications without notice.
All dimensions are approximate
Operators must consider the weight of the patient and accessories
when determining total load on the Chair
Safe Working Load:
Product Dimensions Imperial Metric
Compact 1 Height
Open 76.7 in 935 mm
Folded 66.1 in 765 mm
Width
Overall 22.4 in 435 mm
Depth
Open 34.7 in 430 mm
Folded 9.25 in 235 mm
Weight
Total Weight 9.1kg
Compact 1-S Height
Open 76.7 in 935 mm
Folded 30.5 in 775 mm
Width
Overall 17.5 in 445 mm
Depth
Open 16.5 in 420 mm
Folded 11.2 in 285 mm
Weight
Total Weight 9.7 kg
Compact 2 Height
Open 76.7 in 935 mm
Folded 30.5 in 775 mm
Width
Overall 17.5 in 445 mm
Depth
Open 16.5 in 420 mm
Folded 11.2 in 285 mm
Weight
Total Weight 9.7 kg
Construction Material
Stainless Steel
440 lb
200 kg
32.5 st
3.2 Checking the Chair
The following checks are required each day before the use of the
Carrying Chair:
1. Overall cleanliness of the Carrying Chair.
2. Check that there are no bent or damaged parts,
missing fasteners, etc.
3. Check that the wheels rotate freely with no excess
movement or damage.
4. Check that the Carrying Chair unfolds and locks
securely in the seating position for normal use.
5. Check the upholstery for cracks, splits or any loose
fabric or stitching, etc.
6. Check that the upholstery is correctly secured to
the frame.
If in any doubt then contact a Service Engineer.
NOTE
Regular cleaning helps reduce the risk of transmitting disease
and enables the equipment to function at its optimum.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK 7
Operational Features
4  OPERATIONAL FEATURES
4.1 Unfolding and folding the Chair
The Chair folds for shipping and stowage.
To unfold the chair;
Unfold by placing the Chair on the ground. With your foot on the Chair’s foot-bar, lift the back up and rearward. Completely unfold by
rmly pushing up the back until an audible click is heard.
2. Once the chair is locked, move both of the Safety Rings down
over the hinge bracket.
1. Unbuckle the chest strap securing the chair and fold the chair
out into the seated position
To Fold;
1. To fold the Chair, lift the Safety Rings up over each hinge bracket.
2. Pull the release catch in the centre and fold the Chair forwards.
3. The Restraints may be used to secure the Chair in the folded position.
4.2 Restraints
The Chair is equipped with two restraints for patient comfort. When using the Chair, the patient must be secured by the restraints. Assess
patient condition to determine optimum strapping procedure.
4.3 Folding foot rest (Compact 1-S only)
The Compact 1-S has a folding footrest for convenience when a
seated patient transfers to a standing position.
To fold the footrest, pull to release both plungers and twist to
retain plungers in retracted position. Lift the footrest into the
folded position.
To unfold the footrest, pull forwards and downwards and twist
both plungers to release.
Ensure both sides are locked.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
8
Operational Features
4.5 Removable Head Pad (Compact 1-S with Height Adjustable Backrest only)
The head pad can be attached to the chair when the upper handle is in the second or third position. The pad is designed to optimise patient
comfort.
The head pad can be attached, using Velcro aps, to the upper handle. Position pad with Velcro facing the rear of the chair then fold aps
back onto themselves around the metal frame.
The upper handle can be locked into one of three positions to allow for height variations of operator and patient.
The removable head pad can only be attached when the upper handle is in its second or third position.
To adjust the upper handle into the second or third position, pull the black release knob on the right hand side with right hand. Maintain
grip while adjusting upper handle upwards with left hand. Release knob while still adjusting handle upwards until knob engages into
required position.
To return the upper handle to the rst position, remove head pad if axed. Pull black release knob with right hand, maintaining grip, while
lowering upper handle with left hand. Release knob and adjust handle until knob engages in its rst position.
4  OPERATIONAL FEATURES
4.4 Three position upper handle (Compact 1-S with Height Adjustable Backrest only)
4.6 Accessories
The Oxy-Clip
The Oxy Clip (Cylinder Holder) clips onto the front bar under the
seat of the Chair.
Blankets
Blankets may be used with the Chair to enhance patient comfort,
ensure they are kept clear of any moving parts.
Wall Bracket
The wall bracket is designed to hold the Compact 1,2 or 3 Carry
Chair. This allows the chair to be stored safely ready for use.
Dust Cover
The dust cover is designed to be used with the Compact 1,2 and
3 Carry Chairs whilst situated on the wall bracket.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK 9
Operational Procedure
5  OPERATING PROCEDURE
WARNING
Never leave the Chair unsupported with a patient
on-board as the chair is designed to tilt back easily.
5.1 - General Principles
When moving patients, always inform them of what you are going to do.
Always follow good lifting procedures as specied in the current manual handling regulations and your appropriate training manual.
Medical advice is beyond the parameters of this manual. It is the user’s responsibility to ensure safe practices for the patient and themselves.
Placement techniques, heavy patients, rough terrain or unusual circumstances may require more attendants.
Operators must take extra care precautions when operating the chair on uneven ground.
Extra precautions should be taken to prevent the chair from slipping in adverse, wet or icy weather conditions.
Stay with the patient at all times and always use the patient restraints provided.
5.2 - Placing the Patient
Use a recognised patient handling technique to place the patient
on the Chair.
5.3 - Securing the Patient
After placement on the Chair, the patient should be secured to the
Chair with the leg and chest restraints.
WARNING
In cases of cervical, spinal or some fracture
injuries, use of the Chair for patient transfer is not
recommended.
5.4 - Rolling the Patient and Chair
After placing the patient on the Chair and fastening the restraints,
the attendants move to positions at the front and rear of the Chair.
For the Compact and the Compact 2 carry chairs, the rear
attendant grasps the Chair frame, then tilts the patient/chair back
until the weight is balanced on the Chair wheels. The Chair can
then be rolled without lifting.
The Compact 1-S has two wheels axed to the foot end frame.
These assist with movement on level ground and mean that the
chair can be used without tilting backwards. The operator at the
foot end of the chair assists as required with obstacles like door
frames or uneven surfaces. The lower handle can be used to
overcome larger obstacles.
5.4 - Carrying the Patient and Chair
To carry the patient, the same “tilt/back and balance”procedure is
used. The attendants grasp the front and rear carrying handles and
lift simultaneously, using local recommended lifting guidelines .
WARNING
Before positioning the patient on the chair, always
ensure the chair is fully unfolded and that the safety
rings are up and over each hinge bracket.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
10
Maintenance
6.1 General
The Ferno Compact 1-S and Compact 2 Carrying Chair require
scheduled maintenance to keep them working safely. Set up and
follow a maintenance schedule.
When setting up your maintenance schedule, consider how the
Chair will be used.
Will the Chair be exposed to extreme temperatures, or to salt,
sand, mud, dust, etc.?
Will the Chair be heavily used?
Follow the maintenance schedule below as a minimum.
INSPECTION CHECKLIST
● Are all components present?
● Is the Chair free of excessive wear?
● Are all screws, nuts, bolts, rivets, and roll pins
securely in place?
● Do all moving parts operate smoothly and
properly?
● Does the Chair lock properly into position?
● Are the safety rings present and intact?
● Does the Chair roll smoothly?
● Do the wheels have adequate tread?
● Are the restraints properly installed?
● Is restraint in good condition with no cuts or
frayed edges?
● Are restraint buckles free of visible damage
and do they operate properly?
6  CARE OF THE COMPACT CHAIR
WARNING
Improper maintenance can cause injury and
unpredictable operation. Maintain the
Chair only as described in this manual.
6.2 Maintenance Schedule
When using a maintenance product, follow the manufacturer’s
directions and read the manufacturer’s material safety data sheet.
Contact Ferno (UK) Ltd to order Ferno cleaners and disinfectants.
Keep Service and Maintenance records.
Use the convenient form at the back of this manual.
ESSENTIAL REQUIREMENTS
Every three months lubricate the hinge pins with light oil paying
particular attention to the cross section pins.
6.3 Cleaning the Chair
Remove the restraints and place them in a mesh laundry bag.
Machine wash them in cold water using the delicate cycle and a
mild laundry detergent. Allow them to air dry.
Clean all other surfaces of the Chair with warm water and a mild
detergent. (Use a brush if necessary).
Rinse it with warm water. Towel dry the Chair or allow it to air dry.
Wash the Chair by using a sponge and mild detergent soap mixed
in warm water. For particularly grimy cases, especially if the chair
has been in storage for a long period, it may be necessary to rst
wash the Chair with a solvent soaked cloth prior to using soap
and water.
Once cleaned, dry the Chair with a soft towel paying particular
attention to swivel and sliding joints.
NOTE
Do not use high pressure water or steam to clean the Chair,
these methods remove lubricants.
6.4 Disinfecting the Chair
Wipe all surfaces of the Chair and restraints with disinfectant (see
Page 3, Blood borne Disease Notice).
Follow the manufacturer’s directions. As you wipe down the
Chair, check it for damage and wear.
WARNING
High concentrations of bleach, phenols and iodine
can cause damage.
Contact Ferno (UK) Ltd before use.
Normal levels of disinfecting uids are acceptable.

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK 11
Parts and Service
7  SERVICE, SUPPORT AND WARRANTY
7.1 UK Service Support
In the United Kingdom, to order parts or for professional Chair
repair, contact Ferno UK. - the only agent authorised by Ferno to
manage, service, and repair Ferno products.
Telephone [phone]
Service [phone]
Service Fax [phone]
Email [email protected].uk
Internet www.ferno.co.uk
7.2 Worldwide
To order Ferno parts, and for professional Chair repair, contact your
Ferno distributor. Your distributor is the only agent authorised by
Ferno to manage, service, and repair Ferno products.
WARNING
Improper parts and service can cause injury. Use only
Ferno parts and Ferno-approved service on the Chair.
7.3 Terms and Conditions
Standard terms and conditions apply to all sales. A copy is available upon request. These contain full details of warrant terms and do not
limit the statutory rights of the customer.
7.5 Service Maintenance History
7.4 Warranty and Service
Ferno's standard terms and conditions apply to all sales. A copy is available upon request.
These contain full details of warrant terms and do not limit the statutory rights of the customer.
For service, maintenance and any questions regarding this, or any other Ferno product, please contact our Service Team
on [phone]
Date Serviced By Remarks

© Ferno (UK) Ltd. - FERNO/MAN/10/18/104-R04/UK
12
