FIBARO FGFS-101 User manual

OPERATING
MANUAL
FIBARO FLOOD SENSOR
FGFS-101
CONTENTS
#1: Description and features 4
#2: Basic activation 5
#3: Adding/removing the device 6
#4: Diagrams and connection 7
#5: Powering modes 9
#6: Operating the device 10
#7: Association 12
#8: Z-Wave range test 13
#9: Advanced parameters 14
#10: Specications 19
#11: Guarantee 20
ENG
v1.0

3
Important safety information
Read this manual before attempting to install the device!
Failure to observe recommendations included in this manual
may be dangerous or cause a violation of the law. The manufacturer,
Fibar Group S.A. will not be held responsible for any loss or damage
resulting from not following the instructions of operating manual.
!
General information about
the FIBARO System
FIBARO is a wireless smart home automation system, based on the
Z-Wave protocol. All of available devices can be controlled through
a computer (PC or Mac), smartphone or tablet. Devices are not only
receivers, but can also repeat the signal, increasing the Z-Wave
network’s range. It gives advantage over traditional wireless systems
that require direct link between transmitter and receiver, as a result the
construction of the building could aect network’s range negatively.
Every FIBARO network has its unique identication number (home
ID). Multiple independent networks can exist in the building without
interfering. Transmission security of FIBARO System is comparable to
wired systems.
Z-Wave technology is the leading solution in smart home automation.
There is a wide range of Z-Wave devices that are mutually
compatible, independently of manufacturer. It gives the system the
ability to evolve and expand over time. For more information visit:
www.baro.com.

4
DESCRIPTION AND FEATURES
Main features of FIBARO Flood Sensor:
• Compatible with any Z-Wave or Z-Wave+ Controller
• Supports protected mode (Z-Wave network security mode) with
AES-128 encryption
• May be connected to any alarm system (potential free output
terminal)
• Extremely easy installation - simply put on a surface prone to ooding
• May be installed anywhere - ood sensor’s contacts extended
with a wire
• Battery or VDC powered. When connected to an external, VDC power
source, the battery serves as an emergency power source
• Theft protection - tilt is reported to the Z-Wave network or alarm
system’s main controller
• Two operating modes - ood/temperature sensor or just a
temperature sensor.
• Alarm is signalled by sound, visual indicator (LED diode) and Z-Wave
FIBARO Flood Sensor is a universal, Z-Wave compatible, ood and
temperature sensor. Device can be battery or VDC powered. Flood
alarm is sent to the Z-Wave network devices or additionally to any
alarm system controller, through opening a NC contact.
The device has built in temperature sensor, monitoring temperature
of e.g. oor. Flood Sensor is designed to be placed on the oor or on
a wall with a ood sensor probe extended by connected wire. The
device has built in visual LED indicator and acoustic alarm. LED diode
signals ood, operating mode or the Z-Wave network communication
range.
In addition, the sensor is equipped with a tilt sensor reporting tilt or
movement to the main controller e.g. when someone has taken the
Sensor from its original location.
FIBARO Flood Sensor is sink-proof, which means it drifts on the water
surface and keeps on sending alarm signal in case of substantial
inundation of water.
#1: Description and features
FIBARO Flood Sensor is a fully
compatible Z-Wave PLUS device.
NOTE
This device may be
used with all devices
certied with Z-Wave
certicate and should
be compatible with
such devices pro-
duced by other manu-
facturers.
i
NOTE
FIBARO Flood Sensor
is a Security Enabled
Z-Wave Plus product
and a Security Ena-
bled Z-Wave Control-
ler must be used in or-
der to fully utilize the
product.
i

5
BASIC ACTIVATION
#2: Basic activation
1. Turn the cover counter-clockwise and open it
2. Remove the battery blocker
3. Flood Sensor will conrm being powered with a short beep
4. Add the device (see “Adding/removing the device” on page 6)
5. Close the cover and turn it clockwise
6. Place the sensor onto a surface prone to ooding. Three elec-
trodes underneath the device should evenly touch the surface.
Beep!
NOTE
After completing
installation it is rec-
ommended to test
sensor’s operation
by placing the entire
sensor or its probes’
extension wire onto
water surface.
i
NOTE
When changing the
Sensor’s location, it’s
recommended to
wake up the device
and recongure the
Z-Wave network by
triple clicking the TMP
button.
i

6
ADDING/REMOVING THE DEVICE
#3: Adding/removing the device
Adding (Inclusion) - Z-Wave device learning mode, allowing to add
the device to existing Z-Wave network.
To add the device to the Z-Wave network:
1. Open the cover
2. Place the Flood Sensor within the direct range of your Z-Wave
controller
3. Set the main controller in (security/non-security) add mode (see
the controller’s manual)
4. Quickly, three times press the TMP button
5. Wait for the adding process to end
6. Successful adding will be conrmed by the Z-Wave controller’s
message
Removing (Exclusion) - Z-Wave device learning mode, allowing to
remove the device from existing Z-Wave network.
To remove the device to the Z-Wave network:
1. Open the cover
2. Place the Flood Sensor within the direct range of your Z-Wave
controller
3. Set the main controller in remove mode (see the controller’s
manual)
4. Quickly, three times press the TMP button
5. Wait for the removing process to end
6. Successful removing will be conrmed by the Z-Wave controller’s
message
TMP
button
TMP
button
NOTE
Adding in security
mode must be per-
formed up to 2 meters
from the controller.
i
NOTE
Removing FloodSensor
from the Z-Wave net-
work restores all the
default parameters of
the device.
i
NOTE
In case the Sensor is
not added, please re-
set the Sensor and re-
peat the adding pro-
cedure.
i

7
DIAGRAMS AND CONNECTION
Connecting the FIBARO Flood Sensor in a manner
inconsistent with manual may cause risk to health, life or
material damage.
!
Notes for the diagrams and probes marking:
+12V - 12 / 24 VDC positive terminal
GND - negative (ground) terminal
ALARM NC - potential-free ood sensor terminals (for wired systems)
TAMP NC - potential-free tamper terminals (for wired systems)
SENS1, SENS2 - ood sensor electrodes’ terminals
TMP - tamper button (used to add/remove the device)
ALARM
NC
TAMP
NC
SENS 1 SENS 2 + 12 GND
TMP
#4: Diagrams and connection
1 2
3
12/24 VDC
ADAPTER
ALARM
NC
TAMP
NC
SENS 1 SENS 2 + 12 GND
+
-
TMP
Connection to a constant power source:
CAUTION
Connect while observ-
ing wiring diagram
shown in this manual
only. Incorrect wiring
may be dangerous or
result in the device
breakdown.
!
NOTE
The TMP button has
two functions:
1. Adding / Removing
the device to / from
the Z-Wave network,
2. Tamper contact
for 4th Association
Group. When a sen-
sor is added to the
Z-Wave network, cov-
er open alarm may be
activated (according
to parameter 74 set-
tings).
i

8
DIAGRAMS AND CONNECTION
TAMP
NC
SENS 1
SENS 2
Extending Flood Sensor contacts with a wired probe:
AUX COM Z1 Z2
ALARM
SYSTEM HUB
ALARM
NC
TAMP
NC
SENS 1 SENS 2 + 12 GND
TMP
Connection with a wired alarm system:
NOTE
Mounting screws
shown in a diagram
are not included in
the package. Choose
a screw type depend-
ing on the building
material it is being at-
tached to.
i
CAUTION
Contacts SENS1 and
SENS2 are dedicat-
ed to ood detection
only. Do not connect
external voltage!
!
NOTE
The Sensor detects
resistance between
electrodes 1 and 3, 1
and 2 and electrodes
connected to contacts
(SENS1 and SENS2).
i
NOTE
ALARM NC and TAMP
NC connectors may
be used as end-of-line
protective loop’s ter-
minals.
i

9
POWERING MODES
#5: Powering modes
There are two powering modes for the FIBARO Flood Sensor. By de-
fault it is powered by a factory included battery. In addition it can
work with a constant voltage, after connecting a 12/24 VDC power
supply to +12 and GND terminals (see„Diagrams and connection” on
page 7).
Powering mode conguration is carried out automatically, while a
sensor is being added into the Z-Wave network.
When battery powered, a FIBARO Flood Sensor communicates with
a Z-Wave network main controller periodically. Detected alarms are
sent immediately, but conguration parameters and associations set-
tings only at specied wake up intervals, or at a manual wake up (TMP
button click).
In DC powering mode, conguration and associations parameters are
sent when necessary, and in addition a sensor serves as a Z-Wave sig-
nal repeater.
Switching to a constant voltage powering mode:
1. Remove the sensor from the Z-Wave network
2. Connect constant voltage power source (12/24 VDC) to +12 and
GND terminals in accordance with „Diagrams and connection” on
page 7
3. Add the FIBARO Flood Sensor to the Z-Wave network
In constant powering mode a sensor may operate without a bat-
tery. Installing a battery is recommended though, as it will serve as
an emergency power source. When constant power fails, sensor will
automatically shift to an backup power mode. All reports, including
ood and temperature, will be sent immediately, but it will not be
possible to modify the conguration or association settings until con-
stant power returns. If a sensor served as a signal repeater for other
Z-Wave devices, in emergency mode signal repeating function will be
deactivated.
FIBARO Flood Sensor’s battery life is ca. 2 years at factory default
settings. The current battery level is displayed in a Z-Wave control-
ler interface. Red battery icon means a battery needs replacement. In
order to avoid triggering tamper alarm while replacing the battery,
4th association group’s associations must be deleted, and Sensor’s
parameters’ conguration set to default.
NOTE
FIBARO Flood Sen-
sor will automatically
exit emergency mode
once 12/24 VDC at
+12 and GND termi-
nals is detected
i
CAUTION
Using batteries other
than specied may
result in explosion.
Dispose of properly,
observing environ-
mental protection
rules.
!

10
OPERATING THE DEVICE
#6: Operating the device
Controlling the Flood Sensor using the TMP button:
FIBARO Flood Sensor is equipped with a TMP button, which allows to
use the MENU mode and additionally perform the following actions:
1x click: select the desired MENU option (if MENU mode is active)
3x click: send the Node Info Z-Wave command frame (adding/remov-
ing and wake up)
Holding: enter the MENU mode (conrmed by the visual indicator)
MENU mode & visual indications:
FIBARO Flood Sensor is equipped with a LED diode, signalling sensor’s
operating modes and alarms. In addition the visual indicator may in-
form of the Z-Wave network range and the current temperature.
Visual indicator signalling modes:
1. Flood alarm is signalled with alternating white and blue light.
2. In battery powering mode, with parameter no. 63 set to 1, visual
indicator will periodically show temperature readouts (depend-
ing on parameters 50, 51, 61 and 62 settings).
3. In constant powering mode, the current temperature readouts
will be continuously signalled with a colour depending on the pa-
rameters 50, 51, 61 and 62 settings.
4. Currently chosen MENU position is signalled with an illumination
colour.
Press and hold the TMP button for at least 3 seconds to enter MENU.
Inside MENU, each of the positions will be signalled with a LED colour.
WHITE - entering MENU conrmation
GREEN - cancel alarm for associated devices
VIOLET - Z-Wave network’s range test
YELLOW - sensor reset
Release the TMP button to choose the desired function and conrm
your choice with the TMP button click.
TMP
button
NOTE
By default, ood sen-
sor’s insensitivity is
set to 1 second, which
means ooding will
be reported one sec-
ond after it’s been de-
tected.
Tilt tamper is insensi-
tive to little vibrations
and turns. After its ac-
tivation, insensitivity
is turned o for 15 sec-
onds. After that, each
Sensor’s movement
will trigger audible
alarm, consisting of 3,
brief acoustic signals.
i
