16
ADVANCED PARAMETERS
„ON/OFF” ASSOCIATION GROUPS
21. UP value -„On/O (Power)” association group (3)
Upper power threshold, used in parameter 23. UP value cannot be
lower than a value specied in parameter 22.
Available settings: 100-18000 (10.0-1800.0W, step 0.1W)
Default setting: 500 (50W) Parameter size: 2[bytes]
22. DOWN value -„On/O (Power)” association group (3)
Lower power threshold, used in parameter 23. DOWN value cannot
be higher than a value specied in parameter 21.
Available settings: 0-17900 (0.0-1790.0W, step 0.1W)
Default setting: 300 (30W) Parameter size: 2[bytes]
23. Controlling „On/O (Power)” association group (3)
This parameter denes the way that 3rd association group devices
are controlled. Depends on the actual measured power (according to
parameters 21 and 22 settings).
Available settings:
1- send frame (with value set in parameter 26)
only if power exceeded value of parameter 21
2- send frame (with value set in parameter 27)
only if power dropped below value of parame-
ter 22
3- send frame in both cases
Default setting: 3Parameter size: 1[byte]
24. SWITCH ON value - „On/O (Button)” association group (2)
The value of BASIC SET command frame sent to the devices associat-
ed in 2nd group„On/O (Button)” when turning the device ON using
the button.
Available settings: 0-99 or 255
Default setting: 255 Parameter size: 2[bytes]
25. SWITCH OFF value - „On/O (Button)” association group (2)
The value of BASIC SET command frame sent to the devices associat-
ed in 2nd group„On/O (Button)” when turning the device OFF using
the button.
Available settings: 0-99 or 255
Default setting: 0Parameter size: 2[bytes]
NOTE
Setting parameters
24, 25, 26, 27 to appro-
priate value will result
in:
0 - turning o associ-
ated devices
1-99 - forcing level of
associated devices
255 - setting associat-
ed devices to the last
remembered state or
turning them on
i
