Fimap MINNY 20 User guide

USE AND MAINTENANCE
MINNY 20 – 20 CB
ED. 10-2007 EN
Doc. 10006510

The contained descriptions in the present publication are not binding. The company
therefore reserves itself the right to bring in whatever moment possible organs changes,
details or supplies of accessories, that it holds convenient for an improvement, or for any
demand of constructive or commercial character.
The partial reproduction of the texts and diagrammes contained in the present catalog, is
forbidden by law.
The company reserves itself the right to bring changes of technical character and/or of
endowment. The images are meant of pure reference and not binding in terms of design
and endowment.
Symbols used in the manual
Symbol of the book open with letter i
It points out that this document is a manual of instructions.
Symbol of the open book
It points out to the operator to read the manual of use before using
the machine.
Symbol of warning
Read attentively the sections preceded by this symbol for the safety
of the operator and the machine.

3
.
TABLE OF CONTENTS
TABLE OF CONTENTS ...........................................................................................................................................................................................3
SYMBOLS USED ON THE MACHINE ......................................................................................................................................................................6
GENERAL SAFETY REGULATIONS.........................................................................................................................................................................7
PREPARING THE MACHINE...................................................................................................................................................................................8
1. HANDLING THE PACKAGED MACHINE..........................................................................................................................................................8
2. HOW TO UNPACK THE MACHINE..................................................................................................................................................................8
3. INSERTING THE BATTERIES IN THE MACHINE .............................................................................................................................................9
4. RICARICA BATTERIE .................................................................................................................................................................................10
5. CONNECTING THE BATTERY/SYSTEM CONNECTOR ...................................................................................................................................11
6. BATTERY CHARGE LEVEL GAUGE .............................................................................................................................................................11
7. INSTALLING THE SQUEEGEE .....................................................................................................................................................................11
8. ADJUSTING THE HEIGHT OF THE SQUEEGEE..............................................................................................................................................12
9. ADJUSTING THE COCK...............................................................................................................................................................................12
10. INSTALLING THE BRUSH..........................................................................................................................................................................13
11. SUCTION COWLING..................................................................................................................................................................................13
12. RECOVERY TANK.....................................................................................................................................................................................13
13. DETERGENT SOLUTION...........................................................................................................................................................................13
OPERATION ........................................................................................................................................................................................................14
1. PREPARING TO WORK ..............................................................................................................................................................................14
2. OVERFLOW DEVICE....................................................................................................................................................................................14
3. FORWARD MOVEMENT ..............................................................................................................................................................................14
AFTER WORK IS TERMINATED............................................................................................................................................................................15
DAILY MAINTENANCE.........................................................................................................................................................................................16
1. CLEANING THE RECOVERY TANK..............................................................................................................................................................16
2. CLEANING THE SUCTION FILTER...............................................................................................................................................................16
3. CLEANING THE SQUEEGEE........................................................................................................................................................................16
4. REPLACING THE REAR SQUEEGEE RUBBER...............................................................................................................................................17
5. REPLACING THE FRONT SQUEEGEE RUBBER............................................................................................................................................17
6. DISMANTLING THE BRUSH .......................................................................................................................................................................17
WEEKLY MAINTENANCE .....................................................................................................................................................................................18
1. CLEANING THE SQUEEGEE TUBE ...............................................................................................................................................................18
2. CLEANING THE SOLUTION TANK...............................................................................................................................................................18
CHECKING OPERATION.......................................................................................................................................................................................19
1. INSUFFICIENT WATER ON THE BRUSHES ...................................................................................................................................................19
2. THE MACHINE DOES NOT CLEAN WELL .....................................................................................................................................................19
3. THE SQUEEGEE DOES NOT DRY PERFECTLY..............................................................................................................................................19
4. TOO MUCH FOAM IS GENERATED ..............................................................................................................................................................19
BRUSH SELECTION AND USE .............................................................................................................................................................................20
WASTE DISPOSAL ..............................................................................................................................................................................................21
CE STATEMENT OF COMPLIANCE MODEL MINNY 20 CB ....................................................................................................................................22
CE STATEMENT OF COMPLIANCE MODEL MINNY 20..........................................................................................................................................23

4
Receiving the machine
Immediately check, when receiving the machine, that all the material
indicated on delivery documents has been received and also that the
machine has not been damaged in transit. If it has been damaged,
this damage must be immediately reported to the shipper and also to
our customer service department. Only acting promptly in this manner
will make it possible to receive missing material and to be
compensated for damage.
Foreword
This is a floor scrubbing machine that is able to clean any type of floor
by using the mechanical action of the rotating brush and the chemical
action of a water-detergent solution. As it moves forward it also
gathers up the dirt removed and the detergent solution that has not
been absorbed by the floor.
The machine must only be used for this function. Even the best
machines will only operate efficiently and work with profit if they are
used properly and kept in perfect operating order. Read this
instruction booklet carefully and consult it every time problems arise
with machine operation. Remember that, if necessary, our service
organization, in collaboration with our dealers, is always available for
helpful hints or direct intervention.
Identification plate

5
TECHNICAL DESCRIPTION U/M Minny 20 Minny 20 CB
Working width mm 500 500
Squeegee width mm 660 660
Working capacity, up to m2/h 1750 1750
Brush diameter mm 500 500
Brush revolutions RPM 140 140
Pressure on the brush Kg 25 25
Brush motor, supply voltage V 24 24
Brush motor, rated power W 400 400
Drive type Semi-aut. Semi-aut.
Maximum slope 2% 2%
Suction motor, supply voltage V 24 24
Suction motor, rated power W 410 410
Suction unit vacuum mbar 120 120
Solution tank l 26 26
Recovery tank l 26 26
Machine length mm 1000 1000
Machine height mm 1005 1005
Machine width (without squeegee) mm 500 500
Battery charter V/Ah 24/70
Batteries V/Ah 24/70 24/70
Batteries weight kg 55 55
Batteries compartment mm 175x335x255 (2x) 175x335x255 (2x)
Machine weight (empty and without batteries) kg 65 66
Sound pressure level (in compliance with IEC 704/1) dB (A) 71 71
Vibration level m/s20,004 0,004

6
SYMBOLS USED ON THE MACHINE
Cock symbol
Used to indicate the cock opening solenoid valve switch
Brush symbol
Used to indicate the main/brush motor switch
+
-
Battery symbol
SYMBOLS USED IN THE MANUAL
Indicates the waste disposal.
Keep the regulations. .

7
GENERAL SAFETY REGULATIONS
Follow these regulations carefully to avoid harm to the operator and damage to the machine.
Read the labels on the machine with attention. Never cover them for any reason and always immediately replace them if they are damaged.
The machine must be used exclusively by authorized and trained personnel.
When operating the machine be careful of other persons and of children in particular.
The machine is not suitable for cleaning carpets.
Never mix different types of detergents: this could generate noxious gases.
Never set containers of liquid on the machine.
Storage temperature must be between -25°C and +55°C, do not store outdoors in the damp.
Operating conditions: room temperature between 0°C and 40°C with relative humidity between 30 and 95%.
Never use the machine in an explosive environment.
Never use the machine to transport goods.
Never use acid solutions which could damage the machine and be hazardous for persons.
Avoid running the brushes with the machine stopped: this could damage the floor.
Never suck flammable liquids.
Never use the appliance to gather dangerous powders.
Use a powder fire extinguisher in case of fire. Do not use water.
Do not hit against shelving or scaffolding when there is a danger of falling objects.
Adapt operating speed to adherence conditions
Do not use the appliance on surfaces with a slope higher than the one indicated on the name-plate.
The machine must perform washing and drying operations simultaneously. Any other operations must be done in zones where the
presence of unauthorized persons is prohibited. Signal wet floors with suitable signs.
Whenever the machine has operating troubles make sure that these are not due to insufficient ordinary maintenance. If this is not the case
then enquire with a FIMAP service center.
When replacing parts ask for ORIGINAL spare parts from an Authorized FIMAP Dealer and/or Retailer.
Always turn the machine off and disconnect the battery connector when performing maintenance.
Warning: restore all electrical connections after performing maintenance.
Never remove guards that require tools for removal.
Never wash the machine with direct or pressurized jets of water or with corrosive substances.
Have a FIMAP service center check the machine every year or after 200 hours.
Avoid clogging the solution tank filter: do not fill with detergent solution a long time before starting to use the machine.
Before you use the machine make sure that all doors and covers are positioned as shown in this operating and maintenance manual.
Dispose of consumables in accordance with existing laws.
When, after years of precious work, a FIMAP machine is ready to be retired all of its component materials must be properly disposed of:
they contain oils and electronic components. Remember that the machine itself was built using totally recyclable materials
Use only the brushes supplied with the appliance or those specified in the instruction manual (page 21). Use of other brushes may
jeopardize safety.
The battery must be removed from the appliance before it is disposed of.
Make sure the recovery tank is empty before you remove it.
The machine is not suitable for use by children or persons with physical, mental or sensorial handicaps or persons who lack the necessary
experience and knowledge unless they are supervised and trained on how to use the machine by a person who is responsible for their
safety.
Children should be superintended to make sure they do not play with the appliance.
For CB models with battery charger:
-The outlet for the battery charger power supply cable must have a proper ground.
-Avoid damaging the battery charger power supply cable by crushing, bending or stressing it.
-Immediately turn to a FIMAP Service Center when you find that the battery charger power supply cable has been damaged.
-The appliance must always be disconnected from the power supply when the battery is being removed.
-The battery and the battery charger in the appliance must be disposed of in a safe manner, complying rigorously with current laws.

8
PREPARING THE MACHINE
1. HANDLING THE PACKAGED MACHINE
Figure 1
The machine is contained in a specifically designed package with platform for being handled by
fork lifts. No more than two packages can be stacked.
Total weight is 80 kg (without batteries)
Package dimensions are:
A: 1240 mm
B: 660 mm
C: 1230 mm
A
CB
2. HOW TO UNPACK THE MACHINE
Figure 2
1. Remove the outer package
2. The machine is strapped to the platform.
3. Remove the strap.
Figure 3
4. Keep the front of the machine slightly lifted and push counterclockwise release lever (1) and
lower the side wheel, sliding support arm (2) until it locks at the bottom.
5. Perform the opposite procedure to lower the machine when working.
1
2

9
PREPARING THE MACHINE
Figure 4
6. Check that the squeegee body is lifted. Otherwise use the control lever as described in the
figure.
Figure 5
7. Use a ramp to lower the machine from the platform, pushing it in reverse. Avoid violent
blows to the base.
8. Store the platform for any shipping needs.
3. INSERTING THE BATTERIES IN THE MACHINE
Figure 6
Batteries must be housed in the battery compartment (Figure 6) provided under the tank. They
must be handled using lifting equipment suitable both for their weights and for the hook-up
system.
They must also comply with the requirements specified in CEI 21-5 standards.
WARNING: Comply scrupulously with the instructions given by the
manufacturer or his retailer for daily battery charging and maintenance. All
installation and maintenance procedures must be done by expert
personnel. Danger of inhalation of gases and leakage of corrosive fluids.
Danger of fire: do not approach with open flames.

10
PREPARING THE MACHINE
Figure 7
To insert the batteries proceed as follows:
1. Open the rear hook and pull out the battery compartment (1)
2. The machine is supported by stand (2) that automatically lowers when the battery
compartment is removed
3. Check that the trestle is in the right position.
Figure 8
4. Put the batteries in place.
5. Connect the cable terminals with the connector in position 01 (fig. 8)
6. Connect the bridge cable terminals to position 02 (fig. 08).
7. Insert the battery compartment in its housing and block everything in place with the
previously-actuated hook (fig. 7)
WARNING: This procedure must be performed by qualified personnel.
Mistaken or imperfect connection of the cables on the batteries may cause
severe damage to persons or property
4. RICARICA BATTERIE
Figure 9
Perform a deep charge cycle before start using the machine.
If the batteries replacement needed be sure to install batteries suitable with battery charge (use
only 12V AGM o Gel batteries).
After having turned off the machine, remove the protection lid and plug the power supply cable to
the battery charger, then plug the power cable to the electric supply plug. To use properly the
battery charger refer to the battery charger manual.
WARNING: The machine has an automatic system that remove the power
supply to the electric plant of the machine when the batteries are in
charging conditions.
WARNING: To not damage permanently the batteries you have to not
discharge completely them to avoid a complete discharge. Recharge them
as soon as the low battery level signal appear.
WARNING: Never left the battery totally discharged as well the machine
will not be used.
WARNING: For the daily recharge of the batteries you need to follow
scrupulously the manifacturer indications. All the installation and
manintenance operations had to be performed by authorized personnel
only. Gas leakage and acid leakage hazards. Fire hazard, don’t approach
flames.
1 1
2
2
1
2

11
PREPARING THE MACHINE
5. CONNECTING THE BATTERY/SYSTEM CONNECTOR
Figure 11
Battery connector (2) must be connected to machine connector (1).
6. BATTERY CHARGE LEVEL GAUGE
Figure 12
The battery charge level gauge operates with a microprocessor. The lighted LEDs on the display
give an approximate reading of the level of charge:
4 = maximum charge, 3= 3/4 charge,
2= 2/4 charge, 1= 1/4 charge,
0= batteries discharged (flashing).
WARNING! The brush motor automatically turns off a few seconds after
the flashing “0” appears. The remaining charge permits to finish drying
before carrying out recharge
7. INSTALLING THE SQUEEGEE
Figure 13
Lower the squeegee support arm by pushing the control lever forward.
1
2

12
PREPARING THE MACHINE
Figure 14
Install the squeegee, threading the studs in their holes on the support. Before threading stud (1)
release lock lever (2), rotating it counterclockwise.
Connect the suction tube to the squeegee by threading the sleeve in body (3)
8. ADJUSTING THE HEIGHT OF THE SQUEEGEE
Figure 15
The squeegee can be adjusted in height depending on the rubber wear.
Loosen the small wheel (placed on the side of the squeegee) using nut (1).
Lift it until the rubber touches the floor again.
Retighten nut (1).
When drying is insufficient rotate the rear rubber or replace it if it has not yet been replaced.
9. ADJUSTING THE COCK
Figure 16
Ball cock (1) is located on the base body.
Adjust the ball cock lever to adjust the flow.
1
2
1
1
3

13
PREPARING THE MACHINE
10. INSTALLING THE BRUSH
Figure 17
Lift the machine (fig.3) and position the brush in the central part of the base.
Lower the machine on the brush (fig.3).
The brush will automatically hook up when the motor is actuated (fig.21-23).
11. SUCTION COWLING
Figure 18
Check that the suction unit is correctly inserted.
Check that the power connectors are connected together. If this is the case proceed as follows:
Insert the male connector coming from the machine body all the way into the seat of the female
connector fastened on the cover of the cowling.
Rotate the bayonet joint hook counterclockwise until it locks in place.
12. RECOVERY TANK
Figure 19
Check that the squeegee tube is properly inserted in its seat.
Check that the plug of the drain tube, located in the rear part of the machine, is closed.
13. DETERGENT SOLUTION
Figure 20
Unscrew the solution tank filling plug.
Fill with clean water at a temperature that does not exceed 50°C. Add liquid detergent in the
concentration and according to the procedures recommended by the manufacturer. Use only a
minimal percentage of detergent to prevent formation of an excess amount of foam since too
much foam may damage the suction motor. Put the plug back in its place.
WARNING: Always use low-foam detergent. Introduce a small amount of
anti-foam liquid in the recovery tank before starting to work to be sure to
prevent foam from being generated. Never use pure acids.

14
OPERATION
1. PREPARING TO WORK
Check that the connectors (suction and supply cowlings) are correctly connected (fig.11-18)
Figure 22
1. Press main/brush switch (1)
2. Press cock/solenoid valve switch (2)
Figure 23
3. Use the lever to lower the squeegee body. The suction motor will start to operate.
2. OVERFLOW DEVICE
Figure 25
The machine has a float that trips when the recovery tank is full, closing the suction tube.
At this point you must empty the recovery tank by removing the plug that closes the drain tube..
WARNING: Always wear gloves when doing this operation to protect yourself
from contact with hazardous solutions.
3. FORWARD MOVEMENT
Figure 26
Drive of these machines is done using the brush. When the brush is slightly inclined it pulls the
machine forward.
WARNING: Always make sure the squeegee is lifted when moving backwards,
even for short distances.
3
2
1

15
AFTER WORK IS TERMINATED
Figure 27
After finishing work and before performing any type of maintenance:
1. Press cock push-button (2) to close the water exit solenoid valve.
2. Wait a few seconds and then lift the squeegee using the lever (fig.4) to turn the suction motor off.
This lets the inside of the squeegee body tube to dry out.
3. Press main push-button (1).
4. Lower front wheel (fig.3)
5. Move the machine to where water can be drained.
Figure 28
6. Move the machine to where water can be drained
7. Remove the brush and clean it with a jet of water (to remove the brush refer to the
“DISMANTLING THE BRUSH” section)
WARNING: Always wear gloves when doing this operation to protect yourself
from contact with hazardous solutions.
3
1 2 3

16
DAILY MAINTENANCE
1. CLEANING THE RECOVERY TANK
WARNING: Always wear gloves when doing this operation to protect
yourself from contact with hazardous solutions.
Figure 29
1. Disconnect the power supply connector located between the suction cowling and the
recovery tank (1).
2. Remove the suction unit from the tank after freeing it from the two safety hooks (2)
Figure 30
3. Rinse the inside of the tank with a jet of running water and drain directly using the tube
(fig.25)
2. CLEANING THE SUCTION FILTER
Figure 31
1. Remove the suction unit from the tank (fig.29)
2. Remove the black guard by making a circular movement (1).
3. Detach filter (2) and clean it carefully with a jet of water.
4. Reinstall everything by performing these procedures in reverse order
3. CLEANING THE SQUEEGEE
Figure 32
Check that the squeegee is always clean. This ensures optimum drying.
To clean it:
1. Remove the suction tube from the squeegee.
2. Unhook the squeegee, pushing hook-up plate (2) backwards.
3. Unhook the body from its support by pushing it towards the back of the machine and
removing it from the side.
4. Carefully clean the inside of the squeegee
5. Carefully clean the squeegee rubbers
6. Reinstall everything
1
2
2
2
1
1
2

17
DAILY MAINTENANCE
4. REPLACING THE REAR SQUEEGEE RUBBER
Figure 33
The drying edge of the rear squeegee rubber can be changed if it is worn and no longer dries
properly. To do this proceed as follows:
1. Pull out the squeegee body as specified in “CLEANING THE SQUEEGEE”
2. Unscrew threaded knobs (1)
3. Pull out blade (2) and remove rubber (3)
4. Rotate the rubber or replace as necessary
To reinstall the squeegee repeat these procedures in reverse order
5. REPLACING THE FRONT SQUEEGEE RUBBER
Figure 34
The drying edge of the front squeegee rubber can be changed if it is worn and no longer dries
properly. To do this proceed as follows:
1. Pull out the squeegee body as specified in “CLEANING THE SQUEEGEE”
2. Unscrew threaded knobs (1)
3. Pull out blade (2) and remove rubber (3)
4. Rotate the rubber or replace as necessary
To reinstall the squeegee repeat these procedures in reverse order
6. DISMANTLING THE BRUSH
Figure 35
1. Lift the machine (fig.3)
2. Actuate the main push-button (fig.20)
3. Actuate the deadman lever (fig.24) and the brush automatically unhooks.
WARNING: Always wear gloves when doing this operation to protect
yourself from contact with hazardous solutions.
1 2
1
23
3

18
WEEKLY MAINTENANCE
1. CLEANING THE SQUEEGEE TUBE
Figure 36
1. If suction is inadequate check that the suction tube is not clogged. Clean out as necessary by
introducing a jet of water from the top part of the tank.
2. CLEANING THE SOLUTION TANK
Figure 37
1. Unscrew the filling plug on the solution tank (fig.20)
2. Rinse with a jet of water
3. Unscrew drain plug (1) and pull it out from the tank
4. Empty the tank
5. Carefully clean the filter mounted on the plug
6. Carefully clean the edge of the drain hole
7. At the end of the cleaning process reinstall drain plug (1)
1

19
CHECKING OPERATION
1. INSUFFICIENT WATER ON THE BRUSHES
1. Check that the main switches and solenoid valve are on (fig. 22)
2. Check that the cock is open (fig. 16)
3. Check that there is water in the solution tank.
2. THE MACHINE DOES NOT CLEAN WELL
1. Check the condition of wear of the brush and replace as necessary (the brush must be replaced
when bristles are about 15 mm tall).
To replace the brush refer to “DISMANTLING THE BRUSH” (fig. 35) and “INSTALLING THE
BRUSH” (fig. 17).
2. Use a type of brush different from the standard brush. When cleaning floors where dirt is
particularly difficult to remove you should use special brushes. These are supplied on request to
meet specific requirements (see: “BRUSH SELECTION AND USE”).
3. THE SQUEEGEE DOES NOT DRY PERFECTLY
1. Check that the squeegee rubbers are clean
2. Check that the suction tube is properly inserted in its housing on the recovery tank
3. Dismantle the entire suction unit and clean it (fig. 29-30-31)
4. Replace rubbers if worn (fig. 33-34)
5. Check that the suction motor is on (fig.23)
4. TOO MUCH FOAM IS GENERATED
Check that low-foam detergent is being used. If necessary add a small amount of anti-foam liquid to
the recovery tank.
Remember that more foam is generated when the floor is not very dirty. Dilute the detergent more
when cleaning floors that are not very dirty.

20
BRUSH SELECTION AND USE
POLYPROPYLENE BRUSH (PPL)
This is used on all types of floors and offers good resistance to wear and to hot water (not more than 50°C). PPL is not hygroscopic and
consequently preserves its characteristics even when wet.
BRISTLE THICKNESS
The thicker bristles are more rigid and consequently are used on smooth floors or with thin gaps.
It is better to use softer bristle brushes on uneven floors or floors with deep gaps or humps since these penetrate more easily.
Remember that when brush bristles are worn and then too short they become rigid and are unable to penetrate and clean in depth. Bristles which
become too big, among other things, cause the brush to tend to skip.
DRIVE DISK
Drive disk, recommended for cleaning polished surfaces, is equipped with a set of anchor stubs that retain and drive the abrasive disk during
operation.
BRUSH SELECTION TABLE
Machine No. Brushes Code Type of bristle Øbristle ØBrush Notes
405661
405654
405658
423760
PPL
PPL
Abrasive
Drive disk
0.45
0.7
500
500
500
500
20”
Minny 20
Minny 20 CB
1
405644
405659
405645
405653
405646
405647
405529
PPL
PPL
PPL
PPL
PPL
Abrasive
Drive disk
0.3
0.45
0.6
0.7
1
420
420
420
420
420
420
420
17”
