Fisher & Paykel PROFESSIONAL CDV3-365H User manual

USER GUIDE
US CA
PROFESSIONAL
CDV-65H, CDV-65, CDV-04H, CDV-04
GAS COOKTOP

!WARNING!
If the information in this guide is not
followed exactly, a fire or explosion
may result causing property damage,
personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
NEVER use this appliance as a space
heater to heat or warm the room. Doing
so may result in carbon monoxide
poisoning and overheating of the
appliance.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor’s phone.
• Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the fire department.

!WARNING!
Never operate the top surface cooking
section of this appliance unattended.
• Failure to follow this warning statement
could result in fire, explosion or burn
hazard that could cause property damage,
personal injury or death.
• If a fire should occur, keep away from the
appliance and immediately call your fire
department. Do not attempt to extinguish
an oil/grease fire with water

CONTENTS
Safety and warnings 5
Before you begin 8
Control panel 9
Burner use 10
Care and cleaning 13
Troubleshooting 15
Warranty and service 16
Registration
To register your product visit our website: fisherpaykel.com/register
4

SAFETY AND WARNINGS
!WARNING!
Fire Hazard
Failure to follow this advice may result in
overheating, burning, and injury.
• Never leave the appliance unattended when
in use. Boilover causes smoking and greasy
spillovers that may ignite.
!WARNING!
Cut Hazard
Failure to use caution could result in injury.
• Take care: some edges may be sharp.
!WARNING!
Explosion Hazard
Failure to follow this advice may result in
injury or death.
• Do not use or store flammable materials such as
gasoline near this appliance.
• Do not spray aerosols in the vicinity of this
appliance while it is in operation.
!WARNING!
Poisoning Hazard
Failure to follow this advice may result in
carbon monoxide poisoning or overheating.
• Never use the appliance as a space heater to
heat or warm the room.
5

SAFETY AND WARNINGS
!WARNING!
Hot Surface Hazard
Failure to follow this advice could result in
burns and scalds.
• To avoid burns and scalds, keep children away
from the appliance.
• Surfaces of the appliance may become hot
enough to cause burns.
• During and after use, do not touch or let
clothing or other flammable materials contact
cooktop components or burners until they have
had sufficient time to cool.
6

SAFETY AND WARNINGS
READ AND SAVE THIS GUIDE
WARNING!
To reduce the risk of fire, electrical shock, injury to persons or damage when using
the cooktop, follow the important safety instructions listed below. Read all the
instructions before use.
Installation
zEnsure the appliance is properly installed and earthed by a qualified technician.
zEnsure this cooktop is connected to a circuit that incorporates an isolating switch
providing full disconnection from the power supply.
zDo not install or operate the appliance if it is damaged or not working properly. If you
receive a damaged product, contact your dealer or installer immediately.
Servicing
zDo not repair or replace any part of the appliance unless specifically recommended in
the user guide. All other servicing should be undertaken by a Fisher & Paykel trained
and supported service technician or qualified person.
Fire Hazard
zUse only dry oven mitts or potholders. Moist or damp potholders on hot surfaces could
result in burns from steam. Do not let potholders touch hot areas.
zDo not use a towel or a bulky cloth for a potholder. It could catch fire.
General Use
zHousehold appliances are not intended to be played with by children.
zChildren should not be left alone or unattended in the area where the appliance is in
use. They should never be allowed to sit or stand on any part of the appliance.
zChildren of less than 8 years old must be kept away from the appliance unless
continuously supervised.
zThis appliance can be used by children aged from 8 years and above, and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge,
if they have been given supervision or instruction concerning the use of the appliance
in a safe way and they understand the hazards involved. Cleaning and user maintenance
shall not be carried out by children without supervision.
zCaution: Do not store items of interest to children in cabinets above the cooktop or on.
Children climbing to reach items could be seriously injured.
zDo not wear loose fitting or hanging garments when using the appliance. They could
ignite or melt if they touch a hot surface and you could be burned.
zDo not cook on a broken cooktop. Should the cooktop break, cleaning solutions and
spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact
a qualified electrician immediately.
zDo not place metallic objects such as knives, forks, spoons and lids on the cooktop
surface as they can get hot.
zUtensil handles should be turned inward and not extend over adjacent surface.
Cleaning and maintenance
zClean only the parts listed in this guide.
zDo not use a steam cleaner to clean any part of the cooktop.
zKeep appliance area clear and free from combustible materials. 7

BEFORE YOU BEGIN
zRead this guide, taking special note of the 'Safety and warnings' section.
zRemove all packaging from the cooktop. Recycle responsibly.
zRemove any adhesive residue using dishwashing liquid on a soft cloth. Do not use any
harsh or abrasive cleaners.
2
1
Cooktop features
1 Control panel
2 Burner grates
CDV3-365 model illustrated
8

CONTROL PANEL
Dial halos*
When a burner in use, a red halo will
illuminate. If all dials are turned OFF, all halos
will dim.
Control panel
CDV3-365 model illustrated
Using the burner dials
To use the burner and griddle dials, push in
and turn counterclockwise to HI. Hold the dial
at HI before turning to a flame setting.
Control panel features
1 Burner dials
2 Burner indicators
*Some models only
1
2
1 1 1 1
9

BURNER USE
WARNING!
If the flame is extinguished during a power failure, turn the dial back to OFF as the
burner will not automatically relight and gas may accumulate.
Identify the desired burner and the
corresponding dial.
When the burner is lit, turn the dial to any
setting between HI (high) and SIM (simmer).
When you have finished cooking, turn the
dial clockwise back to OFF.
If you are using LP gas, there may be
a slight extinction pop or flash at the flame
spreader a few seconds after the burner has
been turned off. This is normal.
1
2
3
4
Selecting and using burners
Push the dial in and turn counterclockwise
to HI. Hold the dial at HI before turning to a
flame setting.
You should hear a clicking sound when
setting to HI. If no clicking sound is present,
turn the dial back clockwise to OFF and
refer to ‘Troubleshooting’ for advice.
10

BURNER USE
Manual lighting
If there has been a power outage, the burners can be manually lit. If you have attempted
to light the burner with the ignition, allow 1 minute for any accumulated gas to dissipate
before manually lighting.
1Carefully hold a battery operated lighter
near the desired burner.
When the burner is lit, turn the dial to any
setting between HI (high) and SIM (simmer).
When you have finished cooking, turn the
dial clockwise back to OFF.
If you are using LP gas, there may be
a slight extinction pop or flash at the flame
spreader a few seconds after the burner has
been turned off. This is normal.
2
3
4
Push the dial in and turn counterclockwise
to HI. Hold the dial at HI before turning to a
flame setting.
11

Burner output
All burners have the same low turn-down setting (SIM) for gentle simmering (1,300 BTU/
hr). Use SIM for melting chocolate and butter, cooking rice and delicate sauces, simmering
soups and stews, and keeping cooked food hot.
For cooking that requires intense heat use the burners listed below. These have a higher
maximum output than other burners (20,000 BTU/hr for Natural gas, 15,000 BTU/hr for LP
gas).
CDV3-365 models: Center burner
CDV3-304: Front left
Use and care
zNever leave the cooktop unattended when in use. Boil-over causes smoking and greasy
spills that may ignite.
zNever allow flames to extend beyond cookware or curl up its sides. This could discolor
and damage the utensil and you may get burned touching a hot handle.
zKeep handles out of the way. Turn handles so that they don’t extend over the edge of the
cooktop or another burner that is on.
zTake care when deep-frying. Oil or fat can overheat very quickly, particularly on
a high setting.
zMake sure that all burner parts are correctly fitted. Incorrectly or incompletely assembled
burners may produce dangerous flames. See ‘Replacing burner parts’.
zKeep the burners clean. Especially after a spill or boilover, ensure the affected burners
are cleaned before using them again. Food residue may clog the ignitor and the notches
of the flame spreader, stopping the burner from functioning correctly. See ‘Care and
cleaning’ for instructions.
zCheck that the burner flames are regular. They should be blue with no yellow tipping, and
burn without fluttering around the burner cap. If not, see ‘Troubleshooting’ for advice.
zUse woks only with a wok ring. Wok rings can be purchased separately through your
Fisher & Paykel dealer or Customer Care. To use, place the wok ring over the grates,
making sure the small protrusions on its bottom straddle the grate fingers. The wok ring
should be stable and unable to rotate.
BURNER USE
12

CARE AND CLEANING
ALWAYS NEVER
•Read these instructions and the ‘Safety and
warnings’ section before you start cleaning
your cooktop.
•Before cleaning or removing any part, make
sure that everything on the range has been
turned off.
•Unless suggested otherwise in the chart
following, allow any part to cool to a safe
temperature before cleaning. If you do need
to handle a warm or hot part take extreme
care. Wear long protective mitts to avoid
burns from steam or hot surfaces.
•Try using any cleaner on a small area first, to
ensure it doesn’t stain.
•Use aerosol cleaners until the cooktop has
completely cooled. The propellant substance in
these cleaners could catch fire in the presence of
heat.
•Let soiling or grease accumulate anywhere on
the cooktop. This will make future cleaning more
difficult and may present a fire hazard.
•Use any abrasive or harsh cleaners, cloths, scouring
pads or steel wool. These will scratch your range
and damage its appearance.
•Use a steam cleaner to clean any part of the range.
•Lift the black grill and griddle frames off the
cooktop.
WHAT? HOW? IMPORTANT!
Burners Do not clean these parts. They
self-clean during normal use.
Area around burners •Soften any stubborn stains
using a hot soapy cloth before
cleaning with a solution of mild
detergent and hot water. Wipe
dry with a microfiber cloth.
•For extra shine, use a suitable
stainless steel cleaner. Always
rub the stainless steel in the
direction of the polish lines.
•Always read the label to ensure
your stainless steel cleaner does
not contain chlorine compounds
as these are corrosive and may
damage the appearance of
your cooktop.
Burner caps and
flame spreaders
Ensure the burner is turned OFF
and cool. Lift off the burner cap
and brass flame spreader and wash
in hot soapy water. Rinse and dry.
Use a stiff nylon brush or straight-
ended paper clip to clear the
notches of the flame spreader.
Replace the flame spreader
and burner cap correctly. See
‘Replacing burner parts’.
Keep the notches of the flame
spreaders clear. Soiling may clog
these and cause ignition problems.
Before replacing the burner parts,
ensure they are dry. Wet burner parts
may result in an irregular flame.
Before lighting a burner, ensure
all parts are positioned correctly.
Incorrect assembly can cause
dangerous irregular flames and
ignition problems.
13

Ensure that all burner parts are correctly fitted. Incorrectly assembled burners may
produce dangerous flames. Flames should be blue with no yellow tipping, and burn without
fluttering around the burner cap.
CARE AND CLEANING
Replacing burner parts
Burner cap
Flame spreader
Ignitor
Correct alignment
Incorrect alignment
WHAT? HOW? IMPORTANT!
Ignitors Ensure the burner is turned OFF.
Clean the ignitor with a small
brush or cotton swab that has
been dipped into rubbing alcohol.
The ignitors must be kept clean
and dry to work correctly. Dirty or
wet ignitors could cause constant
clicking and sparking, even if a flame
is present.
Burner grates Ensure grates have cooled
completely before carefully lifting
them off the cooktop. Place on
a protected surface. To remove
stubborn stains, soak the grates in
a mixture of clothes detergent and
water. Wash in a mixture of hot
water and dishwashing liquid, then
rinse and allow to dry. The grates
are also dishwasher safe.
Take care, the grates are heavy.
Ensure you place a dish towel or
other soft cover on the surface before
putting a grate on it.
14

TROUBLESHOOTING
PROBLEM POSSIBLE CAUSES WHAT TO DO
The ignitor keeps clicking
(continuous spark) even
when a burner has lit.
Dirty or wet ignitor(s) Clean the ignitor(s).
See ‘Care and cleaning’
for guidance.
None of the burners
will light.
No power supply The cooktop burners can still be
used. To light them manually refer
to ‘‘Manual lighting’ for guidance.
No gas supply Check that the gas supply to the
house is working. You should hear
the gas when you turn a burner on.
If you are using bottled gas, check
that it is not empty.
Some burners will not
light – Flames do not burn
all around the burner cap.
Burner parts or ignitors may be
wet, dirty, or misaligned.
Check that the burner parts
are clean, dry, and correctly
assembled. Ensure the ignitors
are clean and dry. See ‘Care and
cleaning’ for guidance.
There is no clicking when I
try to light a burner.
The ignitor is dirty or there is a
power outage.
Clean the ignitor(s).
See ‘Care and cleaning’
for guidance.
There is a slight ‘extinction
pop’ or flash after I’ve
turned a burner off.
This is normal for LP gas and
requires no action.
The flames have suddenly
gone out.
A draft or a spill has extinguished
the flame.
No action required. The burner
will detect this and automatically
relight. However, if there has
been a large spill, we recommend
turning the burners off and
cleaning the burners and sump
area. See ‘Care and cleaning’
for guidance.
The burner flames are
uneven, very large, yellow
or yellow-tipped or sooty.
Technical fault: the gas is the
wrong type or hasn’t been
adjusted properly.
Do not use your cooktop burners.
Contact a Fisher & Paykel trained
and supported service technician or
Customer Care.
15

WARRANTY AND SERVICE
Before you call for service or assistance
Refer to the installation guide and user guide and check that your product is correctly
installed and you are familiar with its normal operation.
If after checking these points you still need assistance or parts, please refer to the Service
& Warranty book for warranty details and your nearest Service Center, Customer Care, or
contact us through our website www.fisherpaykel.com.
Complete and keep for safe reference:
Model
Serial No.
Purchase Date
Purchaser
Dealer
Suburb
Town
Country
592190A 05.20
FISHERPAYKEL.COM
16

592190A 05.20
FISHERPAYKEL.COM
© Fisher & Paykel Appliances 2020. All rights reserved.
The models shown in this guide may not be available in all markets
and are subject to change at any time.
The product specifications in this guide apply to the specific products and
models described at the date of issue. Under our policy of continuous product
improvement, these specifications may change at any time.
For current details about model and specification availability in your country,
please go to our website or contact your local Fisher&Paykel dealer.
