Fisher-Price FISHER-PRICE M7932 User manual

IMPORTANT! KEEP INSTRUCTIONS FOR
FUTURE REFERENCE.
WARNING
M7932
www.fisher-price.co.uk

2
Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten the screws.
Shown Actual Size
M5 x 20 mm Screw – 4
This package contains small parts in its
unassembled state. Adult assembly is required.
IMPORTANT! Please remove all parts from the package and identify
them before assembly. Some parts may be packed in the pad.
Consumer Information Parts
To prevent serious injury or death:
•Fall Hazard - It is dangerous to use this
product on an elevated surface, since child’s
movement may cause the product to slide or
tip over. Use only on a floor.
•Suffocation Hazard - Never use on a soft
surface (bed, sofa, cushion) since the
product can tip over and cause suffocation
in soft surfaces.
•Never leave child unattended.
•Never use as a carrier or lift while child is
seated. Never use the toy bar as a handle.
•Always use the restraint system.
• Never use as a car seat.
•Not recommended for children who can sit
up by themselves (6 months approximately,
until 9 Kg/20 lbs).
WARNING
CAUTION
• Please read these instructions before assembly and use of
this product.
• Adult assembly is required. Tool needed for assembly: Phillips
screwdriver (not included).
• Requires one "D" (LR20) alkaline battery (not included)
for operation.
• Product features and decorations may vary from photo.
Pad
Right Base Wire
Base Tube
Left
Base Wire
2 Feet
Footrest
Retainers
Seat Back Tube
Toy Bar
3 Toys (Toys may be different)
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. M7932pr-0726
©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. PRINTED IN CHINA

3
IMPORTANT! Before assembly and each use, inspect this product
for damaged hardware, loose joints, missing parts or sharp edges.
DO NOT use if any parts are missing or broken. Contact Mattel
for replacement parts and instructions if needed. Never
substitute parts.
Left Base Wire
• Place the base tube on a flat surface.
• Position the left and right base wires as shown.
• Fit the left base wire and right base wire into the base tube.
Right Base Wire
Base Tube
1
• Position the feet so the holes are toward you and the non-skid
surface is down.
• Fit the feet on the base tube, as shown.
Feet Holes
2
• Insert an M5 x 20 mm screw through each foot and tighten.
3
• Position the footrest so that the soothing unit is upright.
• Fit the footrest onto the ends of the base wires.
4
Footrest
Base Wires
Assembly

4
• Fit the seat back tube onto the ends of the base wire.
• Push the seat back tube to be sure it is completely on the
base wires.
5
Seat Back Tube
• Fit a retainer to the outside of the seat back tube, as shown.
Make sure the socket in the retainer is upright.
• Insert an M5 x 20 mm screw through the hole in the seat back
tube, base wire and into the inside of the retainer.
• Repeat this procedure to assemble the other retainer to the
other side of the seat back tube.
• Pull the seat back tube up to be sure it is secure. If you can
remove either end of the seat back tube, you have not assembled
the retainers correctly. Remove the screws, re-read and repeat
Assembly steps 5 and 6.
6
Retainer Socket Up
• Position the pad above the frame.
• Fit the upper pocket on the back of the pad onto the seat
back tube.
• Lift the footrest. Fit the lower pocket on the back of the pad
onto the footrest. Lower the footrest.
• Attach the pad fastener to the fastener on the soothing unit.
7
Footrest Soothing Unit
Fastener
Assembly

5
• Insert and “snap” the toy bar plugs into each socket.
Hint: The toy bar is removable. Press the ends of the latches and
lift the toy bar.
9
Toy Bar Plugs
Sockets
• Fasten the toy straps to the toy bar straps.
Assembly is now complete.
10
Toy Bar Straps
Toys
• Fit the retainers through the side openings in the pad.
8
Retainers
Assembly

6
In exceptional circumstances, batteries may leak fluids that can
cause a chemical burn injury or ruin your product. To avoid
battery leakage:
• Do not mix old and new batteries or batteries of different types:
alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always remove
exhausted batteries from the product. Dispose of batteries safely.
Do not dispose of product in a fire. The batteries inside may
explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removeable, rechargeable batteries are used, they are only to
be charged under adult supervision.
• Protect the environment by not disposing of this product
with household waste (2002/96/EC). Check your local
authority for recycling advice and facilities (Europe only).
2
• Insert a coin into the battery compartment door and pry the battery
compartment door off.
• Insert one “D” (LR20) alkaline battery into the battery compartment.
• Replace the battery compartment door.
• Pull and fit the pad seat bottom pocket around the soothing
unit and footrest.
Battery Compartment
Hint: We recommend using alkaline batteries
for longer battery life.
1,5V
“D” (LR20) +
–
1Pad Bottom Pocket
• Remove the pad bottom pocket from the footrest.
AssemblyBattery Installation Battery Safety Information

7
Restraint Straps
Securing Your Child
• Place your child in the seat. Position the restraint pad between
your child’s legs.
• Fasten the restraint straps to the restraint pad. Make sure you
hear a “click” on both sides.
• Check to be sure the restraint system is securely attached by
pulling it away from your child. The restraint system should
remain attached.
1
Restraint Pad
To tighten the restraint straps:
• Feed the anchored end of the restraint strap up through the buckle
to form a loop A. Pull the free end of the restraint strap B.
To loosen the restraint straps:
• Feed the free end of the restraint strap up through the buckle
to form a loop A. Enlarge the loop by pulling on the end of the
loop toward the buckle. Pull the anchored end of the restraint
strap to shorten the free end of the restraint strap B.
Setup and Use
2
Free End
Anchored End
TIGHTEN
LOOSEN
Free End
Anchored End
To prevent serious injury or death:
•Fall Hazard - It is dangerous to use this
product on an elevated surface, since child’s
movement may cause the product to slide or
tip over. Use only on a floor.
•Suffocation Hazard - Never use on a soft
surface (bed, sofa, cushion) since the
product can tip over and cause suffocation
in soft surfaces.
•Never leave child unattended.
•Never use as a carrier or lift while child is
seated. Never use the toy bar as a handle.
•Always use the restraint system.
• Never use as a car seat.
•Not recommended for children who can sit
up by themselves (6 months approximately,
until 9 Kg/20 lbs).
WARNING

8
Consumer Information
• The pad is machine washable. Wash it separately in cold water
on the gentle cycle. Do not use bleach. Tumble dry separately
on low heat and remove promptly.
• The frame and toys may be wiped clean using a mild cleaning
solution and a damp cloth. Do not use bleach. Do not use harsh
or abrasive cleaners. Rinse clean with water to remove residue.
Do not immerse the frame.
To remove the pad: First remove the bottom pocket of the pad A.
Then, remove the upper pad flap B.
To replace the pad, refer to Assembly steps 7 - 8.
A
B
Care
• Make sure your child is properly secured in the seat.
• Slide the power switch to:
O Off
Vibrations
IMPORTANT! Low battery power causes this product to operate
erratically: no vibrations and the product may not turn off. Remove
and discard the battery and replace with a new “D” (LR20)
alkaline battery.
Power Switch
Soothing Unit
