Swing
Deluxe Take-Along
™
Model Number: 79618
Please keep this instruction sheet, as it contains important information.
Adult assembly is required.
Tool needed for battery installation: Phillips Screwdriver.
Requires four “C” (LR14) alkaline batteries for operation (not included).
Weight Limit: 17 lbs (7.7 kg).
IMPORTANT! The maximum weight limit for this product is 17 lbs. If your child
weighs less than 17 lbs., but is really active and appears to be able to climb
out of the swing, immediately discontinue its use.

Occasionally a consumer may experience
a problem with one of our products.
If this should happen, please call us toll-free,
rather than return this product to the store.
Usually, we can solve the problem over the telephone
or send you replacement parts.
Please call Fisher-Price® Consumer Relations,
toll-free at 1-800-432-KIDS,
8 AM - 6 PM EST Monday through Friday.
Hearing-impaired consumers using TTY/TDD equipment,
please call 1-800-382-7470.
Or, write to:
Fisher-Price® Consumer Relations
636 Girard Avenue
East Aurora, New York 14052
• To prevent falls:
- Never use with an active child who
may be able to climb out.
- Never use on any elevated surface.
• To prevent injury or death from falls or
sliding out, always use restraint system.
• Never leave child unattended.
WARNING
Warnings
Consumer Information
2

Parts
Pad with Restraint
Front Tube
Frame with Liner
3
2 Frame Tubes

• Rotate the upper frame tube until it "snaps" into an upright position,
as shown.
Assembly
4
IMPORTANT! Before assembly, inspect this product for damaged
hardware, loose joints, missing parts or sharp edges. DO NOT use if
any parts are missing or broken. Contact Fisher-Price® for replace-
ment parts and instructions if needed. Never substitute parts.
• Position the front tube so that the rubber feet are flat on the surface.
• While pressing the button on the lower frame tube, insert it into an end of the
front tube. Continue to insert the lower frame tube into the front tube until you
hear a "click".
• While pressing the button on the front tube, insert it into the end of the lower
frame tube. Continue to insert the front tube into the lower frame tube until you
hear a "click".
1
2
Upper
Frame
Tube
Rubber
Feet
Down
Press Button on
Lower Frame Tube
Press Button on
Front Tube

Assembly
3
5
• Position the frame with liner so that the seat is over the front tube.
• While pressing the buttons on the upper frame tubes, insert them into the
holes in the underside of the frame with liner.
• Continue to insert the upper frame tubes into the frame with liner until you
hear a "click" on both sides.
4
Press
Button
on Upper
Frame
Tube
Frame
with Liner
• Pull the front tube to be sure it is secure to each lower frame tube.
Lower
Frame
Tubes
Pull
Front
Tube
Seat
Front Tube

Assembly
5
6
Upper
Frame
Tube
Upper
Frame
Tube
• Fit the pad seat back pocket over the seat back and fasten.
• Fit the pad seat bottom pocket over the seat bottom and fasten .
B
IMPORTANT! Attach the provided pad (with restraint system) to
this product. Never use this product without the provided pad.
6
Pad Seat
Back
Pocket
Pad Seat
Bottom
Pocket
• Check to be sure the upper frame tubes are secure in the frame with liner.
If you can remove the upper frame tubes from the frame with liner, you
have not properly inserted the tubes into the frame. Remove the upper
frame tubes from the frame with liner and repeat Assembly step 4.
B
Frame
with Liner

7
Assembly
7
Slot
Slot
Waist
Belts
Pad
• Pull the edges of the pad up slightly and insert the waist belts on
the liner through the slots in the pad.
Assembly is now complete.

• Open the battery holder.
• Insert four "C" (LR14) alkaline batteries as indicated inside the bat-
tery holder.
• Close the battery holder.
• Locate the battery compartment door on the frame.
• Loosen the screw in the battery compartment door with a
Phillips screwdriver.
• Remove the battery compartment door and the battery holder
from the battery compartment.
Battery Installation
Battery
Holder
8
Battery
Compartment
Door
Battery
Holder
Hint: We recommend using alkaline batteries for longer battery life.

Battery Installation
• Align the ridge on the battery holder with the groove in the
battery compartment.
• Slide the battery holder back into the battery compartment.
• Replace the battery compartment door and tighten the screw
with a Phillips screwdriver. Do not over-tighten.
Battery
Holder Battery
Compartment
Door
9

Battery Tips
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium).
• Remove the batteries during long periods of non-use. Always remove
exhausted batteries from the toy. Battery leakage and corrosion can
damage this toy. Dispose of batteries safely.
• Do not dispose of batteries in a fire.The batteries may explode or leak.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type as recommended in the
"Battery Installation" instructions are to be used.
• If removable rechargeable batteries are used, they are only to be
charged under adult supervision.
• Rechargeable batteries are to be removed from the toy before they
are charged.
• If you use a battery charger, it should be examined regularly for damage
to the cord, plug, enclosure and other parts. Do not use a damaged bat-
tery charger until it has been properly repaired.
10
1.5V x 4
"C" (LR14)
SHOWN ACTUAL SIZE

Securing Your Child
Waist
Belt
Restraint
Waist
Belt
1
11
• Place your child in the seat. Position the restraint between your child’s legs.
• Fasten both waist belts to each side of the restraint. Make sure you hear a
"click" on each side.
• Check to be sure the restraint is securely attached by pulling it away from
your child. The restraint should remain attached.
• To prevent falls:
- Never use with an active child who
may be able to climb out.
- Never use on any elevated surface.
• To prevent injury or death from falls or
sliding out, always use restraint system.
• Never leave child unattended.
WARNING

Loosen
To tighten the restraint:
• Feed the anchored end of the restraint belt up through the
buckle to form a loop .
• Pull the free end of the restraint belt .
• Repeat this procedure to tighten the other restraint belt.
To loosen the restraint:
• Feed the free end of the restraint strap up through the buckle to
form a loop .
• Enlarge the loop by pulling on the end of the loop toward
the buckle.
• Pull the anchored end of the restraint belt to shorten the free
end of the restraint belt .
• Repeat this procedure to loosen the other restraint belt.
Note: After adjusting the restraint to fit your child, make sure you
pull on it to be sure it is securely fastened.
B
Securing Your Child
B
Anchored End
Free End
2
12
Tighten
Anchored
End
Free End
B
B

Starting the Swing
13
Power Dial
• Turn the power dial to any of eight settings.
• Give the seat a light push to start the swinging motion. Adjust the swing
power dial to the desired swing motion setting.
• If swinging stops while using a lower setting, try a higher setting. Give the
seat a light push to start the swinging motion again.
• Be sure to turn this product off when not in use.Turn the power dial to the
off setting .
IMPORTANT! Before each use, inspect this product for damaged
hardware, loose joints, missing parts or sharp edges. DO NOT use if
any parts are missing or broken. Contact Fisher-Price® for replace-
ment parts and instructions if needed. Never substitute parts.
Power Dial
Hint: As with most battery-powered swings, a heavier child will
reduce the amount of swinging motion on all settings. In most
cases, the low setting works best for a smaller child while the high
setting works best for a larger child.

Lights and Music!
14
• Slide the lights and music switch to: baby activated lights and
one song ;sound and lights off ; or parent activated
lights and music .
When baby pulls either toy on the arch, one tune plays
along with twinkling lights.
On this setting, six tunes (approximately 10 minutes)
play along with dancing lights.
Turns lights and music off.
• Turn the volume dial to a comfortable listening level.
Volume Dial
Lights and
Music Switch
Baby Activated Parent Activated
Hint: Your baby can enjoy lights and music with or without swinging.
IMPORTANT! The maximum weight limit for this product is 17 lbs. If your
child weighs less than 17 lbs., but is really active and appears to be able to
climb out of the swing, immediately discontinue its use.
Lights and
Music Switch

Room-to-Room Portability
15
• Make sure your child is properly secured in the swing seat.
• With baby facing forward and outward, lift the swing using the handle.
• Carefully carry the swing to another room. Be sure to set the swing down
on a non-elevated, flat surface.
• To prevent falls: Never use on any
elevated surface.
• To prevent injury or death from falls
or sliding out, always use restraint
system.
WARNING

Take-Along
16
Seat Bottom
Lift
Seat
Back Lift Seat
Bottom
• Tip the swing backwards the seat back down.
• Unfasten the straps on the seat bottom.
• Pull the straps from the loops on the seat bottom.
• Press both tabs on the frame at the same time to release the frame base.
Press Tab
Press Tab
Seat
Back
• Lift the seat back and seat bottom together.
1
2
Straps

Take-Along
Lower Frame
Tube
• Fit the straps on the seat bottom between the upper and lower frame
tubes, as shown.
• Wrap the straps around the lower frame tubes and fasten the straps.
To set the swing back up for use:
• Unfasten the straps around the upper and lower frame tubes.
• Replace the straps through the loops on the seat bottom and fasten.
• Rotate the lower frame tube around until it snaps into place.
• Place the swing on a non-elevated, flat surface.
Upper
Frame
Tube
Lower
Frame
Tube
Strap
• Rotate the lower frame tube around to the top of frame, as shown.
3
4
17

• The pad is machine washable.Wash the pad separately in cold water on the gentle
cycle. Do not use bleach. Tumble dry separately on low heat and remove promptly.
The frame, liner and toys may be wiped clean using a mild cleaning solution and a
damp cloth. Do not immerse the frame.
• This product has no consumer serviceable parts. Do not take this
product apart.
IMPORTANT! Never use this product without the provided pad. Be sure to
re-attach the provided pad (with restraint system) to this product.
Care
18
Pad Seat
Back
Pocket
Waist
Belts
Pad Seat
Bottom
Pocket
To remove the pad:
• Push the waist belts back through the slots in the pad.
• Unfasten and slide the pad seat back pocket off of the seat back.
• Unfasten and slide the pad seat bottom pocket off of the seat bottom.
To replace the pad:
• Refer to Assembly steps 6 and 7.

One (1) Year Limited Warranty
19
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, New York 14052 warrants
that the Deluxe Take-Along Swing is free from all defects in material and
workmanship when used under normal conditions for a period of one (1)
year from the date of purchase.
Should the product fail to perform properly, we will repair or replace it at our
option, free of charge. Purchaser is responsible for shipping the product to
Consumer Relations at the address indicated above and for all associated
freight and insurance cost. Fisher-Price, Inc. will bear the cost of shipping the
repaired or replaced item to you.This warranty is void if the owner repairs or
modifies the product.This warranty excludes any liability other than that
expressly stated above including but not limited to any incidental or conse-
quential damages.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLU-
SION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

FCC Statement (United States Only)
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufac-
turer responsible for compliance could void the user's authority to operate
the equipment.
For other countries, outside the United States:
Canada: call 1-800-567-7724, or write to:
Mattel Canada Inc, 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2.
Great Britain: telephone [phone].
Australia: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond,Victoria 3121
Australia.
Consumer Advisory Service 1300 135 312.
New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland.
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. 79618pr-0920
©2001 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. Printed in China
