Fisher-Price Super Show Projector and Flashlight User manual

SUPER SHOW
PROJECTOR
®
AND FLASHLIGHT
Instructions
Product Number: 35588
Please save these instructions for future reference.
Requires four, size “C” (LR14) alkaline batteries (not included).
Requires one KPR113 Krypton light bulb (included).
Adult assembly is required to install batteries and replace light bulb.
Tool required for battery installation and light bulb replacement: Phillips Screwdriver.

Battery Installation
• Loosen the screw in the battery
compartment door with
a Phillips screwdriver.
• Lift the battery compartment door to open.
• Insert four, new size “C” (LR14) alkaline batteries,
as indicated inside the battery compartment.
• Replace the battery compartment door and tighten the
screw with a Phillips screwdriver. Do not over-tighten.
Battery
Compartment
Door
Battery Tips
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium).
• Remove the batteries during long periods of non-use. Always remove exhausted
batteries from this toy. Battery leakage and corrosion can damage the toy.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type as recommended
in the “Battery Installation” instructions are to be used.
• If removable rechargeable batteries are used, they are only to be charged
under adult supervision.
• Rechargeable batteries are to be removed from this toy before they are charged.
• If you use a battery charger, it should be examined regularly for damage to the cord,
plug, enclosure and other parts. Do not use a damaged battery charger until it has
been properly repaired.
1.5V x 4
“C” (LR14)
Shown Actual Size

It’s Show Time!
You can use Super Show Projector®and Flashlight to project
View-Master®images on walls and ceilings, or use as a flashlight!
Power Switch
Focus Ring
Advance
Lever
• To turn power on:
Slide the switch forward.
• To turn power off:
Slide the switch backward.
• Twist the focus ring until the image
is clear.
• To see the next picture, push the
advance lever all the way down and
then back-up to its original position
•Toinsert the reel: Fit the reel into
the slot and push all the way down.
•Toremove the reel: Pull the reel
straight up. (Hint: remove the reel
for flashlight use.)
HINT: Since you cannot rewind to a favorite picture,
simply continue to press the advance lever to find a desired picture.
1 2
3 4

Light Bulb (Glass Bulb) Replacement
IMPORTANT! Should the light bulb become non-functional, you are advised to
remove or replace it. This should be carried out away from the child’s play area.
• Loosen the screw in the battery compartment door with a Phillips screwdriver.
• Lift the battery compartment door to open.
• Remove the batteries.
• Lift and rotate the battery compartment up.
Battery
Compartment
Door
Battery
Compartment
Door

• Pull to remove the reflector.
• Pull to remove the light bulb.
• Discard the light bulb properly. Beware of cracked or broken glass.
• Insert a new, KPR113 Krypton bulb (or equivalent).
• Replace the reflector.
• Rotate the battery compartment down into place.
• Replace the four size “C” (LR14) alkaline batteries, as indicated
in the battery compartment.
• Replace the battery compartment door and tighten the screw
with a Phillips screwdriver. Do not over-tighten.
Light Bulb
Reflector

Consumer Information
Questions? We’d like to hear from you!
Call Fisher-Price®Consumer Affairs, toll-free
at 1-800-432-KIDS, 8 AM - 5 PM EST Monday
through Friday. Hearing-impaired consumers
using TTY/TDD equipment, please call
1-800-382-7470. Or, write to: Fisher-Price®
Consumer Affairs, 636 Girard Avenue,
East Aurora, New York 14052.
If you have any questions about this product:
In Canada, call 1-800-567-7724, or write to: Mattel Canada Inc.,
6155 Freemont Blvd., Mississauga, Ontario L5R 3W2.
In Great Britain, telephone [phone].
In Australia, Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
Consumer Advisory Service 1-800-800-812 (valid only in Australia).
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A.
© 1999 Mattel, Inc. All Rights Reserved.
® and ™ designate U.S. trademarks of Mattel, Inc.
Printed in Mexico 35588-0920
Fun Tips
• For the steadiest picture show, place the projector on a hard, flat surface.
• Make sure the room is completely dark for maximum picture clarity.
• To turn the projector into a flashlight, simply remove the reel.
Care
• Wipe the projector with a clean cloth dampened with a mild soap and
water solution.
• Do not immerse the projector.
