FLIR MPX C233BD User manual

WDR Function Notice
WDR is not supported in analog output mode.
Package Contents
MODEL: C233BD/
C233BDP
QUICK START GUIDE
English Version 2.0
flir.com/security/support
FLIR Systems, Inc., Copyright © 2015
As our products are subject to continuous improvement, FLIR
Systems Inc. reserves the right to modify product design,
specifications and prices, without notice and without incurring
any obligation. E&OE
Safety Precautions
• Use an appropriate low voltage power cable to
prevent fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the
camera. Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens
cover.
2.1MP Fixed Bullet Camera
flir.com/security/support
VISIT
• 1x 2.1MP Fixed Bullet Camera
• 3x Mounting Screws
• 3x Drywall Anchors
• 1x Allen Key
• 1x Power Pigtail Adapter
• 1x Mounting Template
NOTE: 12V DC adapter not included.
On-Screen Display (OSD) Menu
IT’S ALL ON THE WEB!
Language
Video Format
Backlight OFF
WDR (MPX only)
BLC
HLC
DNR
Advanced Lens ELC
ALC
Exposure Brightness
Shutter
Sens-Up
AGC
White Balance Auto
ATW
Preset
Manual
Day&Night Mode
Delay
D N Level
N D Level
Smart IR
Smart IR Level
Image Sharpness
Color Gain
Freeze
Flip
D-Zoom
Defog
Special Black Level
Privacy
DP Comp
Reset
Version
Exit
To use the OSD menu:
• OPTIONAL: Connect a test monitor to the
camera’s analog (yellow) BNC connector.
• Push the middle of the joystick to open the
OSD menu.
• Move the joystick / to select a setting,
then / to change the setting value.
• Push the middle of the joystick to confirm selection.
• Arrows beside settings indicate a submenu ( ).
Select the setting and push the joystick to enter.
• Select RETURN and push the joystick to return to the
previous menu, or EXIT from the main menu to exit.
Configure OSD menu options using the
integrated control stick on the camera
cable (see image to the right).
See the full OSD menu tree below. For detailed
explanation of camera settings, see the OSD
instruction manual on www.flirsecurity.com/pro.

Analog
MPX
Connect to the included
power pigtail or a 12V
DC power adapter
(not included).*
Image Sensor 1/3” 2.1MP CMOS
Video Format NTSC (C233BD)/PAL (C233BDP)
Effective Pixels H: 1920 V: 1080
Resolution Digital: 1080p
Analog: 960H
Scan System Progressive
Sync System Internal
S / N Ratio ≥50dB (AGC Off)
Iris AES
AES Shutter Speed 1/60 (1/50) ~ 1/60,000 sec.
Min. Illumination 0.1 LUX (IR Off)
0 LUX (IR LEDs On)
Video Output Digital: 1080p MPX HD-CVI
Analog: Composite 1.0Vpp @
75ohm
Lens Focal Length / Type 3.6mm F2.0 / Fixed
FOV (Horizontal) MPX: 88°
960H: 82°
Termination BNC Type
IR Range / Qty. 70ft / 21m; 24 IR LED’s
Power Requirement 12V DC ± 10%
Power Consumption 380mA MAX with IR LED
Operating Temp. Range –22° ~ 140°F / –30° ~ 60°C
Environmental Rating IP66
Dimensions (W x H x D) 2.8” x 2.8” x 8.0”
72mm x 72mm x 204mm
Weight (including stand) 0.9lbs / 0.4kg
Camera Dimensions
Camera Specifications
To install the camera:
1. Use the included mounting template to mark and drill
holes for the included mounting screws.
NOTE: Insert the included drywall anchors if installing into
drywall.
2. Connect the video and power cable as detailed in the
section ‘Setting up the Camera’.
3. Attach the camera
base to the mouting
surface using the
included screws.
4. Set the position and angle of the camera using the
provided Allen key.
5. Remove the protective film from the camera lens.
Setting up the Camera
8.0”
204mm
2.8”
72mm
2.8”
72mm
ATTENTION:
Test the camera prior to selecting a permanent
mounting location by temporarily connecting the
camera(s) and cables to the DVR.
Installing the Camera
WARNING:
A REGULATED 12V DC power supply is REQUIRED for use with
this camera. Use of a non-regulated, non-conforming power
supply can damage this product and voids the warranty.
Camera Wiring
MPX
Connect to an MPX
DVR for 1080p viewing
and recording.
Analog
Connect to an analog
DVR for 960H viewing
and recording.
1. Connect one of the two BNC connectors on the camera to
the video cable. See “Camera Wiring” for details.
2. DC Power—Power Pigtail: Connect the included power
pigtail to the camera. Connect the terminating wires of the
cable directly to the DC power source.
OR
3. DC Power—Power Adapter: Connect a 12V DC power adapter
(not included) to the camera and a local power outlet.
NOTE: For pigtail connection with 12V DC, make sure to check
polarity specifications on the power adapter.
Extension Cable Options
Specification Maximum Length
RG59 20AWG Conductor 95% Braid
CSA/UL or C(UL) Approved
Up to 1000ft (300m)†
RG6 20AWG Conductor 95% Braid
CSA/UL or C(UL) Approved
Up to 2000ft (600m)†
Analog CCTV Balun Up to 300ft (91m)
† Long cable runs over 1000ft (300m) may be affected by
electro-mechanical interference (EMI), which can increase the
amount of noise in the picture in some installations.
The entire length of the cable run must be made using a
single extension cable between the camera and the DVR.
B) Loosen lower screw with
the Allen key to adjust the
camera’s vertical position.
C) Loosen upper screw with the
Allen key to rotate the camera
housing.
A) Turn the adjustment ring
to tighten / loosen the stand
connection. Adjust the
camera’s horizontal position.
A B
C
* Camera focus may be affected if the power connection is too
long. It is recommended not to extend the power connection
past 200ft (61m).
