FLIR EXTECH INSTRUMENTS PQ3450 User manual

User Guide
3-Phase Power Analyzer
MODEL PQ3450
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
2
Table of Contents
1.0 INTRODUCTION
1-1 Features ..................................................................................................... 3
1-2 Safety .......................................................................................................... 4
2.0 SPECIFICATIONS
2-1 General Specifications ................................................................................ 5
2-2 Electrical Specifications............................................................................... 6
3.0 METER DESCRIPTION..................................................................................... .7
4.0 METER BASICS AND THE SETUP MODE
4-1 Initialization Screen ..................................................................................... 8
4-2 Measurement Screen Example ................................................................... 8
4-3 Keypad Summary........................................................................................ 9
4-4 Setup Mode Basics ..................................................................................... 9
4-5 Setup Mode In Detail................................................................................. 11
5.0 POWER MEASUREMENT PROCEDURES
5-1 1Φ2W (single phase two wire) measurement ......................................... .17
5-2 1Φ3W (single phase three wire) measurement....................................... .18
5-3 3Φ3W (three phase three wire) measurement........................................ .19
5-4 3Φ4W (three phase four wire) measurement .......................................... .20
5-5 CT and PT measurement ......................................................................... .21
5-6 Data Logger............................................................................................... 22
5-7 Data Hold ................................................................................................. .23
5-8 Display Backlight key ............................................................................... .23
5-9 LOWBAT (Low Battery) screen ................................................................ .23
5-10 Measurement Definitions........................................................................ .24
5-11 Reset Button........................................................................................... .24
5-11 Watt-Hour ZERO Function ..................................................................... .24
6.0 MAINTENANCE
6-1 Cleaning .................................................................................................... 25
6-2 Battery Replacement................................................................................. 25
7.0 PC INTERFACE
7-1 Download Data from SD Card................................................................... 26
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
3
1.0 Introduction
Congratulations on your purchase of the Model PQ3450 Power Analyzer. This instrument is fully
tested and calibrated prior to delivery; proper use and care of this meter will provide years of reliable
service.
1.1 Features
Large dot-matrix, numerical, backlit LCD
Full system analysis with more than 30 parameters:
oVoltage (phase-to-phase) and Voltage (phase-to-ground)
oCurrent (Amps) phase-to-ground
oKW / KVA / KVAR / PF (phase)
oKW / KVA / KVAR / PF (system)
oKWH / KVAH / KVARH / PFH (system)
oPhase angle
High accuracy current clamps
600.0VAC input with CAT III-600V safety rating
Adjustable Current Transformer (CT) and Potential Transformer (PT) ratio for high power
distribution systems
Log up to 30,000 reading on removable SD memory card in Excel® format
Wide sampling rate range (from 2 seconds up to 2 hours)
Easy-to-use onscreen menu
Easy-to-hold rugged over-molded housing
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
4
1.2 Safety
CAUTION: Risk of electric shock. Do not attempt to open or disassemble the meter while
taking measurements
CAUTION: Do not attempt to measure Voltage or Current that exceeds specified limits
Do not operate this instrument in wet or dusty environments.
Do not operate this instrument in the presence of combustible or explosive gas
Do not touch exposed metal parts or unused terminals.
Consider the use of rubber gloves in operation.
Do not operate in excess of AC 500V (Phase to Neutral), or AC 600V (Phase to Phase)
Do not operate this instrument if it appears to be malfunctioning
Remove the test leads from the meter before opening the battery compartment cover
When cleaning, use only a dry cloth to wipe the meter housing. Do not use liquids of any
kind to clean the meter
Safety Symbols:
CAUTION DOUBLE INSULATION RISK OF ELECTRIC SHOCK
Environmental Conditions
Installation Category III 600V
Pollution Degree 2
Altitude limit: 2000m
Indoor use only
Relative Humidity maximum: 80%
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
5
2.0 Specifications
2.1 General Specifications
Circuit Custom single-chip microprocessor LSI circuit
Display LCD Size: 81.4 X 61 mm (3.2 X 2.4”)
Dot Matrix backlit LCD (320 X 240 pixels)
Measurements V (voltage phase to phase)
V (voltage phase to ground)
A (Current Phase to ground)
KW / KVA/ KVAR / PF (Phase)
KW / KVA/ KVAR / PF (System)
Power factor
Phase angle
Frequency
Wire configurations 1P/2W, 1P/3W, 3P/3W, 3P/4W
Voltage ranges 10 ACV to 600 ACV (Auto Range)
Current ranges Current probe input signal voltage (ACV):
200mV /300mV /500mV /1V /2V /3V
Current probe input current range (ACA):
20A/200A/2000A(1200A)/30A/300A/3000A/6000A
Note that the meter has universal probe compatibility
Safety standard IEC1010 CAT III 600 V
ACV input impedance 10M ohms
ACV Auto RangeRange select
ACA Manual Range
Clamp frequency response 40 Hz to 1 KHz
Over-load protection ACV 720 ACV RMS
Over-range "OL" is displayed; Data on SD card will read ‘9999’ or ‘999’ for over-
range data
Under-range "UR" is displayed
Data Hold Freezes displayed reading
Data Recording SD memory card
Sampling Time Approx. 1 second
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
6
Real time data logger saves data to SD memory card for download to
PC (data files open directly to spreadsheet)
Datalogger
Sampling rate: From 2 seconds to 7200 seconds
Data Output RS232 port
Operating Temperature 0 to 50oC (32 to 122oF)
Operating Relative Humidity 80% Relative Humidity max.
Power Supply Eight (8) ‘AA’ 1.5VDC batteries or AC 9V power adapter
Power Consumption Meter: 270 mA DC; Clamp: 22 mA DC
Weight 968g (2.1 lbs.) (with batteries)
Dimensions 225 X 125 X 64 mm (8.86 X 4.92 X 2.52“)
2.2 Electrical Specifications (45 to 65Hz; 23±5°C)
Function Range Resolution Accuracy*
AC Voltage 10.0V to 600.0V 0.1V ± (0.5% range + 3 digits)
AC Current 0.2A to 6000A 0.001A to 1 A ± (0.5% range + 5 digits)*
Power Factor 0.00 to 1.00 0.01 ± 0.04
ΦPhase Angle -180° to 180° 0.1° ± 1°
Frequency 45 to 65Hz 0.1Hz 0.1Hz
0.0 to 3.6MW
0.0 to 3.6MVA
Power
0.0 to 3.6MVAR
0.001k to 0.001M ± (1% range+8 digits)
0.0 to 3.6MWH
0.0 to 3.6MVAH
Watt Hour
0.0 to 3.6MVARH
0.001k to 0.001M ± (1% range+8 digits)
*Meter accuracy only. For system accuracy add the accuracy of the clamp used.
PFH (Power Factor Hours): Long Term Power Factor
For three phase/four wire and three phase/three wire configurations:
PF∑= (PF1 + PF2 + PF3) / 3
For single phase three wire configurations:
PF∑= (PF1 + PF2) / 2
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
7
3.0 Meter Description
Meter Front
3-1 LCD Display
3-2 ◄Left arrow navigation
3-3 Power ON-OFF
3-4 Phase / Wire setup
3-5 REC datalogger memory
3-6 Exit button
3-7 Setup/Enter button
3-8 Measurement input terminals
3-9 ▼Down arrow navigation
3-10 HOLD (freeze display)
3-11 Shift button
3-12 Display Backlight ON-OFF
3-13 ►Right arrow navigation
3-14 ▲Up arrow navigation
Meter Top
3-15 Clamp positive input jacks
3-16 Clamp negative input jacks
3-17 Clamp power lead connections
Meter Right Side
3-18 9V power adaptor jack
3-19 SD memory card socket
3-20 RS232 PC interface socket
3-21 Reset button
3-22 Screw fastener for protective cap
Note: The Battery compartment and Tilt Stand are located on the rear of the instrument
3-1
3-3
3-2
3-4
3-5
3-6
3-7
3-13
3-14
3-12
3-11
3-10
3-9
3-8
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
8
4.0 Meter Basics and Setup Mode
4-1 Initialization Screen
1. When the meter is switched ON the initialization screen appears.
Start-up Initialization Screen
2. The meter will also check for an inserted SD memory card. ‘SD check’ will appear on the lower
right side of the display. If an SD card is inserted, the blinking display will switch off after several
seconds. When no card is inserted the display will show ‘No disk’.
4-2 Measurement Screens
After the initialization screen, the meter displays one of the measurement screen configurations.
The meter reverts to the screen that was displayed at the last power down and may not be the
screen shown below. Other screen configurations are shown later in this User Guide.
Measurement Screen Example
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
9
4.3 Keypad Summary
POWER : Press and hold to power ON/OFF
1Φ3Φ(phase/wire) : Select (1P/2W, 1P/3W, 3P/3W, 3P/4W) measurement function
REC : Data record key for use with the SD Memory Card
HOLD : Freeze the displayed reading
BACKLIGHT : Switch LCD backlight ON/OFF
SETUP/ENTER : Enter the Setup mode. Also used as an Enter key to confirm entries
EXIT : Exit a screen when programming
SHIFT (: Programming key for use in the Setup Mode
Up arrow ▲: Generally, press to move the cursor up or to change a parameter value, however
use varies with each particular function
Down arrow ▼: Generally, press to move the cursor down or to change a parameter value,
however use varies with each particular function
Left arrow ◄: Use varies according to a particular function
Right arrow ►: Use varies according to a particular function
4.4 Setup Mode
4.4.1 Setup Mode Basics
1. Press the SETUP button to access the Setup Mode. The screen shown below will appear on
the meter’s LCD.
2. Use the up and down arrow keys to scroll through the parameters.
3. Press the SHIFT key to open a particular parameter for editing (the
‘SHIFT 1’ display icon will be visible on the upper right hand corner of
the LCD).
4. Once a parameter is opened for editing (parameter variable
highlighted), use the up and down arrow keys to edit the setting.
5. When the SHIFT key is pressed on the FILE NAME parameter, the user can select the first
half of the file name which is the configuration (3P4, for example). When the SHIFT keys is
pressed again, the SHIFT 2 icon appears on the display and the user can select the second
half of the file name (10001.XLS, for example). This applies only to the FILENAME
parameter.
6. Press the SHIFT key to continue scrolling through the other parameters using the up and
down arrow keys.
7. To exit the Setup Mode press the EXIT key.
8. Detailed instructions for each parameter are provided in the next section.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
10
Setup Mode Screen
4.4.2 The Setup Mode Parameter Menu
Folder Name: Select a file name on the SD CARD; the range is WTA01 to WTA10
File Name: Set a file name on the SD CARD (50 filenames are permitted)
REC Date: Show a file’s date-time stamp (Year / Month / Date / Hour / Min / Sec)
Sampling Time: Set the datalogger sampling rate from 2 to 7200 seconds
Delete File: Delete an existing data file from the SD CARD
SD Format: Format the SD CARD
PT: Set Potential Transformer ratio (1 to 1000); CT: Set Current Transformer ratio (1 to 600)
Audible Tone: Set the beeper ON or OFF
Clamp Type: Select the clamp type from the menu list
A (Amps): Set the Current range; V (Volts): Set the Voltage range
RS232 Out Select: RS232 output function (up to nine items can be output)
Year,Month,Date,Hour,Minute,Second: Set the current date and time
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
11
4.5 Setup Mode in Detail
Press SETUP to enter the Setup Mode, selected items will appear highlighted (reverse video). Use
the up and down arrow keys to move through the available parameters and use the Shift key to
open a parameter for editing. Once a parameter is opened for editing, the up and down arrow keys
are used again to change a parameter’s setting. The SHIFT key is then used to return to Setup
Mode editing where the arrow keys are used again for scrolling. Use the EXIT key to leave the
Setup Mode.
4.5.1 Folder name: Set a Folder Name on the SD Memory Card
1. Scroll to the FOLDER NAME field using the up and down arrow keys if necessary
2. The Folder Name range is “WTA01” to “WTA10”
3. Press Shift to open the Folder Name parameter for editing
4. Use the arrow keys ▲▼to select a folder number; the available numbers are "01 to 10"
(Note: Press and hold ▲or ▼continuously for at least two seconds to scroll quickly).
5. Press SHIFT when done
Folder Name Screen 1
Folder Name Screen 2
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
12
4.5.2 File name: Set a file name in the SD Memory Card
1. In the Setup Mode, scroll down to the FILE NAME parameter using the up and down arrow
keys
2. The screen will show the "NO FILE" indicator in the REC Date option area when the
selected file is new .
3. The screen will show the recording date and time in the REC Date option area for existing
data files .
File Name Screen1
File Name Screen 2
4. Press the SHIFT button. The “SHIFT 1” icon will appear on the upper right side of the
screen and the first half of the File Name which represents the number of wires and phases
(3P4, for example) will be highlighted and ready for editing. Use the arrow keys to select
the desired configuration. Select 1P/2W (1P2), 1P/3W (1P3), 3P/3W (3P3), or 3P/4W
(3P4).
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
13
5. Press SHIFT again and the “SHIFT 2” icon will appear on the upper right side of the screen
and the second half of the File Name, which the user can customize as needed, will be
highlighted. Use the arrow keys to select a number between 001 and 0050 inclusive. .
6. File Name Examples:
a. 1P201001: 1P2 is one phase by two wires, 01 is the folder number, and 001 is the file number
b. 1P301001: 1P3 is one phase by three wires, 01 the folder number, and 001 the file number
c. 3P301001: 3P3 is three phases by three wires, 01 the folder number, and 001 the file number.
d. 3P401001: 3P4 is three phases by four wires, 01 the folder number, and 001 the file number.
7. Press the SHIFT key again to continue with the Setup Mode editing.
File Name Screens
4.5.3 Set the Sampling Time (datalogging rate) for recording onto the SD Memory Card
1. In the Setup Mode, use the up and down arrow keys to scroll to the SAMPLING TIME field.
2. Press the SHIFT key and the symbol "SHIFT1" will switch ON.
3. Use the arrow keys to adjust the sampling time; the range is 2 to 7200 seconds.
4. Press the SHIFT key again to return to Setup Mode editing.
4.5.4 Delete a file on the SD Memory Card
1. In the Setup Mode, scroll to the DELETE FILE field using the up and down arrow keys.
2. Press and hold the SETUP/ENTER key for at least 2 seconds and the indicators “Y” and
“N” will appear next to the DELETE FILE field. Use the right and left arrow keys to highlight
“Y” for YES or “N” for NO and then momentarily press the SETUP/ENTER key.
3. If “Y” is selected, the current file will be erased. If “N” is selected, the delete process will be
aborted. When a file is deleted the field next to DELETE FILE will show 100%. When a
delete is aborted, the field shows 0%.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
14
4.5.5 Formatting an SD Memory Card
1. In the Setup Mode, use the arrow keys to scroll to the SD FORMAT field
2. Press and hold the SETUP/ENTER button for at least 2 seconds and the “Y” and “N”
indicators will appear next to the SD FORMAT field
3. Use the right and left arrow buttons to highlight the desired letter: “Y” to confirm formatting
or “N” to abort the formatting.
4. While formatting, the field next to the SD FORMAT field will show the formatting progress 0
to 100%.
5. Note that the display screen shows USE SIZE (amount of memory currently used on the
SD card), FREE SIZE (amount of memory available), and TOTAL SIZE (total size of the
SD card memory) below the SD FORMAT field.
4.5.6 Potential Transformer (PT) Setup
1. In the Setup Mode, use the up and down arrow keys to scroll to the PT field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to adjust the PT value (the range is 1 to 1000)
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.7 Current Transformer (CT) Setup
1. In the Setup Mode, use the up and down arrow keys to scroll to the CT field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to adjust the CT value (the range is 1 to 600)
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.8 Audible Beeper ON/OFF
1. In the Setup Mode, use the up and down arrow keys to scroll to the BEEP field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to select ON or OFF
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.9 SD Card Numerical Format (USA or European)
Note: SD Memory Cards default to the basic numerical format (USA) whereby a period is used
to separate units from tenths, for example: 20.00. European formatting uses a comma (for
example: 20,00).
1. In the Setup Mode, use the up and down arrow keys to scroll to the DECIMAL field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to select the desired format USA (.) or EURO (,).
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
15
4.5.10 Set Clamp type
1. In the Setup Mode, use the up and down arrow keys to scroll to the CLAMP TYPE field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to select the full scale setting of the clamp used.
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.11 Set Current Range
ATTENTION: Ensure that the ‘A’ range setting matches the attached clamp’s rating
1. In the Setup Mode, use the up and down arrow keys to scroll to the “A RANGE” field.
2. Press SHIFT, the display "SHIFT1" will switch ON.
3. Use the ▲or ▼keys to select the current range.
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.12 Set Voltage Range
1. In the Setup Mode, use the up and down arrow keys to scroll to the “V RANGE” field.
2. Press SHIFT, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to select the voltage (Note that unless the CLAMP TYPE is set to
“Other”, this value is fixed)
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.13 Set RS-232 Output Parameters
1. In the Setup Mode, use the up/down arrow keys to scroll to the “RS232 OUT SEL” field.
2. Press the SETUP/ENTER key to access the RS232 Output selection page. Nine output
selections maximum can be highlighted on this page.
3. Use all four arrow buttons to navigate the output choices.
4. To select an output type, press the SETUP key (the selection will highlight).
5. To de-select a selected output type, press the SETUP key (the highlight will switch off).
6. Press and hold the SHIFT key for > 2 seconds to clear all RS-232 output selections.
7. Press the EXIT button to exit the RS232 output mode.
8. If nine items are selected the display will show the indicator "full".
RS232 – Output Selections
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
16
4.5.14 Set Time and Date
1. In the Setup Mode, use the up and down arrow keys to scroll to the YEAR, MONTH, DATE,
HOUR, MINUTE, and SECOND fields.
2. Press SHIFT key when the desired field is selected, the display "SHIFT1" will switch ON
3. Use the ▲or ▼keys to change the date or time value
4. Press SHIFT again to return to Setup Mode editing or press EXIT to leave the Setup mode.
4.5.15 Exit the Setup Mode
When all of the programming has been completed, press the EXIT key to return to the
measurement mode of operation.
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
17
5.0 Power Measurement Procedures
5.1 1Φ2W (Single Phase - Two Wire) Measurement
1. Power the instrument ON by pressing the ‘Power’ key, and then use the ‘1Φ3Φ’ key to
select the 1Φ2W system, the selected name of the system will be shown on the bottom left
side of the display
2. Connect the line voltage L1, Vn (Neutral) to V1 and N terminals of the
instrument.
3. Connect the Clamp (A1) to the conductor (A1)
4. Connect Clamp 1 (A1) to the A1 terminal of the instrument
5. The related measurement factors will appear on the display
6. Measurement definitions can be found in Section 5-10
1Φ2W Screen
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
18
5.2 1Φ3W (single phase - three wire) Measurement
1. Power the instrument ON by pressing ‘Power’ key, and then press the ‘1Φ3Φ’ key to
select 1Φ3W, the selected name of the configuration will appear on bottom left hand
side of the display.
2. Connect the line voltage L1, L2 and Vn (Neutral) to V1, V2 and N terminals of the
instrument
3. Connect the two (2) clamps (A1 and A2) to the conductors (A1) and (A2)
4. Connect Clamp 1 and Clamp 2 (A1 and A2) to the A1 and A2 terminals of the
instrument
5. The related measurement factors will appear on the display
1Φ3W Screen
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
19
5.3 3Φ3W (three phase - three wire) Measurement
1. Power the instrument ON by pressing the ‘Power’ key, and then press ‘1Φ3Φ’ to
select 3Φ3W, the selected configuration name will appear on bottom left hand side
of the display.
2. Connect the line voltage L1, L2 and L3 to V1, V2 and V3 terminals of the instrument.
3. Connect the three (3) clamps (A1, A2, A3) to conductors A1, A2 , A3
4. Connect the three (3) Clamps to the meter using the A1, A2, and A3 terminals
5. The related measurement factors will appear on the display
3Φ3W Screen
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30

PQ3450-EU-EN-V1.2-05/12
20
5.4 3Φ4W (three phase - four wire) Measurement
1. Power the instrument ON by pressing the ‘Power’ key, and then press ‘1Φ3Φ’ to
select the 3Φ4W system, the selected name of the system will appear on the bottom
left hand side of the display.
2. Connect the line voltage L1, L2, L3 and Vn to V1, V2, V3 and N terminals of the
instrument.
3. Connect the three (3) Clamps (A1, A2, and A3) to the conductors A1, A2, and A3.
4. Connect the Clamps (A1, A2, and A3) to the meter’s A1, A2, and A3 terminals.
5. The related measurement factors will appear on the display.
3Φ4W Screen
www.calcert.com [email protected]1.888.610.7664 0
5
10
15
20
25
30
