MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
1
medTester 5000C Field
Upgrade Installation
Instructions
These instructions tell you how to perform an instrument
firmware upgrade to a medTester 5000C and how to install
optional modules into a Fluke Biomedical medTester 5000C.
Note
If you ordered more than one module and/or upgrade, you have
received more than one set of these instructions. But you can
perform all installations at the same time with one set of instructions.
Before You Begin
In these instructions, upgrade means that you are bringing up to date the firmware
in your medTester 5000. Upgrading involves replacing firmware integrated circuits
(ICs). Enabling modules means that you are installing software from diskettes to your
medTester in order to make medTester modules available for use.
In some cases you need to install additional ICs that work with specific
medTester 5000C modules. These are the modules for Expanded Memory, and
medCheck. You have received all of the parts necessary to perform the installation
yourself and to enable individual medTester 5000C modules.
If you have already had Fluke Biomedical upgrade your medTester or install
modules at the factory, you are receiving the module installation disks in the event
that you need to reinstall the modules later. Please save these instructions with
your installation disks. Your instrument is ready to use.

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
2
NOTE: IMPORTANT
When upgrading your 5000C firmware, all memory for test
records and checklists will be erased. Process all current
medTester test records first. For example, upload them to
your compatible CMMS or print them.
Note
If you are installing a medTester 5000C firmware Upgrade; and
Modules 4 or 7; install your ICs before enabling the module(s).
Module Identification
Modules are identified by number according to the following table:
Module Number Module Name
2 RS-232/PRINTER
3 100 RECORDS
4 EXPANDED MEMORY
5 WAVES/EXTENDED TEST
6 DATA TRANSFER
7 MEDCHECK
8 DEFIBRILLATOR
9 IV PUMP
10 CMMS INTERFACE
11 ESU
12 SPO2
13 TRANSCUTANEOUS PACER
14 NIBP

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
3
Module and Upgrade Parts
Check that you have received the following parts with your module or upgrade:
Firmware Upgrade
•2 IC RAM chips (40-pin devices, labeled U20 and U21)
Modules 2, 3, 5, 6, 8, 9, 10, 11, 12, 13, and 14
•Installation disk, 1 for each module
Module 4 Expanded Memory
•Installation disk
•IC RAM (32-pin device without label)
Module 7 medCheck
•Installation disk
•4 IC RAMs (32-pin device without label)
Note
If you are upgrading your medTester 5000C firmware, and your
medTester currently includes medCheck, then your medCheck
Module does not include the four (4) RAM ICs because they are
already in your medTester. However, you may have received the
installation disk in the event you need to reinstall it.
Required Equipment for Upgrade/Modules
To install a medTester 5000 firmware upgrade or to enable a medTester 5000C
module, you need:
For a -medTester 5000C Firmware Upgrade or to install modules that contain ICs
(integrated circuits)
•a knife (not needed if the quality sticker has previously been removed);
•a Phillips screwdriver, #2-type;
•an IC removal tool (not needed for instruments with lever handle IC
sockets).

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
4
To install modules that include an installation disk
•an IBM-compatible personal computer with:
9Microsoft Windows Operating Systems (95, 98, 2000, or XP);
9a 3.5" floppy disk drive;
9a serial port (or compatible USB to serial converter).
•a medTester-to-PC interface cable:
1. If your computer has a 25-pin serial port:
use a 25-pin female to 25-pin female null-modem cable
(Fluke Biomedical part no. 2392186).
2. If your computer has a 9 pin serial port:
use a 25-pin female to 9-pin female, null-modem cable
(Fluke Biomedical part no. 2200102).
Installing Integrated Circuits
Use the procedures described in this section for installing:
1. Any modules that include ICs to be installed inside the instrument,
including:
•Firmware Upgrade
•Module 4: Expanded Memory
•Module 7: medCheck
If you are not installing ICs, skip to the section Enabling Modules below.
All ICs (integrated circuits) have a notch, dot, or dimple on one end. This is the
end with pin 1. All the ICs referenced here are oriented so that pin 1 is towards
the rear of the instrument. Note the notch marked on the PCB (printed circuit
board) on that end.
Note
Always orient an IC correctly when installing it or you could damage
it.
All ICs are referenced by a U number (U20, U21, etc.). The U numbers are
marked on the PCB. When installing an IC, make sure all the pins go into the
socket holes and none are stuck out or bent under. If the instrument doesn't work
correctly after installing an IC, check that it is the correct IC, that all the pins are in
the holes, and that the orientation is correct.

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
5
IC Removal and Installation Description
There are two types of IC sockets which you may encounter—one that is plain,
and one that has a lever handle. ICs are removed or installed as follows:
Plain Socket IC Removal
•Hook the IC removal tool under each end of the IC, and pull it out
of the socket, OR
•Insert a small flat-bladed screwdriver under alternate ends, and
carefully pry them up until the IC comes out.
Plain Socket IC Installation
•Press the IC into the socket firmly.
Lever Handle IC Socket Removal
•Hold down the IC firmly with a finger, and
•Pull the lever up. Remove the IC by hand.
Lever Handle IC Socket Insertion
•Make sure the lever is up.
•Insert the IC by hand.
•Push the lever to one side to lock in the IC.

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
6
IC Installation Procedure
This section describes the procedure you can use to install ICs. It includes
instructions for the disassembly of the medTester 5000, replacement and
installation of ICs, testing of your IC installation, and reassembly.
Note
This is your authorization to remove the Quality seal and to open the
instrument case to install legitimately purchased upgrades and
modules.
DANGER—UNPLUG THE INSTRUMENT POWER CORD!
Service should only be performed by qualified personnel. There are
dangerous voltages present inside this instrument. Always unplug the
power cord before opening the case. Never plug in the power cord
while the case is open.
Disassembly
Disassembly involves opening the medTester case in order to access ICs. To
disassemble:
1. Peel off the Quality seal sticker that seals the case halves together.
Discard it.
2. Remove the nine (9) screws and lockwashers holding the top case to
the bottom case. There are four (4) on top, two (2) in the front, and
three (3) in the back.
3. Pull the case halves apart. Pull the top half forward while turning it
upside down and lay it down. There are cables connecting the two
halves together. Take notice of these—if they come apart, you will
know how to put them back together.
4. Remove the six (6) screws holding the metal shield to the digital PCB
(printed circuit board).

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
7
Install Integrated Circuits
1. For a medTester 5000C Firmware Upgrade, remove IC U20 and U21
on the digital PCB, and install the new U20 and U21 (40-pin devices
with labels).
2. For Modules 4 (Expanded Memory) and 7 (medCheck), install all the
RAM ICs (32-pin devices without labels) that you have received in the
next available positions—U23, U24, U25, U26, U27, in that order.
Test the Installation
1. Fold the two case halves back together temporarily, closing the case.
2. Plug in the instrument, turn on the power:
A. For a Firmware Upgrade an initialization will be performed
automatically.
B. Calibration is not affected by this initialization, so the instrument
remains calibrated.
C. The instrument should display a startup message, then display MAIN
MENU 1.
D. Test the RAMs: From MAIN MENU 1, press F5 UTIL, then RIGHT
arrow, then F2 DIAG, then F4 MEMORY, then F2 RAM. The indicated
RAM ICs should test GOOD:
•All instruments: U22
•With Module 4 Expanded Memory: U23
•With Module 7 medCheck: U24, U25, U26, and U27
•Press Esc enough times to return to MAIN MENU 1.
Reassembly
Reassemble the instrument now.
1. You should have temporarily closed the case. With the unit unplugged,
now open the case again by unfolding the top case and laying it down.
2. Attach the shield to the digital PCB with the six (6) screws. These are
the steel screws without lockwashers.
3. Make sure all cables are still in place. If they have slipped off,
reconnect them firmly.

MEDTESTER 5000C FIELD UPGRADE INSTALLATION INSTRUCTIONS
8
4. Fold the case halves back together. Attach the top case to the bottom
case with the nine (9) screws and lockwashers. These are the stainless
steel screws.
Enabling Modules
Perform the steps described below for installing Modules 2 through 14. You need
to install each module from its separate diskette. Installation requires running a
program on an IBM-compatible personal computer.
Note
You MUST install the modules that you have received in numerical
order, starting with Module 2, or the lowest numbered module you
have. Installing modules in numerical order will lead to a successful
installation.
1. Use the medTester 5000C COM1 port.
2. Decide on a computer COM port—(COM1 through COM4).
3. Decide on a baud rate—(300, 600, 1200, 2400, 4800, 9600, or 19200).
4. To change the medTester baud rate from MAIN MENU 1:
A. Press F5 UTIL, then F1 BAUD;
B. Select the COM1 port;
C. Press F4 BAUD until the desired baud rate is displayed;
D. Press F5 STORE; Press Esc twice to return to MAIN MENU 1.
Note
If Module 2 (RS-232/Printer) has not yet been installed, the
medTester baud rate is not selectable and can not be adjusted. It is
permanently set to 9600. After you install Module 2, you can change
the baud rate.
5. Connect the computer COM port to the medTester COM1 port
(medTester to PC null modem serial cable).
