Flying Industry Development S1XB-AC220-ANT2 User manual

SHENZHEN GUIYUAN INDUSTRY DEVELOPMENT CO.,LTD
Http://www.carymart.com E-Mail: [e-mail]
RF Wireless Remote Control Radio Controller / Transmitter & Receiver
Package Include:
12 x Receiver: S1XB-AC220-ANT2 (1 Channel / Three Control Modes)
1 x Transmitter: CB-12
1 x User manual
Feature:
Wireless control, easy to install
Control Lights, Motors, Fans, electrically operated Doors / Locks / Windows / Blinds / Cars or OtherAppliances with AC 110~240V or DC 0~28V.
You can turn on/off the receiver with transmitter (remote control) from any place within a reliable distance; the wireless RF signal can pass
through walls, floors and doors.
With characteristics of reverse power protection and over current protection
Audible / visual indication
Use microcontroller model of EM78P156, an 8-bit microprocessor designed and developed with low-power and high-speed CMOS technology.
Reliable control: The transmitter (Encoding) and the receiver (Decoding) use an 8-bit code.
One/several transmitters can control one/several receivers simultaneously.
If you use two or more receivers in the same place, you can set them with different codes.
Transmitting Frequency: 315MHz / 433MHz
Working distance of transmitter and receiver with external extend antenna: 2000M / 6000ft (theoretically)
Receiver:
Model No.: S1XB-AC220- ANT2
Channel: 1 CH
Control Modes: Toggle, Momentary, Latched
Coding Type: Fixed code
Coding Setting: By learning
Power Supply (Operating Voltage):AC100~240V (S1XB-AC220-ANT2)
Output: AC 100~240V
PCB size: 75mm x 54mm x 22mm
Case size: 79mm x 58mm x 36mm
Maximum Working Current: 10A
External Extend Antenna:
Frequency Range: 300~450MHz
Impedance: 50Ω
Antenna Length: 15cm
Cable Length: 150cm
Weight: 35g
Anti-interference, waterproof, shielded wire set inside
Magnetic stand design for easy to install
Transmitter:
Model No.: CB-12
Channel: 12 CH
Remote Control Distance: 1000m / 3000ft (theoretically)
Encode: Fixed code by soldering
Unit size: 135mm x 42mm x 25mm
Power Supply: 1 x 6F22-9V battery (included, can be used for 12 months)
Usage:
Setting different control modes (We have set the receiver as Toggle control mode before delivery. If you want to use other control modes, do as
following):
1) Setting control mode Toggle: Only connect Jumper-2.
Press button 1: Turn on the relay, terminal OUT of receiver 1 outputsAC power.
Press button 1 again: Turn off the relay, terminal OUT of receiver 1 no output.
…
Press button 12: Turn on the relay, terminal OUT of receiver 12 outputs AC power.
Press button 12 again: Turn off the relay, terminal OUT of receiver 12 no output.
2) Setting control mode Momentary: Only connect Jumper-1.
Press and hold button 1: Turn on the relay, terminal OUT of receiver 1 outputs AC power.
Release button 1: Turn off the relay, terminal OUT of receiver 1 no output.
…
Press and hold button 12: Turn on the relay, terminal OUT of receiver 12 outputs AC power.
Release button 12: Turn off the relay, terminal OUT of receiver 12 no output.

SHENZHEN GUIYUAN INDUSTRY DEVELOPMENT CO.,LTD
Http://www.carymart.com E-Mail: [e-mail]
3) Setting control mode Latched: Do not connect Jumper-1 and Jumper-2.
Press button 1: Turn on the relay, terminal OUT of receiver 1 outputsAC power.
Press other buttons: Turn off the relay, terminal OUT of receiver 1 no output.
…
Press button 12: Turn on the relay, terminal OUT of receiver 12 outputs AC power.
Press other buttons: Turn off the relay, terminal OUT of receiver 12 no output.
We have learned remote control to the receiver. If you don’t want the receiver to work with the remote control, you can delete all codes of remote
controls, which are stored in the receiver.
Operation: Press and hold the button of receiver until signal LED flashes slowly; release the button, LED keeps slow flash. That means all stored
codes have been deleted successfully.
LEARNING the remote control:
1) Press the button of receiver; signal LED on the receiver keeps shining. The receiver enters into status of LEARNING.
2) Press any one button on remote control. If signal LED flashes quickly 15 times and turns off, it means learning is successful.
3) Press any button on the transmitter; the receiver will learn the corresponding button on the transmitter.
4) When receiver is inthe status of LEARNING, press again the button of receiver, signal LED turns off, it means learning process is discontinued.
5) The receiver can learn several remote controls with different codes.
Relay
OUT
Jumper-2
Jumper-1
Power LED
Signal LED
Button
Live wire
N
L
IC
Antenna
RF module
Power supply
Application Circuit
Lamp
Zero wire
N
L
