Flying Industry Development S1UD-DC06 User manual

SHENZHENGUIYUANINDUSTRY DEVELOPMENT CO.,LTD
Http://www.carymart.com E-Mail: [e-mail]
RF Wireless Remote Control Radio Controller with Delay Time Function / Transmitter & Receiver
Package Include:
1 x Receiver: S1UD-DC06 / S1UD-DC09 / S1UD-DC12 / S1UD-DC24 (1 Channel/ Three Control Modes)
2 x Transmitter: C-2
1 x User manual
Feature:
Wireless control, easy to install
Setting delay time from0 to 99 seconds.
Control Lights, Motors, Fans, electrically operated Doors/Locks/Windows/Blinds/Cars or Other Appliances with voltage AC110~240V or
DC0~28V.
You can turn on/off the receiver with transmitter (remote control) from any place within a reliable distance; the wireless RF signal can pass
throughwalls,floors and doors.
With characteristics of reverse power protection.
Use an 8-bit microcontroller with low-power and high-speed CMOS technology.
Reliable control: The transmitter (Encoding) and the receiver (Decoding) use an 8-bitcode.
One/ several transmitters can control one/several receivers simultaneously.
If you use two or more receivers in thesame place, youcanset themwithdifferentcodes.
Transmitting Frequency: 315MHz / 433MHz
Receiver:
Model No.: S1UD-DC06 / S1UD-DC09 / S1UD-DC12 / S1UD-DC24
Channel: 1 CH
Control Modes: Toggle, Momentary, Latched
Delay time: 0~99 seconds
Coding Type: Fixed code or Learningcode
Coding Setting: By learning
Power Supply (Operating Voltage): DC6V (S1UD-DC06), DC12V±1V (S1UD-DC12), DC9V±1V (S1UD-DC09), DC24V±2V (S1UD-DC24)
Working Voltage Range of Relay:AC110~240V or DC0~28V
Output: Relay output (Normally open and normally closed)
MaximumWorking Current of Relay: 7A
PCB Size: 45mmx 30mmx 15mm
Case Size: 50mmx 35mmx 23mm
Receiver Sensitivity:-114dbm
Static Current: ≤10mA
Transmitter:
Model No.: C-2
Channel: 2 CH
Remote Control Distance: 100m/ 300ft (theoretically)
Encode: Fixed code by soldering
Unit size: 58mmx 39mmx 16mm
Power Supply: 1x 23A -12V battery (included,can be usedfor 12 months)
Usage:
Initial state: Terminals A, B = Normally Closed; Terminals B, C = Normally Open.
Connect device to terminal “B & C”; connect power supply to terminal “+” and “-”.
Setting differentcontrol modes (We haveset the receiver as Toggle control mode before delivery. If youwant to use other control modes, do as
followingoperation):
Setting controlmode Toggle: Connect Jumper-2 and Jumper-3.
Control mode Toggle: Press -> On; Press again -> Off.
Press button 1: Turn on therelay (connect B and C, disconnectA and B)
Press button 1 again: Turn off therelay(disconnect B and C, connectA and B)
If youset delay time, such as 30 seconds:
Press button 1: Turn on therelay(connect B and C, disconnectA and B)
After 30seconds, Turn off the relay automatically (disconnect B and C, connectAand B). Orpress button 1 againwithin 30seconds:Turn off the
relay immediately.
Setting controlmode Momentary: Disconnect Jumper.
Control mode Momentary: Press and hold -> On; Release -> Off.
Press and hold button 1:Turn on therelay(connect B and C, disconnectA and B)
Release button 1: Turn off the relay (disconnect B and C, connectA and B)
If youset delay time, such as 20 seconds:
Press and hold button 1:Turn on therelay(connect B and C, disconnectA and B)
After 20 seconds, Turn off the relay automatically (disconnect B and C, connect A and B). And the relay couldn’t be turned off by pressing any
buttonw ithin 20seconds.

SHENZHENGUIYUANINDUSTRY DEVELOPMENT CO.,LTD
Http://www.carymart.com E-Mail: [e-mail]
Setting controlmode Latched: Connect Jumper-1 and Jumper-2.
Control mode Latched: Press -> On, other relays Off; Press another button-> Off.
Press button 1: Turn on therelay (connect B and C, disconnectA and B)
Press button 2: Turn off therelay (disconnect B and C, connectA and B)
If youset delay time, such as 10 seconds:
Press button 1: Turn on therelay (connect B and C, disconnectA and B)
After 10 seconds, Turnoff the relay automatically (disconnect B and C, connect Aand B). Or press button 2within 10seconds: Turn off the relay
immediately.
Delay timesetting function:
Press thesetting button, the LEDoff, that means enter into the delay time setting mode.
Then you canset delay time through pressing the learn button. Press the learn button, LEDwill flash once, that means the delay time increase1
seconds, if youwant todelay 30seconds,you need to press the learn buttonwith 30 times.
Youcanset longest delay time to 99 seconds.
Press the setting button again, the delay time what you have setwill be preserved forever even if you turn off power. After the delay time is
preserved by the system, LEDwill flash 3 times, the systemwill quit the delay time setting mode.
For example,when you use this receiver to control one lamp, and you already set 30 seconds delay time, you can press button 1 to turn on the
lamp, and the lampwill turn off automatically after 30seconds. If you don’t need the delay function,youshould clear the delay time.
Clear delaytime:
If you don’t w ant toset thedelay time, you can operate as following:
Press thesetting button and enter into the delay time setting mode, the delay timewhatyou havesetwill be cleared automatically.
Press thesetting button again, LED will flash 3 times, the systemw ill quit the delay time setting mode.
Note:
We have learned remote control to the receiver. If you don’t want the receiver to work with the remote control,you can delete all codes of remote
controls,whicharestored in thereceiver.
Operation: Press and hold the learn button of receiver until LED begin flashes slowly; release the button, LEDkeeps slow flash. That means all
storedcodes have been deletedsuccessfully.
Learning the button of remote control:
1) Press thelearn button of receiver, LEDoff. The receiver enters into statusof LEARNING.
2) Press any one button on remote control. If LEDflashes 3 times and turns off, it means learning is successful.
3) When receiver is in the status of LEARNING, you should learn the remote control within 10 seconds, or the receiver will quit the status of
LEARNING after 10seconds.
4) The receivercan learn 16 remote controlswith differentcodes.
Interior Analogue Circuit
Application: For DC12V motor or lamp
DC0~28V/ AC110~240V
Application Circuit
Power supply
A, B=Normally Closed; B, C=Normally Open.
Lamp
Relay
_
+
A
B
C
Relay
_
+
A
B
C
Learn Button
LED
Antenna
RF module
LED
Setting Button
2
1
3
Jumper
Jumper
3
2
1
Learn Button
Setting Button
Antenna
RF module
M
_
+
Power supply
Motor
+
