FOR-A D30 User manual

1
Dear System Owner:
Thank you for purchasing the FORA D30 Blood Glucose plus Blood
Pressure Monitoring System. This manual provides important
information to help you operate this system correctly. Before using
this product, please read the following contents thoroughly and
carefully.
According to the clinical studies from American Diabetes Associa-
tion, elevated blood pressure often accompanies adult diabetes.
These studies also suggest that diabetes patients could reduce
the risk of cardiovascular diseases by managing their blood glu-
cose levels and blood pressure. Therefore, with the compact size
and easy operation of this FORA D30 Blood Glucose plus Blood
Pressure Monitoring System, you can easily monitor your blood
glucose levels and blood pressure by yourself at any time or place.
In addition, this system can help you and your healthcare profes-
sionals to monitor and adjust your treatment plans, and keep your
diabetes and blood pressure under control.
If you have other questions regarding this product, please contact
the place of purchase or call Customer Care Line.
D30
Version 1.0 2010/06 311-3252000-002
English

2
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE USE
1. Use this device ONLY for the intended use described in this
manual.
2. Do NOT use accessories which are not specified by the
manufacturer.
3. Do NOT use the device if it is not working properly or
damaged.
4. Do NOT use the device where aerosol sprays are being used
or where oxygen is being administered.
5. Do NOT use under any circumstances on neonates or
infants.
6. This device does NOT serve as a cure for any symptoms
or diseases. The data measured is for reference only.
7. Before using this device to test blood glucose, read all the
instructions thoroughly and practice the test. Do all quality
control checks as directed.

3
8. Keep the device and testing supplies away from young
children. Small items such as the battery cover, batteries,
test strips, lancets and vial caps are choking hazards.
9. Keep the equipment away from hot surfaces.
10. Do NOT apply the cuff to areas other than the place
directed.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE

4
TABLE OF CONTENTS
BEFORE YOU BEGIN 06
Important Information 06
Intended Use 07
Test Principle 07
Contents of System 08
Monitor Overview 09
Screen Display 10
Test Strip 11
Speaking Function 12
SETTING THE MONITOR 17
THE FOUR MEASURING MODES 22
BEFORE TESTING 23
Control Solution Testing 23
Performing a Control Solution Test 24
TESTING WITH BLOOD SAMPLE 27
Overview of the Lancing Device 27
Setting up the Lancing Device 28
Preparing the Puncture Site 30
Alternative Site Testing 32
Performing a Blood Glucose Test 34
TESTING YOUR BLOOD PRESSURE 37
Before Measurement 37
Fitting the Cuff Properly 38
Proper Measurement Position 39
Taking Measurements 41

5
MONITOR MEMORY 44
Reviewing Test Results 44
Reviewing Day Average Results 45
Downloading Results onto a Computer 47
MAINTENANCE 50
Battery 50
Using the AC Adapter 52
Caring for Your Monitor 53
Caring for Your Test Strips 54
Important Control Solution Information 55
SYSTEM TROUBLESHOOTING 56
Result Readings 56
Error Messages 57
Troubleshooting 59
DETAILED INFORMATION 62
Reference Values 62
Comparing Monitor and Laboratory Results 64
SPECIFICATIONS 66

6
BEFORE YOU BEGIN
Important Information
•Severe dehydration and excessive water loss may cause readings
which are lower than actual values. If you believe you are suffering
from severe dehydration, consult a healthcare professional imme-
diately.
•If your blood glucose results are lower or higher than usual, and you
do not have any symptoms of illness, repeat the test. If you
have symptoms or continue to get results higher or lower than
usual, follow the treatment advice of your healthcare professional.
•Use only fresh whole blood samples to test your blood glucose.
Using other substances will lead to incorrect results.
•If you are experiencing symptoms that are inconsistent with your
blood glucose test results and you have followed all the instructions
described in this owner’s manual, call your healthcare professional.
•We do not recommend using this product on severely hypotensive
individuals or patients in shock. Readings which are lower than
actual values may occur for individuals experiencing a hyperglycae-
mic-hyperosmolar state, with or without ketosis. Please consult the
healthcare professional before use.

7
Intended Use
This system is a 2 in 1 system designed to measure blood glucose
outside the human body (in vitro diagnostic use) and to measure
blood pressure non-invasively. It is intended for use in the home and in
clinical settings as an aid to monitoring the effectiveness of diabetes
control. It should not be used for the diagnosis of diabetes and hyper-
tension, or for testing neonates.
The alternative site testing in this system can be used only during
steady-state blood glucose conditions.
This monitor has some speaking function but is not intended for use
by the visually impaired.
Test Principle
Your system measures the amount of sugar (glucose) in whole blood.
The glucose testing is based on the measurement of electrical current
generated by the reaction of glucose with the reagent of the strip. The
monitor measures the current, calculates the blood glucose level, and
displays the result. The strength of the current produced by the reac-
tion depends on the amount of glucose in the blood sample.
The blood pressure is measured non-invasively at the arm, based on
the oscillometric method.
This device is NOT able to take measurements in the presence of
common arrhythmia, such as arterial or ventricular premature beats or
arterial fibrillation. It may produce reading errors.

8
Contents of System
Your new FORA D30 system kit includes:
Test strips, control solutions, sterile lancets or lancing device are not
included in the kit. They can be purchased separately. Please make
sure you have those items needed for a blood glucose test before-
hand.
NOTE
If any items are missing from your kit or opened before use, please contact
your local customer service or place of purchase for assistance.
1 432
7
8
64 x 1.5V AA alkaline batteries
Daily Log Book
Pressure Cuff (arm type)
1
4
5
3
2
Monitor
Protective Wallet
Quick Start User Guide
Owner’s manual
Warranty Card
5 86 7

9
Monitor Overview
Front Back
Right Side
Left Side Pressure Cuff
Test Slot
Display Screen
Up Button
Down Button
On/Off Button
M Button
S Button
Repeat Button
Data Port (for FORA D30e)
Earphone Jack
DC Adapter Port
Air Jack
Air Tube
Air Plug
BT Indication Light
(for FORA D30f)
Test Strip Ejector
Battery Compartment
1
2
3
4
5
10
12
13
14
15
16
17
11
7
8
9
6
Air Plug
(Connect to the air jack)
12
13 14
1
2
3
4
7
8
6
5
9
10
16
11
17
15

10
Screen Display
Date and Time
Blood Drop Symbol
Test Strip Symbol
Volume Symbol
Systolic Pressure Symbol
Unit of Glucose
Measurement
Unit of Pressure
Measurement
Diastolic Pressure Symbol
Battery Symbol
Ketone Warning
Unit of Pressure
Measurement
Memory Mode Symbol
Day Average
Pulse Rate
Pulse Rate Symbol
User Number
Measuring Modes
Diastolic Pressure/Blood
Glucose Value
Systolic Pressure Value
1
6
9
4
7
5
8
3
2
10
11
19
17
14
18
15
16
13
12
19
18
17
6
7
8
10
14
13
12
11
9
5
1 2 3 4
1516

11
Test Strip
NOTE
The FORA D30 monitor should only be used with FORA D30 Test Strips.
Using other test strips with this meter can produce inaccurate results.
Absorbent Hole
Apply a drop of blood here.
The blood will be
automatically absorbed.
Conrmation Window
This is where you confirm if
enough blood has been
applied to the absorbent
hole in the strip.
Test Strip Handle
Hold this part to insert the
test strip into the slot.
Contact Bars
Insert this end of the test
strip into the meter. Push
it in firmly until it will go no
further.
ATTENTION:
Test results might be wrong if the contact bar
is not fully inserted into the test slot.
The front side of the
test strip should face
up when inserting
the test strip.
Front Back
1
4
3
2

12
Speaking Function
FORA D30 “speaks”aloud with step by step instructions to guide you
through the process of blood glucose testing. The following table tells
you when and what the monitor “says”.
WHEN
does the monitor say?
Setting the year
Setting the month
Setting the date
Setting the hour mode
Setting the hour
Setting the minutes
Setting the blood glucose unit
Setting the temperature unit
Setting the blood pressure unit
Setting the voice volume
Deleting the memory
WHAT
does the monitor say?
You are now in setting mode.
The Year is (number).
The month is (month).
The date is the (number)th.
The time is (12/24) hour mode.
The hour is (number) PM/AM.
The minutes are (number).
Blood glucose unit is (milligrams
per deciliter/ millimoles per liter.)
Temperature unit is degree (Fahr-
enheit/ Celsius).
Blood pressure unit is
(millimeters of mercury / kilopas-
cals).
Voice volume is (number).
1. Delete memory record function.
Press Memory key to clear all
records.
2. Are you sure you want to clear
ALL records?
Setting up the monitor

13
3. Press Memory key again to
clear all records.
4. All memory records have been
deleted.
Thank you for using FORA Tele-
Health products.
1. Today's date is (day) (month)
(day)th, (year).
2. The time is (hour minute) AM/
PM.
3. Blood glucose unit is (mil-
ligrams per deciliter/ millimoles
per liter).
4. Temperature unit is degree
(Fahrenheit/ Celsius).
5. Blood pressure unit is (millime-
ters of mercury / kilopascals)
6. Voice volume is (number)
7. Have a nice day.
1. Thank you for using FORA Tele-
Health products.
Test strip inserted.
2. Today’s date is (week day)
(month) (day), (year).
3. The time is (hour minute) PM/
AM.
Selecting language
At the end of monitor setting
Insert test strip
When the monitor is ready to test.
(symbol appears on display)
Using the monitor

14
4. The room temperature is (num-
ber) degree (Fahrenheit/ Celsius).
5. The user’s number is one.
6. Please apply blood onto the
test strip.
This is before meal measurement.
This is after meal measurement.
You are now in control solution
mode.
Now testing.
The user’s number is one.
Your blood glucose is (number)
(milligrams per deciliter/ mil-
limoles per liter).
Connecting to your computer.
Your blood glucose is less than 20
milligrams per deciliter.
Your blood glucose is over 600
milligrams per deciliter.
Thank you for using FORA Tele-
Health products. The user’s num-
ber is (number). Please select
user’s number.
The user’s number is (number).
Please relax during measure-
ment.
When selected AC for testing
When selected PC for testing
When selected QC for control
solution testing
After sample is applied onto the
test strip
When the test is completed.
(result appears on display)
After displaying the results. (for
FORA D30e only)
When the test result is < 20 mg/
dL.
When the test result is > 600 mg/
dL.
When turning on the monitor
After selecting the user number.

15
Your systolic blood pressure is
(number) (millimeters of mercury/
kilopascals). Your diastolic blood
pressure is (number) (millimeters
of mercury/ kilopascals). Your
heart rate is (number) beats per
minute.
1. Thank you for using FORA Tele-
Health products.
2. Today’s date is (day) (month)th,
(year).
3. The time is (hour minute) AM/
PM.
4. You are now in memory mode.
5. The user’s number is (number).
6. Please select user’s number.
7. The user’s number is (number).
8. Memory Record for (month) (day)
th, (year), (hour minute) AM/PM.
9. Your blood glucose was (num-
ber) (milligrams per deciliter/
millimoles per liter). OR
Your systolic blood pressure was
(number) millimeters of mercury.
Your diastolic blood pressure was
(number) millimeters of mercury.
Your heart rate was (number)
beats per minute.
When the test is completed.
(result appears on display)
Recall the Stored Test Results

16
1. You are now in day average
mode.
2. The (number) day blood
glucose average is (number) (mil-
ligrams per deciliter/ millimoles
per liter) for (number) records.
No memory record available.
The (number) day blood glucose
average does not exist.
Have a nice day.
Room temperature is out of
range, thus unable to measure.
Battery is dead. Please replace.
Please ensure proper operation
then try again.
Test strip has been used. Please
replace.
Reading the Average of Blood
Glucose Results:
If no results stored in memory
If no results stored in memory
When the monitor is turned off
When room temperature is
outside operating range, which is
50-104℉(10-40ºC).
When the power is insufficient
Removing the test strip during the
measurement.
When inserting a used test strip.
NOTE
If you would like to listen to the voice messages by earphone, you can plug a
pair of earphones into the earphone port on the side of your monitor.

17
Before using your monitor for the first time, check and update these
settings. Make sure you complete the steps below and save the
desired settings.
► Entering the setting mode
Start with the monitor switched off. Keep
pressing to turn on the monitor.
Step 1
Set the date.
With the year flashing, press to select
the correct year. Press to set.
With the month flashing, press to se-
lect the correct month. Press to set.
SETTING THE MONITOR

18
With the day flashing, press to se-
lect the correct day. Press to set.
Step 2
Set the time format.
Press to select the desired time
format --- 12h or 24h. Press to set.
Step 3
Set the time.
With the hour flashing, press to
select the correct hour. Press to set.

19
Step 4
Set the unit of glucose measurement.
Press to select mg/dL or mmol/L. Press to set.
Step 5
Set the unit of temperature.
Press to select ºF or ºC. Press to set.
Step 6
Set the unit of pressure measurement.
Press to select mmHg or Kpa. Press to set.

20
Step 7
Set the speaking volume.
There are seven (7) speaking volume options for you to choose. Press
to select the desired speaking volume appears. Press to set.
Volume 0 indicates that the speaking function is turned off, and will
not display “”. Volume 1 to 7 indicates speaking volume from low
to high, and “”will be displayed during testing.
Step 8
Delete the memory.
While “”and a blinking “”symbol appear on the display, if you
do not wish to delete the saved results, press to skip this step.
If you wish to delete ALL the results, press twice. “”and “
”are displayed on the monitor, which indicates that all results have
been deleted.
